Abstract base class for multi-variate surface interpolation schemes. More...

Inheritance diagram for multivariateSurfaceInterpolationScheme< Type >:

[legend]

Collaboration diagram for multivariateSurfaceInterpolationScheme< Type >:

Classes
class	fieldScheme
	surfaceInterpolationScheme sub-class returned by operator(field) More...

class	fieldTable
	fieldTable More...

Public Member Functions
virtual const word &	type () const =0
	Runtime type information. More...

	declareRunTimeSelectionTable (tmp, multivariateSurfaceInterpolationScheme, Istream,(const fvMesh &mesh, const fieldTable &fields, const surfaceScalarField &faceFlux, Istream &is),(mesh, fields, faceFlux, is))

	multivariateSurfaceInterpolationScheme (const fvMesh &mesh, const fieldTable &fields, const surfaceScalarField &faceFlux, Istream &schemeData)
	Construct for interpolating given field. More...

virtual	~multivariateSurfaceInterpolationScheme ()=default
	Destructor. More...

const fvMesh &	mesh () const
	Return mesh reference. More...

const fieldTable &	fields () const
	Return fields to be interpolated. More...

virtual tmp< surfaceInterpolationScheme< Type > >	operator() (const GeometricField< Type, fvPatchField, volMesh > &field) const =0

Public Member Functions inherited from refCount
constexpr	refCount () noexcept
	Default construct, initializing count to 0. More...

int	use_count () const noexcept
	Return the current reference count. More...

bool	unique () const noexcept
	Return true if the reference count is zero. More...

void	operator++ () noexcept
	Increment the reference count. More...

void	operator++ (int) noexcept
	Increment the reference count. More...

void	operator-- () noexcept
	Decrement the reference count. More...

void	operator-- (int) noexcept
	Decrement the reference count. More...

Static Public Member Functions
static tmp< multivariateSurfaceInterpolationScheme< Type > >	New (const fvMesh &mesh, const fieldTable &fields, const surfaceScalarField &faceFlux, Istream &schemeData)
	Return a pointer to a new gradScheme created on freestore. More...

Detailed Description

template<class Type>
class Foam::multivariateSurfaceInterpolationScheme< Type >

Abstract base class for multi-variate surface interpolation schemes.

Source files

Definition at line 48 of file multivariateSurfaceInterpolationScheme.H.

Constructor & Destructor Documentation

◆ multivariateSurfaceInterpolationScheme()

multivariateSurfaceInterpolationScheme	(	const fvMesh &	mesh,
		const fieldTable &	fields,
		const surfaceScalarField &	faceFlux,
		Istream &	schemeData
	)

Construct for interpolating given field.

◆ ~multivariateSurfaceInterpolationScheme()

virtual ~multivariateSurfaceInterpolationScheme ( )

virtualdefault

Destructor.

Member Function Documentation

◆ type()

virtual const word& type ( ) const

pure virtual

Runtime type information.

◆ declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	tmp	,
		multivariateSurfaceInterpolationScheme< Type >	,
		Istream	,
		(const fvMesh &mesh, const fieldTable &fields, const surfaceScalarField &faceFlux, Istream &is)	,
		(mesh, fields, faceFlux, is)
	)

◆ New()

Foam::tmp< Foam::multivariateSurfaceInterpolationScheme< Type > > New	(	const fvMesh &	mesh,
		const fieldTable &	fields,
		const surfaceScalarField &	faceFlux,
		Istream &	schemeData
	)

static

Return a pointer to a new gradScheme created on freestore.

Definition at line 49 of file multivariateSurfaceInterpolationScheme.C.

◆ mesh()

const fvMesh& mesh ( ) const

inline

Return mesh reference.

Definition at line 169 of file multivariateSurfaceInterpolationScheme.H.

◆ fields()

const fieldTable& fields ( ) const

inline

Return fields to be interpolated.

Definition at line 177 of file multivariateSurfaceInterpolationScheme.H.

◆ operator()()

virtual tmp<surfaceInterpolationScheme<Type> > operator() ( const GeometricField< Type, fvPatchField, volMesh > & field ) const

pure virtual

Implemented in multivariateUpwind< Type >, multivariateSelectionScheme< Type >, multivariateScheme< Type, Scheme >, and multivariateIndependentScheme< Type >.

The documentation for this class was generated from the following files:

src/finiteVolume/interpolation/surfaceInterpolation/multivariateSchemes/multivariateSurfaceInterpolationScheme/multivariateSurfaceInterpolationScheme.H
src/finiteVolume/interpolation/surfaceInterpolation/multivariateSchemes/multivariateSurfaceInterpolationScheme/multivariateSurfaceInterpolationScheme.C
