lduMatrix is a general matrix class in which the coefficients are stored as three arrays, one for the upper triangle, one for the lower triangle and a third for the diagonal. More...

Inheritance diagram for lduMatrix:

[legend]

Collaboration diagram for lduMatrix:

[legend]

Classes
class	preconditioner
	Abstract base-class for lduMatrix preconditioners. More...

class	smoother
	Abstract base-class for lduMatrix smoothers. More...

class	solver
	Abstract base-class for lduMatrix solvers. More...

Public Types
enum	normTypes : char { NO_NORM, DEFAULT_NORM, L1_SCALED_NORM }
	Enumerated matrix normalisation types. More...

Public Member Functions
	ClassName ("lduMatrix")

	lduMatrix (const lduMesh &mesh)
	Construct (without coefficients) for an LDU addressed mesh. More...

	lduMatrix (const lduMatrix &)
	Copy construct. More...

	lduMatrix (lduMatrix &&)
	Move construct. More...

	lduMatrix (lduMatrix &, bool reuse)
	Construct as copy or re-use as specified. More...

	lduMatrix (const lduMesh &mesh, Istream &is)
	Construct given an LDU addressed mesh and an Istream from which the coefficients are read. More...

	~lduMatrix ()=default
	Destructor. More...

const lduMesh &	mesh () const noexcept
	Return the LDU mesh from which the addressing is obtained. More...

void	setLduMesh (const lduMesh &m)
	Set the LDU mesh containing the addressing. More...

const lduAddressing &	lduAddr () const
	Return the LDU addressing. More...

const lduSchedule &	patchSchedule () const
	Return the patch evaluation schedule. More...

const scalarField &	diag () const

const scalarField &	upper () const

const scalarField &	lower () const

scalarField &	diag ()

scalarField &	upper ()

scalarField &	lower ()

scalarField &	diag (label size)

scalarField &	upper (label nCoeffs)

scalarField &	lower (label nCoeffs)

word	matrixTypeName () const
	The matrix type (empty, diagonal, symmetric, ...) More...

bool	hasDiag () const noexcept

bool	hasUpper () const noexcept

bool	hasLower () const noexcept

bool	diagonal () const noexcept
	Matrix has diagonal only. More...

bool	symmetric () const noexcept
	Matrix is symmetric. More...

bool	asymmetric () const noexcept
	Matrix is asymmetric (ie, full) More...

void	sumDiag ()

void	negSumDiag ()

void	sumMagOffDiag (scalarField &sumOff) const

void	Amul (solveScalarField &, const tmp< solveScalarField > &, const FieldField< Field, scalar > &, const lduInterfaceFieldPtrsList &, const direction cmpt) const
	Matrix multiplication with updated interfaces. More...

void	Tmul (solveScalarField &, const tmp< solveScalarField > &, const FieldField< Field, scalar > &, const lduInterfaceFieldPtrsList &, const direction cmpt) const
	Matrix transpose multiplication with updated interfaces. More...

void	sumA (solveScalarField &, const FieldField< Field, scalar > &, const lduInterfaceFieldPtrsList &) const
	Sum the coefficients on each row of the matrix. More...

void	residual (solveScalarField &rA, const solveScalarField &psi, const scalarField &source, const FieldField< Field, scalar > &interfaceBouCoeffs, const lduInterfaceFieldPtrsList &interfaces, const direction cmpt) const

tmp< solveScalarField >	residual (const solveScalarField &psi, const scalarField &source, const FieldField< Field, scalar > &interfaceBouCoeffs, const lduInterfaceFieldPtrsList &interfaces, const direction cmpt) const

void	initMatrixInterfaces (const bool add, const FieldField< Field, scalar > &interfaceCoeffs, const lduInterfaceFieldPtrsList &interfaces, const solveScalarField &psiif, solveScalarField &result, const direction cmpt) const
	Initialise the update of interfaced interfaces for matrix operations. More...

void	updateMatrixInterfaces (const bool add, const FieldField< Field, scalar > &interfaceCoeffs, const lduInterfaceFieldPtrsList &interfaces, const solveScalarField &psiif, solveScalarField &result, const direction cmpt, const label startRequest) const
	Update interfaced interfaces for matrix operations. More...

void	setResidualField (const scalarField &residual, const word &fieldName, const bool initial) const
	Set the residual field using an IOField on the object registry if it exists. More...

template<class Type >
tmp< Field< Type > >	H (const Field< Type > &) const

template<class Type >
tmp< Field< Type > >	H (const tmp< Field< Type >> &) const

tmp< scalarField >	H1 () const

template<class Type >
tmp< Field< Type > >	faceH (const Field< Type > &) const

template<class Type >
tmp< Field< Type > >	faceH (const tmp< Field< Type >> &) const

InfoProxy< lduMatrix >	info () const noexcept
	Return info proxy, used to print matrix information to a stream. More...

void	operator= (const lduMatrix &)
	Copy assignment. More...

void	operator= (lduMatrix &&)
	Move assignment. More...

void	negate ()

void	operator+= (const lduMatrix &)

void	operator-= (const lduMatrix &)

void	operator*= (const scalarField &)

void	operator*= (scalar)

template<class Type >
Foam::tmp< Foam::Field< Type > >	H (const Field< Type > &psi) const

template<class Type >
Foam::tmp< Foam::Field< Type > >	H (const tmp< Field< Type >> &tpsi) const

template<class Type >
Foam::tmp< Foam::Field< Type > >	faceH (const Field< Type > &psi) const

template<class Type >
Foam::tmp< Foam::Field< Type > >	faceH (const tmp< Field< Type >> &tpsi) const

Static Public Attributes
static const Enum< normTypes >	normTypesNames_
	Names for the normTypes. More...

static constexpr const label	defaultMaxIter = 1000
	Default maximum number of iterations for solvers (1000) More...

static const scalar	defaultTolerance = 1e-6
	Default (absolute) tolerance (1e-6) More...

Friends
Ostream &	operator<< (Ostream &, const lduMatrix &)

Ostream &	operator<< (Ostream &, const InfoProxy< lduMatrix > &)

Detailed Description

lduMatrix is a general matrix class in which the coefficients are stored as three arrays, one for the upper triangle, one for the lower triangle and a third for the diagonal.

Addressing arrays must be supplied for the upper and lower triangles.

It might be better if this class were organised as a hierarchy starting from an empty matrix, then deriving diagonal, symmetric and asymmetric matrices.

Source files

Definition at line 80 of file lduMatrix.H.

Member Enumeration Documentation

◆ normTypes

enum normTypes : char

strong

Enumerated matrix normalisation types.

Enumerator
NO_NORM	"none" norm (returns 1)
DEFAULT_NORM	"default" norm (== L1_scaled)
L1_SCALED_NORM	"L1_scaled" norm

Definition at line 114 of file lduMatrix.H.

Constructor & Destructor Documentation

◆ lduMatrix() [1/5]

lduMatrix ( const lduMesh & mesh )

Construct (without coefficients) for an LDU addressed mesh.

Not yet 'explicit' (legacy code may rely on implicit construct)

Definition at line 54 of file lduMatrix.C.

◆ lduMatrix() [2/5]

lduMatrix ( const lduMatrix & A )

Copy construct.

Definition at line 60 of file lduMatrix.C.

References A.

◆ lduMatrix() [3/5]

lduMatrix ( lduMatrix && A )

Move construct.

Definition at line 81 of file lduMatrix.C.

◆ lduMatrix() [4/5]

lduMatrix	(	lduMatrix &	A,
		bool	reuse
	)

Construct as copy or re-use as specified.

Definition at line 90 of file lduMatrix.C.

References A.

◆ lduMatrix() [5/5]

lduMatrix	(	const lduMesh &	mesh,
		Istream &	is
	)

Construct given an LDU addressed mesh and an Istream from which the coefficients are read.

Definition at line 121 of file lduMatrix.C.

◆ ~lduMatrix()

~lduMatrix ( )

default

Destructor.

Member Function Documentation

◆ ClassName()

ClassName ( "lduMatrix" )

◆ mesh()

const lduMesh& mesh ( ) const

inlinenoexcept

Return the LDU mesh from which the addressing is obtained.

Definition at line 739 of file lduMatrix.H.

Referenced by assemblyFaceAreaPairGAMGAgglomeration::assemblyFaceAreaPairGAMGAgglomeration(), distributedDILUPreconditioner::distributedDILUPreconditioner(), lduMatrix::lduAddr(), GAMGAgglomeration::New(), and lduMatrix::patchSchedule().

Here is the caller graph for this function:

◆ setLduMesh()

void setLduMesh ( const lduMesh & m )

inline

Set the LDU mesh containing the addressing.

Definition at line 747 of file lduMatrix.H.

◆ lduAddr()

const lduAddressing& lduAddr ( ) const

inline

Return the LDU addressing.

Definition at line 755 of file lduMatrix.H.

References lduMesh::lduAddr(), and lduMatrix::mesh().

Referenced by DICPreconditioner::calcReciprocalD(), DILUPreconditioner::calcReciprocalD(), lduMatrix::H(), lduMatrix::H1(), cyclicFvPatchField< vector >::manipulateMatrix(), cyclicACMIFvPatchField< Type >::manipulateMatrix(), cyclicAMIFvPatchField< scalar >::manipulateMatrix(), symGaussSeidelSmoother::smooth(), GaussSeidelSmoother::smooth(), nonBlockingGaussSeidelSmoother::smooth(), and lduMatrix::sumDiag().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ patchSchedule()

const lduSchedule& patchSchedule ( ) const

inline

Return the patch evaluation schedule.

Definition at line 763 of file lduMatrix.H.

References lduMesh::lduAddr(), lduMatrix::mesh(), and lduAddressing::patchSchedule().

Here is the call graph for this function:

◆ diag() [1/3]

const Foam::scalarField & diag ( ) const

Definition at line 163 of file lduMatrix.C.

References Foam::abort(), Foam::FatalError, and FatalErrorInFunction.

Referenced by velocityDampingConstraint::addDamping(), multiphaseInterSystem::addInterfacePorosity(), oversetFvMeshBase::addInterpolation(), interRegionExplicitPorositySource::addSup(), solidificationMeltingSource::addSup(), DICPreconditioner::DICPreconditioner(), DILUPreconditioner::DILUPreconditioner(), FDICPreconditioner::FDICPreconditioner(), EulerD2dt2Scheme< Type >::fvmD2dt2(), EulerDdtScheme< Type >::fvmDdt(), backwardDdtScheme< Type >::fvmDdt(), CoEulerDdtScheme< Type >::fvmDdt(), SLTSDdtScheme< Type >::fvmDdt(), localEulerDdtScheme< Type >::fvmDdt(), CrankNicolsonDdtScheme< Type >::fvmDdt(), GAMGSolver::GAMGSolver(), waWallFunctionFvPatchScalarField::manipulateMatrix(), mixedEnergyFvPatchScalarField::manipulateMatrix(), cyclicFvPatchField< vector >::manipulateMatrix(), oversetFvPatchField< Type >::manipulateMatrix(), cyclicACMIFvPatchField< Type >::manipulateMatrix(), cyclicAMIFvPatchField< scalar >::manipulateMatrix(), nonBlockingGaussSeidelSmoother::nonBlockingGaussSeidelSmoother(), oversetFvMeshBase::normalisation(), Foam::operator<<(), GaussSeidelSmoother::smooth(), symGaussSeidelSmoother::smooth(), nonBlockingGaussSeidelSmoother::smooth(), oversetFvMeshBase::solveOverset(), lduMatrix::sumDiag(), and oversetFvMeshBase::write().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ upper() [1/3]

const Foam::scalarField & upper ( ) const

Definition at line 203 of file lduMatrix.C.

References Foam::abort(), Foam::FatalError, and FatalErrorInFunction.

Referenced by oversetFvMeshBase::addInterpolation(), algebraicPairGAMGAgglomeration::algebraicPairGAMGAgglomeration(), DICPreconditioner::calcReciprocalD(), DILUPreconditioner::calcReciprocalD(), lduMatrix::faceH(), oversetFvPatchField< Type >::fringeFlux(), gaussConvectionScheme< Type >::fvmDiv(), gaussLaplacianScheme< Type, GType >::fvmLaplacianUncorrected(), relaxedNonOrthoGaussLaplacianScheme< Type, GType >::fvmLaplacianUncorrected(), lduMatrix::H(), lduMatrix::H1(), waWallFunctionFvPatchScalarField::manipulateMatrix(), mixedEnergyFvPatchScalarField::manipulateMatrix(), cyclicFvPatchField< vector >::manipulateMatrix(), oversetFvPatchField< Type >::manipulateMatrix(), cyclicACMIFvPatchField< Type >::manipulateMatrix(), cyclicAMIFvPatchField< scalar >::manipulateMatrix(), lduMatrix::negSumDiag(), Foam::operator<<(), symGaussSeidelSmoother::smooth(), GaussSeidelSmoother::smooth(), nonBlockingGaussSeidelSmoother::smooth(), oversetFvMeshBase::solveOverset(), oversetFvPatchField< Type >::storeFringeCoefficients(), lduMatrix::sumDiag(), lduMatrix::sumMagOffDiag(), and oversetFvMeshBase::write().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ lower() [1/3]

const Foam::scalarField & lower ( ) const

Definition at line 268 of file lduMatrix.C.

References Foam::abort(), Foam::FatalError, and FatalErrorInFunction.

Referenced by oversetFvMeshBase::addInterpolation(), algebraicPairGAMGAgglomeration::algebraicPairGAMGAgglomeration(), DILUPreconditioner::calcReciprocalD(), lduMatrix::faceH(), oversetFvPatchField< Type >::fringeFlux(), gaussConvectionScheme< Type >::fvmDiv(), GAMGSolver::GAMGSolver(), lduMatrix::H(), lduMatrix::H1(), waWallFunctionFvPatchScalarField::manipulateMatrix(), mixedEnergyFvPatchScalarField::manipulateMatrix(), cyclicFvPatchField< vector >::manipulateMatrix(), oversetFvPatchField< Type >::manipulateMatrix(), cyclicACMIFvPatchField< Type >::manipulateMatrix(), cyclicAMIFvPatchField< scalar >::manipulateMatrix(), lduMatrix::negSumDiag(), Foam::operator<<(), GaussSeidelSmoother::smooth(), symGaussSeidelSmoother::smooth(), nonBlockingGaussSeidelSmoother::smooth(), oversetFvMeshBase::solveOverset(), oversetFvPatchField< Type >::storeFringeCoefficients(), lduMatrix::sumDiag(), lduMatrix::sumMagOffDiag(), and oversetFvMeshBase::write().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ diag() [2/3]

Foam::scalarField & diag ( )

Definition at line 176 of file lduMatrix.C.

◆ upper() [2/3]

Foam::scalarField & upper ( )

Definition at line 223 of file lduMatrix.C.

◆ lower() [2/3]

Foam::scalarField & lower ( )

Definition at line 288 of file lduMatrix.C.

◆ diag() [3/3]

Foam::scalarField & diag ( label size )

Definition at line 188 of file lduMatrix.C.

◆ upper() [3/3]

Foam::scalarField & upper ( label nCoeffs )

Definition at line 246 of file lduMatrix.C.

◆ lower() [3/3]

Foam::scalarField & lower ( label nCoeffs )

Definition at line 311 of file lduMatrix.C.

◆ matrixTypeName()

Foam::word matrixTypeName ( ) const

The matrix type (empty, diagonal, symmetric, ...)

Definition at line 146 of file lduMatrix.C.

◆ hasDiag()

bool hasDiag ( ) const

inlinenoexcept

Definition at line 794 of file lduMatrix.H.

Referenced by Foam::operator<<().

Here is the caller graph for this function:

◆ hasUpper()

bool hasUpper ( ) const

inlinenoexcept

Definition at line 795 of file lduMatrix.H.

Referenced by Foam::operator<<().

Here is the caller graph for this function:

◆ hasLower()

bool hasLower ( ) const

inlinenoexcept

Definition at line 796 of file lduMatrix.H.

Referenced by algebraicPairGAMGAgglomeration::algebraicPairGAMGAgglomeration(), and Foam::operator<<().

Here is the caller graph for this function:

◆ diagonal()

bool diagonal ( ) const

inlinenoexcept

Matrix has diagonal only.

Definition at line 801 of file lduMatrix.H.

Referenced by lduMatrix::solver::New().

Here is the caller graph for this function:

◆ symmetric()

bool symmetric ( ) const

inlinenoexcept

Matrix is symmetric.

Definition at line 809 of file lduMatrix.H.

Referenced by lduMatrix::solver::New(), lduMatrix::smoother::New(), and lduMatrix::preconditioner::New().

Here is the caller graph for this function:

◆ asymmetric()

bool asymmetric ( ) const

inlinenoexcept

Matrix is asymmetric (ie, full)

Definition at line 817 of file lduMatrix.H.

Referenced by mixedEnergyFvPatchScalarField::manipulateMatrix(), cyclicFvPatchField< vector >::manipulateMatrix(), cyclicACMIFvPatchField< Type >::manipulateMatrix(), cyclicAMIFvPatchField< scalar >::manipulateMatrix(), lduMatrix::solver::New(), lduMatrix::smoother::New(), and lduMatrix::preconditioner::New().

Here is the caller graph for this function:

◆ sumDiag()

void sumDiag ( )

Definition at line 30 of file lduMatrixOperations.C.

References lduMatrix::diag(), lduMatrix::lduAddr(), lduMatrix::lower(), lduAddressing::lowerAddr(), UList< T >::size(), lduMatrix::upper(), and lduAddressing::upperAddr().

Here is the call graph for this function:

◆ negSumDiag()

void negSumDiag ( )

Definition at line 47 of file lduMatrixOperations.C.

References Foam::diag(), lduMatrix::lower(), UList< T >::size(), and lduMatrix::upper().

Referenced by gaussConvectionScheme< Type >::fvmDiv(), gaussLaplacianScheme< Type, GType >::fvmLaplacianUncorrected(), and relaxedNonOrthoGaussLaplacianScheme< Type, GType >::fvmLaplacianUncorrected().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ sumMagOffDiag()

void sumMagOffDiag ( scalarField & sumOff ) const

Definition at line 65 of file lduMatrixOperations.C.

References lduMatrix::lower(), Foam::mag(), UList< T >::size(), and lduMatrix::upper().

Here is the call graph for this function:

◆ Amul()

void Amul	(	solveScalarField &	Apsi,
		const tmp< solveScalarField > &	tpsi,
		const FieldField< Field, scalar > &	interfaceBouCoeffs,
		const lduInterfaceFieldPtrsList &	interfaces,
		const direction	cmpt
	)		const

Matrix multiplication with updated interfaces.

Definition at line 32 of file lduMatrixATmul.C.

References UList< T >::begin(), tmp< T >::clear(), Foam::diag(), Foam::stringOps::lower(), psi, and Foam::stringOps::upper().

Here is the call graph for this function:

◆ Tmul()

void Tmul	(	solveScalarField &	Tpsi,
		const tmp< solveScalarField > &	tpsi,
		const FieldField< Field, scalar > &	interfaceIntCoeffs,
		const lduInterfaceFieldPtrsList &	interfaces,
		const direction	cmpt
	)		const

Matrix transpose multiplication with updated interfaces.

Definition at line 98 of file lduMatrixATmul.C.

References UList< T >::begin(), tmp< T >::clear(), Foam::diag(), Foam::stringOps::lower(), psi, and Foam::stringOps::upper().

Here is the call graph for this function:

◆ sumA()

void sumA	(	solveScalarField &	sumA,
		const FieldField< Field, scalar > &	interfaceBouCoeffs,
		const lduInterfaceFieldPtrsList &	interfaces
	)		const

Sum the coefficients on each row of the matrix.

Definition at line 162 of file lduMatrixATmul.C.

References UList< T >::begin(), Foam::diag(), forAll, Foam::stringOps::lower(), UPtrList< T >::set(), and Foam::stringOps::upper().

Here is the call graph for this function:

◆ residual() [1/2]

void residual	(	solveScalarField &	rA,
		const solveScalarField &	psi,
		const scalarField &	source,
		const FieldField< Field, scalar > &	interfaceBouCoeffs,
		const lduInterfaceFieldPtrsList &	interfaces,
		const direction	cmpt
	)		const

Definition at line 211 of file lduMatrixATmul.C.

References UList< T >::begin(), Foam::diag(), Foam::stringOps::lower(), psi, and Foam::stringOps::upper().

Referenced by faMatrix< Type >::residual(), and fvMatrix< Type >::residual().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ residual() [2/2]

Foam::tmp< Foam::Field< Foam::solveScalar > > residual	(	const solveScalarField &	psi,
		const scalarField &	source,
		const FieldField< Field, scalar > &	interfaceBouCoeffs,
		const lduInterfaceFieldPtrsList &	interfaces,
		const direction	cmpt
	)		const

Definition at line 286 of file lduMatrixATmul.C.

References Foam::New(), and psi.

Here is the call graph for this function:

◆ initMatrixInterfaces()

void initMatrixInterfaces	(	const bool	add,
		const FieldField< Field, scalar > &	interfaceCoeffs,
		const lduInterfaceFieldPtrsList &	interfaces,
		const solveScalarField &	psiif,
		solveScalarField &	result,
		const direction	cmpt
	)		const

Initialise the update of interfaced interfaces for matrix operations.

Definition at line 27 of file lduMatrixUpdateMatrixInterfaces.C.

References Foam::add(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, forAll, mesh, UPtrList< T >::set(), UList< T >::size(), and UPtrList< T >::size().

Referenced by GaussSeidelSmoother::smooth(), symGaussSeidelSmoother::smooth(), and nonBlockingGaussSeidelSmoother::smooth().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ updateMatrixInterfaces()

void updateMatrixInterfaces	(	const bool	add,
		const FieldField< Field, scalar > &	interfaceCoeffs,
		const lduInterfaceFieldPtrsList &	interfaces,
		const solveScalarField &	psiif,
		solveScalarField &	result,
		const direction	cmpt,
		const label	startRequest
	)		const

Update interfaced interfaces for matrix operations.

Definition at line 102 of file lduMatrixUpdateMatrixInterfaces.C.

References Foam::add(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, forAll, UPtrList< T >::get(), mesh, UPtrList< T >::set(), UPtrList< T >::size(), and lduInterfaceField::updateInterfaceMatrix().

Referenced by GaussSeidelSmoother::smooth(), symGaussSeidelSmoother::smooth(), and nonBlockingGaussSeidelSmoother::smooth().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ setResidualField()

void setResidualField	(	const scalarField &	residual,
		const word &	fieldName,
		const bool	initial
	)		const

Set the residual field using an IOField on the object registry if it exists.

Definition at line 335 of file lduMatrix.C.

References DebugInfo, Foam::endl(), objectRegistry::findObject(), objectRegistry::getObjectPtr(), mesh, IOobject::scopedName(), and fvMesh::thisDb().

Referenced by PCG::scalarSolve(), PBiCGStab::scalarSolve(), FPCG::scalarSolve(), PBiCG::solve(), and smoothSolver::solve().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ H() [1/4]

tmp<Field<Type> > H ( const Field< Type > & ) const

Referenced by faMatrix< Type >::H(), and fvMatrix< Type >::H().

Here is the caller graph for this function:

◆ H() [2/4]

tmp<Field<Type> > H ( const tmp< Field< Type >> & ) const

◆ H1()

Foam::tmp< Foam::scalarField > H1 ( ) const

Definition at line 300 of file lduMatrixATmul.C.

References UList< T >::begin(), lduMatrix::lduAddr(), lduMatrix::lower(), lduAddressing::lowerAddr(), tmp< T >::New(), UList< T >::size(), lduMatrix::upper(), lduAddressing::upperAddr(), and Foam::Zero.

Referenced by fvMatrix< Type >::H1().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ faceH() [1/4]

tmp<Field<Type> > faceH ( const Field< Type > & ) const

Referenced by faMatrix< Type >::flux(), and fvMatrix< Type >::flux().

Here is the caller graph for this function:

◆ faceH() [2/4]

tmp<Field<Type> > faceH ( const tmp< Field< Type >> & ) const

◆ info()

InfoProxy<lduMatrix> info ( ) const

inlinenoexcept

Return info proxy, used to print matrix information to a stream.

Definition at line 946 of file lduMatrix.H.

◆ operator=() [1/2]

void operator= ( const lduMatrix & A )

Copy assignment.

Definition at line 85 of file lduMatrixOperations.C.

References A, Foam::diag(), Foam::stringOps::lower(), and Foam::stringOps::upper().

Referenced by faMatrix< Type >::operator=(), and fvMatrix< Type >::operator=().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ operator=() [2/2]

void operator= ( lduMatrix && A )

Move assignment.

Definition at line 117 of file lduMatrixOperations.C.

References A.

◆ negate()

void negate ( )

Definition at line 130 of file lduMatrixOperations.C.

Referenced by faMatrix< Type >::negate(), and fvMatrix< Type >::negate().

Here is the caller graph for this function:

◆ operator+=()

void operator+= ( const lduMatrix & A )

Definition at line 149 of file lduMatrixOperations.C.

References A, Foam::ensightOutput::debug, Foam::diag(), Foam::endl(), Foam::stringOps::lower(), Foam::nl, Foam::stringOps::upper(), and WarningInFunction.

Referenced by faMatrix< Type >::operator+=(), and fvMatrix< Type >::operator+=().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ operator-=()

void operator-= ( const lduMatrix & A )

Definition at line 221 of file lduMatrixOperations.C.

References A, Foam::ensightOutput::debug, Foam::diag(), Foam::endl(), Foam::stringOps::lower(), Foam::nl, Foam::stringOps::upper(), and WarningInFunction.

Referenced by faMatrix< Type >::operator-=(), and fvMatrix< Type >::operator-=().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ operator*=() [1/2]

void operator*= ( const scalarField & sf )

Definition at line 293 of file lduMatrixOperations.C.

References Foam::stringOps::lower(), and Foam::stringOps::upper().

Referenced by faMatrix< Type >::operator*=(), and fvMatrix< Type >::operator*=().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ operator*=() [2/2]

void operator*= ( scalar s )

Definition at line 323 of file lduMatrixOperations.C.

References s.

◆ H() [3/4]

Foam::tmp<Foam::Field<Type> > H ( const Field< Type > & psi ) const

Definition at line 30 of file lduMatrixTemplates.C.

References UList< T >::begin(), lduMatrix::lduAddr(), lduMatrix::lower(), lduAddressing::lowerAddr(), Foam::New(), psi, UList< T >::size(), lduMatrix::upper(), and lduAddressing::upperAddr().

Here is the call graph for this function:

◆ H() [4/4]

Foam::tmp<Foam::Field<Type> > H ( const tmp< Field< Type >> & tpsi ) const

Definition at line 60 of file lduMatrixTemplates.C.

References H().

Here is the call graph for this function:

◆ faceH() [3/4]

Foam::tmp<Foam::Field<Type> > faceH ( const Field< Type > & psi ) const

Definition at line 70 of file lduMatrixTemplates.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, lduMatrix::lower(), Foam::New(), psi, UList< T >::size(), and lduMatrix::upper().

Here is the call graph for this function:

◆ faceH() [4/4]

Foam::tmp<Foam::Field<Type> > faceH ( const tmp< Field< Type >> & tpsi ) const

Definition at line 104 of file lduMatrixTemplates.C.

Friends And Related Function Documentation

◆ operator<< [1/2]

Ostream& operator<<	(	Ostream &	,
		const lduMatrix &
	)

friend

◆ operator<< [2/2]

Ostream& operator<<	(	Ostream &	,
		const InfoProxy< lduMatrix > &
	)

friend

Member Data Documentation

◆ normTypesNames_

const Foam::Enum< Foam::lduMatrix::normTypes > normTypesNames_

static

Names for the normTypes.

Definition at line 124 of file lduMatrix.H.

Referenced by LduMatrix< Type, DType, LUType >::solver::readControls(), and lduMatrix::solver::readControls().

◆ defaultMaxIter

constexpr const label defaultMaxIter = 1000

static

Default maximum number of iterations for solvers (1000)

Definition at line 129 of file lduMatrix.H.

Referenced by lduMatrix::solver::readControls().

◆ defaultTolerance

const Foam::scalar defaultTolerance = 1e-6

static

Default (absolute) tolerance (1e-6)

Definition at line 134 of file lduMatrix.H.

Referenced by lduMatrix::solver::readControls().

The documentation for this class was generated from the following files:

src/OpenFOAM/matrices/lduMatrix/lduMatrix/lduMatrix.H
src/OpenFOAM/matrices/lduMatrix/lduMatrix/lduMatrix.C
src/OpenFOAM/matrices/lduMatrix/lduMatrix/lduMatrixATmul.C
src/OpenFOAM/matrices/lduMatrix/lduMatrix/lduMatrixOperations.C
src/OpenFOAM/matrices/lduMatrix/lduMatrix/lduMatrixTemplates.C
src/OpenFOAM/matrices/lduMatrix/lduMatrix/lduMatrixUpdateMatrixInterfaces.C

Classes

Public Types

Public Member Functions

Static Public Attributes

Friends

Detailed Description

Member Enumeration Documentation

◆ normTypes

Constructor & Destructor Documentation

◆ lduMatrix() [1/5]

◆ lduMatrix() [2/5]

◆ lduMatrix() [3/5]

◆ lduMatrix() [4/5]

◆ lduMatrix() [5/5]

◆ ~lduMatrix()

Member Function Documentation

◆ ClassName()

◆ mesh()

◆ setLduMesh()

◆ lduAddr()

◆ patchSchedule()

◆ diag() [1/3]

◆ upper() [1/3]

◆ lower() [1/3]

◆ diag() [2/3]

◆ upper() [2/3]

◆ lower() [2/3]

◆ diag() [3/3]

◆ upper() [3/3]

◆ lower() [3/3]

◆ matrixTypeName()

◆ hasDiag()

◆ hasUpper()

◆ hasLower()

◆ diagonal()

◆ symmetric()

◆ asymmetric()

◆ sumDiag()

◆ negSumDiag()

◆ sumMagOffDiag()

◆ Amul()

◆ Tmul()

◆ sumA()

◆ residual() [1/2]

◆ residual() [2/2]

◆ initMatrixInterfaces()

◆ updateMatrixInterfaces()

◆ setResidualField()

◆ H() [1/4]

◆ H() [2/4]

◆ H1()

◆ faceH() [1/4]

◆ faceH() [2/4]

◆ info()

◆ operator=() [1/2]

◆ operator=() [2/2]

◆ negate()

◆ operator+=()

◆ operator-=()

◆ operator*=() [1/2]

◆ operator*=() [2/2]

◆ H() [3/4]

◆ H() [4/4]

◆ faceH() [3/4]

◆ faceH() [4/4]

Friends And Related Function Documentation

◆ operator<< [1/2]

◆ operator<< [2/2]

Member Data Documentation

◆ normTypesNames_

◆ defaultMaxIter

◆ defaultTolerance
