Mesh consisting of general polyhedral cells. More...
Public Types | |
| enum | readUpdateState { UNCHANGED, POINTS_MOVED, TOPO_CHANGE, TOPO_PATCH_CHANGE } |
| Enumeration defining the state of the mesh after a read update. More... | |
| enum | cellDecomposition { FACE_PLANES, FACE_CENTRE_TRIS, FACE_DIAG_TRIS, CELL_TETS } |
| Enumeration defining the decomposition of the cell for. More... | |
| typedef polyMesh | Mesh |
| The mesh type. More... | |
| typedef polyBoundaryMesh | BoundaryMesh |
| The boundary type associated with the mesh. More... | |
 Public Types inherited from IOobject | |
| enum | objectState : char { GOOD, BAD } |
| Enumeration defining the valid states of an IOobject. More... | |
| enum | fileCheckTypes : char { timeStamp, timeStampMaster, inotify, inotifyMaster } |
| Enumeration defining the file checking options. More... | |
| Public Types inherited from IOobjectOption | |
| enum | readOption : unsigned char { NO_READ = 0, MUST_READ = 0x1, MUST_READ_IF_MODIFIED = 0x3, READ_IF_PRESENT = 0x4 } |
| Enumeration defining read preferences. More... | |
| enum | writeOption : unsigned char { NO_WRITE = 0, AUTO_WRITE = 0x10 } |
| Enumeration defining write preferences. More... | |
| enum | registerOption : unsigned char { NO_REGISTER = 0, REGISTER = 1 } |
| Enumeration for use with registerObject(). Values map to bool (false/true) More... | |
| Public Types inherited from HashTable< regIOobject *> | |
| typedef HashTable< regIOobject *, word, Foam::Hash< word > > | this_type |
| The template instance used for this HashTable. More... | |
| typedef std::conditional< std::is_same< zero::null, typename std::remove_cv< regIOobject * >::type >::value, Detail::HashTableSingle< word >, Detail::HashTablePair< word, regIOobject * > >::type | node_type |
| A table entry (node) that encapsulates the key/val tuple with an additional linked-list entry for hash collisions. More... | |
| typedef word | key_type |
| The second template parameter, type of keys used. More... | |
| typedef regIOobject * | mapped_type |
| The first template parameter, type of objects contained. More... | |
| typedef regIOobject * | value_type |
| Same as mapped_type for OpenFOAM HashTables. More... | |
| typedef Foam::Hash< word > | hasher |
| The third template parameter, the hash index method. More... | |
| typedef regIOobject * * | pointer |
| Pointer type for storing into value_type objects. More... | |
| typedef regIOobject * & | reference |
| Reference to the stored value_type. More... | |
| typedef const regIOobject * * | const_pointer |
| Const pointer type for the stored value_type. More... | |
| typedef const regIOobject * & | const_reference |
| Const reference to the stored value_type. More... | |
| typedef label | difference_type |
| The type to represent the difference between two iterators. More... | |
| typedef label | size_type |
| The type that can represent the size of a HashTable. More... | |
| using | key_iterator = key_iterator_base< iterator > |
| Forward iterator returning the key. More... | |
| using | const_key_iterator = key_iterator_base< const_iterator > |
| Forward const iterator returning the key. More... | |
Public Member Functions | |
| TypeName ("polyMesh") | |
| Runtime type information. More... | |
| polyMesh (const IOobject &io, const bool doInit=true) | |
| Read construct from IOobject. More... | |
| polyMesh (const IOobject &io, const zero, const bool syncPar=true) | |
| Construct from IOobject or as zero-sized mesh. More... | |
| polyMesh (const IOobject &io, pointField &&points, faceList &&faces, labelList &&owner, labelList &&neighbour, const bool syncPar=true) | |
| Construct from IOobject and components. More... | |
| polyMesh (const IOobject &io, pointField &&points, faceList &&faces, cellList &&cells, const bool syncPar=true) | |
| Construct without boundary with cells rather than owner/neighbour. More... | |
| polyMesh (const IOobject &io, pointField &&points, const cellShapeList &shapes, const faceListList &boundaryFaces, const wordList &boundaryPatchNames, const wordList &boundaryPatchTypes, const word &defaultBoundaryPatchName, const word &defaultBoundaryPatchType, const wordList &boundaryPatchPhysicalTypes, const bool syncPar=true) | |
| Construct from cell shapes. More... | |
| polyMesh (const IOobject &io, pointField &&points, const cellShapeList &shapes, const faceListList &boundaryFaces, const wordList &boundaryPatchNames, const PtrList< dictionary > &boundaryDicts, const word &defaultBoundaryPatchName, const word &defaultBoundaryPatchType, const bool syncPar=true) | |
| Construct from cell shapes, with patch information in dictionary format. More... | |
| virtual | ~polyMesh () |
| Destructor. More... | |
| virtual const fileName & | dbDir () const |
| Override the objectRegistry dbDir for a single-region case. More... | |
| fileName | meshDir () const |
| Return the local mesh directory (dbDir()/meshSubDir) More... | |
| const fileName & | pointsInstance () const |
| Return the current instance directory for points. More... | |
| const fileName & | facesInstance () const |
| Return the current instance directory for faces. More... | |
| void | setInstance (const fileName &instance, const IOobjectOption::writeOption wOpt=IOobject::AUTO_WRITE) |
| Set the instance for mesh files. More... | |
| const word & | regionName () const |
| The mesh region name or word::null if polyMesh::defaultRegion. More... | |
| virtual const pointField & | points () const |
| Return raw points. More... | |
| virtual bool | upToDatePoints (const regIOobject &io) const |
| Return true if io is up-to-date with points. More... | |
| virtual void | setUpToDatePoints (regIOobject &io) const |
| Set io to be up-to-date with points. More... | |
| virtual const faceList & | faces () const |
| Return raw faces. More... | |
| virtual const labelList & | faceOwner () const |
| Return face owner. More... | |
| virtual const labelList & | faceNeighbour () const |
| Return face neighbour. More... | |
| virtual const pointField & | oldPoints () const |
| Return old points (mesh motion) More... | |
| virtual const pointField & | oldCellCentres () const |
| Return old cellCentres (mesh motion) More... | |
| const polyBoundaryMesh & | boundaryMesh () const |
| Return boundary mesh. More... | |
| const boundBox & | bounds () const |
| Return mesh bounding box. More... | |
| const Vector< label > & | geometricD () const |
| Return the vector of geometric directions in mesh. More... | |
| label | nGeometricD () const |
| Return the number of valid geometric dimensions in the mesh. More... | |
| const Vector< label > & | solutionD () const |
| Return the vector of solved-for directions in mesh. More... | |
| label | nSolutionD () const |
| Return the number of valid solved-for dimensions in the mesh. More... | |
| const labelIOList & | tetBasePtIs () const |
| Return the tetBasePtIs. More... | |
| const indexedOctree< treeDataCell > & | cellTree () const |
| Return the cell search tree. More... | |
| const pointZoneMesh & | pointZones () const noexcept |
| Return point zone mesh. More... | |
| const faceZoneMesh & | faceZones () const noexcept |
| Return face zone mesh. More... | |
| const cellZoneMesh & | cellZones () const noexcept |
| Return cell zone mesh. More... | |
| const globalMeshData & | globalData () const |
| Return parallel info. More... | |
| label | comm () const noexcept |
| Return communicator used for parallel communication. More... | |
| label & | comm () noexcept |
| Return communicator used for parallel communication. More... | |
| const objectRegistry & | thisDb () const noexcept |
| Return the object registry. More... | |
| virtual bool | dynamic () const |
| Is mesh dynamic. More... | |
| bool | moving () const noexcept |
| Is mesh moving. More... | |
| bool | moving (const bool on) noexcept |
| Set the mesh to be moving. More... | |
| bool | topoChanging () const noexcept |
| Is mesh topology changing. More... | |
| bool | topoChanging (const bool on) noexcept |
| Set the mesh topology to be changing. More... | |
| bool | changing () const noexcept |
| Is mesh changing (topology changing and/or moving) More... | |
| virtual void | movePoints (const pointField &) |
| Move points. More... | |
| void | resetMotion () const |
| Reset motion. More... | |
| pointZoneMesh & | pointZones () noexcept |
| Return non-const access to the pointZones. More... | |
| faceZoneMesh & | faceZones () noexcept |
| Return non-const access to the faceZones. More... | |
| cellZoneMesh & | cellZones () noexcept |
| Return non-const access to the cellZones. More... | |
| void | addPatches (polyPatchList &plist, const bool validBoundary=true) |
| Add boundary patches. More... | |
| void | addPatches (const List< polyPatch *> &p, const bool validBoundary=true) |
| Add boundary patches. More... | |
| void | addZones (PtrList< pointZone > &&pz, PtrList< faceZone > &&fz, PtrList< cellZone > &&cz) |
| Add mesh zones. More... | |
| void | addZones (const List< pointZone *> &pz, const List< faceZone *> &fz, const List< cellZone *> &cz) |
| Add mesh zones. More... | |
| virtual bool | init (const bool doInit) |
| Initialise all non-demand-driven data. More... | |
| virtual readUpdateState | readUpdate () |
| Update the mesh based on the mesh files saved in. More... | |
| virtual void | updateMesh (const mapPolyMesh &mpm) |
| Update the mesh corresponding to given map. More... | |
| void | removeBoundary () |
| Remove boundary patches. More... | |
| void | resetPrimitives (autoPtr< pointField > &&points, autoPtr< faceList > &&faces, autoPtr< labelList > &&owner, autoPtr< labelList > &&neighbour, const labelUList &patchSizes, const labelUList &patchStarts, const bool validBoundary=true) |
| Reset mesh primitive data. Assumes all patch info correct. More... | |
| void | clearGeom () |
| Clear geometry. More... | |
| void | updateGeomPoints (pointIOField &&newPoints, autoPtr< labelIOList > &newTetBasePtIsPtr) |
| Update geometry points; keep topology. Optionally with new face decomposition. More... | |
| void | clearAddressing (const bool isMeshUpdate=false) |
| Clear addressing. More... | |
| void | clearOut () |
| Clear all geometry and addressing unnecessary for CFD. More... | |
| void | clearPrimitives () |
| Clear primitive data (points, faces and cells) More... | |
| void | clearTetBasePtIs () |
| Clear tet base points. More... | |
| void | clearCellTree () |
| Clear cell tree data. More... | |
| void | removeFiles (const fileName &instanceDir) const |
| Remove all files from mesh instance. More... | |
| void | removeFiles () const |
| Remove all files from mesh instance() More... | |
| bool | hasTetBasePtIs () const |
| virtual bool | checkFaceOrthogonality (const bool report=false, labelHashSet *setPtr=nullptr) const |
| Check non-orthogonality. More... | |
| virtual bool | checkFaceSkewness (const bool report=false, labelHashSet *setPtr=nullptr) const |
| Check face skewness. More... | |
| virtual bool | checkEdgeAlignment (const bool report, const Vector< label > &directions, labelHashSet *setPtr) const |
| Check edge alignment for 1D/2D cases. More... | |
| virtual bool | checkCellDeterminant (const bool report, labelHashSet *setPtr) const |
| virtual bool | checkMeshMotion (const pointField &newPoints, const bool report=false, const bool detailedReport=false) const |
| Check mesh motion for correctness given motion points. More... | |
| virtual bool | checkFaceWeight (const bool report, const scalar minWeight=0.05, labelHashSet *setPtr=nullptr) const |
| Check for face weights. More... | |
| virtual bool | checkVolRatio (const bool report, const scalar minRatio=0.01, labelHashSet *setPtr=nullptr) const |
| Check for neighbouring cell volumes. More... | |
| void | findCellFacePt (const point &p, label &celli, label &tetFacei, label &tetPti) const |
| Find the cell, tetFacei and tetPti for point p. More... | |
| void | findTetFacePt (const label celli, const point &p, label &tetFacei, label &tetPti) const |
| Find the tetFacei and tetPti for point p in celli. More... | |
| bool | pointInCell (const point &p, label celli, const cellDecomposition=CELL_TETS) const |
| Test if point p is in the celli. More... | |
| label | findCell (const point &p, const cellDecomposition=CELL_TETS) const |
| Find cell enclosing this location and return index. More... | |
| Public Member Functions inherited from objectRegistry | |
| TypeName ("objectRegistry") | |
| Declare type name for this IOobject. More... | |
| objectRegistry (const Time &db, const label nObjects=128) | |
| Construct the time objectRegistry, with estimated table capacity (default: 128) More... | |
| objectRegistry (const IOobject &io, const label nObjects=128) | |
| Construct sub-registry given an IObject to describe the registry, with estimated table capacity (default: 128) More... | |
| virtual | ~objectRegistry () |
| Destructor, with checkOut() for all objects that are ownedByRegistry. More... | |
| const objectRegistry & | thisDb () const noexcept |
| Return the object registry. More... | |
| const objectRegistry & | parent () const noexcept |
| Return the parent objectRegistry. More... | |
| const Time & | time () const noexcept |
| Return time registry. More... | |
| bool | isTimeDb () const noexcept |
| True if the registry is Time. More... | |
| HashTable< wordHashSet > | classes () const |
| A summary hash of classes used and their associated object names. More... | |
| template<class MatchPredicate > | |
| HashTable< wordHashSet > | classes (const MatchPredicate &matchName) const |
| A summary hash of classes used and their associated object names, restricted to objects that have a matching object name. More... | |
| UPtrList< const regIOobject > | csorted () const |
| Return sorted list of objects. More... | |
| UPtrList< const regIOobject > | sorted () const |
| Return sorted list of objects. More... | |
| UPtrList< regIOobject > | sorted () |
| Return sorted list of objects. More... | |
| template<class Type > | |
| UPtrList< const Type > | csorted () const |
Return sorted list of objects with a class satisfying isA<Type> More... | |
| template<class Type > | |
| UPtrList< const Type > | sorted () const |
Return sorted list of objects with a class satisfying isA<Type> More... | |
| template<class Type > | |
| UPtrList< Type > | sorted () |
Return sorted list of objects with a class satisfying isA<Type> More... | |
| template<class Type , class MatchPredicate > | |
| UPtrList< const Type > | csorted (const MatchPredicate &matchName) const |
Return sorted list of objects with a class satisfying isA<Type> that also have a matching object name. More... | |
| template<class Type , class MatchPredicate > | |
| UPtrList< const Type > | sorted (const MatchPredicate &matchName) const |
Return sorted list of objects with a class satisfying isA<Type> that also have a matching object name. More... | |
| template<class Type , class MatchPredicate > | |
| UPtrList< Type > | sorted (const MatchPredicate &matchName) |
Return sorted list of objects with a class satisfying isA<Type> that also have a matching object name. More... | |
| label | count (const char *clsName) const |
| The number of objects of the given class name. More... | |
| template<class MatchPredicate > | |
| label | count (const MatchPredicate &matchClass) const |
| The number of objects of the given class name. More... | |
| template<class MatchPredicate1 , class MatchPredicate2 > | |
| label | count (const MatchPredicate1 &matchClass, const MatchPredicate2 &matchName) const |
| The number of objects of the given class name. More... | |
| template<class Type > | |
| label | count (const bool strict=false) const |
The names of objects with a class satisfying isA<Type> More... | |
| template<class Type , class MatchPredicate > | |
| label | count (const MatchPredicate &matchName) const |
The names of objects with a class satisfying isA<Type> that also have a matching object name. More... | |
| wordList | names () const |
| The unsorted names of all objects. More... | |
| wordList | names (const char *clsName) const |
| The unsorted names of objects with the given class name. More... | |
| template<class MatchPredicate > | |
| wordList | names (const MatchPredicate &matchClass) const |
| The unsorted names of objects with a matching class name. More... | |
| template<class MatchPredicate1 , class MatchPredicate2 > | |
| wordList | names (const MatchPredicate1 &matchClass, const MatchPredicate2 &matchName) const |
| The unsorted names of objects with a matching class name that also have a matching object name. More... | |
| template<class Type > | |
| wordList | names () const |
The unsorted names of objects with a class satisfying isA<Type>. More... | |
| template<class Type , class MatchPredicate > | |
| wordList | names (const MatchPredicate &matchName) const |
The unsorted names of objects with a class satisfying isA<Type> that also have a matching object name. More... | |
| wordList | sortedNames () const |
| The sorted names of all objects. More... | |
| wordList | sortedNames (const char *clsName) const |
| The sorted names of objects with the given class name. More... | |
| template<class MatchPredicate > | |
| wordList | sortedNames (const MatchPredicate &matchClass) const |
| The sorted names objects with a matching class name. More... | |
| template<class MatchPredicate1 , class MatchPredicate2 > | |
| wordList | sortedNames (const MatchPredicate1 &matchClass, const MatchPredicate2 &matchName) const |
| The sorted names of objects with a matching class name that also have a matching object name. More... | |
| template<class Type > | |
| wordList | sortedNames () const |
The sorted names of objects with a class satisfying isA<Type> More... | |
| template<class Type , class MatchPredicate > | |
| wordList | sortedNames (const MatchPredicate &matchName) const |
The sorted names of objects with a class satisfying isA<Type> that also have a matching object name. More... | |
| const objectRegistry & | subRegistry (const word &name, const bool forceCreate=false, const bool recursive=false) const |
| Lookup and return a const sub-objectRegistry. More... | |
| template<class Type > | |
| HashTable< const Type * > | lookupClass (const bool strict=false) const |
Return all objects with a class satisfying isA<Type> More... | |
| template<class Type > | |
| HashTable< Type * > | lookupClass (const bool strict=false) |
Return all objects with a class satisfying isA<Type> More... | |
| const regIOobject * | cfindIOobject (const word &name, const bool recursive=false) const |
| Return const pointer to the regIOobject. More... | |
| bool | found (const word &name, const bool recursive=false) const |
| Can the regIOobject object be found (by name). More... | |
| template<class Type > | |
| bool | foundObject (const word &name, const bool recursive=false) const |
| Is the named Type found? More... | |
| template<class Type > | |
| const Type * | cfindObject (const word &name, const bool recursive=false) const |
| Return const pointer to the object of the given Type. More... | |
| template<class Type > | |
| const Type * | findObject (const word &name, const bool recursive=false) const |
| Return const pointer to the object of the given Type. More... | |
| template<class Type > | |
| Type * | findObject (const word &name, const bool recursive=false) |
| Return non-const pointer to the object of the given Type. More... | |
| template<class Type > | |
| Type * | getObjectPtr (const word &name, const bool recursive=false) const |
| Return non-const pointer to the object of the given Type, using a const-cast to have it behave like a mutable. More... | |
| template<class Type > | |
| const Type & | lookupObject (const word &name, const bool recursive=false) const |
| Lookup and return const reference to the object of the given Type. Fatal if not found or the wrong type. More... | |
| template<class Type > | |
| Type & | lookupObjectRef (const word &name, const bool recursive=false) const |
| Lookup and return non-const reference to the object of the given Type. Fatal if not found or the wrong type. More... | |
| label | getEvent () const |
| Return new event number. More... | |
| bool | checkIn (regIOobject *io) const |
| Add a regIOobject to registry. A nullptr is ignored. More... | |
| bool | checkIn (regIOobject &io) const |
| Add a regIOobject to registry. More... | |
| bool | checkOut (regIOobject *io) const |
| Remove a regIOobject from registry and free memory if the object is ownedByRegistry. A nullptr is ignored. More... | |
| bool | checkOut (regIOobject &io) const |
| Remove a regIOobject from registry and free memory if the object is ownedByRegistry. More... | |
| bool | checkOut (const word &key) const |
| Remove a regIOobject by name from registry and free memory if the object is ownedByRegistry. More... | |
| void | clear () |
| Clear all entries from the registry. More... | |
| void | clearStorage () |
| Clear all entries from the registry and the table itself. More... | |
| bool | erase (const iterator &iter) |
| Erase an entry specified by the given iterator. More... | |
| bool | erase (const word &key) |
| Erase an entry specified by the given key. More... | |
| label | erase (std::initializer_list< word > keys) |
| Remove entries given by the listed keys. More... | |
| label | erase (const UList< word > &keys) |
| Remove entries given by the listed keys. More... | |
| virtual void | rename (const word &newName) |
| Rename. More... | |
| virtual bool | modified () const |
| Return true if any of the object's files have been modified. More... | |
| void | readModifiedObjects () |
| Read the objects that have been modified. More... | |
| virtual bool | readIfModified () |
| Read object if modified. More... | |
| virtual bool | writeData (Ostream &) const |
| writeData function required by regIOobject but not used. More... | |
| virtual bool | writeObject (IOstreamOption streamOpt, const bool valid) const |
| Write the objects using stream options. More... | |
| template<class Type > | |
| const Type * | lookupObjectPtr (const word &name, bool recursive=false) const |
| Deprecated(2018-10) find object. More... | |
| template<class Type > | |
| Type * | lookupObjectRefPtr (const word &name, bool recursive=false) const |
| Deprecated(2018-10) get object pointer, ignoring constness. More... | |
| template<class MatchPredicate > | |
| Foam::HashTable< Foam::wordHashSet > | classesImpl (const objectRegistry &list, const MatchPredicate &matchName) |
| template<class MatchPredicate1 , class MatchPredicate2 > | |
| Foam::label | countImpl (const objectRegistry &list, const MatchPredicate1 &matchClass, const MatchPredicate2 &matchName) |
| template<class Type , class MatchPredicate > | |
| Foam::label | countTypeImpl (const objectRegistry &list, const MatchPredicate &matchName) |
| template<class MatchPredicate1 , class MatchPredicate2 > | |
| Foam::wordList | namesImpl (const objectRegistry &list, const MatchPredicate1 &matchClass, const MatchPredicate2 &matchName, const bool doSort) |
| template<class Type , class MatchPredicate > | |
| Foam::wordList | namesTypeImpl (const objectRegistry &list, const MatchPredicate &matchName, const bool doSort) |
| template<class Type , class MatchPredicate > | |
| Foam::UPtrList< Type > | objectsTypeImpl (const objectRegistry &list, const MatchPredicate &matchName) |
| template<class MatchPredicate > | |
| Foam::HashTable< Foam::wordHashSet > | classes (const MatchPredicate &matchName) const |
| template<class MatchPredicate > | |
| Foam::label | count (const MatchPredicate &matchClass) const |
| template<class MatchPredicate1 , class MatchPredicate2 > | |
| Foam::label | count (const MatchPredicate1 &matchClass, const MatchPredicate2 &matchName) const |
| template<class Type , class MatchPredicate > | |
| Foam::label | count (const MatchPredicate &matchName) const |
| template<class Type > | |
| Foam::label | count (const bool strict) const |
| template<class Type > | |
| Foam::UPtrList< const Type > | csorted () const |
| template<class Type > | |
| Foam::UPtrList< const Type > | sorted () const |
| template<class Type > | |
| Foam::UPtrList< Type > | sorted () |
| template<class Type , class MatchPredicate > | |
| Foam::UPtrList< const Type > | csorted (const MatchPredicate &matchName) const |
| template<class Type , class MatchPredicate > | |
| Foam::UPtrList< const Type > | sorted (const MatchPredicate &matchName) const |
| template<class Type , class MatchPredicate > | |
| Foam::UPtrList< Type > | sorted (const MatchPredicate &matchName) |
| template<class MatchPredicate > | |
| Foam::wordList | names (const MatchPredicate &matchClass) const |
| template<class MatchPredicate1 , class MatchPredicate2 > | |
| Foam::wordList | names (const MatchPredicate1 &matchClass, const MatchPredicate2 &matchName) const |
| template<class Type > | |
| Foam::wordList | names () const |
| template<class Type , class MatchPredicate > | |
| Foam::wordList | names (const MatchPredicate &matchName) const |
| template<class MatchPredicate > | |
| Foam::wordList | sortedNames (const MatchPredicate &matchClass) const |
| template<class MatchPredicate1 , class MatchPredicate2 > | |
| Foam::wordList | sortedNames (const MatchPredicate1 &matchClass, const MatchPredicate2 &matchName) const |
| template<class Type > | |
| Foam::wordList | sortedNames () const |
| template<class Type , class MatchPredicate > | |
| Foam::wordList | sortedNames (const MatchPredicate &matchName) const |
| template<class Type > | |
| Foam::HashTable< const Type * > | lookupClass (const bool strict) const |
| template<class Type > | |
| Foam::HashTable< Type * > | lookupClass (const bool strict) |
| Public Member Functions inherited from regIOobject | |
| TypeName ("regIOobject") | |
| Runtime type information. More... | |
| regIOobject (const IOobject &io, const bool isTimeObject=false) | |
| Construct from IOobject. The optional flag adds special handling if the object is the top-level regIOobject (eg, Time). More... | |
| regIOobject (const regIOobject &rio) | |
| Copy construct. More... | |
| regIOobject (const regIOobject &rio, bool registerCopy) | |
| Copy construct, transferring registry registration to the copy if registerCopy is true. More... | |
| regIOobject (const word &newName, const regIOobject &, bool registerCopy) | |
| Copy construct with new name, transferring registry registration to the copy f registerCopy is true. More... | |
| regIOobject (const IOobject &io, const regIOobject &rio) | |
| Copy construct with new IO parameters. More... | |
| virtual | ~regIOobject () |
| Destructor. More... | |
| bool | checkIn () |
| Add object to registry, if not already registered. More... | |
| bool | checkOut () |
| Remove all file watches and remove object from registry. More... | |
| virtual void | addWatch () |
| Add file watch on object (if registered and READ_IF_MODIFIED) More... | |
| bool | registered () const noexcept |
| Query the registered state (ie, has been checked in). This is not necessarily the same as registerObject(), which is just a stated preference. More... | |
| bool | ownedByRegistry () const noexcept |
| Is this object owned by the registry? More... | |
| bool | store () |
| Register object with its registry and transfer ownership to the registry. More... | |
| void | release (const bool unregister=false) noexcept |
| Set object as not ownedByRegistry. More... | |
| label | eventNo () const noexcept |
| Event number at last update. More... | |
| label & | eventNo () noexcept |
| Event number at last update. More... | |
| bool | upToDate (const regIOobject &) const |
| Return true if up-to-date with respect to given object. More... | |
| bool | upToDate (const regIOobject &, const regIOobject &) const |
| Return true if up-to-date with respect to given objects. More... | |
| bool | upToDate (const regIOobject &, const regIOobject &, const regIOobject &) const |
| Return true if up-to-date with respect to given objects. More... | |
| bool | upToDate (const regIOobject &, const regIOobject &, const regIOobject &, const regIOobject &) const |
| Return true if up-to-date with respect to given objects. More... | |
| void | setUpToDate () |
| Set as up-to-date. More... | |
| const dictionary * | findMetaData () const noexcept |
| Return pointer to meta-data or nullptr. More... | |
| dictionary & | getMetaData () noexcept |
| Get or create meta-data. More... | |
| void | removeMetaData () |
| Remove meta-data. More... | |
| virtual void | updateMetaData () |
| Update internal meta-data (eg, prior to writing) More... | |
| virtual fileName | filePath () const |
| Return complete path + object name if the file exists. More... | |
| bool | headerOk () |
| Read and check header info. Does not check the headerClassName. More... | |
| Istream & | readStream (const word &, const bool valid=true) |
| Return Istream and check object type against that given. More... | |
| void | close () |
| Close Istream. More... | |
| virtual bool | readData (Istream &) |
| Virtual readData function. More... | |
| virtual bool | read () |
| Read object. More... | |
| virtual label | addWatch (const fileName &) |
| Add file watch for fileName on object if not yet watched. More... | |
| const labelList & | watchIndices () const noexcept |
| Read access to file-monitoring handles. More... | |
| labelList & | watchIndices () noexcept |
| Write access to file-monitoring handles. More... | |
| virtual bool | write (const bool valid=true) const |
| Write using setting from DB. More... | |
| virtual bool | global () const |
| Is object global. More... | |
| void | operator= (const IOobject &io) |
| Copy assignment. More... | |
| virtual bool | writeObject (IOstreamOption::streamFormat fmt, IOstreamOption::versionNumber ver, IOstreamOption::compressionType cmp, const bool valid) const |
| Write using given format, version and compression. More... | |
| Public Member Functions inherited from IOobject | |
| TypeName ("IOobject") | |
| Declare type-name, virtual type (with debug switch) More... | |
| IOobject (const IOobject &)=default | |
| Copy construct. More... | |
| virtual | ~IOobject ()=default |
| Destructor. More... | |
| IOobject (const word &name, const fileName &instance, const objectRegistry ®istry, IOobjectOption ioOpt=IOobjectOption()) | |
| Construct from name, instance, registry, io options. More... | |
| IOobject (const word &name, const fileName &instance, const fileName &local, const objectRegistry ®istry, IOobjectOption ioOpt=IOobjectOption()) | |
| Construct from name, instance, local, registry, io options. More... | |
| IOobject (const fileName &path, const objectRegistry ®istry, IOobjectOption ioOpt=IOobjectOption()) | |
| Construct from path, registry, io options. More... | |
| IOobject (const word &name, const fileName &instance, const objectRegistry ®istry, IOobjectOption::readOption rOpt, IOobjectOption::writeOption wOpt=IOobjectOption::NO_WRITE, bool registerObject=true, bool globalObject=false) | |
| Construct from name, instance, registry, io options. More... | |
| IOobject (const word &name, const fileName &instance, const fileName &local, const objectRegistry ®istry, IOobjectOption::readOption rOpt, IOobjectOption::writeOption wOpt=IOobjectOption::NO_WRITE, bool registerObject=true, bool globalObject=false) | |
| Construct from name, instance, local, registry, io options. More... | |
| IOobject (const fileName &path, const objectRegistry ®istry, IOobjectOption::readOption rOpt, IOobjectOption::writeOption wOpt=IOobjectOption::NO_WRITE, bool registerObject=true, bool globalObject=false) | |
| Construct from path, registry, io options. More... | |
| IOobject (const IOobject &io, const objectRegistry ®istry) | |
| Copy construct, resetting registry. More... | |
| IOobject (const IOobject &io, const word &name) | |
| Copy construct, resetting name. More... | |
| IOobject (const IOobject &io, const word &name, const fileName &local) | |
| Copy construct, resetting name and local component. More... | |
| IOobject (const IOobject &io, IOobjectOption::readOption rOpt, IOobjectOption::writeOption wOpt) | |
| Copy construct, resetting read/write options. More... | |
| autoPtr< IOobject > | clone () const |
| Clone. More... | |
| autoPtr< IOobject > | clone (const objectRegistry ®istry) const |
| Clone resetting registry. More... | |
| const objectRegistry & | db () const noexcept |
| Return the local objectRegistry. More... | |
| const Time & | time () const |
| Return Time associated with the objectRegistry. More... | |
| const word & | name () const noexcept |
| Return the object name. More... | |
| const word & | headerClassName () const noexcept |
| Return name of the class name read from header. More... | |
| word & | headerClassName () noexcept |
| Return non-constant access to the class name read from header. More... | |
| const string & | note () const noexcept |
| Return the optional note. More... | |
| string & | note () noexcept |
| Modifiable access to the optional note. More... | |
| unsigned | labelByteSize () const noexcept |
| The sizeof (label) in bytes, possibly read from the header. More... | |
| unsigned | scalarByteSize () const noexcept |
| The sizeof (scalar) in bytes, possibly read from the header. More... | |
| bool | hasHeaderClass () const noexcept |
| True if headerClassName() is non-empty (after reading) More... | |
| template<class Type > | |
| bool | isHeaderClass () const |
| Check if headerClassName() equals Type::typeName. More... | |
| template<class Type > | |
| bool | isHeaderClassName () const |
| Same as isHeaderClass() More... | |
| word | group () const |
| Return group (extension part of name) More... | |
| word | member () const |
| Return member (name without the extension) More... | |
| const fileName & | rootPath () const |
| Return the Time::rootPath() More... | |
| const fileName & | caseName () const |
| Return the Time::caseName() More... | |
| const fileName & | instance () const noexcept |
| Read access to instance path component. More... | |
| fileName & | instance () noexcept |
| Write access to instance path component. More... | |
| const fileName & | local () const noexcept |
| Read access to local path component. More... | |
| fileName | path () const |
| The complete path. More... | |
| fileName | path (const word &instance, const fileName &local=fileName::null) const |
| The complete path with alternative instance and local. More... | |
| fileName | objectPath () const |
| The complete path + object name. More... | |
| fileName | objectRelPath () const |
| The object path relative to the root. More... | |
| fileName | localFilePath (const word &typeName, const bool search=true) const |
| Redirect to fileHandler filePath, searching locally. More... | |
| fileName | globalFilePath (const word &typeName, const bool search=true) const |
| Redirect to fileHandler filePath, searching up if in parallel. More... | |
| IOstreamOption | parseHeader (const dictionary &headerDict) |
| Parse 'FoamFile' header contents and set the IOobject characteristics and return the stream characteristics. More... | |
| bool | readHeader (Istream &is) |
| Read header ('FoamFile' dictionary) and set the IOobject and stream characteristics. More... | |
| bool | readHeader (dictionary &headerDict, Istream &is) |
| Read header (the 'FoamFile' dictionary) and set the IOobject and stream characteristics. More... | |
| template<class Type > | |
| bool | typeHeaderOk (const bool checkType=true, const bool search=true, const bool verbose=true) |
| Read header (uses typeFilePath to find file) and check its info. More... | |
| template<class Type > | |
| void | warnNoRereading () const |
| Helper: warn that type does not support re-reading. More... | |
| bool | writeHeader (Ostream &os) const |
| Write header with current type() More... | |
| bool | writeHeader (Ostream &os, const word &objectType) const |
| Write header with override of type. More... | |
| void | writeHeader (dictionary &dict, IOstreamOption streamOpt) const |
| Write header into a dictionary with current type() and given output format. More... | |
| void | writeHeader (dictionary &dict, const word &objectType, IOstreamOption streamOpt) const |
| Write header into a dictionary with override of type and given output format. More... | |
| bool | good () const noexcept |
| Did last readHeader() succeed? More... | |
| bool | bad () const noexcept |
| Did last readHeader() fail? More... | |
| InfoProxy< IOobject > | info () const |
| Return info proxy, for printing information to a stream. More... | |
| void | operator= (const IOobject &io) |
| Copy assignment, copies all values (except the registry) More... | |
| template<> | |
| bool | isHeaderClass () const |
Specialization for void always returns true (no headerClassName check). More... | |
| template<class StringType > | |
| Foam::word | groupName (StringType base, const word &group) |
| Public Member Functions inherited from IOobjectOption | |
| constexpr | IOobjectOption (readOption rOpt=readOption::NO_READ, writeOption wOpt=writeOption::NO_WRITE, registerOption registerObject=registerOption::REGISTER, bool globalObject=false) noexcept |
| Default construct (NO_READ, NO_WRITE, register, non-global) or construct with specified options. More... | |
| constexpr | IOobjectOption (readOption rOpt, registerOption registerObject=registerOption::REGISTER, bool globalObject=false) noexcept |
| Construct NO_WRITE with specified read/register options. More... | |
| constexpr | IOobjectOption (writeOption wOpt, registerOption registerObject=registerOption::REGISTER, bool globalObject=false) noexcept |
| Construct NO_READ with specified write/register options. More... | |
| constexpr | IOobjectOption (registerOption registerObject, bool globalObject=false) noexcept |
| Construct (NO_READ, NO_WRITE) with specified register option. More... | |
| constexpr | IOobjectOption (readOption rOpt, writeOption wOpt, bool registerObject, bool globalObject=false) noexcept |
| Construct from components with specified register option as bool. More... | |
| constexpr | IOobjectOption (bool registerObject, bool globalObject=false) noexcept |
| Construct (NO_READ, NO_WRITE) with specified register option as bool. More... | |
| readOption | readOpt () const noexcept |
| Get the read option. More... | |
| readOption | readOpt (readOption opt) noexcept |
| Set the read option. More... | |
| writeOption | writeOpt () const noexcept |
| Get the write option. More... | |
| writeOption | writeOpt (writeOption opt) noexcept |
| Set the write option. More... | |
| bool | registerObject () const noexcept |
| Should objects created with this IOobject be registered? More... | |
| bool | registerObject (bool on) noexcept |
| Change registration preference. More... | |
| bool | globalObject () const noexcept |
| True if object is treated the same for all processors. More... | |
| bool | globalObject (bool on) noexcept |
| Change global-object status. More... | |
| bool | isReadRequired () const noexcept |
| True if (MUST_READ | MUST_READ_IF_MODIFIED) bits are set. More... | |
| bool | isReadOptional () const noexcept |
| True if (READ_IF_PRESENT) bits are set. More... | |
| readOption & | readOpt () noexcept |
| Access to the read option. More... | |
| writeOption & | writeOpt () noexcept |
| Access to the write option. More... | |
| bool & | registerObject () noexcept |
| Access to the register object option. More... | |
| bool & | globalObject () noexcept |
| Access to the global object option. More... | |
| Public Member Functions inherited from HashTable< regIOobject *> | |
| HashTable () | |
| Default construct with default (128) table capacity. More... | |
| HashTable (const label size) | |
| Construct given initial table capacity. More... | |
| HashTable (Istream &is, const label size=128) | |
| Construct from Istream with default table capacity. More... | |
| HashTable (const this_type &ht) | |
| Copy construct. More... | |
| HashTable (this_type &&rhs) | |
| Move construct. More... | |
| HashTable (std::initializer_list< std::pair< word, regIOobject * >> list) | |
| Construct from an initializer list. More... | |
| ~HashTable () | |
| Destructor. More... | |
| label | capacity () const noexcept |
| The size of the underlying table. More... | |
| label | size () const noexcept |
| The number of elements in table. More... | |
| bool | empty () const noexcept |
| True if the hash table is empty. More... | |
| regIOobject * & | at (const word &key) |
| Find and return a hashed entry. FatalError if it does not exist. More... | |
| const regIOobject * & | at (const word &key) const |
| Find and return a hashed entry. FatalError if it does not exist. More... | |
| bool | found (const word &key) const |
| True if hashed key is found in table. More... | |
| iterator | find (const word &key) |
| Find and return an iterator set at the hashed entry. More... | |
| const_iterator | find (const word &key) const |
| Find and return an const_iterator set at the hashed entry. More... | |
| const_iterator | cfind (const word &key) const |
| Find and return an const_iterator set at the hashed entry. More... | |
| const regIOobject * & | lookup (const word &key, const regIOobject * &deflt) const |
| Return hashed entry if it exists, or return the given default. More... | |
| List< word > | toc () const |
| The table of contents (the keys) in unsorted order. More... | |
| List< word > | sortedToc () const |
| The table of contents (the keys) in sorted order. More... | |
| List< word > | sortedToc (const Compare &comp) const |
| The table of contents (the keys) sorted according to the specified comparator. More... | |
| Foam::List< word > | sortedToc (const Compare &comp) const |
| List< word > | tocKeys (const UnaryPredicate &pred, const bool invert=false) const |
| The table of contents (the keys) selected according to the unary predicate applied to the keys. More... | |
| Foam::List< word > | tocKeys (const UnaryPredicate &pred, const bool invert) const |
| List< word > | tocValues (const UnaryPredicate &pred, const bool invert=false) const |
| The table of contents (the keys) selected according to the unary predicate applied to the values. More... | |
| Foam::List< word > | tocValues (const UnaryPredicate &pred, const bool invert) const |
| List< word > | tocEntries (const BinaryPredicate &pred, const bool invert=false) const |
| The table of contents (the keys) selected according to the binary predicate applied to the keys and values. More... | |
| Foam::List< word > | tocEntries (const BinaryPredicate &pred, const bool invert) const |
| UPtrList< const node_type > | csorted () const |
| Const access to the hash-table contents in sorted order (sorted by keys). More... | |
| UPtrList< const node_type > | sorted () const |
| Const access to the hash-table contents in sorted order (sorted by keys). More... | |
| UPtrList< node_type > | sorted () |
| Non-const access to the hash-table contents in sorted order (sorted by keys). More... | |
| label | countKeys (const UnaryPredicate &pred, const bool invert=false) const |
| Count the number of keys that satisfy the unary predicate. More... | |
| Foam::label | countKeys (const UnaryPredicate &pred, const bool invert) const |
| label | countValues (const UnaryPredicate &pred, const bool invert=false) const |
| Count the number of values that satisfy the unary predicate. More... | |
| Foam::label | countValues (const UnaryPredicate &pred, const bool invert) const |
| label | countEntries (const BinaryPredicate &pred, const bool invert=false) const |
| Count the number of entries that satisfy the binary predicate. More... | |
| Foam::label | countEntries (const BinaryPredicate &pred, const bool invert) const |
| bool | emplace (const word &key, Args &&... args) |
| Emplace insert a new entry, not overwriting existing entries. More... | |
| bool | emplace_set (const word &key, Args &&... args) |
| Emplace set an entry, overwriting any existing entries. More... | |
| bool | insert (const word &key, const regIOobject * &obj) |
| Copy insert a new entry, not overwriting existing entries. More... | |
| bool | insert (const word &key, regIOobject * &&obj) |
| Move insert a new entry, not overwriting existing entries. More... | |
| bool | set (const word &key, const regIOobject * &obj) |
| Copy assign a new entry, overwriting existing entries. More... | |
| bool | set (const word &key, regIOobject * &&obj) |
| Move assign a new entry, overwriting existing entries. More... | |
| bool | erase (const iterator &iter) |
| Erase an entry specified by given iterator. More... | |
| bool | erase (const word &key) |
| Erase an entry specified by the given key. More... | |
| label | erase (const HashTable< AnyType, word, AnyHash > &other) |
| Remove table entries given by keys of the other hash-table. More... | |
| label | erase (std::initializer_list< word > keys) |
| Remove table entries given by the listed keys. More... | |
| label | erase (InputIter first, InputIter last) |
| Remove multiple entries using an iterator range of keys. More... | |
| label | erase (const FixedList< word, N > &keys) |
| Remove table entries given by the listed keys. More... | |
| label | erase (const UList< word > &keys) |
| Remove table entries given by the listed keys. More... | |
| Foam::label | erase (InputIter first, InputIter last) |
| Foam::label | erase (const FixedList< word, N > &keys) |
| Foam::label | erase (const HashTable< AnyType, word, AnyHash > &other) |
| label | retain (const HashTable< AnyType, word, AnyHash > &other) |
| Retain table entries given by keys of the other hash-table. More... | |
| Foam::label | retain (const HashTable< AnyType, word, AnyHash > &other) |
| label | filterKeys (const UnaryPredicate &pred, const bool pruning=false) |
| Generalized means to filter table entries based on their keys. More... | |
| Foam::label | filterKeys (const UnaryPredicate &pred, const bool pruning) |
| label | filterValues (const UnaryPredicate &pred, const bool pruning=false) |
| Generalized means to filter table entries based on their values. More... | |
| Foam::label | filterValues (const UnaryPredicate &pred, const bool pruning) |
| label | filterEntries (const BinaryPredicate &pred, const bool pruning=false) |
| Generalized means to filter table entries based on their key/value. More... | |
| Foam::label | filterEntries (const BinaryPredicate &pred, const bool pruning) |
| void | resize (const label sz) |
| Resize the hash table for efficiency. More... | |
| void | clear () |
| Clear all entries from table. More... | |
| void | clearStorage () |
| Clear the table entries and the table itself. More... | |
| void | swap (HashTable< regIOobject *, word, Foam::Hash< word > > &rhs) |
| Swap contents into this table. More... | |
| void | transfer (HashTable< regIOobject *, word, Foam::Hash< word > > &rhs) |
| Transfer contents into this table. More... | |
| regIOobject * & | operator[] (const word &key) |
| Find and return a hashed entry. FatalError if it does not exist. More... | |
| const regIOobject * & | operator[] (const word &key) const |
| Find and return a hashed entry. FatalError if it does not exist. More... | |
| regIOobject * & | operator() (const word &key) |
| Return existing entry or create a new entry. More... | |
| regIOobject * & | operator() (const word &key, const regIOobject * &deflt) |
| Return existing entry or insert a new entry. More... | |
| void | operator= (const this_type &rhs) |
| Copy assign. More... | |
| void | operator= (std::initializer_list< std::pair< word, regIOobject * >> rhs) |
| Copy assign from an initializer list. More... | |
| void | operator= (this_type &&rhs) |
| Move assign. More... | |
| bool | operator== (const this_type &rhs) const |
| Equality. Tables are equal if all keys and values are equal, independent of order or underlying storage size. More... | |
| bool | operator!= (const this_type &rhs) const |
| The opposite of the equality operation. More... | |
| this_type & | operator+= (const this_type &rhs) |
| Add entries into this HashTable. More... | |
| const_iterator_pair< const_key_iterator, this_type > | keys () const |
| A const iterator begin/end pair for iterating over keys. More... | |
| iterator | begin () |
| iterator set to the beginning of the HashTable More... | |
| const_iterator | begin () const |
| const_iterator set to the beginning of the HashTable More... | |
| const_iterator | cbegin () const |
| const_iterator set to the beginning of the HashTable More... | |
| iterator | end () noexcept |
| iterator to signal the end (for any HashTable) More... | |
| const_iterator | end () const noexcept |
| const_iterator to signal the end (for any HashTable) More... | |
| constexpr const_iterator | cend () const noexcept |
| const_iterator to signal the end (for any HashTable) More... | |
| Ostream & | printInfo (Ostream &os) const |
| Print information. More... | |
| Ostream & | writeKeys (Ostream &os, const label shortLen=0) const |
| Write unordered keys (list), with line-breaks when length exceeds shortLen. More... | |
| Public Member Functions inherited from HashTableCore | |
| ClassName ("HashTable") | |
| Declare type-name (with debug switch) More... | |
| HashTableCore () noexcept=default | |
| Default construct. More... | |
| Public Member Functions inherited from primitiveMesh | |
| ClassName ("primitiveMesh") | |
| primitiveMesh (const label nPoints, const label nInternalFaces, const label nFaces, const label nCells) | |
| Construct from components. More... | |
| virtual | ~primitiveMesh () |
| Destructor. More... | |
| void | reset (const label nPoints, const label nInternalFaces, const label nFaces, const label nCells) |
| Reset this primitiveMesh given the primitive array sizes. More... | |
| void | reset (const label nPoints, const label nInternalFaces, const label nFaces, const label nCells, cellList &cells) |
| Reset this primitiveMesh given the primitive array sizes and cells. More... | |
| void | resetGeometry (pointField &&faceCentres, pointField &&faceAreas, pointField &&cellCentres, scalarField &&cellVolumes) |
| Reset the local geometry. More... | |
| label | nPoints () const noexcept |
| Number of mesh points. More... | |
| label | nEdges () const |
| Number of mesh edges. More... | |
| label | nFaces () const noexcept |
| Number of mesh faces. More... | |
| label | nCells () const noexcept |
| Number of mesh cells. More... | |
| label | nInternalFaces () const noexcept |
| Number of internal faces. More... | |
| label | nBoundaryFaces () const noexcept |
| Number of boundary faces (== nFaces - nInternalFaces) More... | |
| label | nInternalPoints () const noexcept |
| Points not on boundary. More... | |
| label | nInternal0Edges () const |
| Internal edges (i.e. not on boundary face) using no boundary point. More... | |
| label | nInternal1Edges () const |
| Internal edges using 0 or 1 boundary point. More... | |
| label | nInternalEdges () const |
| Internal edges using 0,1 or 2 boundary points. More... | |
| const cellShapeList & | cellShapes () const |
| Return cell shapes. More... | |
| const edgeList & | edges () const |
| Return mesh edges. Uses calcEdges. More... | |
| const labelListList & | cellCells () const |
| const labelListList & | edgeCells () const |
| const labelListList & | pointCells () const |
| const cellList & | cells () const |
| const labelListList & | edgeFaces () const |
| const labelListList & | pointFaces () const |
| const labelListList & | cellEdges () const |
| const labelListList & | faceEdges () const |
| const labelListList & | pointEdges () const |
| const labelListList & | pointPoints () const |
| const labelListList & | cellPoints () const |
| const vectorField & | cellCentres () const |
| const vectorField & | faceCentres () const |
| const scalarField & | cellVolumes () const |
| const vectorField & | faceAreas () const |
| void | movePoints (const pointField &p, const pointField &oldP) |
| Move points. More... | |
| bool | isInternalFace (const label faceIndex) const noexcept |
| Return true if given face label is internal to the mesh. More... | |
| virtual bool | checkUpperTriangular (const bool report=false, labelHashSet *setPtr=nullptr) const |
| Check face ordering. More... | |
| virtual bool | checkCellsZipUp (const bool report=false, labelHashSet *setPtr=nullptr) const |
| Check cell zip-up. More... | |
| virtual bool | checkFaceVertices (const bool report=false, labelHashSet *setPtr=nullptr) const |
| Check uniqueness of face vertices. More... | |
| virtual bool | checkPoints (const bool report=false, labelHashSet *setPtr=nullptr) const |
| Check for unused points. More... | |
| virtual bool | checkFaceFaces (const bool report=false, labelHashSet *setPtr=nullptr) const |
| Check face-face connectivity. More... | |
| virtual bool | checkClosedBoundary (const bool report=false) const |
| Check boundary for closedness. More... | |
| virtual bool | checkClosedCells (const bool report=false, labelHashSet *setPtr=nullptr, labelHashSet *highAspectSetPtr=nullptr, const Vector< label > &solutionD=Vector< label >::one) const |
| Check cells for closedness. More... | |
| virtual bool | checkFaceAreas (const bool report=false, labelHashSet *setPtr=nullptr) const |
| Check for negative face areas. More... | |
| virtual bool | checkCellVolumes (const bool report=false, labelHashSet *setPtr=nullptr) const |
| Check for negative cell volumes. More... | |
| virtual bool | checkFacePyramids (const bool report=false, const scalar minPyrVol=-SMALL, labelHashSet *setPtr=nullptr) const |
| Check face pyramid volume. More... | |
| virtual bool | checkFaceAngles (const bool report=false, const scalar maxSin=10, labelHashSet *setPtr=nullptr) const |
| Check face angles. More... | |
| virtual bool | checkFaceFlatness (const bool report, const scalar warnFlatness, labelHashSet *setPtr) const |
| Check face warpage: decompose face and check ratio between. More... | |
| virtual bool | checkPointNearness (const bool report, const scalar reportDistSqr, labelHashSet *setPtr=nullptr) const |
| Check for point-point-nearness,. More... | |
| virtual bool | checkEdgeLength (const bool report, const scalar minLenSqr, labelHashSet *setPtr=nullptr) const |
| Check edge length. More... | |
| virtual bool | checkConcaveCells (const bool report=false, labelHashSet *setPtr=nullptr) const |
| Check for concave cells by the planes of faces. More... | |
| virtual bool | checkTopology (const bool report=false) const |
| Check mesh topology for correctness. More... | |
| virtual bool | checkGeometry (const bool report=false) const |
| Check mesh geometry (& implicitly topology) for correctness. More... | |
| virtual bool | checkMesh (const bool report=false) const |
| Check mesh for correctness. Returns false for no error. More... | |
| boundBox | cellBb (const label celli) const |
| The bounding box for given cell index. More... | |
| bool | pointInCellBB (const point &p, label celli, scalar inflationFraction=0) const |
| Return true if the point in the cell bounding box. More... | |
| bool | pointInCell (const point &p, label celli) const |
| Return true if the point is in the cell. More... | |
| label | findNearestCell (const point &location) const |
| Find the cell with the nearest cell centre to location. More... | |
| label | findCell (const point &location) const |
| Find cell enclosing this location (-1 if not in mesh) More... | |
| void | printAllocated () const |
| Print a list of all the currently allocated mesh data. More... | |
| bool | hasCellShapes () const noexcept |
| bool | hasEdges () const noexcept |
| bool | hasCellCells () const noexcept |
| bool | hasEdgeCells () const noexcept |
| bool | hasPointCells () const noexcept |
| bool | hasCells () const noexcept |
| bool | hasEdgeFaces () const noexcept |
| bool | hasPointFaces () const noexcept |
| bool | hasCellEdges () const noexcept |
| bool | hasFaceEdges () const noexcept |
| bool | hasPointEdges () const noexcept |
| bool | hasPointPoints () const noexcept |
| bool | hasCellPoints () const noexcept |
| bool | hasCellCentres () const noexcept |
| bool | hasCellVolumes () const noexcept |
| bool | hasFaceCentres () const noexcept |
| bool | hasFaceAreas () const noexcept |
| const labelList & | cellCells (const label celli, DynamicList< label > &) const |
| cellCells using cells. More... | |
| const labelList & | cellCells (const label celli) const |
| const labelList & | cellPoints (const label celli, labelHashSet &, DynamicList< label > &) const |
| cellPoints using cells More... | |
| const labelList & | cellPoints (const label celli) const |
| const labelList & | pointCells (const label pointi, DynamicList< label > &) const |
| pointCells using pointFaces More... | |
| const labelList & | pointCells (const label pointi) const |
| const labelList & | pointPoints (const label pointi, DynamicList< label > &) const |
| pointPoints using edges, pointEdges More... | |
| const labelList & | pointPoints (const label pointi) const |
| const labelList & | faceEdges (const label facei, DynamicList< label > &) const |
| faceEdges using pointFaces, edges, pointEdges More... | |
| const labelList & | faceEdges (const label facei) const |
| const labelList & | edgeFaces (const label edgeI, DynamicList< label > &) const |
| edgeFaces using pointFaces, edges, pointEdges More... | |
| const labelList & | edgeFaces (const label edgeI) const |
| const labelList & | edgeCells (const label edgeI, DynamicList< label > &) const |
| edgeCells using pointFaces, edges, pointEdges More... | |
| const labelList & | edgeCells (const label edgeI) const |
| const labelList & | cellEdges (const label celli, labelHashSet &, DynamicList< label > &) const |
| cellEdges using cells, pointFaces, edges, pointEdges More... | |
| const labelList & | cellEdges (const label celli) const |
| virtual void | updateGeom () |
| Update all geometric data. More... | |
| void | clearGeom () |
| Clear geometry. More... | |
| void | clearCellGeom () |
| Clear cell-based geometry only. More... | |
| void | clearAddressing () |
| Clear topological data. More... | |
| void | clearOut () |
| Clear all geometry and addressing unnecessary for CFD. More... | |
Static Public Member Functions | |
| static const word & | regionName (const word ®ion) |
| The mesh region name or word::null if polyMesh::defaultRegion. More... | |
| Static Public Member Functions inherited from regIOobject | |
| template<class Type > | |
| static Type & | store (Type *p) |
| Transfer pointer ownership to its registry. More... | |
| template<class Type > | |
| static Type & | store (autoPtr< Type > &ptr) |
| Transfer pointer ownership to its registry. More... | |
| template<class Type > | |
| static Type & | store (autoPtr< Type > &&ptr) |
