Public Member Functions | Static Public Attributes | List of all members
blackBodyEmission Class Reference

Class black body emission. More...

Collaboration diagram for blackBodyEmission:
Collaboration graph
[legend]

Public Member Functions

 blackBodyEmission (const label nLambda, const volScalarField &T)
 Construct from components. More...

 ~blackBodyEmission ()
 Destructor. More...

const volScalarField & bLambda (const label lambdaI) const
 Black body spectrum. More...

dimensionedScalar EblambdaT (const dimensionedScalar &T, const scalar lambda) const
 Spectral emission for the black body at T and lambda. More...

tmp< Foam::volScalarField > deltaLambdaT (const volScalarField &T, const Vector2D< scalar > &band) const
 Proportion of total energy at T from lambda1 to lambda2. More...

tmp< Foam::volScalarField > EbDeltaLambdaT (const volScalarField &T, const Vector2D< scalar > &band) const
 Integral energy at T from lambda1 to lambda2. More...

void correct (const label lambdaI, const Vector2D< scalar > &band)


Static Public Attributes

static const List< Tuple2< scalar, scalar > > emissivePowerTable
 Static table of black body emissive power. More...


Detailed Description

Class black body emission.

Table of black body emissive power from: Modest, "Radiative Heat Transfer", pp.775-777, 1993

Source files

Definition at line 55 of file blackBodyEmission.H.

Constructor & Destructor Documentation

◆ blackBodyEmission()

blackBodyEmission ( const label  nLambda,
const volScalarField &  T
)

Construct from components.

Definition at line 135 of file blackBodyEmission.C.

References forAll, Foam::name(), IOobjectOption::NO_READ, IOobjectOption::NO_WRITE, Foam::pow4(), Foam::constant::physicoChemical::sigma, and Foam::T().

Here is the call graph for this function:

◆ ~blackBodyEmission()

~blackBodyEmission ( )

Destructor.

Definition at line 176 of file blackBodyEmission.C.

Member Function Documentation

◆ bLambda()

const volScalarField& bLambda ( const label  lambdaI) const
inline

Black body spectrum.

Definition at line 123 of file blackBodyEmission.H.

◆ EblambdaT()

dimensionedScalar EblambdaT ( const dimensionedScalar &  T,
const scalar  lambda
) const
inline

Spectral emission for the black body at T and lambda.

Returns Planck spectral emissive power [W/m³]

Definition at line 134 of file blackBodyEmission.H.

References dimensioned< Type >::dimensions(), Foam::dimLength, Foam::exp(), lambda(), Foam::pow5(), Foam::T(), and dimensioned< Type >::value().

Here is the call graph for this function:

◆ deltaLambdaT()

Foam::tmp< Foam::volScalarField > deltaLambdaT ( const volScalarField &  T,
const Vector2D< scalar > &  band
) const

Proportion of total energy at T from lambda1 to lambda2.

Definition at line 193 of file blackBodyEmission.C.

References Foam::dimless, forAll, GeometricField< scalar, fvPatchField, volMesh >::New(), IOobjectOption::NO_REGISTER, and Foam::T().

Here is the call graph for this function:

◆ EbDeltaLambdaT()

Foam::tmp< Foam::volScalarField > EbDeltaLambdaT ( const volScalarField &  T,
const Vector2D< scalar > &  band
) const

Integral energy at T from lambda1 to lambda2.

Definition at line 222 of file blackBodyEmission.C.

References fvPatchFieldBase::coupled(), forAll, GeometricField< scalar, fvPatchField, volMesh >::New(), IOobjectOption::NO_REGISTER, Foam::pow4(), Foam::constant::physicoChemical::sigma, and Foam::T().

Here is the call graph for this function:

◆ correct()

void correct ( const label  lambdaI,
const Vector2D< scalar > &  band
)

Definition at line 269 of file blackBodyEmission.C.

Member Data Documentation

◆ emissivePowerTable

const Foam::List< Foam::Tuple2< Foam::scalar, Foam::scalar > > emissivePowerTable
static

Static table of black body emissive power.

Definition at line 62 of file blackBodyEmission.H.

The documentation for this class was generated from the following files:
