filmTurbulenceModel Class Reference

Base class for film turbulence models. More...

Inheritance diagram for filmTurbulenceModel:

Collaboration diagram for filmTurbulenceModel:

Public Types
enum	frictionMethodType { mquadraticProfile, mlinearProfile, mDarcyWeisbach, mManningStrickler }
	Options for the friction models. More...
enum	shearMethodType { msimple, mwallFunction }
	Options for the shear stress models. More...

Public Member Functions
	TypeName ("filmTurbulenceModel")
	Runtime type information. More...
	declareRunTimeSelectionTable (autoPtr, filmTurbulenceModel, dictionary,(liquidFilmBase &film, const dictionary &dict),(film, dict))
	filmTurbulenceModel (const word &modelType, liquidFilmBase &film, const dictionary &dict)
	Construct from type name, dictionary and surface film model. More...
virtual	~filmTurbulenceModel ()=default
	Destructor. More...
const liquidFilmBase &	film () const
	Return film. More...
tmp< volSymmTensorField >	devRhoReff () const
	Return the effective viscous stress (laminar + turbulent) More...
tmp< faVectorMatrix >	primaryRegionFriction (areaVectorField &U) const
	Return primary region friction. More...
tmp< volScalarField >	rho () const
	Return rho if specified otherwise rhoRef. More...
virtual tmp< areaScalarField >	Cw () const
	Return the wall film surface friction. More...
virtual tmp< areaScalarField >	mut () const =0
	Return the film turbulence viscosity. More...
virtual void	correct ()=0
	Correct/update the model. More...
virtual tmp< faVectorMatrix >	Su (areaVectorField &U) const =0
	Return the source for the film momentum equation. More...

Static Public Member Functions
static autoPtr< filmTurbulenceModel >	New (liquidFilmBase &film, const dictionary &dict)
	Return a reference to the selected injection model. More...

Protected Attributes
const liquidFilmBase &	film_
	Reference to liquidFilmBase. More...
const dictionary	dict_
	Model dictionary. More...
const frictionMethodType	method_
	Method used. More...
const shearMethodType	shearMethod_
	Shear method used. More...
word	rhoName_
	Name of density field (optional) More...
scalar	rhoRef_
	Reference density needed for incompressible calculations. More...

Static Protected Attributes
static const Enum< frictionMethodType >	frictionMethodTypeNames_
	Names for friction models. More...
static const Enum< shearMethodType >	shearMethodTypeNames_
	Names for shear stress models. More...

Detailed Description

Base class for film turbulence models.

Source files

• filmTurbulenceModel.H
• filmTurbulenceModel.C
• filmTurbulenceModelNew.C

Definition at line 56 of file filmTurbulenceModel.H.

Member Enumeration Documentation

frictionMethodType

enum frictionMethodType

Options for the friction models.

Enumerator
mquadraticProfile
mlinearProfile
mDarcyWeisbach
mManningStrickler

Definition at line 78 of file filmTurbulenceModel.H.

shearMethodType

enum shearMethodType

Options for the shear stress models.

Enumerator
msimple
mwallFunction

Definition at line 89 of file filmTurbulenceModel.H.

Constructor & Destructor Documentation

filmTurbulenceModel()

filmTurbulenceModel	(	const word &	modelType,
		liquidFilmBase &	film,
		const dictionary &	dict
	)

Construct from type name, dictionary and surface film model.

Definition at line 68 of file filmTurbulenceModel.C.

References Enum< EnumType >::get().

Here is the call graph for this function:

~filmTurbulenceModel()

virtual ~filmTurbulenceModel ( )

virtualdefault

Destructor.

Member Function Documentation

TypeName()

TypeName

(

"filmTurbulenceModel"

)

Runtime type information.

declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	autoPtr	,
		filmTurbulenceModel	,
		dictionary	,
		(liquidFilmBase &film, const dictionary &dict)	,
		(film, dict)
	)

New()

autoPtr< filmTurbulenceModel > New ( liquidFilmBase &  film, const dictionary &  dict  )

static

Return a reference to the selected injection model.

Definition at line 35 of file filmTurbulenceModelNew.C.

References dict, Foam::endl(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInLookup, dictionary::get(), and Foam::Info.

Here is the call graph for this function:

film()

const liquidFilmBase & film

(

)

const

Return film.

Definition at line 90 of file filmTurbulenceModel.C.

References filmTurbulenceModel::film_.

Referenced by laminar::mut().

Here is the caller graph for this function:

devRhoReff()

tmp< Foam::volSymmTensorField > devRhoReff

(

)

const

Return the effective viscous stress (laminar + turbulent)

Definition at line 296 of file filmTurbulenceModel.C.

References Foam::dev(), dictionary::dictName(), Foam::dimViscosity, Foam::exit(), Foam::FatalError, FatalErrorInFunction, filmTurbulenceModel::film_, objectRegistry::foundObject(), Foam::fvc::grad(), objectRegistry::lookupObject(), nu, GeometricField< symmTensor, fvPatchField, volMesh >::null(), regionFaModel::primaryMesh(), filmTurbulenceModel::rho(), transportProperties(), turb, Foam::twoSymm(), U, and liquidFilmBase::UName().

Here is the call graph for this function:

primaryRegionFriction()

tmp< faVectorMatrix > primaryRegionFriction

(

areaVectorField &

U

)

const

Return primary region friction.

Definition at line 187 of file filmTurbulenceModel.C.

References Foam::dimLength, Foam::dimVelocity, UList< T >::first(), forAll, UList< T >::get(), tmp< T >::New(), patchIds, tmp< T >::ref(), HashPtrTable< T, Key, Hash >::set(), UList< T >::size(), Foam::fam::Sp(), Foam::sqr(), U, and Foam::Zero.

Referenced by laminar::Su().

Here is the call graph for this function:

Here is the caller graph for this function:

rho()

tmp< Foam::volScalarField > rho

(

)

const

Return rho if specified otherwise rhoRef.

Definition at line 353 of file filmTurbulenceModel.C.

References Foam::dimDensity, filmTurbulenceModel::film_, objectRegistry::lookupObject(), tmp< T >::New(), regionFaModel::primaryMesh(), filmTurbulenceModel::rhoName_, filmTurbulenceModel::rhoRef_, fvMesh::time(), and Time::timeName().

Referenced by filmTurbulenceModel::Cw(), and filmTurbulenceModel::devRhoReff().

Here is the call graph for this function:

Here is the caller graph for this function:

Cw()

tmp< areaScalarField > Cw ( ) const

virtual

Return the wall film surface friction.

Definition at line 96 of file filmTurbulenceModel.C.

References Foam::cbrt(), filmTurbulenceModel::dict_, Foam::dimVelocity, Foam::exit(), Foam::FatalError, FatalErrorInFunction, filmTurbulenceModel::film_, Foam::flatOutput(), filmTurbulenceModel::frictionMethodTypeNames_, g, dictionary::get(), Foam::constant::universal::h, liquidFilmBase::h(), h0, liquidFilmBase::h0(), Foam::mag(), filmTurbulenceModel::mDarcyWeisbach, filmTurbulenceModel::method_, filmTurbulenceModel::mlinearProfile, filmTurbulenceModel::mManningStrickler, filmTurbulenceModel::mquadraticProfile, Foam::constant::physicoChemical::mu, liquidFilmBase::mu(), n, gravity::New(), tmp< T >::New(), Foam::nl, regionFaModel::primaryMesh(), GeometricField< Type, PatchField, GeoMesh >::primitiveField(), regionFaModel::regionMesh(), filmTurbulenceModel::rho(), liquidFilmBase::rho(), Enum< EnumType >::sortedToc(), Foam::sqr(), fvMesh::time(), Time::timeName(), Uf, liquidFilmBase::Uf(), and dimensioned< Type >::value().

Referenced by laminar::wallFriction().

Here is the call graph for this function:

Here is the caller graph for this function:

mut()

virtual tmp<areaScalarField> mut ( ) const

pure virtual

Return the film turbulence viscosity.

Implemented in laminar.

correct()

virtual void correct ( )

pure virtual

Correct/update the model.

Implemented in laminar.

Su()

virtual tmp<faVectorMatrix> Su ( areaVectorField &  U ) const

pure virtual

Return the source for the film momentum equation.

Implemented in laminar.

Member Data Documentation

film_

const liquidFilmBase& film_

protected

Reference to liquidFilmBase.

Definition at line 103 of file filmTurbulenceModel.H.

Referenced by filmTurbulenceModel::Cw(), filmTurbulenceModel::devRhoReff(), filmTurbulenceModel::film(), filmTurbulenceModel::rho(), and laminar::wallFriction().

frictionMethodTypeNames_

const Enum< filmTurbulenceModel::frictionMethodType > frictionMethodTypeNames_

staticprotected

Initial value:

{
    { frictionMethodType::mquadraticProfile, "quadraticProfile" },
    { frictionMethodType::mlinearProfile, "linearProfile" },
    { frictionMethodType::mDarcyWeisbach, "DarcyWeisbach" },
    { frictionMethodType::mManningStrickler, "ManningStrickler" }
}

Names for friction models.

Definition at line 108 of file filmTurbulenceModel.H.

Referenced by filmTurbulenceModel::Cw().

shearMethodTypeNames_

const Enum< filmTurbulenceModel::shearMethodType > shearMethodTypeNames_

staticprotected

Initial value:

{
    { shearMethodType::msimple, "simple" },
    { shearMethodType::mwallFunction, "wallFunction" }
}

Names for shear stress models.

Definition at line 113 of file filmTurbulenceModel.H.

dict_

const dictionary dict_

protected

Model dictionary.

Definition at line 118 of file filmTurbulenceModel.H.

Referenced by filmTurbulenceModel::Cw().

method_

const frictionMethodType method_

protected

Method used.

Definition at line 123 of file filmTurbulenceModel.H.

Referenced by filmTurbulenceModel::Cw().

shearMethod_

const shearMethodType shearMethod_

protected

Shear method used.

Definition at line 128 of file filmTurbulenceModel.H.

rhoName_

word rhoName_

protected

Name of density field (optional)

Definition at line 133 of file filmTurbulenceModel.H.

Referenced by filmTurbulenceModel::rho().

rhoRef_

scalar rhoRef_

protected

Reference density needed for incompressible calculations.

Definition at line 138 of file filmTurbulenceModel.H.

Referenced by filmTurbulenceModel::rho().

---

The documentation for this class was generated from the following files:

• src/regionFaModels/liquidFilm/subModels/kinematic/filmTurbulenceModel/filmTurbulenceModel/filmTurbulenceModel.H
• src/regionFaModels/liquidFilm/subModels/kinematic/filmTurbulenceModel/filmTurbulenceModel/filmTurbulenceModel.C
• src/regionFaModels/liquidFilm/subModels/kinematic/filmTurbulenceModel/filmTurbulenceModel/filmTurbulenceModelNew.C
