Foam::MatrixTools Namespace Reference

Collection of functions for matrix-related verifications. More...

Functions
template<class Form1 , class Form2 , class Type >
bool	equal (const Matrix< Form1, Type > &A, const Matrix< Form2, Type > &B, const bool verbose=false, const label maxDiffs=10, const scalar relTol=1e-5, const scalar absTol=1e-8)
	Compare matrix elements for absolute or relative equality. More...
template<class Container >
Ostream &	printMatrix (Ostream &os, const Container &mat)
	Simple ASCII output of Matrix, MatrixBlock. More...
template<class MatrixType >
MatrixType	pinv (const MatrixType &A, scalar tol=1e-5)
	Moore-Penrose inverse of singular/non-singular square/rectangular scalar/complex matrices (KPP:p. 9834; KP:p. 648) More...

Detailed Description

Collection of functions for matrix-related verifications.

Source files

• MatrixTools.H
• MatrixTools.C

Function Documentation

equal()

bool equal	(	const Matrix< Form1, Type > &	A,
		const Matrix< Form2, Type > &	B,
		const bool	verbose = false,
		const label	maxDiffs = 10,
		const scalar	relTol = 1e-5,
		const scalar	absTol = 1e-8
	)

Compare matrix elements for absolute or relative equality.

Parameters

maxDiffs

Stop reporting after maxDiffs (0 to disable)

Definition at line 27 of file MatrixTools.C.

References A, B, Foam::Info, Foam::mag(), and Foam::nl.

Here is the call graph for this function:

printMatrix()

Ostream& Foam::MatrixTools::printMatrix	(	Ostream &	os,
		const Container &	mat
	)

Simple ASCII output of Matrix, MatrixBlock.

pinv()

MatrixType pinv	(	const MatrixType &	A,
		scalar	tol = 1e-5
	)

Moore-Penrose inverse of singular/non-singular square/rectangular scalar/complex matrices (KPP:p. 9834; KP:p. 648)

The tolerance to ensure the R1 matrix full-rank is set to 1e-5 by (TA; mentioned in (KPP:p. 9832)) in contrast to 1e-13 (KPP:p. 9834).

Definition at line 577 of file QRMatrix.C.

References A, Foam::abort(), C, Foam::diag(), Foam::distance(), Foam::constant::electromagnetic::e, Foam::endl(), Foam::FatalError, FatalErrorInFunction, Foam::ListOps::find_if(), Foam::mag(), QRMatrix< MatrixType >::P(), QRMatrix< MatrixType >::Q(), R, QRMatrix< MatrixType >::R(), Matrix< RectangularMatrix< Type >, Type >::resize(), QRMatrix< MatrixType >::solve(), WarningInFunction, x, and Foam::Zero.

Referenced by Foam::SVDinv().

Here is the call graph for this function:

Here is the caller graph for this function:
