Public Types | |
| typedef HashTable< autoPtr< phasePair >, phasePairKey, phasePairKey::hash > | phasePairTable |
| typedef HashTable< autoPtr< multiphaseInter::phaseModel > > | phaseModelTable |
| typedef HashTable< volScalarField::Internal > | SuSpTable |
 Public Types inherited from IOobject | |
| enum | objectState : char { GOOD, BAD } |
| Enumeration defining the valid states of an IOobject. More... | |
| enum | fileCheckTypes : char { timeStamp = 1, timeStampMaster = 3, inotify = 4, inotifyMaster = 6 } |
| Enumeration defining the file checking options (time-stamp | inotify) | (all | masterOnly) More... | |
| Public Types inherited from IOobjectOption | |
| enum | readOption : unsigned char { NO_READ = 0, MUST_READ = 0x1, READ_MODIFIED = 0x3, MUST_READ_IF_MODIFIED = 0x3, LAZY_READ = 0x4, READ_IF_PRESENT = 0x4 } |
| Enumeration defining read preferences. More... | |
| enum | writeOption : unsigned char { NO_WRITE = 0, AUTO_WRITE = 0x10 } |
| Enumeration defining write preferences. More... | |
| enum | registerOption : unsigned char { NO_REGISTER = 0, REGISTER = 1, LEGACY_REGISTER = 2 } |
| Enumeration for use with registerObject(). Values map to bool (false/true) More... | |
| enum | Layout : unsigned char { regular, global } |
| The layout of the case structure. More... | |
| Public Types inherited from dictionary | |
| typedef Searcher< true > | const_searcher |
| Searcher with const access. More... | |
| typedef Searcher< false > | searcher |
| Searcher with non-const access. More... | |
| Public Types inherited from UILList< LListBase, T > | |
| typedef T | value_type |
| Type of values stored. More... | |
| typedef T * | pointer |
| Pointer for value_type. More... | |
| typedef const T * | const_pointer |
| Const pointer for value_type. More... | |
| typedef T & | reference |
| Reference for value_type. More... | |
| typedef const T & | const_reference |
| Const reference for value_type. More... | |
| typedef label | size_type |
| The type that can represent the container size. More... | |
| typedef label | difference_type |
| The difference between iterator objects. More... | |
| using | base_iterator = typename LListBase::iterator |
| using | const_base_iterator = typename LListBase::const_iterator |
Public Member Functions | |
| TypeName ("multiphaseInterSystem") | |
| Runtime type information. More... | |
| multiphaseInterSystem (const fvMesh &mesh) | |
| Construct from fvMesh. More... | |
| virtual | ~multiphaseInterSystem () |
| Destructor. More... | |
| virtual volScalarField & | he () |
| Return access to the internal energy field [J/Kg]. More... | |
| virtual const volScalarField & | he () const |
| Return access to the internal energy field [J/Kg]. More... | |
| virtual tmp< volScalarField > | he (const volScalarField &p, const volScalarField &T) const |
| Enthalpy/Internal energy. More... | |
| virtual tmp< scalarField > | he (const scalarField &p, const scalarField &T, const labelList &cells) const |
| Enthalpy/Internal energy for cell-set [J/kg]. More... | |
| virtual tmp< scalarField > | he (const scalarField &p, const scalarField &T, const label patchi) const |
| Enthalpy/Internal energy for patch [J/kg]. More... | |
| virtual tmp< volScalarField > | hc () const |
| Chemical enthalpy of the mixture [J/kg]. More... | |
| virtual tmp< scalarField > | THE (const scalarField &h, const scalarField &p, const scalarField &T0, const labelList &cells) const |
| Temperature from enthalpy/internal energy for cell-set. More... | |
| virtual tmp< scalarField > | THE (const scalarField &h, const scalarField &p, const scalarField &T0, const label patchi) const |
| Temperature from enthalpy/internal energy for patch. More... | |
| virtual tmp< volScalarField > | rho () const |
| Return the mixture density. More... | |
| virtual tmp< scalarField > | rho (const label patchi) const |
| Return the mixture density on a patch. More... | |
| virtual tmp< volScalarField > | Cp () const |
| Return Cp of the mixture. More... | |
| virtual tmp< scalarField > | Cp (const scalarField &p, const scalarField &T, const label patchi) const |
| Heat capacity at constant pressure for patch [J/kg/K]. More... | |
| virtual tmp< scalarField > | Cp (const scalarField &p, const scalarField &T, const labelList &cells) const |
| Heat capacity using pressure and temperature. More... | |
| virtual tmp< volScalarField > | Cv () const |
| Return Cv of the mixture. More... | |
| virtual tmp< scalarField > | Cv (const scalarField &p, const scalarField &T, const label patchI) const |
| Heat capacity at constant volume for patch [J/kg/K]. More... | |
| virtual tmp< scalarField > | rhoEoS (const scalarField &p, const scalarField &T, const labelList &cells) const |
| Density from pressure and temperature. More... | |
| virtual tmp< volScalarField > | gamma () const |
| Gamma = Cp/Cv []. More... | |
| virtual tmp< scalarField > | gamma (const scalarField &p, const scalarField &T, const label patchi) const |
| Gamma = Cp/Cv for patch []. More... | |
| virtual tmp< volScalarField > | Cpv () const |
| Heat capacity at constant pressure/volume [J/kg/K]. More... | |
| virtual tmp< scalarField > | Cpv (const scalarField &p, const scalarField &T, const label patchi) const |
| Heat capacity at constant pressure/volume for patch [J/kg/K]. More... | |
| virtual tmp< volScalarField > | CpByCpv () const |
| Heat capacity ratio []. More... | |
| virtual tmp< scalarField > | CpByCpv (const scalarField &p, const scalarField &T, const label patchi) const |
| Heat capacity ratio for patch []. More... | |
| virtual tmp< volScalarField > | W () const |
| Molecular weight [kg/kmol] of the mixture. More... | |
| virtual tmp< volScalarField > | kappa () const |
| Thermal diffusivity for temperature of mixture [J/m/s/K]. More... | |
| virtual tmp< scalarField > | kappa (const label patchi) const |
| Thermal diffusivity for temperature. More... | |
| virtual tmp< volScalarField > | alphahe () const |
| Thermal diffusivity for energy of mixture [kg/m/s]. More... | |
| virtual tmp< scalarField > | alphahe (const label patchi) const |
| Thermal diffusivity for energy of mixture for patch [kg/m/s]. More... | |
| virtual tmp< volScalarField > | kappaEff (const volScalarField &kappat) const |
| Effective thermal diffusivity for temperature. More... | |
| virtual tmp< scalarField > | kappaEff (const scalarField &alphat, const label patchi) const |
| Effective thermal diffusivity for temperature. More... | |
| virtual tmp< volScalarField > | alphaEff (const volScalarField &alphat) const |
| Effective thermal diffusivity of mixture [kg/m/s]. More... | |
| virtual tmp< scalarField > | alphaEff (const scalarField &alphat, const label patchi) const |
| Effective thermal diffusivity of mixture for patch [kg/m/s]. More... | |
| const dimensionedScalar & | Prt () const |
| Return Prandt number. More... | |
| virtual tmp< volScalarField > | mu () const |
| Dynamic viscosity of mixture [kg/m/s]. More... | |
| virtual tmp< scalarField > | mu (const label patchi) const |
| Dynamic viscosity of mixture for patch [kg/m/s]. More... | |
| virtual tmp< volScalarField > | nu () const |
| Kinematic viscosity of mixture [m^2/s]. More... | |
| virtual tmp< scalarField > | nu (const label patchi) const |
| Kinematic viscosity of mixture for patch [m^2/s]. More... | |
| void | setTurbulence (compressibleTurbulenceModel &turb) |
| Set turbulence model. More... | |
| compressibleTurbulenceModel * | turbulence () const |
| Return pointer to turbulence model. More... | |
| tmp< volScalarField > | mut () const |
| Return the turbulent dynamic viscosity. More... | |
| tmp< volScalarField > | muEff () const |
| Return the effective dynamic viscosity. More... | |
| tmp< volScalarField > | nut () const |
| Return the turbulent kinematic viscosity. More... | |
| tmp< volScalarField > | nuEff () const |
| Return the effective kinematic viscosity. More... | |
| tmp< volScalarField > | kappaEff () const |
| Effective thermal turbulent diffusivity for temperature. More... | |
| tmp< scalarField > | kappaEff (const label patchi) const |
| Effective thermal turbulent diffusivity for temperature. More... | |
| tmp< volScalarField > | alphaEff () const |
| Effective thermal turbulent diffusivity of mixture [kg/m/s]. More... | |
| tmp< scalarField > | alphaEff (const label patchi) const |
| Effective thermal turbulent diffusivity of mixture [kg/m/s]. More... | |
| const surfaceScalarField & | phi () const |
| Constant access to the total flux. More... | |
| surfaceScalarField & | phi () |
| Access to the total mixture flux. More... | |
| const surfaceScalarField & | rhoPhi () const |
| Constant access to the mixture mass flux. More... | |
| surfaceScalarField & | rhoPhi () |
| Access to the total mixture mass flux. More... | |
| tmp< volVectorField > | U () const |
| Mixture U. More... | |
| tmp< surfaceScalarField > | surfaceTensionForce () const |
| Calculate surface tension of the mixture. More... | |
| virtual tmp< volScalarField > | surfaceTensionCoeff (const phasePairKey &key) const |
| Return the surface tension coefficient. More... | |
| virtual tmp< volScalarField > | coeffs (const word &key) const |
| Return coefficients (1/rho) More... | |
| void | addInterfacePorosity (fvVectorMatrix &UEqn) |
| Add interface porosity on phasePair. More... | |
| virtual tmp< volScalarField > | dmdt (const phasePairKey &key) const =0 |
| Return interfacial source mass rate per phase pair. More... | |
| virtual tmp< fvScalarMatrix > | heatTransfer (const volScalarField &T)=0 |
| Return the heat transfer matrices. More... | |
| virtual tmp< fvScalarMatrix > | volTransfer (const volScalarField &p)=0 |
| Return the volumetric rate transfer matrix. More... | |
| virtual void | alphaTransfer (SuSpTable &Su, SuSpTable &Sp)=0 |
| Calculate mass transfer for alpha's. More... | |
| virtual void | massSpeciesTransfer (const multiphaseInter::phaseModel &phase, volScalarField::Internal &Su, volScalarField::Internal &Sp, const word speciesName)=0 |
| Calculate mass transfer for species. More... | |
| virtual bool | includeVolChange ()=0 |
| Add volume change in pEq. More... | |
| virtual void | solve ()=0 |
| Solve for the phase transport equations. More... | |
| virtual void | correct () |
| Correct the mixture thermos. More... | |
| virtual void | correctMassSources (const volScalarField &T)=0 |
| Correct mass sources. More... | |
| virtual word | thermoName () const |
| Return the name of the thermo physics. More... | |
| virtual void | correctTurbulence () |
| Correct the turbulence. More... | |
| virtual bool | read () |
| Read base phaseProperties dictionary. More... | |
| const phasePairTable & | totalPhasePairs () const |
| Constant access the total phase pairs. More... | |
| phasePairTable & | totalPhasePairs () |
| Non-constant access the total phase pairs. More... | |
| const phaseModelTable & | phases () const |
| Constant access the phases. More... | |
| phaseModelTable & | phases () |
| Access the phases. More... | |
| template<class modelType > | |
| const modelType & | lookupSubModel (const phasePair &key) const |
| Access a sub model between a phase pair. More... | |
| template<class modelType > | |
| const modelType & | lookupSubModel (const multiphaseInter::phaseModel &from, const multiphaseInter::phaseModel &to) const |
| Access a sub model between two phases. More... | |
| virtual bool | incompressible () const |
| Return true if the equation of state is incompressible for all. More... | |
| virtual bool | incompressible (const word) const |
| Return true if a phase is incompressible. More... | |
| virtual bool | isochoric () const |
| Return true if the equation of state is isochoric for all phasses. More... | |
| const fvMesh & | mesh () const |
| Return mesh. More... | |
| tmp< surfaceVectorField > | nHatfv (const volScalarField &alpha1, const volScalarField &alpha2) const |
| Interface normal surface vector. More... | |
| tmp< volVectorField > | nVolHatfv (const volScalarField &alpha1, const volScalarField &alpha2) const |
| Interface normal volField vector. More... | |
| tmp< surfaceScalarField > | nHatf (const volScalarField &alpha1, const volScalarField &alpha2) const |
| Interface normal surface vector. More... | |
| tmp< volScalarField > | K (const volScalarField &alpha1, const volScalarField &alpha2) const |
| Interface curvature. More... | |
| tmp< volScalarField > | nearInterface (const volScalarField &alpha1, const volScalarField &alpha2) const |
| Near Interface of alpha1 and alpha2. More... | |
| tmp< volScalarField > | nearInterface () const |
| Near Interface of alpha'n. More... | |
| Public Member Functions inherited from basicThermo | |
| TypeName ("basicThermo") | |
| Runtime type information. More... | |
| declareRunTimeSelectionTable (autoPtr, basicThermo, fvMesh,(const fvMesh &mesh, const word &phaseName),(mesh, phaseName)) | |
| Declare run-time constructor selection table. More... | |
| declareRunTimeSelectionTable (autoPtr, basicThermo, fvMeshDictPhase,(const fvMesh &mesh, const word &phaseName, const word &dictName),(mesh, phaseName, dictName)) | |
| Declare run-time constructor selection table for dictionary based. More... | |
| basicThermo (const fvMesh &, const word &phaseName) | |
| Construct from mesh and phase name. More... | |
| basicThermo (const fvMesh &, const dictionary &, const word &phaseName) | |
| Construct from mesh, dictionary and phase name. More... | |
| basicThermo (const fvMesh &, const word &phaseName, const word &dictionaryName) | |
| Construct from mesh, phase name and explicit naming of the dictionary (so it can be shared amongst phases). More... | |
| virtual | ~basicThermo () |
| Destructor. More... | |
| word | phasePropertyName (const word &name) const |
| The phase property name as property.phase (using phaseName_) More... | |
| word | phaseScopedName (const std::string &scope, const word &name) const |
| The phase property name scoped as scope:property.phase. More... | |
| void | validate (const string &app, const word &) const |
| Check that the thermodynamics package is consistent. More... | |
| void | validate (const string &app, const word &, const word &) const |
| Check that the thermodynamics package is consistent. More... | |
| void | validate (const string &app, const word &, const word &, const word &) const |
| Check that the thermodynamics package is consistent. More... | |
| void | validate (const string &app, const word &, const word &, const word &, const word &) const |
| Check that the thermodynamics package is consistent. More... | |
| virtual bool | isZoneMixture () const |
| True if the mixture uses cellZone-dependent properties. More... | |
| bool | dpdt () const noexcept |
| True if dpdt term should be included in enthalpy equation. More... | |
| bool | updateT () const noexcept |
| True if T should be updated. More... | |
| virtual volScalarField & | p () |
| Pressure [Pa]. More... | |
| virtual const volScalarField & | p () const |
| Pressure [Pa]. More... | |
| virtual const volScalarField & | T () const |
| Temperature [K]. More... | |
| virtual volScalarField & | T () |
| Temperature [K]. More... | |
| virtual const volScalarField & | alpha () const |
| Thermal diffusivity for enthalpy of mixture [kg/m/s]. More... | |
| virtual const scalarField & | alpha (const label patchi) const |
| Thermal diffusivity for enthalpy of mixture for patch [kg/m/s]. More... | |
| template<class Thermo > | |
| Foam::autoPtr< Thermo > | New (const fvMesh &mesh, const word &phaseName) |
| template<class Thermo > | |
| Foam::autoPtr< Thermo > | New (const fvMesh &mesh, const dictionary &dict, const word &phaseName) |
| template<class Thermo > | |
| Foam::autoPtr< Thermo > | New (const fvMesh &mesh, const word &phaseName, const word &dictName) |
| Public Member Functions inherited from IOdictionary | |
| IOdictionary (const IOobject &io, const dictionary *fallback=nullptr) | |
| Construct given an IOobject and optional fallback dictionary content. More... | |
| IOdictionary (const IOobject &io, const dictionary &dict) | |
| Construct given an IOobject and fallback dictionary content. More... | |
| IOdictionary (const IOobject &io, const word &wantedType, const dictionary *fallback=nullptr) | |
| Construct given an IOobject, wanted typeName and optional fallback dictionary content. More... | |
| IOdictionary (const IOobject &io, Istream &is) | |
| Construct given an IOobject and Istream. More... | |
| virtual | ~IOdictionary ()=default |
| Destructor. More... | |
| virtual bool | global () const |
| The object is global. More... | |
| virtual fileName | filePath () const |
| Return complete path + object name if the file exists either in the case/processor or case otherwise null. More... | |
| Public Member Functions inherited from baseIOdictionary | |
| TypeName ("dictionary") | |
| Declare type-name, virtual type (with debug switch) More... | |
| baseIOdictionary (const baseIOdictionary &)=default | |
| Copy construct. More... | |
| baseIOdictionary (baseIOdictionary &&)=default | |
| Move construct. More... | |
| virtual | ~baseIOdictionary ()=default |
| Destructor. More... | |
| baseIOdictionary (const IOobject &io, const dictionary *fallback=nullptr) | |
| Construct given an IOobject and optional fallback dictionary content (ununsed) More... | |
| baseIOdictionary (const IOobject &io, const dictionary &dict) | |
| Construct given an IOobject and fallback dictionary content (ununsed) More... | |
| baseIOdictionary (const IOobject &io, Istream &is) | |
| Construct given an IOobject and Istream (ununsed) More... | |
| const word & | name () const |
| Name function is needed to disambiguate those inherited from regIOobject and dictionary. More... | |
| virtual bool | readData (Istream &) |
| The readData function required by regIOobject read operation. More... | |
| virtual bool | writeData (Ostream &) const |
| The writeData function required by regIOobject write operation. More... | |
| void | operator= (const baseIOdictionary &rhs) |
| Copy assignment of dictionary entries. More... | |
| void | operator= (baseIOdictionary &&rhs) |
| Move assignment of dictionary entries. More... | |
| void | operator= (const dictionary &rhs) |
| Copy assignment of dictionary entries. More... | |
| Public Member Functions inherited from regIOobject | |
| void | operator= (const regIOobject &)=delete |
| No copy assignment. More... | |
| TypeName ("regIOobject") | |
| Runtime type information. More... | |
| regIOobject (const IOobject &io, const bool isTimeObject=false) | |
| Construct from IOobject. The optional flag adds special handling if the object is the top-level regIOobject (eg, Time). More... | |
| regIOobject (const regIOobject &rio) | |
| Copy construct. More... | |
| regIOobject (const regIOobject &rio, bool registerCopy) | |
| Copy construct, transferring registry registration to the copy if registerCopy is true. More... | |
| regIOobject (const word &newName, const regIOobject &, bool registerCopy) | |
| Copy construct with new name, transferring registry registration to the copy if registerCopy is true. More... | |
| regIOobject (const IOobject &io, const regIOobject &rio) | |
| Copy construct with new IO parameters. More... | |
| virtual | ~regIOobject () |
| Destructor. More... | |
| bool | checkIn () |
| Add object to registry, if not already registered. More... | |
| bool | checkOut () |
| Remove object from registry, and remove all file watches. More... | |
| virtual void | addWatch () |
| Add file watch on object (if registered and READ_IF_MODIFIED) More... | |
| bool | registered () const noexcept |
| Query the registered state (ie, has been checked in). This is not necessarily the same as registerObject(), which is just a stated preference. More... | |
| bool | ownedByRegistry () const noexcept |
| Is this object owned by the registry? More... | |
| bool | store () |
| Register object with its registry and transfer ownership to the registry. More... | |
| void | release (const bool unregister=false) noexcept |
| Set object as not ownedByRegistry. More... | |
| label | eventNo () const noexcept |
| Event number at last update. More... | |
| label & | eventNo () noexcept |
| Event number at last update. More... | |
| bool | upToDate (const regIOobject &) const |
| Return true if up-to-date with respect to given object. More... | |
| bool | upToDate (const regIOobject &, const regIOobject &) const |
| Return true if up-to-date with respect to given objects. More... | |
| bool | upToDate (const regIOobject &, const regIOobject &, const regIOobject &) const |
| Return true if up-to-date with respect to given objects. More... | |
| bool | upToDate (const regIOobject &, const regIOobject &, const regIOobject &, const regIOobject &) const |
| Return true if up-to-date with respect to given objects. More... | |
| void | setUpToDate () |
| Set as up-to-date. More... | |
| virtual void | rename (const word &newName) |
| Rename. More... | |
| const dictionary * | findMetaData () const noexcept |
| Return pointer to meta-data or nullptr. More... | |
| dictionary & | getMetaData () noexcept |
| Get or create meta-data. More... | |
| void | removeMetaData () |
| Remove meta-data. More... | |
| virtual void | updateMetaData () |
| Update internal meta-data (eg, prior to writing) More... | |
| bool | headerOk () |
| Read and check header info. Does not check the headerClassName. More... | |
| Istream & | readStream (const word &, const bool readOnProc=true) |
| Return Istream and check object type against that given. More... | |
| void | close () |
| Close Istream. More... | |
| virtual label | addWatch (const fileName &) |
| Add file watch for fileName on object if not yet watched. More... | |
| const labelList & | watchIndices () const noexcept |
| Read access to file-monitoring handles. More... | |
| labelList & | watchIndices () noexcept |
| Write access to file-monitoring handles. More... | |
| virtual bool | modified () const |
| Return true if the object's file (or files for objectRegistry) have been modified. (modified state is cached by Time) More... | |
| virtual bool | readIfModified () |
| Read object if modified (as set by call to modified) More... | |
| virtual bool | writeObject (IOstreamOption streamOpt, const bool writeOnProc) const |
| Write using stream options. More... | |
| virtual bool | write (const bool writeOnProc=true) const |
| Write using setting from DB. More... | |
| void | operator= (const IOobject &io) |
| Copy assignment. More... | |
| virtual bool | writeObject (IOstreamOption::streamFormat fmt, IOstreamOption::versionNumber ver, IOstreamOption::compressionType cmp, const bool writeOnProc) const |
| Write using given format, version and compression. More... | |
| Public Member Functions inherited from IOobject | |
| TypeName ("IOobject") | |
| Declare type-name, virtual type (with debug switch) More... | |
| IOobject (const IOobject &)=default | |
| Copy construct. More... | |
| virtual | ~IOobject ()=default |
| Destructor. More... | |
| IOobject (const word &name, const fileName &instance, const objectRegistry ®istry, IOobjectOption ioOpt=IOobjectOption()) | |
| Construct from name, instance, registry, io options. More... | |
| IOobject (const word &name, const fileName &instance, const fileName &local, const objectRegistry ®istry, IOobjectOption ioOpt=IOobjectOption()) | |
| Construct from name, instance, local, registry, io options. More... | |
| IOobject (const fileName &path, const objectRegistry ®istry, IOobjectOption ioOpt=IOobjectOption()) | |
| Construct from path, registry, io options. More... | |
| IOobject (const word &name, const fileName &instance, const objectRegistry ®istry, IOobjectOption::readOption rOpt, IOobjectOption::writeOption wOpt=IOobjectOption::NO_WRITE, bool registerObject=true, bool globalObject=false) | |
| Construct from name, instance, registry, io options. More... | |
| IOobject (const word &name, const fileName &instance, const fileName &local, const objectRegistry ®istry, IOobjectOption::readOption rOpt, IOobjectOption::writeOption wOpt=IOobjectOption::NO_WRITE, bool registerObject=true, bool globalObject=false) | |
| Construct from name, instance, local, registry, io options. More... | |
| IOobject (const fileName &path, const objectRegistry ®istry, IOobjectOption::readOption rOpt, IOobjectOption::writeOption wOpt=IOobjectOption::NO_WRITE, bool registerObject=true, bool globalObject=false) | |
| Construct from path, registry, io options. More... | |
| IOobject (const IOobject &io, const objectRegistry ®istry) | |
| Copy construct, resetting registry. More... | |
| IOobject (const IOobject &io, const word &name) | |
| Copy construct, resetting name. More... | |
| IOobject (const IOobject &io, const word &name, const fileName &local) | |
| Copy construct, resetting name and local component. More... | |
| IOobject (const IOobject &io, IOobjectOption::readOption rOpt, IOobjectOption::writeOption wOpt) | |
| Copy construct, resetting read/write options. More... | |
| IOobject (const IOobject &io, IOobjectOption::registerOption regOpt) | |
| Copy construct, resetting register option. More... | |
| autoPtr< IOobject > | clone () const |
| Clone. More... | |
| autoPtr< IOobject > | clone (const objectRegistry ®istry) const |
| Clone resetting registry. More... | |
| const objectRegistry & | db () const noexcept |
| Return the local objectRegistry. More... | |
| const Time & | time () const noexcept |
| Return Time associated with the objectRegistry. More... | |
| const word & | name () const noexcept |
| Return the object name. More... | |
| const word & | headerClassName () const noexcept |
| Return name of the class name read from header. More... | |
| word & | headerClassName () noexcept |
| Modifiable access to the class name read from header. More... | |
| const string & | note () const noexcept |
| Return the optional note. More... | |
| string & | note () noexcept |
| Modifiable access to the optional note. More... | |
| unsigned | labelByteSize () const noexcept |
| The sizeof (label) in bytes, possibly read from the header. More... | |
| unsigned | scalarByteSize () const noexcept |
| The sizeof (scalar) in bytes, possibly read from the header. More... | |
| void | resetHeader (const word &newName=word::null) |
| Clear various bits (headerClassName, note, sizeof...) that would be obtained when reading from a file. More... | |
| bool | hasHeaderClass () const noexcept |
| True if headerClassName() is non-empty (after reading) More... | |
| bool | isHeaderClass (const word &expectedType) const |
| Check if headerClassName() equals the expected type. Always true if the expected type is empty. More... | |
| template<class Type > | |
| bool | isHeaderClass () const |
Check if headerClassName() equals Type::typeName Always true for a void type. More... | |
| word | group () const |
| Return group (extension part of name) More... | |
| word | member () const |
| Return member (name without the extension) More... | |
| const fileName & | rootPath () const noexcept |
| Return the Time::rootPath() More... | |
| const fileName & | caseName () const noexcept |
| Return the Time::caseName() More... | |
| const fileName & | globalCaseName () const noexcept |
| Return the Time::globalCaseName() More... | |
| const fileName & | caseName (IOobjectOption::Layout) const noexcept |
| Return the Time::caseName() - normal or global. More... | |
| const fileName & | instance () const noexcept |
| Read access to instance path component. More... | |
| fileName & | instance () noexcept |
| Modifiable access to instance path component. More... | |
| scalar | instanceValue () const |
| Return the scalar value of the instance component (or 0), which often corresponds to a time index/value. More... | |
| const fileName & | local () const noexcept |
| Read access to local path component. More... | |
| fileName & | local () noexcept |
| Modifiable access to the local path component. More... | |
| fileName | path () const |
| The complete path for the object (with instance, local,...). More... | |
| fileName | globalPath () const |
| The complete global path for the object (with instance, local,...) More... | |
| fileName | path (IOobjectOption::Layout) const |
| The complete path (normal or global) for the object. More... | |
| fileName | path (const word &instance, const fileName &local=fileName::null) const |
| The complete path with alternative instance and local. More... | |
| fileName | globalPath (const word &instance, const fileName &local=fileName::null) const |
| The complete global path with alternative instance and local. More... | |
| fileName | path (IOobjectOption::Layout, const word &instance, const fileName &local=fileName::null) const |
| The complete path (normal or global) with alternative instance and local. More... | |
| fileName | objectPath () const |
| The complete path + object name. More... | |
| fileName | globalObjectPath () const |
| The complete global path + object name. More... | |
| fileName | objectPath (IOobjectOption::Layout) const |
| The complete path (normal or global) + object name. More... | |
| fileName | objectPath (IOobjectOption::Layout, const word &instance) const |
| The complete path (normal or global) + object name with alternative instance. More... | |
| fileName | objectPath (const word &instance) const |
| The complete path + object name with alternative instance. More... | |
| fileName | globalObjectPath (const word &instance) const |
| The complete global path + object name with alternative instance. More... | |
| fileName | objectRelPath () const |
| The object path relative to the case. More... | |
| fileName | localFilePath (const word &typeName, const bool search=true) const |
| Redirect to fileHandler filePath, searching locally. More... | |
| fileName | globalFilePath (const word &typeName, const bool search=true) const |
| Redirect to fileHandler filePath, searching up if in parallel. More... | |
| IOstreamOption | parseHeader (const dictionary &headerDict) |
| Parse 'FoamFile' header contents and set the IOobject characteristics and return the stream characteristics. More... | |
| bool | readHeader (Istream &is) |
| Read header ('FoamFile' dictionary) and set the IOobject and stream characteristics. More... | |
| bool | readHeader (dictionary &headerDict, Istream &is) |
| Read header (the 'FoamFile' dictionary) and set the IOobject and stream characteristics. More... | |
| template<class Type > | |
| bool | typeHeaderOk ([[maybe_unused]] const bool checkType=true, const bool search=true, const bool verbose=true) |
Read header (respects is_globalIOobject trait) and check its info. A void type suppresses trait and type-name checks. More... | |
| template<class Type , bool Searching> | |
| bool | typeHeaderOk (const bool checkType=true, const bool verbose=true) |
Forwards to single-parameter version with the specified search type. A void type suppresses trait and type-name checks. More... | |
| template<class Type > | |
| fileName | typeFilePath (const bool search=true) const |
| Call localFilePath or globalFilePath for given type depending on its is_globalIOobject trait. More... | |
| template<class Type > | |
| void | warnNoRereading () const |
| Helper: warn that type does not support re-reading. More... | |
| bool | writeHeader (Ostream &os) const |
| Write header with current type() More... | |
| bool | writeHeader (Ostream &os, const word &objectType) const |
| Write header with override of type. More... | |
| void | writeHeader (dictionary &dict, IOstreamOption streamOpt) const |
| Write header into a dictionary with current type() and given output format. More... | |
| void | writeHeader (dictionary &dict, const word &objectType, IOstreamOption streamOpt) const |
| Write header into a dictionary with override of type and given output format. More... | |
| bool | good () const noexcept |
| Did last readHeader() succeed? More... | |
| bool | bad () const noexcept |
| Did last readHeader() fail? More... | |
| InfoProxy< IOobject > | info () const noexcept |
| Return info proxy, for printing information to a stream. More... | |
| void | operator= (const IOobject &io) |
| Copy assignment, copies all values (except the registry) More... | |
| template<class Type > | |
| bool | isHeaderClassName () const |
| Same as isHeaderClass() More... | |
| template<class StringType > | |
| Foam::word | groupName (StringType base, const word &group) |
| template<class Type > | |
| bool | typeHeaderOk (const bool checkType, const bool search, const bool verbose) |
| template<class Type > | |
| Foam::fileName | typeFilePath (const bool search) const |
| Public Member Functions inherited from IOobjectOption | |
| constexpr | IOobjectOption (readOption rOpt=readOption::NO_READ, writeOption wOpt=writeOption::NO_WRITE, registerOption registerObject=registerOption::REGISTER, bool globalObject=false) noexcept |
| Default construct (NO_READ, NO_WRITE, REGISTER, non-global) or construct with specified options. More... | |
| constexpr | IOobjectOption (readOption rOpt, registerOption registerObject=registerOption::REGISTER, bool globalObject=false) noexcept |
| Construct NO_WRITE with specified read/register options. More... | |
| constexpr | IOobjectOption (writeOption wOpt, registerOption registerObject=registerOption::REGISTER, bool globalObject=false) noexcept |
| Construct NO_READ with specified write/register options. More... | |
| constexpr | IOobjectOption (registerOption registerObject, bool globalObject=false) noexcept |
| Construct (NO_READ, NO_WRITE) with specified register option. More... | |
| constexpr | IOobjectOption (readOption rOpt, writeOption wOpt, bool registerObject, bool globalObject=false) noexcept |
| Construct from components with specified register option as bool. More... | |
| constexpr | IOobjectOption (bool registerObject, bool globalObject=false) noexcept |
| Construct (NO_READ, NO_WRITE) with specified register option as bool. More... | |
| readOption | readOpt () const noexcept |
| Get the read option. More... | |
| readOption | readOpt (readOption opt) noexcept |
| Set the read option. More... | |
| writeOption | writeOpt () const noexcept |
| Get the write option. More... | |
| writeOption | writeOpt (writeOption opt) noexcept |
| Set the write option. More... | |
| bool | registerObject () const noexcept |
| Should objects created with this IOobject be registered? More... | |
| bool | registerObject (bool on) noexcept |
| Change registration preference. More... | |
| bool | globalObject () const noexcept |
| True if object is treated the same for all processors. More... | |
| bool | globalObject (bool on) noexcept |
| Change global-object status. More... | |
| bool | isAnyRead () const noexcept |
| True if any reading may be required (ie, != NO_READ) More... | |
| bool | isReadRequired () const noexcept |
| True if (MUST_READ | READ_MODIFIED) bits are set. More... | |
| bool | isReadOptional () const noexcept |
| True if (LAZY_READ) bits are set [same as READ_IF_PRESENT]. More... | |
| readOption & | readOpt () noexcept |
| Access to the read option. More... | |
| writeOption & | writeOpt () noexcept |
| Access to the write option. More... | |
| bool & | registerObject () noexcept |
| Access to the register object option. More... | |
| bool & | globalObject () noexcept |
| Access to the global object option. More... | |
| Public Member Functions inherited from dictionary | |
| ClassName ("dictionary") | |
| dictionary () | |
| Default construct, a top-level empty dictionary. More... | |
| dictionary (const fileName &name) | |
| Construct top-level empty dictionary with given name. More... | |
| dictionary (const fileName &name, const dictionary &parentDict, Istream &is, bool keepHeader=false) | |
| Construct given the entry name, parent dictionary and Istream, reading entries until EOF, optionally keeping the header. More... | |
| dictionary (Istream &is) | |
| Construct top-level dictionary from Istream (discards the header). Reads entries until EOF or when the first token is a '{' character, it will stop reading at the matching '}' character. More... | |
| dictionary (Istream &is, bool keepHeader) | |
| Construct top-level dictionary from Istream, reading entries until EOF, optionally keeping the header. More... | |
| dictionary (const dictionary &parentDict, const dictionary &dict) | |
| Copy construct given the parent dictionary. More... | |
| dictionary (const dictionary &dict) | |
| Copy construct top-level dictionary. More... | |
| dictionary (const dictionary *dict) | |
| Construct top-level dictionary as copy from pointer to dictionary. More... | |
| dictionary (const dictionary &parentDict, dictionary &&dict) | |
| Move construct for given parent dictionary. More... | |
| dictionary (dictionary &&dict) | |
| Move construct top-level dictionary. More... | |
| autoPtr< dictionary > | clone () const |
| Construct and return clone. More... | |
| virtual | ~dictionary () |
| Destructor. More... | |
| const fileName & | name () const noexcept |
| The dictionary name. More... | |
| fileName & | name () noexcept |
| The dictionary name for modification (use with caution). More... | |
| word | dictName () const |
| The local dictionary name (final part of scoped name) More... | |
| fileName | relativeName (const bool caseTag=false) const |
| The dictionary name relative to the case. More... | |
| bool | isNullDict () const noexcept |
| The dictionary is actually dictionary::null (root dictionary) More... | |
| const dictionary & | parent () const noexcept |
| Return the parent dictionary. More... | |
| const dictionary & | topDict () const |
| Return the top of the tree. More... | |
| label | startLineNumber () const |
| Return line number of first token in dictionary. More... | |
| label | endLineNumber () const |
| Return line number of last token in dictionary. More... | |
| SHA1Digest | digest () const |
| Return the SHA1 digest of the dictionary contents. More... | |
| tokenList | tokens () const |
| Return the dictionary as a list of tokens. More... | |
| const entry * | findEntry (const word &keyword, enum keyType::option matchOpt=keyType::REGEX) const |
| Find an entry (const access) with the given keyword. More... | |
| entry * | findEntry (const word &keyword, enum keyType::option matchOpt=keyType::REGEX) |
| Find an entry (non-const access) with the given keyword. More... | |
| bool | found (const word &keyword, enum keyType::option matchOpt=keyType::REGEX) const |
| Find an entry (const access) with the given keyword. More... | |
| const entry * | findScoped (const word &keyword, enum keyType::option matchOpt=keyType::REGEX) const |
| Search for a scoped entry (const access) with the given keyword. More... | |
| const dictionary * | findDict (const word &keyword, enum keyType::option matchOpt=keyType::REGEX) const |
| Find and return a sub-dictionary pointer if present (and it is a dictionary) otherwise return nullptr. More... | |
| dictionary * | findDict (const word &keyword, enum keyType::option matchOpt=keyType::REGEX) |
| Find and return a sub-dictionary pointer if present (and it is a dictionary) otherwise return nullptr. More... | |
| ITstream * | findStream (const word &keyword, enum keyType::option matchOpt=keyType::REGEX) const |
| Find and return an entry stream if present (and it is a stream) otherwise return nullptr. More... | |
| const entry & | lookupEntry (const word &keyword, enum keyType::option matchOpt) const |
| Search for an entry (const access) with the given keyword. More... | |
| ITstream & | lookup (const word &keyword, enum keyType::option matchOpt=keyType::REGEX) const |
| Find and return an entry data stream. FatalIOError if not found, or not a stream. More... | |
| template<class T > | |
| T | get (const word &keyword, enum keyType::option matchOpt=keyType::REGEX) const |
| Find and return a T. FatalIOError if not found, or if the number of tokens is incorrect. More... | |
| template<class T > | |
| T | getOrDefault (const word &keyword, const T &deflt, enum keyType::option matchOpt=keyType::REGEX) const |
| Find and return a T, or return the given default value. FatalIOError if it is found and the number of tokens is incorrect. More... | |
| template<class T > | |
| T | getOrAdd (const word &keyword, const T &deflt, enum keyType::option matchOpt=keyType::REGEX) |
| Find and return a T, or return the given default value and add it to dictionary. FatalIOError if it is found and the number of tokens is incorrect. More... | |
| template<class T > | |
| bool | readEntry (const word &keyword, T &val, enum keyType::option matchOpt=keyType::REGEX, IOobjectOption::readOption readOpt=IOobjectOption::MUST_READ) const |
| Find entry and assign to T val. FatalIOError if it is found and the number of tokens is incorrect, or it is mandatory and not found. More... | |
| template<class T > | |
| bool | readIfPresent (const word &keyword, T &val, enum keyType::option matchOpt=keyType::REGEX) const |
| Find an entry if present, and assign to T val. FatalIOError if it is found and the number of tokens is incorrect. More... | |
| template<class T , class Predicate > | |
| T | getCheck (const word &keyword, const Predicate &pred, enum keyType::option matchOpt=keyType::REGEX) const |
| Find and return a T with additional checking FatalIOError if not found, or if the number of tokens is incorrect. More... | |
| template<class T , class Predicate > | |
| T | getCheckOrDefault (const word &keyword, const T &deflt, const Predicate &pred, enum keyType::option matchOpt=keyType::REGEX) const |
| Find and return a T, or return the given default value. FatalIOError if it is found and the number of tokens is incorrect. More... | |
| template<class T , class Predicate > | |
| T | getCheckOrAdd (const word &keyword, const T &deflt, const Predicate &pred, enum keyType::option matchOpt=keyType::REGEX) |
| Find and return a T, or return the given default value and add it to dictionary. FatalIOError if it is found and the number of tokens is incorrect. More... | |
| template<class T , class Predicate > | |
| bool | readCheck (const word &keyword, T &val, const Predicate &pred, enum keyType::option matchOpt=keyType::REGEX, IOobjectOption::readOption readOpt=IOobjectOption::MUST_READ) const |
| Find entry and assign to T val. FatalIOError if it is found and the number of tokens is incorrect, or it is mandatory and not found. More... | |
| template<class T , class Predicate > | |
| bool | readCheckIfPresent (const word &keyword, T &val, const Predicate &pred, enum keyType::option matchOpt=keyType::REGEX) const |
| Find an entry if present, and assign to T val. FatalIOError if it is found and the number of tokens is incorrect. More... | |
| const dictionary & | subDict (const word &keyword, enum keyType::option matchOpt=keyType::REGEX) const |
| Find and return a sub-dictionary. More... | |
| dictionary & | subDict (const word &keyword, enum keyType::option matchOpt=keyType::REGEX) |
| Find and return a sub-dictionary for manipulation. More... | |
| dictionary & | subDictOrAdd (const word &keyword, enum keyType::option matchOpt=keyType::REGEX) |
| Find and return a sub-dictionary for manipulation. More... | |
| dictionary | subOrEmptyDict (const word &keyword, enum keyType::option matchOpt=keyType::REGEX, const bool mandatory=false) const |
| Find and return a sub-dictionary as a copy, otherwise return an empty dictionary. More... | |
| const dictionary & | optionalSubDict (const word &keyword, enum keyType::option matchOpt=keyType::REGEX) const |
| Find and return a sub-dictionary, otherwise return this dictionary. More... | |
| wordList | toc () const |
| Return the table of contents. More... | |
| wordList | sortedToc () const |
| Return the sorted table of contents. More... | |
| template<class Compare > | |
| wordList | sortedToc (const Compare &comp) const |
| Return table of contents sorted using the specified comparator. More... | |
| List< keyType > | keys (bool patterns=false) const |
| Return the list of available keys or patterns. More... | |
| bool | substituteKeyword (const word &keyword, bool mergeEntry=false) |
| Substitute the given keyword (which is prefixed by '$') More... | |
| bool | substituteScopedKeyword (const word &keyword, bool mergeEntry=false) |
| Substitute the given scoped keyword (which is prefixed by '$') More... | |
| entry * | add (entry *entryPtr, bool mergeEntry=false) |
| Add a new entry. More... | |
| entry * | add (const entry &e, bool mergeEntry=false) |
| Add an entry. More... | |
| entry * | add (const keyType &k, const word &v, bool overwrite=false) |
| Add a word entry. More... | |
| entry * | add (const keyType &k, const string &v, bool overwrite=false) |
| Add a string entry. More... | |
| entry * | add (const keyType &k, const label v, bool overwrite=false) |
| Add a label entry. More... | |
| entry * | add (const keyType &k, const scalar v, bool overwrite=false) |
| Add a scalar entry. More... | |
| entry * | add (const keyType &k, const dictionary &d, bool mergeEntry=false) |
| Add a dictionary entry. More... | |
| template<class T > | |
| entry * | add (const keyType &k, const T &v, bool overwrite=false) |
| Add a T entry. More... | |
| entry * | set (entry *entryPtr) |
| Assign a new entry, overwriting any existing entry. More... | |
| entry * | set (const entry &e) |
| Assign a new entry, overwriting any existing entry. More... | |
| entry * | set (const keyType &k, const dictionary &v) |
| Assign a dictionary entry, overwriting any existing entry. More... | |
| entry * | set (const keyType &k, std::nullptr_t) |
| Assign an empty primitive entry, overwriting any existing entry. More... | |
| entry * | set (const keyType &k, const UList< token > &tokens) |
| Assign a primitive entry from a list of tokens, overwriting any existing entry. More... | |
| entry * | set (const keyType &k, List< token > &&tokens) |
| Assign a primitive entry from a list of tokens, overwriting any existing entry. More... | |
| template<class T > | |
| entry * | set (const keyType &k, const T &v) |
| Assign a T entry, overwriting any existing entry. More... | |
| bool | remove (const word &keyword) |
| Remove an entry specified by keyword. More... | |
| bool | changeKeyword (const keyType &oldKeyword, const keyType &newKeyword, bool overwrite=false) |
| Change the keyword for an entry,. More... | |
| bool | merge (const dictionary &dict) |
| Merge entries from the given dictionary. More... | |
| void | clear () |
| Clear the dictionary. More... | |
| void | transfer (dictionary &dict) |
| Transfer the contents of the argument and annul the argument. More... | |
| void | checkITstream (const ITstream &is, const word &keyword) const |
| Check after reading if the input token stream has unconsumed tokens remaining or if there were no tokens in the first place. More... | |
| bool | read (Istream &is) |
| Read dictionary from Istream (discards the header). Reads entries until EOF or when the first token is a '{' character, it will stop reading at the matching '}' character. More... | |
| bool | read (Istream &is, bool keepHeader) |
| Read dictionary from Istream (optionally keeping the header) Reads entries until EOF or when the first token is a '{' character, it will stop reading at the matching '}' character. More... | |
| void | writeEntry (Ostream &os) const |
| Write sub-dictionary with its dictName as its header. More... | |
| void | writeEntry (const keyType &keyword, Ostream &os) const |
| Write sub-dictionary with the keyword as its header. More... | |
| void | writeEntries (Ostream &os, const bool extraNewLine=false) const |
| Write dictionary entries. More... | |
| void | write (Ostream &os, const bool subDict=true) const |
| Write dictionary, normally with sub-dictionary formatting. More... | |
| const_searcher | csearch (const word &keyword, enum keyType::option matchOpt=keyType::REGEX) const |
| Search dictionary for given keyword. More... | |
| const_searcher | search (const word &keyword, enum keyType::option matchOpt=keyType::REGEX) const |
| Search dictionary for given keyword. More... | |
| searcher | search (const word &keyword, enum keyType::option matchOpt=keyType::REGEX) |
| Search dictionary for given keyword. More... | |
| const_searcher | csearchScoped (const word &keyword, enum keyType::option matchOpt) const |
| Search using scoping. More... | |
| const_searcher | searchScoped (const word &keyword, enum keyType::option matchOpt) const |
| Search using dot or slash scoping. More... | |
| searcher | searchScoped (const word &keyword, enum keyType::option matchOpt) |
| Search using dot or slash scoping. More... | |
| const dictionary * | cfindScopedDict (const fileName &dictPath) const |
| Locate a sub-dictionary using slash-scoping. More... | |
| const dictionary * | findScopedDict (const fileName &dictPath) const |
| Locate a sub-dictionary using slash-scoping. More... | |
| dictionary * | findScopedDict (const fileName &dictPath) |
| Locate a sub-dictionary using slash-scoping. More... | |
| dictionary * | makeScopedDict (const fileName &dictPath) |
| Locate existing or create sub-dictionary using slash-scoping. More... | |
| const_searcher | csearchCompat (const word &keyword, std::initializer_list< std::pair< const char *, int >> compat, enum keyType::option matchOpt=keyType::REGEX) const |
| Search dictionary for given keyword and any compatibility names. More... | |
| const entry * | findCompat (const word &keyword, std::initializer_list< std::pair< const char *, int >> compat, enum keyType::option matchOpt) const |
| Find and return an entry pointer if present, or return a nullptr, using any compatibility names if needed. More... | |
| bool | foundCompat (const word &keyword, std::initializer_list< std::pair< const char *, int >> compat, enum keyType::option matchOpt=keyType::REGEX) const |
| Search dictionary for given keyword and any compatibility names. More... | |
| const entry & | lookupEntryCompat (const word &keyword, std::initializer_list< std::pair< const char *, int >> compat, enum keyType::option matchOpt) const |
| Find and return an entry if present, otherwise FatalIOError, using any compatibility names if needed. More... | |
| ITstream & | lookupCompat (const word &keyword, std::initializer_list< std::pair< const char *, int >> compat, enum keyType::option matchOpt=keyType::REGEX) const |
| Find and return an entry data stream, using any compatibility names if needed. More... | |
| template<class T > | |
| T | getCompat (const word &keyword, std::initializer_list< std::pair< const char *, int >> compat, enum keyType::option matchOpt=keyType::REGEX) const |
| Find and return a T using any compatibility names if needed. FatalIOError if not found, or if there are excess tokens. More... | |
| template<class T > | |
| T | getOrDefaultCompat (const word &keyword, std::initializer_list< std::pair< const char *, int >> compat, const T &deflt, enum keyType::option matchOpt=keyType::REGEX) const |
| Find and return a T, or return the given default value using any compatibility names if needed. More... | |
| template<class T > | |
| bool | readCompat (const word &keyword, std::initializer_list< std::pair< const char *, int >> compat, T &val, enum keyType::option matchOpt=keyType::REGEX, IOobjectOption::readOption readOpt=IOobjectOption::MUST_READ) const |
| Find entry and assign to T val using any compatibility names if needed. FatalIOError if there are excess tokens. More... | |
| template<class T > | |
| bool | readIfPresentCompat (const word &keyword, std::initializer_list< std::pair< const char *, int >> compat, T &val, enum keyType::option matchOpt=keyType::REGEX) const |
| Find an entry if present, and assign to T val using any compatibility names if needed. FatalIOError if it is found and there are excess tokens. More... | |
| void | operator= (const dictionary &rhs) |
| Copy assignment. More... | |
| void | operator+= (const dictionary &rhs) |
| Include entries from the given dictionary. More... | |
| void | operator|= (const dictionary &rhs) |
| Conditionally include entries from the given dictionary. More... | |
| void | operator<<= (const dictionary &rhs) |
| Unconditionally include entries from the given dictionary. More... | |
| bool | getBool (const word &keyword, enum keyType::option matchOpt=keyType::REGEX) const |
| Same as get< bool >(const word&, keyType::option) More... | |
| label | getLabel (const word &keyword, enum keyType::option matchOpt=keyType::REGEX) const |
| Same as get< label >(const word&, keyType::option) More... | |
| scalar | getScalar (const word &keyword, enum keyType::option matchOpt=keyType::REGEX) const |
| Same as get< scalar >(const word&, keyType::option) More... | |
| string | getString (const word &keyword, enum keyType::option matchOpt=keyType::REGEX) const |
| Same as get< string >(const word&, keyType::option) More... | |
| word | getWord (const word &keyword, enum keyType::option matchOpt=keyType::REGEX) const |
| Same as get< word >(const word&, keyType::option) More... | |
| fileName | getFileName (const word &keyword, enum keyType::option matchOpt=keyType::REGEX) const |
| Same as get< fileName >(const word&, keyType::option) More... | |
| bool | isDict (const word &keyword, enum keyType::option matchOpt=keyType::REGEX) const |
| Check for existence of a sub-dictionary. Generally prefer findDict() for more flexibility. More... | |
| template<class T > | |
| T | lookupOrDefault (const word &keyword, const T &deflt, enum keyType::option matchOpt=keyType::REGEX) const |
| Same as getOrDefault() More... | |
| template<class T > | |
| T | lookupOrAddDefault (const word &keyword, const T &deflt, enum keyType::option matchOpt=keyType::REGEX) |
| Same as getOrAdd() More... | |
| ITstream & | operator[] (const word &keyword) const |
| Deprecated(2018-07) - use lookup() method. More... | |
| bool | found (const word &keyword, bool recursive, bool patternMatch=true) const |
| Deprecated(2018-10) More... | |
| entry * | lookupEntryPtr (const word &keyword, bool recursive, bool patternMatch) |
| Deprecated(2018-10) More... | |
| const entry * | lookupEntryPtr (const word &keyword, bool recursive, bool patternMatch) const |
| Deprecated(2018-10) More... | |
| const entry * | lookupScopedEntryPtr (const word &keyword, bool recursive, bool patternMatch) const |
| Deprecated(2018-10) More... | |
| const dictionary * | subDictPtr (const word &keyword) const |
| Deprecated(2018-10) More... | |
| dictionary * | subDictPtr (const word &keyword) |
| Deprecated(2018-10) Find and return a sub-dictionary pointer if present. More... | |
| const entry & | lookupEntry (const word &keyword, bool recursive, bool patternMatch) const |
| Deprecated(2018-10) More... | |
| ITstream & | lookup (const word &keyword, bool recursive, bool patternMatch=true) const |
| Deprecated(2018-10) More... | |
| template<class T > | |
| T | lookupOrDefault (const word &keyword, const T &deflt, bool recursive, bool patternMatch=true) const |
| Deprecated(2018-10) More... | |
| template<class T > | |
| T | lookupOrAddDefault (const word &keyword, const T &deflt, bool recursive, bool patternMatch=true) |
| Deprecated(2018-10) More... | |
| template<class T > | |
| bool | readIfPresent (const word &keyword, T &val, bool recursive, bool patternMatch=true) const |
| Deprecated(2018-10) More... | |
| template<class T > | |
| T | lookupType (const word &keyword, bool recursive=false, bool patternMatch=true) const |
| Deprecated(2018-10) find and return a T. More... | |
| template<class Compare > | |
| Foam::wordList | sortedToc (const Compare &comp) const |
| template<class T > | |
| Foam::entry * | add (const keyType &k, const T &v, bool overwrite) |
| template<class T > | |
| Foam::entry * | set (const keyType &k, const T &v) |
| Public Member Functions inherited from ILList< LListBase, T > | |
| ILList ()=default | |
| Default construct. More... | |
| ILList (T *item) | |
| Construct and add initial item pointer. More... | |
| ILList (Istream &is) | |
| Construct from Istream. More... | |
| ILList (const ILList< LListBase, T > &lst) | |
| Copy construct using the 'clone()' method for each element. More... | |
| ILList (ILList< LListBase, T > &&lst) | |
| Move construct. More... | |
| template<class CloneArg > | |
| ILList (const ILList< LListBase, T > &lst, const CloneArg &cloneArg) | |
| Copy constructor with additional argument for clone 'clone()'. More... | |
| template<class INew > | |
| ILList (Istream &is, const INew &inew) | |
| Construct from Istream using given Istream constructor class. More... | |
| ~ILList () | |
| Destructor. Calls clear() More... | |
| void | clear () |
| Clear the contents of the list. More... | |
| void | pop_front (label n=1) |
| Remove first element(s) from the list (deletes pointers) More... | |
| bool | erase (T *item) |
| Remove the specified element from the list and delete it. More... | |
| void | transfer (ILList< LListBase, T > &lst) |
| Transfer the contents of the argument into this List and annul the argument list. More... | |
| void | operator= (const ILList< LListBase, T > &lst) |
| Copy assignment using the 'clone()' method for each element. More... | |
| void | operator= (ILList< LListBase, T > &&lst) |
| Move assignment. More... | |
| Public Member Functions inherited from UILList< LListBase, T > | |
| UILList ()=default | |
| Default construct. More... | |
| UILList (T *item) | |
| Construct and add initial item pointer. More... | |
| UILList (const UILList< LListBase, T > &list) | |
| Construct as copy. More... | |
| T * | front () |
| The first entry in the list. More... | |
| const T * | front () const |
| The first entry in the list (const access) More... | |
| T * | back () |
| The last entry in the list. More... | |
| const T * | back () const |
| The last entry in the list (const access) More... | |
| T * | removeHead () |
| Remove and return head. More... | |
| T * | remove (T *item) |
| Remove and return element. More... | |
| T * | remove (iterator &iter) |
| Remove and return item specified by iterator. More... | |
| void | operator= (const UILList< LListBase, T > &lst) |
| Copy assignment. More... | |
| bool | operator== (const UILList< LListBase, T > &lst) const |
| Equality. True both lists are element-wise equal. More... | |
| bool | operator!= (const UILList< LListBase, T > &lst) const |
| The opposite of the equality operation. Takes linear time. More... | |
| Ostream & | writeList (Ostream &os, const label shortLen=0) const |
| Write UILList with line-breaks when length exceeds shortLen. More... | |
| iterator | begin () |
| Iterator to first item in list with non-const access. More... | |
| const_iterator | cbegin () const |
| Iterator to first item in list with const access. More... | |
| reverse_iterator | rbegin () |
| Iterator to last item in list with non-const access. More... | |
| const_reverse_iterator | crbegin () const |
| Iterator to last item in list with const access. More... | |
| const_iterator | begin () const |
| Iterator to first item in list with const access. More... | |
| const_reverse_iterator | rbegin () const |
| Iterator to last item in list with const access. More... | |
| const iterator & | end () |
| End of list for forward iterators. More... | |
| const const_iterator & | cend () const |
| End of list for forward iterators. More... | |
| const reverse_iterator & | rend () |
| End of list for reverse iterators. More... | |
| const const_reverse_iterator & | crend () const |
| End of list for reverse iterators. More... | |
| const const_iterator & | end () const |
| End of list for forward iterators. More... | |
| const const_reverse_iterator & | rend () const |
| End of list for reverse iterators. More... | |
| T * | first () |
| The first entry in the list. More... | |
| const T * | first () const |
| The first entry in the list (const access) More... | |
| T * | last () |
| The last entry in the list. More... | |
| const T * | last () const |
| The last entry in the list (const access) More... | |
| Public Member Functions inherited from compressibleTransportModel | |
| TypeName ("compressibleTransportModel") | |
| Runtime type information. More... | |
| compressibleTransportModel () | |
| Construct from components. More... | |
| virtual | ~compressibleTransportModel () |
| Destructor. More... | |
Static Public Attributes | |
| static const word | phasePropertiesName |
| Default name of the phase properties dictionary. More... | |
| Static Public Attributes inherited from basicThermo | |
| static const word | dictName |
| The dictionary name ("thermophysicalProperties") More... | |
| Static Public Attributes inherited from IOobject | |
| static const Enum< fileCheckTypes > | fileCheckTypesNames |
| Names for the fileCheckTypes. More... | |
| static char | scopeSeparator |
| Character for scoping object names (':' or '_') More... | |
| static fileCheckTypes | fileModificationChecking |
| Type of file modification checking. More... | |
| static float | fileModificationSkew |
| Time skew (seconds) for file modification checks. More... | |
| static int | maxFileModificationPolls |
| Max number of times to poll for file modification changes. More... | |
| Static Public Attributes inherited from dictionary | |
| static int | writeOptionalEntries |
| Report optional keywords and values if not present in dictionary. More... | |
| static const dictionary | null |
| An empty dictionary, which is also the parent for all dictionaries. More... | |
| static refPtr< OSstream > | reportingOutput |
| Output location when reporting default values. More... | |
Protected Types | |
| typedef HashTable< dictionary, phasePairKey, phasePairKey::hash > | dictTable |
| typedef HashTable< autoPtr< multiphaseInter::surfaceTensionModel >, phasePairKey, phasePairKey::hash > | surfaceTensionModelTable |
| typedef HashTable< autoPtr< porousModel >, phasePairKey, phasePairKey::hash > | interfacePorousModelTable |
Protected Member Functions | |
| void | calcMu () |
| Calculate and return the laminar viscosity. More... | |
| HashTable< autoPtr< multiphaseInter::phaseModel > > | generatePhaseModels (const wordList &names) const |
| Generate the phases. More... | |
| tmp< surfaceScalarField > | generatePhi (const HashTable< autoPtr< multiphaseInter::phaseModel >> &phaseModels) const |
| Generate the mixture flux. More... | |
| void | generatePairs (const dictTable &modelDicts) |
| Generate pairs. More... | |
| void | generatePairsTable () |
| Generate pair table. More... | |
| template<class modelType > | |
| void | createSubModels (const dictTable &modelDicts, HashTable< autoPtr< modelType >, phasePairKey, phasePairKey::hash > &models) |
| Generate pairs and sub-model tables using pair keys. More... | |
| template<class modelType > | |
| void | createSubModels (const dictTable &modelDicts, const fvMesh &mesh, HashTable< autoPtr< modelType >, phasePairKey, phasePairKey::hash > &models) |
| Generate pairs and sub-model tables using mesh. More... | |
| template<class modelType > | |
| void | generatePairsAndSubModels (const word &modelName, HashTable< autoPtr< modelType >, phasePairKey, phasePairKey::hash > &models) |
| Generate pairs and sub-model tables. More... | |
| template<class modelType > | |
| void | generatePairsAndSubModels (const word &modelName, const fvMesh &mesh, HashTable< autoPtr< modelType >, phasePairKey, phasePairKey::hash > &models) |
| Generate pairs and per-phase sub-model tables with mesh ref. More... | |
| template<class modelType > | |
| void | generatePairsAndSubModels (const word &modelName, HashTable< HashTable< autoPtr< modelType >>, phasePairKey, phasePairKey::hash > &models) |
| Generate pairs and per-phase sub-model tables. More... | |
| Protected Member Functions inherited from basicThermo | |
| wordList | heBoundaryTypes () |
| Return the enthalpy/internal energy field boundary types by interrogating the temperature field boundary types. More... | |
| wordList | heBoundaryBaseTypes () |
| Return the enthalpy/internal energy field boundary base types by interrogating the temperature field boundary types. More... | |
| basicThermo (const basicThermo &)=delete | |
| No copy construct. More... | |
| Protected Member Functions inherited from regIOobject | |
| bool | readHeaderOk (const IOstreamOption::streamFormat fmt, const word &typeName) |
| Helper: check readOpt flags and read if necessary. More... | |
| Protected Member Functions inherited from IOobject | |
| void | setBad (const string &s) |
| Set the object state to bad. More... | |
Protected Attributes | |
| const fvMesh & | mesh_ |
| Reference to the mesh. More... | |
| volScalarField | mu_ |
| Dynamic viscocity. More... | |
| wordList | phaseNames_ |
| Phase names. More... | |
| surfaceScalarField | phi_ |
| Mixture total volumetric flux. More... | |
| surfaceScalarField | rhoPhi_ |
| Mixture total mass flux. More... | |
| phaseModelTable | phaseModels_ |
| Phase models. More... | |
| phasePairTable | phasePairs_ |
| Phase pairs. More... | |
| phasePairTable | totalPhasePairs_ |
| Total ordered phase pairs in the system. More... | |
| dimensionedScalar | Prt_ |
| Turbulent Prandt number. More... | |
| compressibleTurbulenceModel * | turb_ |
| Turbulence model. More... | |
| surfaceTensionModelTable | surfaceTensionModels_ |
| Surface tension models. More... | |
| interfacePorousModelTable | interfacePorousModelTable_ |
| Interface porous models. More... | |
| Protected Attributes inherited from basicThermo | |
| const word & | phaseName_ |
| Phase-name. More... | |
| bool | pOwner_ |
| Pressure created and stored by this instance. More... | |
| bool | TOwner_ |
| Temperature created and stored by this instance. More... | |
| bool | dpdt_ |
| Include dpdt term in the enthalpy equation? More... | |
| volScalarField & | p_ |
| Pressure [Pa]. More... | |
| volScalarField & | T_ |
| Temperature [K]. More... | |
| volScalarField | alpha_ |
| Laminar thermal diffusivity [kg/m/s]. More... | |
Additional Inherited Members | |
| Static Public Member Functions inherited from basicThermo | |
| template<class Thermo > | |
| static autoPtr< Thermo > | New (const fvMesh &, const word &phaseName=word::null) |
| Generic New for each of the related thermodynamics packages. More... | |
| template<class Thermo > | |
| static autoPtr< Thermo > | New (const fvMesh &, const dictionary &, const word &phaseName=word::null) |
| Generic New for each of the related thermodynamics packages. More... | |
| template<class Thermo > | |
| static autoPtr< Thermo > | New (const fvMesh &, const word &phaseName, const word &dictName) |
| Generic New for each of the related thermodynamics packages. More... | |
| static autoPtr< basicThermo > | New (const fvMesh &, const word &phaseName=word::null) |
| Specialisation of the Generic New for basicThermo. More... | |
| static word | phasePropertyName (const word &name, const word &phaseName) |
| The phase property name as property.phase. More... | |
| static const basicThermo & | lookupThermo (const fvPatchScalarField &pf) |
| static Ostream & | printThermoNames (Ostream &os, const wordList &cmptNames, const wordList &thermoNames) |
Print (filtered) table of thermo names, splits on " ,<>". More... | |
| static wordList | splitThermoName (const std::string &thermoName, const int nExpectedCmpts) |
| Split thermo package name into a list of components names. More... | |
| Static Public Member Functions inherited from IOdictionary | |
| static dictionary | readContents (const IOobject &io) |
| Read and return contents, testing for "dictionary" type. The IOobject will not be registered. More... | |
| static dictionary | readContents (const IOobject &io, const word &wantedType) |
| Read and return contents, testing for expected type. The IOobject will not be registered. More... | |
| Static Public Member Functions inherited from regIOobject | |
| template<class Type > | |
| static Type & | store (Type *p) |
| Transfer pointer ownership to its registry. More... | |
| template<class Type > | |
| static Type & | store (std::unique_ptr< Type > &&ptr) |
| Transfer pointer ownership to its registry. More... | |
| template<class Type > | |
| static Type & | store (autoPtr< Type > &ptr) |
| Transfer pointer ownership to its registry. More... | |
| template<class Type > | |
| static Type & | store (autoPtr< Type > &&ptr) |
| Transfer pointer ownership to its registry. More... | |
| template<class Type > | |
| static Type & | store (refPtr< Type > &ptr) |
| Transfer pointer ownership to its registry. More... | |
| template<class Type > | |
| static Type & | store (refPtr< Type > &&ptr) |
| Transfer pointer ownership to its registry. More... | |
| template<class Type > | |
| static Type & | store (tmp< Type > &ptr) |
| Transfer pointer ownership to its registry. More... | |
| template<class Type > | |
| static Type & | store (tmp< Type > &&ptr) |
| Transfer pointer ownership to its registry. More... | |
| Static Public Member Functions inherited from IOobject | |
| static bool | bannerEnabled () noexcept |
| Status of output file banner. More... | |
| static bool | bannerEnabled (bool on) noexcept |
| Enable/disable output file banner. More... | |
| static bool | fileModificationChecking_masterOnly () noexcept |
| Test fileModificationChecking for master-only. More... | |
| static bool | fileNameComponents (const fileName &path, fileName &instance, fileName &local, word &name) |
| Split path into instance, local, name components. More... | |
| template<class StringType > | |
| static word | groupName (StringType base, const word &group) |
| Create dot-delimited name.group string. More... | |
| static word | group (const word &name) |
| Return group (extension part of name) More... | |
| static word | member (const word &name) |
| Return member (name without the extension) More... | |
| static word | scopedName (const std::string &scope, const word &name) |
| Create scope:name or scope_name string. More... | |
| static word | scopedName (const std::string &scope, const word &name1, const word &name2) |
| Create scope:name1:name2 or scope_name1_name2 string. More... | |
| static IOobject | selectIO (const IOobject &io, const fileName &altFile, const word &ioName="") |
| Return the IOobject, but also consider an alternative file name. More... | |
| static Ostream & | writeBanner (Ostream &os, const bool noSyntaxHint=false) |
| Write the standard OpenFOAM file/dictionary banner. More... | |
| static Ostream & | writeDivider (Ostream &os) |
| Write the standard file section divider. More... | |
| static Ostream & | writeEndDivider (Ostream &os) |
| Write the standard end file divider. More... | |
| Static Public Member Functions inherited from IOobjectOption | |
| static bool | isAnyRead (readOption opt) noexcept |
| True if any reading may be required (ie, != NO_READ) More... | |
| static bool | isReadRequired (readOption opt) noexcept |
| True if (MUST_READ | READ_MODIFIED) bits are set. More... | |
| static bool | isReadOptional (readOption opt) noexcept |
| True if (LAZY_READ) bits are set [same as READ_IF_PRESENT]. More... | |
| static readOption | lazierRead (readOption opt) noexcept |
| Downgrade readOption optional (LAZY_READ), leaves NO_READ intact. More... | |
| Static Public Member Functions inherited from dictionary | |
| static int | reportOptional () noexcept |
| Return the state of reporting optional (default) entries. More... | |
| static int | reportOptional (const int level) noexcept |
| Change the state of reporting optional (default) entries. More... | |
| static autoPtr< dictionary > | New (Istream &is) |
| Construct top-level dictionary on freestore from Istream. More... | |
| Public Attributes inherited from dictionary | |
| friend | const_searcher |
| Declare friendship with the searcher classes. More... | |
| friend | searcher |
| Static Protected Member Functions inherited from IOobject | |
| static void | writeHeaderContent (Ostream &os, const IOobject &io, const word &objectType, const dictionary *metaDataDict=nullptr) |
| Helper: write content for FoamFile IOobject header with optional meta information. More... | |
| static void | writeHeaderContent (dictionary &dict, const IOobject &io, const word &objectType, IOstreamOption streamOpt, const dictionary *metaDataDict=nullptr) |
| Helper: write dictionary content for FoamFile header with optional meta information. More... | |
| Static Protected Attributes inherited from regIOobject | |
| static bool | masterOnlyReading = false |
| To flag master-only reading of objects. More... | |
Definition at line 64 of file multiphaseInterSystem.H.
| typedef HashTable< autoPtr<phasePair>, phasePairKey, phasePairKey::hash > phasePairTable |
Definition at line 78 of file multiphaseInterSystem.H.
Definition at line 81 of file multiphaseInterSystem.H.
| typedef HashTable<volScalarField::Internal> SuSpTable |
Definition at line 84 of file multiphaseInterSystem.H.
|
protected |
Definition at line 92 of file multiphaseInterSystem.H.
|
protected |
Definition at line 102 of file multiphaseInterSystem.H.
|
protected |
Definition at line 112 of file multiphaseInterSystem.H.
| multiphaseInterSystem | ( | const fvMesh & | mesh | ) |
|
virtual |
Destructor.
Definition at line 288 of file multiphaseInterSystem.C.
|
protected |
Calculate and return the laminar viscosity.
Definition at line 52 of file multiphaseInterSystem.C.
References multiphaseInterSystem::mu(), and multiphaseInterSystem::mu_.
|
protected |
Generate the phases.
Definition at line 60 of file multiphaseInterSystem.C.
References HashTable< T, Key, Hash >::insert(), and phaseModel::New().
|
protected |
Generate the mixture flux.
Definition at line 84 of file multiphaseInterSystem.C.
References HashTable< T, Key, Hash >::cbegin(), HashTable< T, Key, Hash >::cend(), Foam::fvc::interpolate(), GeometricField< scalar, fvsPatchField, surfaceMesh >::New(), IOobjectOption::NO_REGISTER, and phi.
|
protected |
Generate pairs.
Definition at line 106 of file multiphaseInterSystem.C.
References forAllConstIters(), and Foam::glTF::key().
|
protected |
Generate pair table.
Definition at line 153 of file multiphaseInterSystem.C.
References forAllConstIters(), Foam::glTF::key(), and Foam::name().
|
protected |
Generate pairs and sub-model tables using pair keys.
Definition at line 25 of file multiphaseInterSystemTemplates.H.
References forAllConstIters(), Foam::glTF::key(), and Foam::New().
|
protected |
Generate pairs and sub-model tables using mesh.
Definition at line 54 of file multiphaseInterSystemTemplates.H.
References forAllConstIters(), Foam::glTF::key(), mesh, and Foam::New().
|
protected |
Generate pairs and sub-model tables.
Definition at line 84 of file multiphaseInterSystemTemplates.H.
|
protected |
Generate pairs and per-phase sub-model tables with mesh ref.
Definition at line 104 of file multiphaseInterSystemTemplates.H.
References mesh.
|
protected |
Generate pairs and per-phase sub-model tables.
Definition at line 125 of file multiphaseInterSystemTemplates.H.
References forAllConstIters(), and Foam::glTF::key().
| TypeName | ( | "multiphaseInterSystem" | ) |
Runtime type information.
|
inlinevirtual |
Return access to the internal energy field [J/Kg].
Implements basicThermo.
Definition at line 332 of file multiphaseInterSystem.H.
References DimensionedField< Type, GeoMesh >::constCast(), NotImplemented, and GeometricField< scalar, fvPatchField, volMesh >::null().
|
inlinevirtual |
Return access to the internal energy field [J/Kg].
Implements basicThermo.
Definition at line 343 of file multiphaseInterSystem.H.
References NotImplemented, and GeometricField< scalar, fvPatchField, volMesh >::null().
|
virtual |
Enthalpy/Internal energy.
for given pressure and temperature [J/kg]
Implements basicThermo.
Definition at line 295 of file multiphaseInterSystem.C.
References NotImplemented.
|
virtual |
Enthalpy/Internal energy for cell-set [J/kg].
Implements basicThermo.
Definition at line 306 of file multiphaseInterSystem.C.
References NotImplemented.
|
virtual |
Enthalpy/Internal energy for patch [J/kg].
Implements basicThermo.
Definition at line 318 of file multiphaseInterSystem.C.
References NotImplemented.
|
virtual |
Chemical enthalpy of the mixture [J/kg].
Implements basicThermo.
Definition at line 329 of file multiphaseInterSystem.C.
References tmp< T >::ref().
|
virtual |
Temperature from enthalpy/internal energy for cell-set.
Implements basicThermo.
Definition at line 348 of file multiphaseInterSystem.C.
References NotImplemented.
|
virtual |
Temperature from enthalpy/internal energy for patch.
Implements basicThermo.
Definition at line 361 of file multiphaseInterSystem.C.
References NotImplemented.
|
virtual |
Return the mixture density.
Implements basicThermo.
Definition at line 373 of file multiphaseInterSystem.C.
References tmp< T >::ref(), and rho.
|
virtual |
Return the mixture density on a patch.
Implements basicThermo.
Definition at line 392 of file multiphaseInterSystem.C.
References tmp< T >::ref(), and rho.
|
virtual |
Return Cp of the mixture.
Implements basicThermo.
Definition at line 417 of file multiphaseInterSystem.C.
References multiphaseInterSystem::Cp(), and tmp< T >::ref().
Referenced by multiphaseInterSystem::Cp().
|
virtual |
Heat capacity at constant pressure for patch [J/kg/K].
Implements basicThermo.
Definition at line 436 of file multiphaseInterSystem.C.
References Cp, p, tmp< T >::ref(), and Foam::T().
|
inlinevirtual |
Heat capacity using pressure and temperature.
Implements basicThermo.
Definition at line 439 of file multiphaseInterSystem.H.
References NotImplemented.
|
virtual |
Return Cv of the mixture.
Implements basicThermo.
Definition at line 458 of file multiphaseInterSystem.C.
References Cv, and tmp< T >::ref().
|
virtual |
Heat capacity at constant volume for patch [J/kg/K].
Implements basicThermo.
Definition at line 477 of file multiphaseInterSystem.C.
References Cv, p, tmp< T >::ref(), and Foam::T().
|
virtual |
Density from pressure and temperature.
Implements basicThermo.
Definition at line 500 of file multiphaseInterSystem.C.
References NotImplemented.
|
virtual |
Gamma = Cp/Cv [].
Implements basicThermo.
Definition at line 511 of file multiphaseInterSystem.C.
References Cp, Cv, and tmp< T >::ref().
|
virtual |
Gamma = Cp/Cv for patch [].
Implements basicThermo.
Definition at line 536 of file multiphaseInterSystem.C.
References gamma.
|
virtual |
Heat capacity at constant pressure/volume [J/kg/K].
Implements basicThermo.
Definition at line 549 of file multiphaseInterSystem.C.
References tmp< T >::ref().
|
virtual |
Heat capacity at constant pressure/volume for patch [J/kg/K].
Implements basicThermo.
Definition at line 568 of file multiphaseInterSystem.C.
References p, tmp< T >::ref(), and Foam::T().
|
virtual |
Heat capacity ratio [].
Implements basicThermo.
Definition at line 590 of file multiphaseInterSystem.C.
References tmp< T >::ref().
|
virtual |
Heat capacity ratio for patch [].
Implements basicThermo.
Definition at line 609 of file multiphaseInterSystem.C.
References p, tmp< T >::ref(), and Foam::T().
|
virtual |
Molecular weight [kg/kmol] of the mixture.
Implements basicThermo.
Definition at line 636 of file multiphaseInterSystem.C.
References NotImplemented.
|
virtual |
Thermal diffusivity for temperature of mixture [J/m/s/K].
Implements basicThermo.
Definition at line 643 of file multiphaseInterSystem.C.
References Foam::constant::electromagnetic::kappa, and tmp< T >::ref().
|
virtual |
Thermal diffusivity for temperature.
of mixture for patch [J/m/s/K]
Implements basicThermo.
Definition at line 662 of file multiphaseInterSystem.C.
References Foam::constant::electromagnetic::kappa, and tmp< T >::ref().
|
virtual |
Thermal diffusivity for energy of mixture [kg/m/s].
Implements basicThermo.
Definition at line 687 of file multiphaseInterSystem.C.
References tmp< T >::ref().
|
virtual |
Thermal diffusivity for energy of mixture for patch [kg/m/s].
Implements basicThermo.
Definition at line 706 of file multiphaseInterSystem.C.
References tmp< T >::ref().
|
virtual |
Effective thermal diffusivity for temperature.
of mixture [J/m/s/K]
Implements basicThermo.
Definition at line 730 of file multiphaseInterSystem.C.
References Foam::constant::electromagnetic::kappa, and kappaEff.
Referenced by temperatureCoupledBase::kappa().
|
virtual |
Effective thermal diffusivity for temperature.
of mixture for patch [J/m/s/K]
Implements basicThermo.
Definition at line 741 of file multiphaseInterSystem.C.
References Foam::constant::electromagnetic::kappa.
|
virtual |
Effective thermal diffusivity of mixture [kg/m/s].
Implements basicThermo.
Definition at line 751 of file multiphaseInterSystem.C.
References Foam::constant::atomic::alpha, and tmp< T >::ref().
|
virtual |
Effective thermal diffusivity of mixture for patch [kg/m/s].
Implements basicThermo.
Definition at line 774 of file multiphaseInterSystem.C.
References Foam::constant::atomic::alpha, and tmp< T >::ref().
| const Foam::dimensionedScalar & Prt | ( | ) | const |
Return Prandt number.
Definition at line 802 of file multiphaseInterSystem.C.
|
virtual |
Dynamic viscosity of mixture [kg/m/s].
Implements compressibleTransportModel.
Definition at line 808 of file multiphaseInterSystem.C.
References Foam::constant::physicoChemical::mu, and tmp< T >::ref().
Referenced by multiphaseInterSystem::calcMu().
|
virtual |
Dynamic viscosity of mixture for patch [kg/m/s].
Implements compressibleTransportModel.
Definition at line 827 of file multiphaseInterSystem.C.
References Foam::constant::physicoChemical::mu, and tmp< T >::ref().
|
virtual |
Kinematic viscosity of mixture [m^2/s].
Implements compressibleTransportModel.
Definition at line 852 of file multiphaseInterSystem.C.
References nu, and tmp< T >::ref().
|
virtual |
Kinematic viscosity of mixture for patch [m^2/s].
Implements compressibleTransportModel.
Definition at line 871 of file multiphaseInterSystem.C.
References nu, and tmp< T >::ref().
|
inline |
Set turbulence model.
Definition at line 624 of file multiphaseInterSystem.H.
References turb, and multiphaseInterSystem::turb_.
|
inline |
Return pointer to turbulence model.
Definition at line 632 of file multiphaseInterSystem.H.
References multiphaseInterSystem::turb_.
| Foam::tmp< Foam::volScalarField > mut | ( | ) | const |
Return the turbulent dynamic viscosity.
Definition at line 896 of file multiphaseInterSystem.C.
| Foam::tmp< Foam::volScalarField > muEff | ( | ) | const |
Return the effective dynamic viscosity.
Definition at line 902 of file multiphaseInterSystem.C.
| Foam::tmp< Foam::volScalarField > nut | ( | ) | const |
Return the turbulent kinematic viscosity.
Definition at line 908 of file multiphaseInterSystem.C.
| Foam::tmp< Foam::volScalarField > nuEff | ( | ) | const |
Return the effective kinematic viscosity.
Definition at line 914 of file multiphaseInterSystem.C.
| Foam::tmp< Foam::volScalarField > kappaEff | ( | ) | const |
Effective thermal turbulent diffusivity for temperature.
of mixture [J/m/s/K]
Definition at line 920 of file multiphaseInterSystem.C.
References Cp, and Foam::constant::electromagnetic::kappa.
| Foam::tmp< Foam::scalarField > kappaEff | ( | const label | patchi | ) | const |
Effective thermal turbulent diffusivity for temperature.
of mixture for patch [J/m/s/K]
Definition at line 930 of file multiphaseInterSystem.C.
References Cp, Foam::constant::electromagnetic::kappa, and tmp< T >::New().
| Foam::tmp< Foam::volScalarField > alphaEff | ( | ) | const |
Effective thermal turbulent diffusivity of mixture [kg/m/s].
Definition at line 942 of file multiphaseInterSystem.C.
References Foam::constant::atomic::alpha.
| Foam::tmp< Foam::scalarField > alphaEff | ( | const label | patchi | ) | const |
Effective thermal turbulent diffusivity of mixture [kg/m/s].
Definition at line 949 of file multiphaseInterSystem.C.
References Foam::constant::atomic::alpha.
| const Foam::surfaceScalarField & phi | ( | ) | const |
Constant access to the total flux.
Definition at line 955 of file multiphaseInterSystem.C.
| Foam::surfaceScalarField & phi | ( | ) |
Access to the total mixture flux.
Definition at line 961 of file multiphaseInterSystem.C.
| const Foam::surfaceScalarField & rhoPhi | ( | ) | const |
Constant access to the mixture mass flux.
Definition at line 967 of file multiphaseInterSystem.C.
| Foam::surfaceScalarField & rhoPhi | ( | ) |
Access to the total mixture mass flux.
Definition at line 973 of file multiphaseInterSystem.C.
| Foam::tmp< Foam::volVectorField > U | ( | ) | const |
Mixture U.
Definition at line 1114 of file multiphaseInterSystem.C.
References Foam::dimVelocity, forAllConstIters(), GeometricField< vector, fvPatchField, volMesh >::New(), IOobjectOption::NO_REGISTER, and Foam::Zero.
| Foam::tmp< Foam::surfaceScalarField > surfaceTensionForce | ( | ) | const |
Calculate surface tension of the mixture.
Definition at line 1068 of file multiphaseInterSystem.C.
References alpha1, alpha2, forAllConstIters(), Foam::fvc::interpolate(), Foam::name(), GeometricField< scalar, fvsPatchField, surfaceMesh >::New(), IOobjectOption::NO_REGISTER, Foam::fvc::snGrad(), and Foam::Zero.
|
virtual |
Return the surface tension coefficient.
Definition at line 1136 of file multiphaseInterSystem.C.
References Foam::glTF::key().
|
virtual |
Return coefficients (1/rho)
Definition at line 1143 of file multiphaseInterSystem.C.
References Foam::glTF::key().
| void addInterfacePorosity | ( | fvVectorMatrix & | UEqn | ) |
Add interface porosity on phasePair.
Definition at line 1151 of file multiphaseInterSystem.C.
References lduMatrix::diag(), false, forAllConstIters(), phaseModel::name(), Foam::name(), phasei, porousModel::S(), and UEqn.
|
pure virtual |
Return interfacial source mass rate per phase pair.
|
pure virtual |
Return the heat transfer matrices.
|
pure virtual |
Return the volumetric rate transfer matrix.
Calculate mass transfer for alpha's.
Referenced by multiphaseSystem::calculateSuSp().
|
pure virtual |
Calculate mass transfer for species.
|
pure virtual |
Add volume change in pEq.
|
pure virtual |
Solve for the phase transport equations.
Implemented in multiphaseSystem.
|
virtual |
Correct the mixture thermos.
Implements basicThermo.
Definition at line 979 of file multiphaseInterSystem.C.
References forAllIters.
|
pure virtual |
Correct mass sources.
|
inlinevirtual |
Return the name of the thermo physics.
Implements basicThermo.
Definition at line 805 of file multiphaseInterSystem.H.
References NotImplemented.
|
virtual |
Correct the turbulence.
Definition at line 990 of file multiphaseInterSystem.C.
References forAllIters.
|
virtual |
Read base phaseProperties dictionary.
Reimplemented from basicThermo.
Reimplemented in multiphaseSystem.
Definition at line 1329 of file multiphaseInterSystem.C.
References regIOobject::read().
| const Foam::multiphaseInterSystem::phasePairTable & totalPhasePairs | ( | ) | const |
Constant access the total phase pairs.
Definition at line 1014 of file multiphaseInterSystem.C.
| Foam::multiphaseInterSystem::phasePairTable & totalPhasePairs | ( | ) |
Non-constant access the total phase pairs.
Definition at line 1021 of file multiphaseInterSystem.C.
| const Foam::multiphaseInterSystem::phaseModelTable & phases | ( | ) | const |
Constant access the phases.
Definition at line 1000 of file multiphaseInterSystem.C.
| Foam::multiphaseInterSystem::phaseModelTable & phases | ( | ) |
Access the phases.
Definition at line 1007 of file multiphaseInterSystem.C.
| const modelType & lookupSubModel | ( | const phasePair & | key | ) | const |
Access a sub model between a phase pair.
Definition at line 173 of file multiphaseInterSystemTemplates.H.
References Foam::glTF::key(), and mesh.
| const modelType & lookupSubModel | ( | const multiphaseInter::phaseModel & | from, |
| const multiphaseInter::phaseModel & | to | ||
| ) | const |
Access a sub model between two phases.
Definition at line 187 of file multiphaseInterSystemTemplates.H.
|
virtual |
Return true if the equation of state is incompressible for all.
phases
Implements basicThermo.
Definition at line 1027 of file multiphaseInterSystem.C.
References forAllConstIters(), and thermo.
|
virtual |
Return true if a phase is incompressible.
Definition at line 1041 of file multiphaseInterSystem.C.
|
virtual |
Return true if the equation of state is isochoric for all phasses.
i.e. rho = const
Implements basicThermo.
Definition at line 1047 of file multiphaseInterSystem.C.
References forAllConstIters(), and thermo.
| const Foam::fvMesh & mesh | ( | ) | const |
Return mesh.
Definition at line 1061 of file multiphaseInterSystem.C.
| Foam::tmp< Foam::surfaceVectorField > nHatfv | ( | const volScalarField & | alpha1, |
| const volScalarField & | alpha2 | ||
| ) | const |
Interface normal surface vector.
Definition at line 1285 of file multiphaseInterSystem.C.
References alpha1, alpha2, Foam::average(), Foam::cbrt(), Foam::clamp(), Foam::constant::electromagnetic::e, Foam::fvc::grad(), Foam::fvc::interpolate(), and Foam::mag().
| Foam::tmp< Foam::volVectorField > nVolHatfv | ( | const volScalarField & | alpha1, |
| const volScalarField & | alpha2 | ||
| ) | const |
Interface normal volField vector.
Definition at line 1252 of file multiphaseInterSystem.C.
References alpha1, alpha2, Foam::average(), Foam::cbrt(), Foam::clamp(), Foam::constant::electromagnetic::e, Foam::fvc::grad(), and Foam::mag().
| Foam::tmp< Foam::surfaceScalarField > nHatf | ( | const volScalarField & | alpha1, |
| const volScalarField & | alpha2 | ||
| ) | const |
Interface normal surface vector.
Definition at line 1319 of file multiphaseInterSystem.C.
| Foam::tmp< Foam::volScalarField > K | ( | const volScalarField & | alpha1, |
| const volScalarField & | alpha2 | ||
| ) | const |
Interface curvature.
Definition at line 1190 of file multiphaseInterSystem.C.
References alpha1, alpha2, Foam::fvc::div(), and tmp< T >::ref().
| Foam::tmp< Foam::volScalarField > nearInterface | ( | const volScalarField & | alpha1, |
| const volScalarField & | alpha2 | ||
| ) | const |
Near Interface of alpha1 and alpha2.
Definition at line 1203 of file multiphaseInterSystem.C.
References alpha1, alpha2, and Foam::pos().
| Foam::tmp< Foam::volScalarField > nearInterface | ( | ) | const |
Near Interface of alpha'n.
Definition at line 1217 of file multiphaseInterSystem.C.
References alpha1, alpha2, Foam::dimless, forAllConstIters(), GeometricField< scalar, fvPatchField, volMesh >::New(), IOobjectOption::NO_REGISTER, Foam::pos(), and Foam::Zero.
|
protected |
Reference to the mesh.
Definition at line 121 of file multiphaseInterSystem.H.
|
protected |
Dynamic viscocity.
Definition at line 126 of file multiphaseInterSystem.H.
Referenced by multiphaseInterSystem::calcMu().
|
protected |
Phase names.
Definition at line 131 of file multiphaseInterSystem.H.
|
protected |
Mixture total volumetric flux.
Definition at line 136 of file multiphaseInterSystem.H.
|
protected |
Mixture total mass flux.
Definition at line 141 of file multiphaseInterSystem.H.
|
protected |
Phase models.
Definition at line 146 of file multiphaseInterSystem.H.
|
protected |
Phase pairs.
Definition at line 151 of file multiphaseInterSystem.H.
|
protected |
Total ordered phase pairs in the system.
Definition at line 156 of file multiphaseInterSystem.H.
|
protected |
Turbulent Prandt number.
Definition at line 161 of file multiphaseInterSystem.H.
|
protected |
Turbulence model.
Definition at line 166 of file multiphaseInterSystem.H.
Referenced by multiphaseInterSystem::setTurbulence(), and multiphaseInterSystem::turbulence().
|
protected |
Surface tension models.
Definition at line 174 of file multiphaseInterSystem.H.
|
protected |
Interface porous models.
Definition at line 179 of file multiphaseInterSystem.H.
|
static |
Default name of the phase properties dictionary.
Definition at line 306 of file multiphaseInterSystem.H.
1.8.14
