An edge is a list of two point labels. The functionality it provides supports the discretisation on a 2-D flat mesh. More...

Inheritance diagram for edge:

[legend]

Collaboration diagram for edge:

[legend]

Classes
struct	Hash
	Deprecated(2021-04) hashing functor. Use hasher() More...

struct	hasher
	Hashing functor for edge (commutative) More...

Public Member Functions
	edge ()
	Default construct, with invalid point labels (-1) More...

	edge (const label from, const label to)
	Construct from two point labels. More...

	edge (const labelPair &pair)
	Construct from pair of point labels. More...

	edge (const FixedList< label, 2 > &list)
	Construct from list of point labels. More...

	edge (const label from, const label to, const bool doSort)
	Construct from two point labels, sorted with first less-than second. More...

	edge (const FixedList< label, 2 > &list, const bool doSort)
	Construct from list, sorted with first less-than second. More...

	edge (const UList< label > &list, const FixedList< label, 2 > &indices)
	Copy construct from a subset of point labels. More...

	edge (Istream &is)
	Construct from Istream. More...

label	a () const noexcept
	The first vertex. More...

label	b () const noexcept
	The second vertex. More...

label &	a () noexcept
	The first vertex. More...

label &	b () noexcept
	The second vertex. More...

label	start () const noexcept
	The start (first) vertex label. More...

label	end () const noexcept
	The end (last/second) vertex label. More...

label &	start () noexcept
	The start (first) vertex label. More...

label &	end () noexcept
	The end (second/last) vertex label. More...

edge	reverseEdge () const
	Return reverse edge as copy. More...

label	minVertex () const
	Return the smallest point label used by the edge. More...

label	maxVertex () const
	Return the largest point label used by the edge. More...

bool	good () const noexcept
	True if the vertices are unique and non-negative. More...

bool	valid () const noexcept
	True if the vertices are unique and non-negative. More...

bool	found (const label pointLabel) const
	Return true if point label is found in edge. More...

label	which (const label pointLabel) const
	Return local index (0,1) of point label in edge -1 on failure. More...

bool	connected (const edge &other) const
	True if the edge has at least one vertex in common with other. More...

label	commonVertex (const edge &other) const
	Return vertex common with other edge or -1 on failure. More...

label	otherVertex (const label pointLabel) const
	Given the point label for one vertex, return the other one. More...

bool	connects (const edge &other) const
	Do the edges share a common vertex index? More...

label	collapse ()
	'Collapse' edge by marking duplicate point labels as '-1', the lower vertex is retained. More...

label	count () const
	Return the number of unique, valid (non -1) point labels. More...

bool	empty () const
	Return true if edge has no valid point labels. More...

void	clear ()
	'Clears' edge by setting both ends to invalid point labels. More...

bool	insert (const label index)
	Fill any open slot with the index if it did not previously exist. More...

template<class InputIterator >
label	insert (InputIterator begIter, InputIterator endIter)
	Insert values, using begin/end iterators. More...

label	insert (std::initializer_list< label > list)
	Fill open slots with the indices if they did not previously exist. More...

template<unsigned N>
label	insert (const FixedList< label, N > &list)
	Fill open slots with the indices if they did not previously exist. More...

label	insert (const labelUList &list)
	Fill open slots with the indices if they did not previously exist. More...

label	erase (const label index)
	Remove an existing index from the edge and set its location to '-1'. More...

template<class InputIterator >
label	erase (InputIterator begIter, InputIterator endIter)
	Remove values, using begin/end iterators. More...

label	erase (std::initializer_list< label > list)
	Remove existing indices from the edge and set locations to '-1'. More...

template<unsigned N>
label	erase (const FixedList< label, N > &list)
	Remove existing indices from the edge and set locations to '-1'. More...

label	erase (const labelUList &list)
	Remove existing indices from the edge and set locations to '-1'. More...

point	centre (const UList< point > &pts) const
	Return centre point (centroid) of the edge. More...

vector	vec (const UList< point > &pts) const
	Return the vector (end - start) More...

vector	unitVec (const UList< point > &pts) const
	Return the unit vector (end - start) More...

scalar	mag (const UList< point > &pts) const
	Return scalar magnitude of the edge. More...

Pair< point >	box (const UList< point > &pts) const
	The enclosing (bounding) box for the edge. More...

linePointRef	line (const UList< point > &pts) const
	Return edge line. More...

label &	operator[] (const label i)
	Return edge element. Index should be limited to 0/1. More...

const label &	operator[] (const label i) const
	Return constant edge element. Index should be limited to 0/1. More...

unsigned	hash_code (unsigned seed=0) const
	The (commutative) hash value for edge, hashes lower value first. More...

template<class InputIterator>
Foam::label	insert (InputIterator begIter, InputIterator endIter)

template<unsigned N>
Foam::label	insert (const FixedList< label, N > &list)

template<class InputIterator>
Foam::label	erase (InputIterator begIter, InputIterator endIter)

template<unsigned N>
Foam::label	erase (const FixedList< label, N > &list)

Public Member Functions inherited from Pair< label >
	Pair ()=default
	Default construct. More...

	Pair (const label &f, const label &s)
	Copy construct from components. More...

	Pair (label &&f, label &&s)
	Move construct from components. More...

	Pair (const std::pair< label, label > &vals)
	Copy construct from std::pair. More...

	Pair (std::pair< label, label > &&vals)
	Move construct from std::pair. More...

	Pair (const FixedList< label, 2 > &list)
	Copy construct FixedList of two items. More...

	Pair (const label &f, const label &s, const bool doSort)
	Copy construct, optionally sorted with first less-than second. More...

	Pair (const FixedList< label, 2 > &list, const bool doSort)
	Copy construct, optionally sorted with first less-than second. More...

	Pair (Istream &is)
	Construct from Istream. More...

void	front ()=delete
	The front() accessor (from FixedList) has no purpose. More...

void	back ()=delete
	The back() accessor (from FixedList) has no purpose. More...

const label &	first () const noexcept
	Access the first element. More...

label &	first () noexcept
	Access the first element. More...

const label &	second () const noexcept
	Access the second element. More...

label &	second () noexcept
	Access the second element. More...

const label &	other (const label &a) const
	Return other element. More...

bool	sorted () const
	True if first() is less-than second() More...

void	flip ()
	Flip the Pair in-place. More...

void	sort ()
	Sort so that first() is less-than second() More...

Public Member Functions inherited from FixedList< label, 2 >
void	writeEntry (const word &keyword, Ostream &os) const
	Write the list as a dictionary entry with keyword. More...

	FixedList ()=default
	Default construct. More...

	FixedList (const label &val)
	Construct and initialize all entries to given value. More...

	FixedList (const Foam::zero)
	Construct and initialize all entries to zero. More...

	FixedList (const label list[N])
	Copy construct from C-array (deprecated) More...

	FixedList (const FixedList< label, N > &list)
	Copy construct. More...

	FixedList (FixedList< label, N > &&list)
	Move construct by using move assignment for the individual list elements. More...

	FixedList (std::initializer_list< label > list)
	Construct from an initializer list. Runtime size check. More...

	FixedList (const UList< label > &list)
	Construct from UList. Runtime size check. More...

	FixedList (const FixedList< label, AnyNum > &list, const FixedList< label, N > &indices)
	Copy construct from a subset of the input. No size check. More...

	FixedList (const UList< label > &list, const FixedList< label, N > &indices)
	Copy construct from a subset of the input. No size check. More...

	FixedList (const SLList< label > &list)
	Construct from SLList. Runtime size check. More...

	FixedList (Istream &is)
	Construct from Istream. More...

autoPtr< FixedList< label, N > >	clone () const
	Clone. More...

const label *	cdata () const noexcept
	Return pointer to the underlying array serving as data storage. More...

label *	data () noexcept
	Return pointer to the underlying array serving as data storage. More...

const char *	cdata_bytes () const noexcept
	Return pointer to the underlying array serving as data storage,. More...

char *	data_bytes () noexcept
	Return pointer to the underlying array serving as data storage,. More...

label &	get () noexcept
	Element access using compile-time indexing. More...

const label &	get () const noexcept
	Element access using compile-time indexing. More...

label &	front () noexcept
	Access first element of the list, position [0]. More...

const label &	front () const noexcept
	Access first element of the list, position [0]. More...

label &	back () noexcept
	Access last element of the list, position [N-1]. More...

const label &	back () const noexcept
	Access last element of the list, position [N-1]. More...

label	fcIndex (const label i) const
	Return the forward circular index, i.e. next index which returns to the first at the end of the list. More...

const label &	fcValue (const label i) const
	Return forward circular value (ie, next value in the list) More...

label &	fcValue (const label i)
	Return forward circular value (ie, next value in the list) More...

label	rcIndex (const label i) const
	Return the reverse circular index, i.e. previous index which returns to the last at the beginning of the list. More...

const label &	rcValue (const label i) const
	Return reverse circular value (ie, previous value in the list) More...

label &	rcValue (const label i)
	Return reverse circular value (ie, previous value in the list) More...

void	checkStart (const label start) const
	Check start is within valid range [0,size) More...

void	checkSize (const label size) const
	Check size is identical to template parameter N. More...

void	checkIndex (const label i) const
	Check index is within valid range [0,N) More...

bool	uniform () const
	True if all entries have identical values, and list is non-empty. More...

label	find (const label &val, label pos=0) const
	Find index of the first occurrence of the value. More...

label	rfind (const label &val, label pos=-1) const
	Find index of the last occurrence of the value. More...

bool	found (const label &val, label pos=0) const
	True if the value if found in the list. More...

void	resize (const label n)
	Dummy function, to make FixedList consistent with List. More...

void	resize_nocopy (const label n)
	Dummy function, to make FixedList consistent with List. More...

void	setSize (const label n)
	Dummy function, to make FixedList consistent with List. More...

void	fill (const label &val)
	Assign all entries to the given value. More...

void	fill (const Foam::zero)
	Assign all entries to zero. More...

void	moveFirst (const label i)
	Move element to the first position. More...

void	moveLast (const label i)
	Move element to the last position. More...

void	swapFirst (const label i)
	Swap element with the first element. More...

void	swapLast (const label i)
	Swap element with the last element. More...

void	transfer (FixedList< label, N > &list)
	Transfer by swapping using a move assignment for the content of the individual list elements. More...

label &	operator[] (const label i)
	Return element of FixedList. More...

const label &	operator[] (const label i) const
	Return element of constant FixedList. More...

void	operator= (const label list[N])
	Assignment to array operator. Takes linear time. More...

void	operator= (const UList< label > &list)
	Assignment to UList operator. Takes linear time. More...

void	operator= (const SLList< label > &list)
	Assignment to SLList operator. Takes linear time. More...

void	operator= (std::initializer_list< label > list)
	Assignment to an initializer list. Takes linear time. More...

void	operator= (const label &val)
	Assign all entries to the given value. fill() More...

void	operator= (const Foam::zero)
	Assign all entries to zero. fill() More...

void	operator= (const FixedList< label, N > &list)
	Copy assignment. More...

void	operator= (FixedList< label, N > &&list)
	Move assignment. More...

iterator	begin () noexcept
	Return an iterator to begin traversing the FixedList. More...

const_iterator	begin () const noexcept
	Return const_iterator to begin traversing the constant FixedList. More...

iterator	end () noexcept
	Return an iterator to end traversing the FixedList. More...

const_iterator	end () const noexcept
	Return const_iterator to end traversing the constant FixedList. More...

const_iterator	cbegin () const noexcept
	Return const_iterator to begin traversing the constant FixedList. More...

const_iterator	cend () const noexcept
	Return const_iterator to end traversing the constant FixedList. More...

reverse_iterator	rbegin ()
	Return reverse_iterator to begin reverse traversing the FixedList. More...

const_reverse_iterator	rbegin () const
	Return const_reverse_iterator to begin reverse traversing FixedList. More...

reverse_iterator	rend ()
	Return reverse_iterator to end reverse traversing the FixedList. More...

const_reverse_iterator	rend () const
	Return const_reverse_iterator to end reverse traversing FixedList. More...

const_reverse_iterator	crbegin () const
	Return const_reverse_iterator to begin reverse traversing FixedList. More...

const_reverse_iterator	crend () const
	Return const_reverse_iterator to end reverse traversing FixedList. More...

void	swap (FixedList< label, N > &other)
	Swap lists by swapping the content of the individual list elements. More...

bool	operator== (const FixedList< label, N > &list) const
	Equality operation on FixedLists of the same type. More...

bool	operator!= (const FixedList< label, N > &list) const
	The opposite of the equality operation. Takes linear time. More...

bool	operator< (const FixedList< label, N > &list) const
	Compare two FixedLists lexicographically. Takes linear time. More...

bool	operator> (const FixedList< label, N > &list) const
	Compare two FixedLists lexicographically. Takes linear time. More...

bool	operator<= (const FixedList< label, N > &list) const
	Return true if !(a > b). Takes linear time. More...

bool	operator>= (const FixedList< label, N > &list) const
	Return true if !(a < b). Takes linear time. More...

Istream &	readList (Istream &is)
	Read from Istream, discarding contents of existing List. More...

Ostream &	writeList (Ostream &os, const label shortLen=0) const
	Write List, with line-breaks in ASCII when length exceeds shortLen. More...

label &	first () noexcept
	Access first element of the list, position [0] - front() More...

const label &	first () const noexcept
	Access first element of the list, position [0] - front() More...

label &	last () noexcept
	Access last element of the list, position [N-1] - back() More...

const label &	last () const noexcept
	Access last element of the list, position [N-1] - back() More...

Static Public Member Functions
static int	compare (const edge &a, const edge &b)
	Compare edges. More...

Static Public Member Functions inherited from Pair< label >
static int	compare (const Pair< label > &a, const Pair< label > &b)
	Compare Pairs. More...

Static Public Member Functions inherited from FixedList< label, 2 >
static const FixedList< label, N > &	null ()
	Return a null FixedList. More...

static std::streamsize	size_bytes () noexcept
	Number of contiguous bytes for the list data,. More...

static std::streamsize	byteSize ()
	Number of contiguous bytes for the list data, runtime FatalError if type is not contiguous. More...

static constexpr bool	empty () noexcept
	Always false since zero-sized FixedList is compile-time disabled. More...

static constexpr label	size () noexcept
	Return the number of elements in the FixedList. More...

static constexpr unsigned	max_size () noexcept
	The dimensioned size (template parameter N) of the FixedList. More...

Static Public Attributes
static const char *const	typeName = "edge"

Additional Inherited Members
Public Types inherited from FixedList< label, 2 >
typedef label	value_type
	The value type the FixedList contains. More...

typedef label *	pointer
	The pointer type for non-const access to value_type items. More...

typedef const label *	const_pointer
	The pointer type for const access to value_type items. More...

typedef label &	reference
	The type used for storing into value_type objects. More...

typedef const label &	const_reference
	The type used for reading from constant value_type objects. More...

typedef label *	iterator
	Random access iterator for traversing FixedList. More...

typedef const label *	const_iterator
	Random access iterator for traversing FixedList. More...

typedef label	size_type
	The type to represent the size of a FixedList. More...

typedef label	difference_type
	The difference between iterator objects. More...

typedef std::reverse_iterator< iterator >	reverse_iterator
	Reverse iterator (non-const access) More...

typedef std::reverse_iterator< const_iterator >	const_reverse_iterator
	Reverse iterator (const access) More...

Protected Member Functions inherited from FixedList< label, 2 >
void	writeEntry (Ostream &os) const
	Write the FixedList with its compound type. More...

Detailed Description

An edge is a list of two point labels. The functionality it provides supports the discretisation on a 2-D flat mesh.

The edge is implemented as a Pair/FixedList of labels. As well as geometrically relevant methods, it also provides methods similar to HashSet for additional convenience. Valid point labels are always non-negative (since they correspond to addressing within the mesh). The value '-1' is used to tag invalid point labels that correspond conceptually to open 'slots', which can be filled with a HashSet-like functionality.

Source files

Definition at line 59 of file edge.H.

Constructor & Destructor Documentation

◆ edge() [1/8]

edge ( )

inline

Default construct, with invalid point labels (-1)

Definition at line 34 of file edgeI.H.

Referenced by cellShape::edge().

Here is the caller graph for this function:

◆ edge() [2/8]

edge	(	const label	from,
		const label	to
	)

inline

Construct from two point labels.

Definition at line 40 of file edgeI.H.

◆ edge() [3/8]

edge ( const labelPair & pair )

inline

Construct from pair of point labels.

Definition at line 46 of file edgeI.H.

◆ edge() [4/8]

edge ( const FixedList< label, 2 > & list )

inline

Construct from list of point labels.

Definition at line 52 of file edgeI.H.

◆ edge() [5/8]

edge	(	const label	from,
		const label	to,
		const bool	doSort
	)

inline

Construct from two point labels, sorted with first less-than second.

Definition at line 58 of file edgeI.H.

◆ edge() [6/8]

edge	(	const FixedList< label, 2 > &	list,
		const bool	doSort
	)

inline

Construct from list, sorted with first less-than second.

Definition at line 64 of file edgeI.H.

◆ edge() [7/8]

edge	(	const UList< label > &	list,
		const FixedList< label, 2 > &	indices
	)

inline

Copy construct from a subset of point labels.

Definition at line 71 of file edgeI.H.

◆ edge() [8/8]

edge ( Istream & is )

inline

Construct from Istream.

Definition at line 80 of file edgeI.H.

Member Function Documentation

◆ a() [1/2]

label a ( ) const

inlinenoexcept

The first vertex.

Definition at line 124 of file edge.H.

References Pair< label >::first().

Referenced by edge::compare().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ b() [1/2]

label b ( ) const

inlinenoexcept

The second vertex.

Definition at line 129 of file edge.H.

References Pair< label >::second().

Referenced by edge::compare().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ a() [2/2]

label& a ( )

inlinenoexcept

The first vertex.

Definition at line 134 of file edge.H.

References Pair< label >::first().

Here is the call graph for this function:

◆ b() [2/2]

label& b ( )

inlinenoexcept

The second vertex.

Definition at line 139 of file edge.H.

References Pair< label >::second().

Here is the call graph for this function:

◆ start() [1/2]

label start ( ) const

inlinenoexcept

The start (first) vertex label.

Definition at line 144 of file edge.H.

References Pair< label >::first().

Referenced by cellFeatures::isFeaturePoint(), PrimitivePatch<::Foam::List< labelledTri >, pointField >::meshEdge(), PrimitivePatch<::Foam::List< labelledTri >, pointField >::meshEdges(), slidingInterface::modifyMotionPoints(), line< Point, PointRef >::nearestDist(), surfaceFeatures::nearestFeatEdge(), Foam::polyMeshZipUpCells(), PatchTools::sortedPointEdges(), and extendedEdgeMesh::sortPointsAndEdges().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ end() [1/2]

label end ( ) const

inlinenoexcept

The end (last/second) vertex label.

Definition at line 149 of file edge.H.

References Pair< label >::second().

Referenced by cellFeatures::isFeaturePoint(), slidingInterface::modifyMotionPoints(), line< Point, PointRef >::nearestDist(), Foam::polyMeshZipUpCells(), PatchTools::sortedPointEdges(), and extendedEdgeMesh::sortPointsAndEdges().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ start() [2/2]

label& start ( )

inlinenoexcept

The start (first) vertex label.

Definition at line 154 of file edge.H.

References Pair< label >::first().

Here is the call graph for this function:

◆ end() [2/2]

label& end ( )

inlinenoexcept

The end (second/last) vertex label.

Definition at line 159 of file edge.H.

References Pair< label >::second().

Here is the call graph for this function:

◆ reverseEdge()

Foam::edge reverseEdge ( ) const

inline

Return reverse edge as copy.

No special handling of negative point labels.

Definition at line 195 of file edgeI.H.

Referenced by hexCell::reverseEdge(), and tetCell::reverseEdge().

Here is the caller graph for this function:

◆ minVertex()

Foam::label minVertex ( ) const

inline

Return the smallest point label used by the edge.

No special handling of negative point labels.

Definition at line 88 of file edgeI.H.

◆ maxVertex()

Foam::label maxVertex ( ) const

inline

Return the largest point label used by the edge.

No special handling of negative point labels.

Definition at line 94 of file edgeI.H.

◆ good()

bool good ( ) const

inlinenoexcept

True if the vertices are unique and non-negative.

Definition at line 100 of file edgeI.H.

Referenced by edge::valid().

Here is the caller graph for this function:

◆ valid()

bool valid ( ) const

inlinenoexcept

True if the vertices are unique and non-negative.

Definition at line 194 of file edge.H.

References edge::good().

Referenced by multiWorldConnections::addConnectionById(), multiWorldConnections::addConnectionByName(), multiWorldConnections::getCommById(), and multiWorldConnections::getCommByName().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ found()

bool found ( const label pointLabel ) const

inline

Return true if point label is found in edge.

Always false for a negative label.

Definition at line 106 of file edgeI.H.

Referenced by edge::commonVertex(), edge::connected(), intersectedSurface::intersectedSurface(), patchEdgeFaceRegions::updateEdge(), and patchEdgeFaceRegions::updateFace().

Here is the caller graph for this function:

◆ which()

Foam::label which ( const label pointLabel ) const

inline

Return local index (0,1) of point label in edge -1 on failure.

Always return -1 for a negative label.

Definition at line 117 of file edgeI.H.

◆ connected()

bool connected ( const edge & other ) const

inline

True if the edge has at least one vertex in common with other.

Definition at line 136 of file edgeI.H.

References edge::found().

Referenced by Foam::calcProximityOfFeatureEdges(), and edge::connects().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ commonVertex()

Foam::label commonVertex ( const edge & other ) const

inline

Return vertex common with other edge or -1 on failure.

Negative point labels are never considered common between edges.

Definition at line 142 of file edgeI.H.

References edge::found().

Referenced by removePoints::countPointUsage(), and GTSsurfaceFormat< Face >::read().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ otherVertex()

Foam::label otherVertex ( const label pointLabel ) const

inline

Given the point label for one vertex, return the other one.

No special treatment for negative point labels.

Definition at line 158 of file edgeI.H.

Referenced by removePoints::countPointUsage(), searchableExtrudedCircle::findParametricNearest(), and GTSsurfaceFormat< Face >::read().

Here is the caller graph for this function:

◆ connects()

bool connects ( const edge & other ) const

inline

Do the edges share a common vertex index?

Negative point labels never connect.

Definition at line 234 of file edge.H.

References edge::connected(), and Pair< label >::other().

Here is the call graph for this function:

◆ collapse()

Foam::label collapse ( )

inline

'Collapse' edge by marking duplicate point labels as '-1', the lower vertex is retained.

Return the effective size after collapsing.

Definition at line 174 of file edgeI.H.

References n.

◆ count()

Foam::label count ( ) const

inline

Return the number of unique, valid (non -1) point labels.

Similar to a HashTable::size().

Definition at line 208 of file edgeI.H.

References n.

◆ empty()

bool empty ( ) const

inline

Return true if edge has no valid point labels.

Definition at line 224 of file edgeI.H.

◆ clear()

void clear ( )

inline

'Clears' edge by setting both ends to invalid point labels.

Definition at line 201 of file edgeI.H.

◆ insert() [1/7]

bool insert ( const label index )

inline

Fill any open slot with the index if it did not previously exist.

Returns true on success. A negative label never inserts. Similar to a HashTable::insert().

Definition at line 230 of file edgeI.H.

◆ insert() [2/7]

label insert	(	InputIterator	begIter,
		InputIterator	endIter
	)

inline

Insert values, using begin/end iterators.

◆ insert() [3/7]

Foam::label insert ( std::initializer_list< label > list )

inline

Fill open slots with the indices if they did not previously exist.

Returns true on success. Negative labels never insert. Return the number of slots filled. Similar to a HashTable::insert().

Definition at line 285 of file edgeI.H.

References insert().

Here is the call graph for this function:

◆ insert() [4/7]

label insert ( const FixedList< label, N > & list )

inline

Fill open slots with the indices if they did not previously exist.

Returns true on success. Negative labels never insert. Return the number of slots filled. Similar to a HashTable::insert().

◆ insert() [5/7]

Foam::label insert ( const labelUList & list )

inline

Fill open slots with the indices if they did not previously exist.

Returns true on success. Negative labels never insert. Return the number of slots filled. Similar to a HashTable::insert().

Definition at line 298 of file edgeI.H.

References UList< T >::begin(), UList< T >::end(), and insert().

Here is the call graph for this function:

◆ erase() [1/7]

Foam::label erase ( const label index )

inline

Remove an existing index from the edge and set its location to '-1'.

Returns the number of changes. A negative label never removes. Similar to a HashTable::erase().

Definition at line 304 of file edgeI.H.

References n.

◆ erase() [2/7]

label erase	(	InputIterator	begIter,
		InputIterator	endIter
	)

inline

Remove values, using begin/end iterators.

◆ erase() [3/7]

Foam::label erase ( std::initializer_list< label > list )

inline

Remove existing indices from the edge and set locations to '-1'.

Returns the number of changes.

Definition at line 351 of file edgeI.H.

References erase().

Here is the call graph for this function:

◆ erase() [4/7]

label erase ( const FixedList< label, N > & list )

inline

Remove existing indices from the edge and set locations to '-1'.

Returns the number of changes.

◆ erase() [5/7]

Foam::label erase ( const labelUList & list )

inline

Remove existing indices from the edge and set locations to '-1'.

Returns the number of changes.

Definition at line 364 of file edgeI.H.

References UList< T >::begin(), UList< T >::end(), and erase().

Here is the call graph for this function:

◆ centre()

Foam::point centre ( const UList< point > & pts ) const

inline

Return centre point (centroid) of the edge.

No special handling of negative point labels.

Definition at line 372 of file edgeI.H.

References Foam::abort(), Foam::FatalError, FatalErrorInFunction, and pts.

Referenced by surfaceFeatures::nearestEdges(), and surfaceFeatures::nearestFeatEdge().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ vec()

Foam::vector vec ( const UList< point > & pts ) const

inline

Return the vector (end - start)

No special handling of negative point labels.

Definition at line 387 of file edgeI.H.

References Foam::abort(), Foam::FatalError, FatalErrorInFunction, and pts.

Referenced by searchableExtrudedCircle::findParametricNearest(), slidingInterface::modifyMotionPoints(), extendedEdgeMesh::sortPointsAndEdges(), and cuttingSurfaceBase::walkCellCuts().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ unitVec()

Foam::vector unitVec ( const UList< point > & pts ) const

inline

Return the unit vector (end - start)

No special handling of negative point labels.

Definition at line 402 of file edgeI.H.

References Foam::abort(), Foam::FatalError, FatalErrorInFunction, Foam::mag(), pts, s, and Foam::Zero.

Referenced by cellFeatures::isFeaturePoint().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ mag()

Foam::scalar mag ( const UList< point > & pts ) const

inline

Return scalar magnitude of the edge.

No special handling of negative point labels.

Definition at line 420 of file edgeI.H.

References Foam::mag(), and pts.

Referenced by face::longestEdge(), and surfaceFeatures::trimFeatures().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ box()

Foam::Pair< Foam::point > box ( const UList< point > & pts ) const

inline

The enclosing (bounding) box for the edge.

Definition at line 427 of file edgeI.H.

References Foam::abort(), line< Point, PointRef >::box(), Foam::FatalError, FatalErrorInFunction, and pts.

Here is the call graph for this function:

◆ line()

Foam::linePointRef line ( const UList< point > & pts ) const

inline

Return edge line.

No special handling of negative point labels.

Definition at line 442 of file edgeI.H.

References Foam::abort(), Foam::FatalError, FatalErrorInFunction, and pts.

Referenced by slidingInterface::modifyMotionPoints(), and syncTools::syncEdgeList().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ compare()

int compare	(	const edge &	a,
		const edge &	b
	)

inlinestatic

Compare edges.

Returns

0: different
+1: identical values and order used
-1: identical values, but in different order

Definition at line 26 of file edgeI.H.

References edge::a(), edge::b(), and Pair< label >::compare().

Referenced by Foam::operator!=(), Foam::operator==(), and syncTools::syncEdgeList().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ operator[]() [1/2]

Foam::label & operator[] ( const label i )

inline

Return edge element. Index should be limited to 0/1.

Definition at line 459 of file edgeI.H.

References Foam::abort(), Foam::FatalError, and FatalErrorInFunction.

Here is the call graph for this function:

◆ operator[]() [2/2]

const Foam::label & operator[] ( const label i ) const

inline

Return constant edge element. Index should be limited to 0/1.

Definition at line 472 of file edgeI.H.

References Foam::abort(), Foam::FatalError, and FatalErrorInFunction.

Here is the call graph for this function:

◆ hash_code()

unsigned hash_code ( unsigned seed = 0 ) const

inline

The (commutative) hash value for edge, hashes lower value first.

Definition at line 422 of file edge.H.

References Pair< label >::first(), and Pair< label >::second().

Referenced by edge::hasher::operator()().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ insert() [6/7]

Foam::label insert	(	InputIterator	begIter,
		InputIterator	endIter
	)

inline

Definition at line 263 of file edgeI.H.

References insert().

Here is the call graph for this function:

◆ insert() [7/7]

Foam::label insert ( const FixedList< label, N > & list )

inline

Definition at line 292 of file edgeI.H.

References FixedList< T, N >::begin(), FixedList< T, N >::end(), and insert().

Here is the call graph for this function:

◆ erase() [6/7]

Foam::label erase	(	InputIterator	begIter,
		InputIterator	endIter
	)

inline

Definition at line 332 of file edgeI.H.

References erase().

Here is the call graph for this function:

◆ erase() [7/7]

Foam::label erase ( const FixedList< label, N > & list )

inline

Definition at line 358 of file edgeI.H.

References FixedList< T, N >::begin(), FixedList< T, N >::end(), and erase().

Here is the call graph for this function:

Member Data Documentation

◆ typeName

const char *const typeName = "edge"

static

Definition at line 67 of file edge.H.

The documentation for this class was generated from the following files:

src/OpenFOAM/meshes/meshShapes/edge/edge.H
src/OpenFOAM/meshes/meshShapes/edge/edge.C
src/OpenFOAM/meshes/meshShapes/edge/edgeI.H

Classes

Public Member Functions

Static Public Member Functions

Static Public Attributes

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ edge() [1/8]

◆ edge() [2/8]

◆ edge() [3/8]

◆ edge() [4/8]

◆ edge() [5/8]

◆ edge() [6/8]

◆ edge() [7/8]

◆ edge() [8/8]

Member Function Documentation

◆ a() [1/2]

◆ b() [1/2]

◆ a() [2/2]

◆ b() [2/2]

◆ start() [1/2]

◆ end() [1/2]

◆ start() [2/2]

◆ end() [2/2]

◆ reverseEdge()

◆ minVertex()

◆ maxVertex()

◆ good()

◆ valid()

◆ found()

◆ which()

◆ connected()

◆ commonVertex()

◆ otherVertex()

◆ connects()

◆ collapse()

◆ count()

◆ empty()

◆ clear()

◆ insert() [1/7]

◆ insert() [2/7]

◆ insert() [3/7]

◆ insert() [4/7]

◆ insert() [5/7]

◆ erase() [1/7]

◆ erase() [2/7]

◆ erase() [3/7]

◆ erase() [4/7]

◆ erase() [5/7]

◆ centre()

◆ vec()

◆ unitVec()

◆ mag()

◆ box()

◆ line()

◆ compare()

◆ operator[]() [1/2]

◆ operator[]() [2/2]

◆ hash_code()

◆ insert() [6/7]

◆ insert() [7/7]

◆ erase() [6/7]

◆ erase() [7/7]

Member Data Documentation

◆ typeName