| Transfer pointer ownership to its registry. More... | |
| template<class Type > | |
| static Type & | store (refPtr< Type > &ptr) |
| Transfer pointer ownership to its registry. More... | |
| template<class Type > | |
| static Type & | store (refPtr< Type > &&ptr) |
| Transfer pointer ownership to its registry. More... | |
| template<class Type > | |
| static Type & | store (tmp< Type > &ptr) |
| Transfer pointer ownership to its registry. More... | |
| template<class Type > | |
| static Type & | store (tmp< Type > &&ptr) |
| Transfer pointer ownership to its registry. More... | |
| Static Public Member Functions inherited from IOobject | |
| static bool | bannerEnabled () noexcept |
| Status of output file banner. More... | |
| static bool | bannerEnabled (bool on) noexcept |
| Enable/disable output file banner. More... | |
| static bool | fileNameComponents (const fileName &path, fileName &instance, fileName &local, word &name) |
| Split path into instance, local, name components. More... | |
| template<class StringType > | |
| static word | groupName (StringType base, const word &group) |
| Create dot-delimited name.group string. More... | |
| static word | group (const word &name) |
| Return group (extension part of name) More... | |
| static word | member (const word &name) |
| Return member (name without the extension) More... | |
| static word | scopedName (const std::string &scope, const word &name) |
| Create scope:name or scope_name string. More... | |
| static IOobject | selectIO (const IOobject &io, const fileName &altFile, const word &ioName="") |
| Return the IOobject, but also consider an alternative file name. More... | |
| static Ostream & | writeBanner (Ostream &os, const bool noSyntaxHint=false) |
| Write the standard OpenFOAM file/dictionary banner. More... | |
| static Ostream & | writeDivider (Ostream &os) |
| Write the standard file section divider. More... | |
| static Ostream & | writeEndDivider (Ostream &os) |
| Write the standard end file divider. More... | |
| Static Public Member Functions inherited from IOobjectOption | |
| static bool | isReadRequired (readOption opt) noexcept |
| True if (MUST_READ | MUST_READ_IF_MODIFIED) bits are set. More... | |
| static bool | isReadOptional (readOption opt) noexcept |
| True if (READ_IF_PRESENT) bits are set. More... | |
| Static Public Member Functions inherited from HashTableCore | |
| static label | canonicalSize (const label requested_size) |
| Return a canonical (power-of-two) of the requested size. More... | |
| Static Public Member Functions inherited from primitiveMesh | |
| static void | calcCells (cellList &, const labelUList &own, const labelUList &nei, const label nCells=-1) |
| Helper function to calculate cell-face addressing from. More... | |
| static bool | calcPointOrder (label &nInternalPoints, labelList &pointMap, const faceList &, const label nInternalFaces, const label nPoints) |
| Helper function to calculate point ordering. Returns true. More... | |
| static scalar | setClosedThreshold (const scalar) |
| Set the closedness ratio warning threshold. More... | |
| static scalar | setAspectThreshold (const scalar) |
| Set the aspect ratio warning threshold. More... | |
| static scalar | setNonOrthThreshold (const scalar) |
| Set the non-orthogonality warning threshold in degrees. More... | |
| static scalar | setSkewThreshold (const scalar) |
| Set the skewness warning threshold as percentage. More... | |
Static Public Attributes | |
| static word | defaultRegion = "region0" |
| Return the default region name. More... | |
| static word | meshSubDir = "polyMesh" |
| Return the mesh sub-directory name (usually "polyMesh") More... | |
| Static Public Attributes inherited from IOobject | |
| static const Enum< fileCheckTypes > | fileCheckTypesNames |
| Names for the fileCheckTypes. More... | |
| static char | scopeSeparator |
| Character for scoping object names (':' or '_') More... | |
| static fileCheckTypes | fileModificationChecking |
| Type of file modification checking. More... | |
| static float | fileModificationSkew |
| Time skew (seconds) for file modification checks. More... | |
| static int | maxFileModificationPolls |
| Max number of times to poll for file modification changes. More... | |
| Static Public Attributes inherited from HashTableCore | |
| static const label | maxTableSize |
| Maximum allowable internal table size. Approximately labelMax/4. More... | |
| Static Public Attributes inherited from primitiveMesh | |
| static const unsigned | cellsPerEdge_ = 4 |
| Estimated number of cells per edge. More... | |
| static const unsigned | cellsPerPoint_ = 8 |
| Estimated number of cells per point. More... | |
| static const unsigned | facesPerCell_ = 6 |
| Estimated number of faces per cell. More... | |
| static const unsigned | facesPerEdge_ = 4 |
| Estimated number of faces per edge. More... | |
| static const unsigned | facesPerPoint_ = 12 |
| Estimated number of faces per point. More... | |
| static const unsigned | edgesPerCell_ = 12 |
| Estimated number of edges per cell. More... | |
| static const unsigned | edgesPerFace_ = 4 |
| Estimated number of edges per cell. More... | |
| static const unsigned | edgesPerPoint_ = 6 |
| Estimated number of edges per point. More... | |
| static const unsigned | pointsPerCell_ = 8 |
| Estimated number of points per cell. More... | |
| static const unsigned | pointsPerFace_ = 4 |
| Estimated number of points per face. More... | |
Additional Inherited Members | |
| Protected Member Functions inherited from regIOobject | |
| bool | readHeaderOk (const IOstreamOption::streamFormat fmt, const word &typeName) |
| Helper: check readOpt flags and read if necessary. More... | |
| Protected Member Functions inherited from IOobject | |
| void | setBad (const string &s) |
| Set the object state to bad. More... | |
| Protected Member Functions inherited from HashTable< regIOobject *> | |
| bool | iterator_erase (node_type *&entry, label &index) |
| Low-level entry erasure using iterator internals. More... | |
| Protected Member Functions inherited from primitiveMesh | |
| void | calcFaceCentresAndAreas () const |
| Calculate face centres and areas. More... | |
| void | calcCellCentresAndVols () const |
| Calculate cell centres and volumes. More... | |
| void | calcEdgeVectors () const |
| Calculate edge vectors. More... | |
| bool | checkDuplicateFaces (const label, const Map< label > &, label &nBaffleFaces, labelHashSet *) const |
| Check if all points on face are shared with another face. More... | |
| bool | checkCommonOrder (const label, const Map< label > &, labelHashSet *) const |
| Check that shared points are in consecutive order. More... | |
| bool | checkClosedBoundary (const vectorField &areas, const bool report, const bitSet &internalOrCoupledFaces) const |
| Check boundary for closedness. More... | |
| bool | checkClosedCells (const vectorField &faceAreas, const scalarField &cellVolumes, const bool report, labelHashSet *setPtr, labelHashSet *aspectSetPtr, const Vector< label > &meshD) const |
| Check cells for closedness. More... | |
| bool | checkFaceAreas (const vectorField &faceAreas, const bool report, const bool detailedReport, labelHashSet *setPtr) const |
| Check for negative face areas. More... | |
| bool | checkCellVolumes (const scalarField &vols, const bool report, const bool detailedReport, labelHashSet *setPtr) const |
| Check for negative cell volumes. More... | |
| bool | checkFaceOrthogonality (const vectorField &fAreas, const vectorField &cellCtrs, const bool report, labelHashSet *setPtr) const |
| Check for non-orthogonality. More... | |
| bool | checkFacePyramids (const pointField &points, const vectorField &ctrs, const bool report, const bool detailedReport, const scalar minPyrVol, labelHashSet *setPtr) const |
| Check face pyramid volume. More... | |
| bool | checkFaceSkewness (const pointField &points, const vectorField &fCtrs, const vectorField &fAreas, const vectorField &cellCtrs, const bool report, labelHashSet *setPtr) const |
| Check face skewness. More... | |
| bool | checkFaceAngles (const pointField &points, const vectorField &faceAreas, const bool report, const scalar maxDeg, labelHashSet *setPtr) const |
| Check face angles. More... | |
| bool | checkFaceFlatness (const pointField &points, const vectorField &faceCentres, const vectorField &faceAreas, const bool report, const scalar warnFlatness, labelHashSet *setPtr) const |
| Check face warpage. More... | |
| bool | checkConcaveCells (const vectorField &fAreas, const pointField &fCentres, const bool report, labelHashSet *setPtr) const |
| Check for concave cells by the planes of faces. More... | |
| primitiveMesh () | |
| Construct null. More... | |
| Static Protected Member Functions inherited from IOobject | |
| static void | writeHeaderContent (Ostream &os, const IOobject &io, const word &objectType, const dictionary *metaDataDict=nullptr) |
| Helper: write content for FoamFile IOobject header with optional meta information. More... | |
| static void | writeHeaderContent (dictionary &dict, const IOobject &io, const word &objectType, IOstreamOption streamOpt, const dictionary *metaDataDict=nullptr) |
| Helper: write dictionary content for FoamFile header with optional meta information. More... | |
| Static Protected Attributes inherited from regIOobject | |
| static bool | masterOnlyReading = false |
| To flag master-only reading of objects. More... | |
| Static Protected Attributes inherited from primitiveMesh | |
| static scalar | closedThreshold_ = 1.0e-6 |
| Static data to control mesh checking. More... | |
| static scalar | aspectThreshold_ = 1000 |
| Aspect ratio warning threshold. More... | |
| static scalar | nonOrthThreshold_ = 70 |
| Non-orthogonality warning threshold in deg. More... | |
| static scalar | skewThreshold_ = 4 |
| Skewness warning threshold. More... | |
| static scalar | planarCosAngle_ = 1.0e-6 |
| Threshold where faces are considered coplanar. More... | |
The mesh type.
Definition at line 381 of file polyMesh.H.
| typedef polyBoundaryMesh BoundaryMesh |
The boundary type associated with the mesh.
Definition at line 386 of file polyMesh.H.
| enum readUpdateState |
Enumeration defining the state of the mesh after a read update.
Used for post-processing applications, where the mesh needs to update based on the files written in time directories
| Enumerator | |
|---|---|
| UNCHANGED | |
| POINTS_MOVED | |
| TOPO_CHANGE | |
| TOPO_PATCH_CHANGE | |
Definition at line 89 of file polyMesh.H.
| enum cellDecomposition |
Enumeration defining the decomposition of the cell for.
inside/outside test
| Enumerator | |
|---|---|
| FACE_PLANES | |
| FACE_CENTRE_TRIS | |
| FACE_DIAG_TRIS | |
| CELL_TETS | |
Definition at line 102 of file polyMesh.H.
Read construct from IOobject.
Definition at line 164 of file polyMesh.C.
References UPtrList< T >::empty(), Foam::endl(), IOobject::hasHeaderClass(), polyMesh::init(), polyMesh::meshDir(), polyMesh::meshSubDir, IOobjectOption::MUST_READ, primitiveMesh::nCells(), IOobjectOption::NO_WRITE, primitiveMesh::nPoints(), Foam::returnReduceAnd(), Foam::returnReduceOr(), objectRegistry::time(), WarningInFunction, and regIOobject::write().
Construct from IOobject or as zero-sized mesh.
Boundary is added using addPatches() member function
Definition at line 702 of file polyMesh.C.
| polyMesh | ( | const IOobject & | io, |
| pointField && | points, | ||
| faceList && | faces, | ||
| labelList && | owner, | ||
| labelList && | neighbour, | ||
| const bool | syncPar = true |
||
| ) |
Construct from IOobject and components.
Boundary is added using addPatches() member function
Definition at line 379 of file polyMesh.C.
References Foam::abort(), Foam::FatalError, FatalErrorInFunction, forAll, Foam::max(), Foam::min(), and UList< T >::size().
| polyMesh | ( | const IOobject & | io, |
| pointField && | points, | ||
| faceList && | faces, | ||
| cellList && | cells, | ||
| const bool | syncPar = true |
||
| ) |
Construct without boundary with cells rather than owner/neighbour.
Boundary is added using addPatches() member function
Definition at line 533 of file polyMesh.C.
References Foam::abort(), cells, Foam::FatalError, FatalErrorInFunction, forAll, Foam::max(), Foam::min(), and UList< T >::size().
| polyMesh | ( | const IOobject & | io, |
| pointField && | points, | ||
| const cellShapeList & | shapes, | ||
| const faceListList & | boundaryFaces, | ||
| const wordList & | boundaryPatchNames, | ||
| const wordList & | boundaryPatchTypes, | ||
| const word & | defaultBoundaryPatchName, | ||
| const word & | defaultBoundaryPatchType, | ||
| const wordList & | boundaryPatchPhysicalTypes, | ||
| const bool | syncPar = true |
||
| ) |
Construct from cell shapes.
Definition at line 439 of file polyMeshFromShapeMesh.C.
References cells, Foam::ensightOutput::debug, DebugInfo, Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, UList< T >::find(), forAll, Foam::Info, polyPatch::New(), Foam::reduce(), UList< T >::size(), and WarningInFunction.
| polyMesh | ( | const IOobject & | io, |
| pointField && | points, | ||
| const cellShapeList & | shapes, | ||
| const faceListList & | boundaryFaces, | ||
| const wordList & | boundaryPatchNames, | ||
| const PtrList< dictionary > & | boundaryDicts, | ||
| const word & | defaultBoundaryPatchName, | ||
| const word & | defaultBoundaryPatchType, | ||
| const bool | syncPar = true |
||
| ) |
Construct from cell shapes, with patch information in dictionary format.
Definition at line 721 of file polyMeshFromShapeMesh.C.
References boundaryDicts, cells, Foam::ensightOutput::debug, DebugInfo, Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, UList< T >::find(), forAll, Foam::Info, Foam::name(), polyPatch::New(), Foam::reduce(), dictionary::set(), UList< T >::size(), Foam::type(), and WarningInFunction.
|
virtual |
Destructor.
Definition at line 807 of file polyMesh.C.
| TypeName | ( | "polyMesh" | ) |
Runtime type information.
|
virtual |
Override the objectRegistry dbDir for a single-region case.
Reimplemented from objectRegistry.
Definition at line 824 of file polyMesh.C.
References objectRegistry::dbDir().
Referenced by topoSet::findIOobject(), faMesh::meshDir(), sensitivitySurface::smoothSensitivities(), and cellCellStencil::zoneID().
| Foam::fileName meshDir | ( | ) | const |
Return the local mesh directory (dbDir()/meshSubDir)
Definition at line 835 of file polyMesh.C.
Referenced by points0MotionSolver::points0IO(), polyMesh::polyMesh(), and polyMesh::readUpdate().
| const Foam::fileName & pointsInstance | ( | ) | const |
Return the current instance directory for points.
Used in the construction of geometric mesh data dependent on points
Definition at line 847 of file polyMesh.C.
Referenced by isoSurfacePoint::isoSurfacePoint(), fvMesh::makeSf(), averageNeighbourFvGeometryScheme::movePoints(), faMesh::pointsInstance(), polyMesh::readUpdate(), shortestPathSet::shortestPathSet(), shapeOptimisation::updateDesignVariables(), mappedPatchBase::updateMeshTime(), and mappedPatchBase::updateSampleMeshTime().
| const Foam::fileName & facesInstance | ( | ) | const |
Return the current instance directory for faces.
Definition at line 853 of file polyMesh.C.
Referenced by attachPolyTopoChanger::attach(), faMesh::facesInstance(), topoSet::findIOobject(), fvMeshTools::loadOrCreateMesh(), polyMesh::readUpdate(), processorFaMeshes::removeFiles(), processorMeshes::removeFiles(), topoSet::removeFiles(), refinementHistory::removeFiles(), hexRef8::removeFiles(), meshRefinement::removeFiles(), manualRenumber::renumber(), hexRef8Data::updateMesh(), and cellCellStencil::zoneID().
| void setInstance | ( | const fileName & | instance, |
| const IOobjectOption::writeOption | wOpt = IOobject::AUTO_WRITE |
||
| ) |
Set the instance for mesh files.
Definition at line 29 of file polyMeshIO.C.
References DebugInFunction, and Foam::endl().
Referenced by snappyLayerDriver::addLayers(), attachPolyTopoChanger::attach(), polyMesh::readUpdate(), and polyMesh::updateMesh().
|
static |
The mesh region name or word::null if polyMesh::defaultRegion.
Definition at line 816 of file polyMesh.C.
References polyMesh::defaultRegion, and word::null.
Referenced by faMeshTools::loadOrCreateMesh(), and faMeshTools::newMesh().
| const Foam::word & regionName | ( | ) | const |
The mesh region name or word::null if polyMesh::defaultRegion.
Definition at line 841 of file polyMesh.C.
References IOobject::name().
Referenced by fvMeshTools::loadOrCreateMesh(), dynamicFvMesh::New(), fvMeshTools::newMesh(), faMesh::regionName(), and vtkWrite::write().
|
virtual |
Return raw points.
Implements primitiveMesh.
Definition at line 1066 of file polyMesh.C.
References Foam::abort(), Foam::FatalError, and FatalErrorInFunction.
Referenced by polyMeshAdder::add(), sensitivitySurface::addGeometricSens(), snappyLayerDriver::addLayers(), polyTopoChange::addMesh(), tetIndices::barycentricToPoint(), treeDataCell::bounds(), Foam::boundsImpl(), cell::box(), Foam::boxesImpl(), holeToFace::calcClosure(), polyDualMesh::calcFeatures(), meshRefinement::calculateEdgeWeights(), deltaBoundary::cellCenters_d(), polyTopoChange::changeMesh(), layerAdditionRemoval::changeTopology(), polyMeshGeometry::checkEdgeLength(), pointZone::checkParallelSync(), distanceSurface::createGeometry(), volumetricBSplinesMotionSolver::curPoints(), geomCellLooper::cut(), faceCoupleInfo::faceCoupleInfo(), mappedPatchBase::facePoint(), tetIndices::faceTri(), sensitivitySurfacePoints::finalisePointSensitivities(), localPointRegion::findDuplicateFaces(), mappedPatchBase::findLocalSamples(), searchableExtrudedCircle::findParametricNearest(), polyMeshAdder::findSharedPoints(), Foam::getMeshPointRef(), searchableExtrudedCircle::getNormal(), globalIndexAndTransform::globalIndexAndTransform(), leastSquaresEdgeInterpolation< Type >::interpolate(), volPointInterpolation::interpolateDimensionedInternalField(), wallBoundedParticle::isTriAlongTrack(), meshRefinement::makePatch(), polyMeshAdder::mergePoints(), cyclicACMIFvPatch::movePoints(), stabilisedFvGeometryScheme::movePoints(), highAspectRatioFvGeometryScheme::movePoints(), averageNeighbourFvGeometryScheme::movePoints(), faMesh::movePoints(), zoneCellStencils::nonEmptyFacesPatch(), treeDataCell::findIntersectOp::operator()(), tetOverlapVolume::overlappingCells(), cuttingPlane::performCut(), pointHistory::pointHistory(), fvMeshDistribute::printMeshInfo(), boundaryMesh::read(), fvMeshSubset::reset(), laplacianMotionSolver::setBoundaryConditions(), elasticityMotionSolver::setBoundaryConditions(), edgeFaceCirculator::setCanonical(), motionSmootherAlgo::setDisplacement(), boundaryMesh::setFeatureEdges(), fvGeometryScheme::setMeshPhi(), perfectInterface::setRefinement(), meshCutAndRemove::setRefinement(), meshCutter::setRefinement(), shortestPathSet::shortestPathSet(), syncTools::syncEdgeList(), meshRefinement::testSyncPointList(), tetIndices::tet(), blockMesh::topology(), wallBoundedParticle::trackFaceTri(), triSurfaceTools::triangulate(), triSurfaceTools::triangulateFaceCentre(), dynamicMotionSolverListFvMesh::update(), trackingInverseDistance::update(), inverseDistance::update(), shapeOptimisation::updateDesignVariables(), PointIntegrateData< DataType >::updateEdge(), pointEdgePoint::updateEdge(), points0MotionSolver::updateMesh(), componentDisplacementMotionSolver::updateMesh(), pointEdgePoint::updatePoint(), velocityDisplacementMotionSolver::velocityDisplacementMotionSolver(), wallLayerCells::wallLayerCells(), ensightCells::write(), meshToMeshMethod::writeConnectivity(), pointBitSet::writeDebug(), and pointSet::writeDebug().
|
virtual |
Return true if io is up-to-date with points.
Definition at line 1079 of file polyMesh.C.
References io().
Referenced by mappedPatchBase::upToDate().
|
virtual |
Set io to be up-to-date with points.
Definition at line 1085 of file polyMesh.C.
References io().
|
virtual |
Return raw faces.
Implements primitiveMesh.
Definition at line 1091 of file polyMesh.C.
References Foam::abort(), Foam::FatalError, and FatalErrorInFunction.
Referenced by polyMeshAdder::add(), cyclicAMIPolyPatch::addAMIFaces(), sensitivitySurface::addGeometricSens(), polyTopoChange::addMesh(), Foam::boundsImpl(), cell::box(), Foam::boxesImpl(), nearWallFields::calcAddressing(), holeToFace::calcClosure(), polyDualMesh::calcFeatures(), deltaBoundary::cellCenters_d(), layerAdditionRemoval::changeTopology(), polyMeshGeometry::checkEdgeLength(), primitiveMeshGeometry::checkFaceAngles(), polyMeshGeometry::checkFaceAngles(), polyMeshGeometry::checkFaceFlatness(), primitiveMeshGeometry::checkFacePyramids(), polyMeshGeometry::checkFacePyramids(), polyMeshGeometry::checkFaceSkewness(), primitiveMeshGeometry::checkFaceTwist(), polyMeshGeometry::checkFaceTwist(), polyMeshGeometry::checkTriangleTwist(), inversePointDistanceDiffusivity::correct(), wallBoundedParticle::crossDiagonalEdge(), wallBoundedParticle::crossEdgeConnectedFace(), wallBoundedParticle::currentEdge(), decompositionMethod::decompose(), directionInfo::edgeToFaceIndex(), faceCoupleInfo::faceCoupleInfo(), mappedPatchBase::facePoint(), tetIndices::faceTriIs(), sensitivitySurfacePoints::finalisePointSensitivities(), localPointRegion::findDuplicateFaces(), treeDataFace::findNearest(), sampledSet::findNearFace(), dynamicMultiMotionSolverFvMesh::init(), prismMatcher::isA(), tetWedgeMatcher::isA(), wedgeMatcher::isA(), meshRefinement::makePatch(), degenerateMatcher::match(), wedgeMatcher::matches(), prismMatcher::matches(), tetWedgeMatcher::matches(), tetMatcher::matches(), pyrMatcher::matches(), hexMatcher::matches(), polyMeshAdder::mergePoints(), averageNeighbourFvGeometryScheme::movePoints(), zoneCellStencils::nonEmptyFacesPatch(), treeDataCell::findIntersectOp::operator()(), treeDataFace::overlaps(), particle< Type >::procTetPt(), fvMeshSubset::reset(), edgeFaceCirculator::sameOrder(), edgeFaceCirculator::setCanonical(), fvGeometryScheme::setMeshPhi(), lumpedPointMovement::setPatchControl(), perfectInterface::setRefinement(), meshCutAndRemove::setRefinement(), meshCutter::setRefinement(), shortestPathSet::shortestPathSet(), syncTools::syncEdgeMap(), hexMatcher::test(), tetMatcher::test(), pyrMatcher::test(), blockMesh::topology(), tetIndices::triIs(), directionInfo::updateCell(), wallLayerCells::wallLayerCells(), meshToMeshMethod::writeConnectivity(), and lumpedPointMovement::writeZonesVTP().
|
virtual |
Return face owner.
Implements primitiveMesh.
Definition at line 1104 of file polyMesh.C.
Referenced by polyMeshAdder::add(), cyclicAMIPolyPatch::addAMIFaces(), polyTopoChange::addMesh(), polyMeshGeometry::affectedCells(), snappySnapDriver::avgCellCentres(), decompositionMethod::calcCellCells(), polyDualMesh::calcFeatures(), edgeFaceCirculator::cellLabel(), primitiveMeshGeometry::checkFaceDotProduct(), polyMeshGeometry::checkFaceDotProduct(), primitiveMeshGeometry::checkFacePyramids(), polyMeshGeometry::checkFacePyramids(), primitiveMeshGeometry::checkFaceSkewness(), polyMeshGeometry::checkFaceSkewness(), polyMeshGeometry::checkFaceTets(), polyMeshGeometry::checkFaceTwist(), primitiveMeshGeometry::checkFaceWeights(), polyMeshGeometry::checkFaceWeights(), polyMeshGeometry::checkVolRatio(), cellDistFuncs::correctBoundaryFaceCells(), decompositionMethod::decompose(), faMesh::faceCells(), mappedPatchBase::facePoint(), tetIndices::faceTriIs(), sampledSet::getBoundaryCell(), sampledSet::getNeighbourCell(), cellCellStencil::globalCellCells(), cellToCellStencil::insertFaceCells(), cellToFaceStencil::insertFaceCells(), prismMatcher::isA(), tetWedgeMatcher::isA(), wedgeMatcher::isA(), fvMeshAdder::MapSurfaceField(), Foam::markGrowFaceCellFace(), degenerateMatcher::match(), tetWedgeMatcher::matches(), wedgeMatcher::matches(), prismMatcher::matches(), pyrMatcher::matches(), tetMatcher::matches(), hexMatcher::matches(), polyMeshAdder::mergePoints(), edgeFaceCirculator::operator++(), sampledSet::pointInCell(), particle< Type >::procTetPt(), sampledSet::pushIn(), undoableMeshCutter::removeSplitFaces(), SloanRenumber::renumber(), fvMeshSubset::reset(), edgeFaceCirculator::setCanonical(), perfectInterface::setRefinement(), meshCutAndRemove::setRefinement(), meshCutter::setRefinement(), Foam::sumNeighbours(), blockMesh::topology(), and tetIndices::triIs().
|
virtual |
Return face neighbour.
Implements primitiveMesh.
Definition at line 1110 of file polyMesh.C.
Referenced by polyMeshAdder::add(), addPatchCellLayer::addedCells(), polyTopoChange::addMesh(), polyMeshGeometry::affectedCells(), decompositionMethod::calcCellCells(), edgeFaceCirculator::cellLabel(), primitiveMeshGeometry::checkFaceDotProduct(), polyMeshGeometry::checkFaceDotProduct(), primitiveMeshGeometry::checkFacePyramids(), polyMeshGeometry::checkFacePyramids(), primitiveMeshGeometry::checkFaceSkewness(), polyMeshGeometry::checkFaceSkewness(), polyMeshGeometry::checkFaceTets(), polyMeshGeometry::checkFaceTwist(), primitiveMeshGeometry::checkFaceWeights(), polyMeshGeometry::checkFaceWeights(), polyMeshGeometry::checkVolRatio(), decompositionMethod::decompose(), sampledSet::getNeighbourCell(), cellCellStencil::globalCellCells(), cellToCellStencil::insertFaceCells(), cellToFaceStencil::insertFaceCells(), Foam::markGrowFaceCellFace(), polyMeshAdder::mergePoints(), edgeFaceCirculator::operator++(), undoableMeshCutter::removeSplitFaces(), SloanRenumber::renumber(), fvMeshSubset::reset(), edgeFaceCirculator::setCanonical(), perfectInterface::setRefinement(), meshCutAndRemove::setRefinement(), meshCutter::setRefinement(), Foam::sumNeighbours(), and blockMesh::topology().
|
virtual |
Return old points (mesh motion)
Implements primitiveMesh.
Definition at line 1116 of file polyMesh.C.
References Foam::ensightOutput::debug, Foam::endl(), and WarningInFunction.
Referenced by attachPolyTopoChanger::attach(), tetIndices::oldFaceTri(), tetIndices::oldTet(), and fvGeometryScheme::setMeshPhi().
|
virtual |
Return old cellCentres (mesh motion)
Definition at line 1138 of file polyMesh.C.
Referenced by tetIndices::oldTet().
|
inline |
Return boundary mesh.
Definition at line 584 of file polyMesh.H.
Referenced by fvMeshAdder::add(), polyMeshAdder::add(), snappyRefineDriver::addFaceZones(), sensitivitySurface::addGeometricSens(), snappyLayerDriver::addLayers(), polyTopoChange::addMesh(), meshRefinement::addPatch(), cellToCellStencil::allCoupledFacesPatch(), cellToFaceStencil::allCoupledFacesPatch(), meshRefinement::appendPatch(), lumpedPointMovement::areas(), sensitivitySurfacePoints::assembleSensitivities(), assemblyFaceAreaPairGAMGAgglomeration::assemblyFaceAreaPairGAMGAgglomeration(), attachPolyTopoChanger::attach(), patchMeshWriter::beginPiece(), extrudePatchMesh::bottomPatch(), decompositionMethod::calcCellCells(), addPatchCellLayer::calcExtrudeInfo(), polyDualMesh::calcFeatures(), snappySnapDriver::calcNearestSurface(), deltaBoundary::cellCenters_d(), polyTopoChange::changeMesh(), polyMeshGeometry::checkFaceDotProduct(), polyMeshGeometry::checkFaceSkewness(), polyMeshGeometry::checkFaceTets(), polyMeshGeometry::checkFaceTwist(), polyMeshGeometry::checkFaceWeights(), faceZone::checkParallelSync(), polyMeshGeometry::checkVolRatio(), inverseFaceDistanceDiffusivity::correct(), inversePointDistanceDiffusivity::correct(), patchInjection::correct(), cellDistFuncs::correctBoundaryFaceCells(), cellDistFuncs::correctBoundaryPointCells(), Foam::createReconstructMap(), Foam::createZeroBoundaryPointFieldPtr(), curvatureSeparation::curvatureSeparation(), structuredDecomp::decompose(), decompositionMethod::decompose(), directions::directions(), snappyLayerDriver::doLayers(), extrudePatchMesh::extrudePatchMesh(), localPointRegion::findDuplicateFacePairs(), lumpedPointMovement::forcesAndMoments(), syncTools::getInternalOrCoupledFaces(), syncTools::getInternalOrMasterFaces(), syncTools::getMasterFaces(), cellDistFuncs::getPatchIDs(), globalIndexAndTransform::globalIndexAndTransform(), Sampled< Type >::haveSampleField(), isoSurfaceBase::ignoreCyclics(), fvBoundaryMesh::indices(), injectionModelList::info(), transferModelList::info(), singleDirectionUniformBin::initialise(), heatExchangerModel::initialise(), uniformBin::initialise(), objectivePtLosses::initialize(), objectiveUniformityPatch::initialize(), SurfaceFilmModel< Foam::KinematicCloud< Cloud< basicKinematicCollidingParcel > > >::inject(), SurfaceFilmModel< Foam::KinematicCloud< Cloud< basicKinematicCollidingParcel > > >::injectParticles(), PDRblock::innerMesh(), interpolationCellPatchConstrained< Type >::interpolate(), regionModel::interRegionAMI(), fvMeshTools::loadOrCreateMesh(), mappedPatchBase::lookupMesh(), mappedPatchBase::lookupPatch(), polyTopoChange::makeMesh(), meshRefinement::makePatch(), waWallFunctionFvPatchScalarField::manipulateMatrix(), Foam::MapConsistentSubMesh(), mappedPatchFieldBase< scalar >::mappedField(), mapPolyMesh::mapPolyMesh(), cellDistFuncs::maxPatchSize(), polyMeshAdder::mergePoints(), meshReader::mesh(), Cloud< passivePositionParticle >::move(), regionModel::nbrCoupledPatchID(), fvMeshTools::newMesh(), faceShading::nonCoupledPatches(), zoneCellStencils::nonEmptyFacesPatch(), polyMeshAdder::patchFacePairs(), sampledPatch::patchIDs(), boundaryMesh::patchify(), patchInjection::patchInjection(), patchInteractionDataList::patchInteractionDataList(), polyTopoChange::polyTopoChange(), uniformBin::processField(), binModel::read(), boundaryMesh::read(), fvMeshTools::removeEmptyPatches(), SloanRenumber::renumber(), fvMeshTools::reorderPatches(), snappySnapDriver::repatchToSurface(), fvMeshSubset::reset(), fvFieldDecomposer::reset(), sampledCuttingPlane::sampledCuttingPlane(), sampledInterface::sampledInterface(), sampledIsoSurface::sampledIsoSurface(), Sampled< Type >::sampleField(), mappedPatchFieldBase< scalar >::sampleField(), mappedPatchBase::samplePolyPatch(), laplacianMotionSolver::setBoundaryConditions(), elasticityMotionSolver::setBoundaryConditions(), adjointBoundaryCondition< Type >::setBoundaryContributionPtr(), patchInjectionBase::setPositionAndCell(), perfectInterface::setRefinement(), meshCutAndRemove::setRefinement(), thermoSingleLayer::Sh(), shortestPathSet::shortestPathSet(), extrudePatchMesh::sidesPatch(), singleCellFvMesh::singleCellFvMesh(), thermalBaffle::solveEnergy(), thermoSingleLayer::Srho(), Foam::sumNeighbours(), cellDistFuncs::sumPatchSize(), mappedPatchBase::surfPtr(), syncTools::swapBoundaryCellList(), syncTools::syncBoundaryFaceList(), syncTools::syncEdgeMap(), syncTools::syncFaceList(), syncTools::syncPointMap(), blockMesh::topology(), extrudePatchMesh::topPatch(), sampledFaceZone::update(), sampledPatch::update(), patchInjectionBase::updateMesh(), perfectInterface::updateMesh(), attachDetach::updateMesh(), slidingInterface::updateMesh(), mappedPatchBase::updateMeshTime(), thermoSingleLayer::updateSurfaceTemperatures(), kinematicSingleLayer::updateSurfaceVelocities(), mappedPatchBase::upToDate(), liquidFilmBase::Uw(), cellToFaceStencil::validBoundaryFaces(), cellToCellStencil::validBoundaryFaces(), wallLayerCells::wallLayerCells(), fieldExtents::writeFileHeader(), lumpedPointMovement::writeVTP(), and lumpedPointMovement::writeZonesVTP().
|
inline |
Return mesh bounding box.
Definition at line 592 of file polyMesh.H.
Referenced by nearWallFields::calcAddressing(), sensitivitySurface::computeRadius(), isoSurfaceCell::isoSurfaceCell(), isoSurfaceTopo::isoSurfaceTopo(), meshToMeshMethod::maskCells(), streamLineParticle::move(), interRegionOption::setMapper(), and sampledMeshedSurface::update().
| const Foam::Vector< Foam::label > & geometricD | ( | ) | const |
Return the vector of geometric directions in mesh.
Defined according to the presence of empty and wedge patches. 1 indicates unconstrained direction and -1 a constrained direction.
Definition at line 859 of file polyMesh.C.
Referenced by sensitivitySurface::computeRadius().
| Foam::label nGeometricD | ( | ) | const |
Return the number of valid geometric dimensions in the mesh.
Definition at line 870 of file polyMesh.C.
References Foam::cmptSum().
Referenced by sensitivitySurface::computeRadius(), and inverseDistance::update().
| const Foam::Vector< Foam::label > & solutionD | ( | ) | const |
Return the vector of solved-for directions in mesh.
Differs from geometricD in that it includes for wedge cases the circumferential direction in case of swirl. 1 indicates valid direction and -1 an invalid direction.
Definition at line 876 of file polyMesh.C.
Referenced by InjectionModel< CloudType >::inject(), InjectionModel< CloudType >::injectSteadyState(), KinematicSurfaceFilm< CloudType >::splashInteraction(), and fvMesh::validComponents().
| Foam::label nSolutionD | ( | ) | const |
Return the number of valid solved-for dimensions in the mesh.
Definition at line 887 of file polyMesh.C.
References Foam::cmptSum().
Referenced by GradientDispersionRAS< CloudType >::update().
| const Foam::labelIOList & tetBasePtIs | ( | ) | const |
Return the tetBasePtIs.
Definition at line 893 of file polyMesh.C.
References Foam::ensightOutput::debug, Foam::endl(), polyMeshTetDecomposition::findFaceBasePts(), IOobjectOption::NO_WRITE, IOobjectOption::READ_IF_PRESENT, and WarningInFunction.
Referenced by waveMethod::calculate(), wallBoundedParticle::crossEdgeConnectedFace(), wallBoundedParticle::currentEdge(), mappedPatchBase::facePoint(), mappedPatchBase::facePoints(), tetIndices::faceTriIs(), meshRefinement::findCell(), meshRefinement::findRegion(), trackingInverseDistance::markDonors(), inverseDistance::markDonors(), meshSearch::meshSearch(), Foam::readLagrangian(), and tetIndices::triIs().
| const Foam::indexedOctree< Foam::treeDataCell > & cellTree | ( | ) | const |
Return the cell search tree.
Definition at line 927 of file polyMesh.C.
References Foam::constant::electromagnetic::e, boundBox::inflate(), points, and rndGen.
Referenced by waveMethod::calculate(), mappedPatchBase::findLocalSamples(), and tetOverlapVolume::overlappingCells().
|
inlinenoexcept |
Return point zone mesh.
Definition at line 638 of file polyMesh.H.
Referenced by fvMeshAdder::add(), polyMeshAdder::add(), polyTopoChange::addMesh(), polyTopoChange::changeMesh(), fvMeshTools::loadOrCreateMesh(), polyTopoChange::makeMesh(), mapPolyMesh::mapPolyMesh(), blockMesh::mesh(), slidingInterface::modifyMotionPoints(), fvMeshTools::newMesh(), pointZoneSet::pointZoneSet(), polyTopoChange::polyTopoChange(), fvMeshDistribute::printMeshInfo(), and slidingInterface::updateMesh().
|
inlinenoexcept |
Return face zone mesh.
Definition at line 646 of file polyMesh.H.
Referenced by fvMeshAdder::add(), polyMeshAdder::add(), cyclicAMIPolyPatch::addAMIFaces(), surfaceZonesInfo::addFaceZone(), surfaceZonesInfo::addFaceZonesToMesh(), snappyLayerDriver::addLayers(), polyTopoChange::addMesh(), polyTopoChange::changeMesh(), layerAdditionRemoval::changeTopology(), meshRefinement::checkCoupledFaceZones(), extractEulerianParticles::checkFaceZone(), snappyLayerDriver::doLayers(), snappySnapDriver::doSnap(), faceZoneSet::faceZoneSet(), heatExchangerModel::initialise(), fvMeshTools::loadOrCreateMesh(), polyTopoChange::makeMesh(), mapPolyMesh::mapPolyMesh(), polyMeshAdder::mergePoints(), blockMesh::mesh(), slidingInterface::modifyMotionPoints(), fvMeshTools::newMesh(), polyTopoChange::polyTopoChange(), fvMeshDistribute::printMeshInfo(), snappySnapDriver::repatchToSurface(), perfectInterface::setRefinement(), meshRefinement::subsetBaffles(), sampledFaceZone::update(), perfectInterface::updateMesh(), attachDetach::updateMesh(), slidingInterface::updateMesh(), and sampledFaceZone::zoneIDs().
|
inlinenoexcept |
Return cell zone mesh.
Definition at line 654 of file polyMesh.H.
Referenced by fvMeshAdder::add(), polyMeshAdder::add(), surfaceZonesInfo::addCellZone(), cellTable::addCellZones(), surfaceZonesInfo::addCellZonesToMesh(), objectiveUniformityCellZone::addHeaderColumns(), polyTopoChange::addMesh(), DarcyForchheimer::calcTransformModelData(), cellZoneSet::cellZoneSet(), polyTopoChange::changeMesh(), multiphaseMangrovesSource::dragCoeff(), dynamicMultiMotionSolverFvMesh::init(), singleDirectionUniformBin::initialise(), uniformBin::initialise(), objectivePowerDissipation::J(), objectiveNutSqr::J(), objectiveUniformityCellZone::J(), fvMeshTools::loadOrCreateMesh(), polyTopoChange::makeMesh(), mapPolyMesh::mapPolyMesh(), blockMesh::mesh(), fvMeshTools::newMesh(), cellTable::operator=(), polyTopoChange::polyTopoChange(), fvMeshDistribute::printMeshInfo(), uniformBin::processField(), multiphaseMangrovesTurbulenceModel::read(), binModel::read(), sampledCuttingPlane::sampledCuttingPlane(), sampledInterface::sampledInterface(), sampledIsoSurface::sampledIsoSurface(), sampledPlane::sampledPlane(), sizeDistribution::setCellZoneCells(), displacementLayeredMotionMotionSolver::solve(), objectivePowerDissipation::update_divDxDbMultiplier(), objectiveUniformityCellZone::update_divDxDbMultiplier(), objectiveNutSqr::update_divDxDbMultiplier(), objectivePowerDissipation::update_dJdv(), objectiveNutSqr::update_dJdv(), objectiveUniformityCellZone::update_dJdv(), objectivePowerDissipation::update_gradDxDbMultiplier(), and zeroATCcells::zeroATCcells().
| const Foam::globalMeshData & globalData | ( | ) | const |
Return parallel info.
Definition at line 1293 of file polyMesh.C.
References Foam::ensightOutput::debug, Foam::endl(), and Foam::Pout.
Referenced by addPatchCellLayer::calcExtrudeInfo(), faBoundaryMesh::calcGeometry(), waveMethod::calculate(), structuredDecomp::decompose(), decompositionMethod::decompose(), polyMeshAdder::findSharedPoints(), faMeshTools::forceDemandDriven(), syncTools::getMasterEdges(), globalIndexAndTransform::globalIndexAndTransform(), injectionModelList::info(), transferModelList::info(), faMeshTools::loadOrCreateMesh(), fvMeshTools::loadOrCreateMesh(), pointBoundaryMesh::movePoints(), faBoundaryMesh::movePoints(), polyBoundaryMesh::movePoints(), faMeshTools::newMesh(), patchInjection::patchInjection(), zoltanRenumber::renumber(), motionSmootherAlgo::setDisplacement(), syncTools::syncEdgeList(), syncTools::syncEdgeMap(), syncTools::syncPointList(), syncTools::syncPointMap(), pointBoundaryMesh::updateMesh(), faBoundaryMesh::updateMesh(), and polyBoundaryMesh::updateMesh().
|
noexcept |
Return communicator used for parallel communication.
Definition at line 1311 of file polyMesh.C.
Referenced by processorPolyPatch::comm(), and fvMesh::comm().
|
noexcept |
Return communicator used for parallel communication.
Definition at line 1317 of file polyMesh.C.
|
inlinenoexcept |
Return the object registry.
Definition at line 677 of file polyMesh.H.
Referenced by fvMesh::thisDb().
|
inlinevirtual |
Is mesh dynamic.
Reimplemented in dynamicFvMesh, engineMesh, and staticFvMesh.
Definition at line 688 of file polyMesh.H.
|
inlinenoexcept |
Is mesh moving.
Definition at line 696 of file polyMesh.H.
Referenced by snappyLayerDriver::addLayers(), backwardDdtScheme< Type >::backwardDdtScheme(), polyMesh::changing(), CrankNicolsonDdtScheme< Type >::CrankNicolsonDdtScheme(), faMesh::moving(), fvGeometryScheme::setMeshPhi(), reactingOneDim::solveSpeciesMass(), and movingWallVelocityFvPatchVectorField::updateCoeffs().
|
inlinenoexcept |
Set the mesh to be moving.
Definition at line 704 of file polyMesh.H.
|
inlinenoexcept |
Is mesh topology changing.
Definition at line 714 of file polyMesh.H.
Referenced by polyTopoChange::changeMesh(), polyMesh::changing(), and isoAlpha::reconstruct().
|
inlinenoexcept |
Set the mesh topology to be changing.
Definition at line 722 of file polyMesh.H.
|
inlinenoexcept |
Is mesh changing (topology changing and/or moving)
Definition at line 732 of file polyMesh.H.
References polyMesh::moving(), and polyMesh::topoChanging().
Referenced by adjointRASModel::correct(), omegaWallFunctionFvPatchScalarField::createAveragingWeights(), epsilonWallFunctionFvPatchScalarField::createAveragingWeights(), and pyrolysisModelCollection::evolve().
|
virtual |
Move points.
Reimplemented in fvMesh.
Definition at line 1156 of file polyMesh.C.
References IOobjectOption::AUTO_WRITE, Foam::ensightOutput::debug, DebugInFunction, Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::Info, InfoInFunction, primitiveMesh::movePoints(), Foam::nl, UList< T >::size(), timeIndex, regIOobject::write(), and Foam::Zero.
Referenced by attachPolyTopoChanger::attach(), and fvMesh::movePoints().
| void resetMotion | ( | ) | const |
Reset motion.
Definition at line 1285 of file polyMesh.C.
|
inlinenoexcept |
Return non-const access to the pointZones.
Definition at line 753 of file polyMesh.H.
|
inlinenoexcept |
Return non-const access to the faceZones.
Definition at line 761 of file polyMesh.H.
|
inlinenoexcept |
Return non-const access to the cellZones.
Definition at line 769 of file polyMesh.H.
| void addPatches | ( | polyPatchList & | plist, |
| const bool | validBoundary = true |
||
| ) |
Add boundary patches.
Definition at line 959 of file polyMesh.C.
References Foam::abort(), Foam::FatalError, FatalErrorInFunction, and Foam::Zero.
Referenced by polyMeshAdder::add(), attachPolyTopoChanger::attach(), PDRblock::innerMesh(), meshReader::mesh(), and blockMesh::topology().
Add mesh zones.
Definition at line 997 of file polyMesh.C.
References Foam::abort(), IOobjectOption::AUTO_WRITE, Foam::FatalError, and FatalErrorInFunction.
Referenced by fvMeshTools::loadOrCreateMesh(), blockMesh::mesh(), and fvMeshTools::newMesh().
| void addZones | ( | const List< pointZone *> & | pz, |
| const List< faceZone *> & | fz, | ||
| const List< cellZone *> & | cz | ||
| ) |
Add mesh zones.
Definition at line 1050 of file polyMesh.C.
|
virtual |
Initialise all non-demand-driven data.
Reimplemented from primitiveMesh.
Reimplemented in interfaceTrackingFvMesh, fvMesh, dynamicRefineFvMesh, dynamicFvMesh, movingConeTopoFvMesh, dynamicMotionSolverFvMeshAMI, dynamicMotionSolverFvMesh, dynamicMotionSolverTopoFvMesh, dynamicMultiMotionSolverFvMesh, and dynamicMotionSolverListFvMesh.
Definition at line 358 of file polyMesh.C.
References primitiveMesh::init().
Referenced by fvMesh::init(), and polyMesh::polyMesh().
|
virtual |
Update the mesh based on the mesh files saved in.
time directories
Reimplemented in fvMesh.
Definition at line 68 of file polyMeshIO.C.
References primitiveMesh::cells(), PtrList< T >::clear(), polyMesh::clearOut(), IOobject::clone(), Foam::ensightOutput::debug, DebugInFunction, Foam::endl(), polyMesh::facesInstance(), forAll, IOobject::hasHeaderClass(), Foam::Info, IOobject::instance(), polyMesh::meshDir(), polyMesh::meshSubDir, IOobjectOption::MUST_READ, IOobject::name(), polyBoundaryMesh::names(), Foam::nl, IOobjectOption::NO_WRITE, polyMesh::POINTS_MOVED, polyMesh::pointsInstance(), IOobjectOption::READ_IF_PRESENT, PtrList< T >::set(), polyMesh::setInstance(), PtrList< T >::setSize(), UPtrList< T >::size(), HashTable< regIOobject *>::size(), objectRegistry::time(), polyMesh::TOPO_CHANGE, polyMesh::TOPO_PATCH_CHANGE, polyBoundaryMesh::types(), polyMesh::UNCHANGED, polyMesh::updateGeomPoints(), polyBoundaryMesh::updateMesh(), WarningInFunction, and Foam::Zero.
Referenced by fvMesh::readUpdate().
|
virtual |
Update the mesh corresponding to given map.
Reimplemented in fvMesh.
Definition at line 36 of file polyMeshUpdate.C.
References primitiveMesh::cellCentres(), mapPolyMesh::cellMap(), ZoneMesh< ZoneType, MeshType >::clearAddressing(), DebugInFunction, Foam::endl(), forAll, mapPolyMesh::hasMotionPoints(), Field< Type >::map(), newPointi, mapPolyMesh::pointMap(), List< T >::resize(), mapPolyMesh::reversePointMap(), polyMesh::setInstance(), UList< T >::size(), HashTable< regIOobject *>::size(), objectRegistry::time(), timeName, polyBoundaryMesh::updateMesh(), and Foam::Zero.
Referenced by fvMesh::updateMesh().
| void removeBoundary | ( | ) |
Remove boundary patches.
Definition at line 32 of file polyMeshClear.C.
References PtrList< T >::clear(), polyMesh::clearOut(), DebugInFunction, Foam::endl(), and PtrList< T >::setSize().
Referenced by attachPolyTopoChanger::attach(), and fvMesh::removeFvBoundary().
| void resetPrimitives | ( | autoPtr< pointField > && | points, |
| autoPtr< faceList > && | faces, | ||
| autoPtr< labelList > && | owner, | ||
| autoPtr< labelList > && | neighbour, | ||
| const labelUList & | patchSizes, | ||
| const labelUList & | patchStarts, | ||
| const bool | validBoundary = true |
||
| ) |
Reset mesh primitive data. Assumes all patch info correct.
(so does e.g. parallel communication). If not use validBoundary=false
Definition at line 709 of file polyMesh.C.
References Foam::abort(), Foam::endl(), Foam::FatalError, FatalErrorInFunction, forAll, Foam::max(), Foam::min(), nPoints, points, Foam::returnReduceAnd(), UList< T >::size(), and timeName.
Referenced by polyTopoChange::changeMesh().
| void clearGeom | ( | ) |
Clear geometry.
Definition at line 46 of file polyMeshClear.C.
References primitiveMesh::clearGeom(), DebugInFunction, Foam::endl(), and Foam::Zero.
| void updateGeomPoints | ( | pointIOField && | newPoints, |
| autoPtr< labelIOList > & | newTetBasePtIsPtr | ||
| ) |
Update geometry points; keep topology. Optionally with new face decomposition.
Definition at line 68 of file polyMeshClear.C.
References primitiveMesh::clearGeom(), meshObject::clearUpto(), DebugInFunction, Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, and Foam::Zero.
Referenced by polyMesh::readUpdate().
| void clearAddressing | ( | const bool | isMeshUpdate = false | ) |
Clear addressing.
Definition at line 145 of file polyMeshClear.C.
References primitiveMesh::clearAddressing(), meshObject::clearUpto(), DebugInFunction, Foam::endl(), and Foam::Zero.
| void clearOut | ( | ) |
Clear all geometry and addressing unnecessary for CFD.
Definition at line 215 of file polyMeshClear.C.
Referenced by fvMesh::clearOut(), polyMesh::readUpdate(), and polyMesh::removeBoundary().
| void clearPrimitives | ( | ) |
Clear primitive data (points, faces and cells)
Definition at line 202 of file polyMeshClear.C.
| void clearTetBasePtIs | ( | ) |
Clear tet base points.
Definition at line 222 of file polyMeshClear.C.
References DebugInFunction, and Foam::endl().
| void clearCellTree | ( | ) |
Clear cell tree data.
Definition at line 230 of file polyMeshClear.C.
References DebugInFunction, and Foam::endl().
| void removeFiles | ( | const fileName & | instanceDir | ) | const |
Remove all files from mesh instance.
Definition at line 1323 of file polyMesh.C.
References Foam::isDir(), fileName::path(), Foam::rm(), and Foam::rmDir().
Referenced by meshReader::writeMesh().
| void removeFiles | ( | ) | const |
Remove all files from mesh instance()
Definition at line 1347 of file polyMesh.C.
|
inline |
Definition at line 909 of file polyMesh.H.
|
virtual |
Check non-orthogonality.
Reimplemented from primitiveMesh.
Definition at line 634 of file polyMeshCheck.C.
|
virtual |
Check face skewness.
Reimplemented from primitiveMesh.
Definition at line 651 of file polyMeshCheck.C.
References points.
|
virtual |
Check edge alignment for 1D/2D cases.
Definition at line 670 of file polyMeshCheck.C.
References points.
|
virtual |
Definition at line 687 of file polyMeshCheck.C.
|
virtual |
Check mesh motion for correctness given motion points.
Definition at line 733 of file polyMeshCheck.C.
References cellVols, Foam::ensightOutput::debug, Foam::endl(), primitiveMeshTools::makeCellCentresAndVols(), primitiveMeshTools::makeFaceCentresAndAreas(), and Foam::Pout.
|
virtual |
Check for face weights.
Definition at line 703 of file polyMeshCheck.C.
|
virtual |
Check for neighbouring cell volumes.
Definition at line 722 of file polyMeshCheck.C.
| void findCellFacePt | ( | const point & | p, |
| label & | celli, | ||
| label & | tetFacei, | ||
| label & | tetPti | ||
| ) | const |
Find the cell, tetFacei and tetPti for point p.
Definition at line 1354 of file polyMesh.C.
Referenced by patchInjectionBase::setPositionAndCell().
| void findTetFacePt | ( | const label | celli, |
| const point & | p, | ||
| label & | tetFacei, | ||
| label & | tetPti | ||
| ) | const |
Find the tetFacei and tetPti for point p in celli.
tetFacei and tetPtI are set to -1 if not found
Definition at line 1379 of file polyMesh.C.
References tetIndices::face(), polyMeshTetDecomposition::findTet(), mesh, p, and tetIndices::tetPt().
Referenced by nearWallFields::calcAddressing(), sampledSet::pushIn(), and patchInjectionBase::setPositionAndCell().
| bool pointInCell | ( | const point & | p, |
| label | celli, | ||
| const cellDecomposition | decompMode = CELL_TETS |
||
| ) | const |
Test if point p is in the celli.
Definition at line 1395 of file polyMesh.C.
References triangle< Point, PointRef >::areaNormal(), cells, triangle< Point, PointRef >::centre(), f(), tetIndices::faceTri(), forAll, p, primitiveMesh::pointInCell(), points, and UList< T >::size().
Referenced by sampledSet::getTrackingPoint(), and sampledSet::pointInCell().
| Foam::label findCell | ( | const point & | p, |
| const cellDecomposition | decompMode = CELL_TETS |
||
| ) | const |
Find cell enclosing this location and return index.
If not found -1 is returned
Definition at line 1505 of file polyMesh.C.
References p, and UPstream::parRun().
Referenced by waveMethod::calculate(), meshRefinement::findCell(), probes::findElements(), meshRefinement::findRegion(), sampledSet::getTrackingPoint(), trackingInverseDistance::markDonors(), and inverseDistance::markDonors().
|
static |
Return the default region name.
Definition at line 397 of file polyMesh.H.
Referenced by regIOobject::checkIn(), externalCoupled::compositeName(), polyBoundaryMesh::findPatchID(), FIREMeshReader::mesh(), meshReader::mesh(), reader::mesh(), dynamicFvMesh::New(), polyMesh::regionName(), and setRegistry().
|
static |
Return the mesh sub-directory name (usually "polyMesh")
Definition at line 402 of file polyMesh.H.
Referenced by refinementHistory::add(), refinementHistory::apply(), componentDisplacementMotionSolver::componentDisplacementMotionSolver(), faMeshDecomposition::decomposeMesh(), faMeshReconstructor::faMeshReconstructor(), topoSet::findIOobject(), isoSurfacePoint::isoSurfacePoint(), fvMeshTools::loadOrCreateMesh(), solidBodyMotionDisplacementPointPatchVectorField::localPoints0(), fvMesh::makeSf(), fvMeshTools::newMesh(), points0MotionSolver::points0IO(), points0MotionSolver::points0MotionSolver(), polyMesh::polyMesh(), polyMesh::readUpdate(), processorMeshes::reconstructPoints(), processorMeshes::removeFiles(), topoSet::removeFiles(), refinementHistory::removeFiles(), hexRef8::removeFiles(), meshRefinement::removeFiles(), shapeOptimisation::updateDesignVariables(), faMeshDecomposition::writeDecomposition(), and cellCellStencil::zoneID().
Copyright © 2011-2018 OpenFOAM | OPENFOAM® is a registered trademark of OpenCFD Ltd.
Generated by
1.8.14
