Applies semi-implicit source within a specified region for Type, where <Type>=Scalar/Vector/SphericalTensor/SymmTensor/Tensor. The source rate coefficients are specified as pairs of Su-Sp coefficients, i.e.: More...

Inheritance diagram for SemiImplicitSource< Type >:

[legend]

Collaboration diagram for SemiImplicitSource< Type >:

[legend]

Public Types
enum	volumeModeType { vmAbsolute, vmSpecific }
	Options for the volume mode type. More...

Public Types inherited from cellSetOption
enum	selectionModeType : char { smAll, smCellSet, smCellZone, smPoints, smMovingPoints, smGeometric, smCellType }
	Enumeration for selection mode types. More...

Public Member Functions
	TypeName ("SemiImplicitSource")
	Runtime type information. More...

	SemiImplicitSource (const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh)
	Construct from components. More...

volumeModeType	volumeMode () const noexcept
	The volume mode. More...

volumeModeType &	volumeMode () noexcept
	Modifiable access to the volume mode. More...

virtual void	addSup (fvMatrix< Type > &eqn, const label fieldi)
	Add explicit contribution to incompressible equation. More...

virtual void	addSup (const volScalarField &rho, fvMatrix< Type > &eqn, const label fieldi)
	Add explicit contribution to compressible equation. More...

virtual bool	read (const dictionary &dict)
	Read source dictionary. More...

Public Member Functions inherited from cellSetOption
	TypeName ("cellSetOption")
	Runtime type information. More...

	cellSetOption (const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh)
	Construct from components. More...

virtual	~cellSetOption ()=default
	Destructor. More...

scalar	timeStart () const noexcept
	Return const access to the time start. More...

scalar	duration () const noexcept
	Return const access to the duration. More...

bool	inTimeLimits (const scalar timeValue) const
	True if within time limits. More...

bool	useSubMesh () const noexcept
	True if sub-selection should be used. More...

selectionModeType	selectionMode () const noexcept
	Return the cell selection mode. More...

const wordRes &	selectionNames () const noexcept
	Return const access to the selection names (set or zone selection) More...

const wordRe &	zoneName () const
	Return const access to the first set/zone name. More...

scalar	V () const noexcept
	Return const access to the total cell volume. More...

const labelList &	cells () const noexcept
	Return const access to the cell selection. More...

bool	isSelectionUpdated () const noexcept
	Return flag for selection updates. More...

scalar	timeStart (scalar val) noexcept
	Adjust the time start, return the old value. More...

scalar	duration (scalar val) noexcept
	Adjust the duration, return the old value. More...

virtual bool	isActive ()
	Is the source active? More...

const word &	cellSetName () const
	The name of the cell set/zone [as a word] for "cellSet" / "cellZone" selection modes) More...

Public Member Functions inherited from option
	TypeName ("option")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, option, dictionary,(const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh),(name, modelType, dict, mesh))

	option (const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh)
	Construct from components. More...

autoPtr< option >	clone () const
	Return clone. More...

virtual	~option ()=default
	Destructor. More...

const word &	name () const noexcept
	Return const access to the source name. More...

const fvMesh &	mesh () const noexcept
	Return const access to the mesh database. More...

const dictionary &	coeffs () const noexcept
	Return dictionary. More...

bool	active () const noexcept
	True if source is active. More...

void	setApplied (const label fieldi)
	Set the applied flag to true for field index fieldi. More...

bool	active (const bool on) noexcept
	Change source active flag, return previous value. More...

virtual label	applyToField (const word &fieldName) const
	Return index of field name if found in fieldNames list. More...

virtual void	checkApplied () const
	Check that the source has been applied. More...

virtual void	addSup (fvMatrix< scalar > &eqn, const label fieldi)

virtual void	addSup (fvMatrix< vector > &eqn, const label fieldi)

virtual void	addSup (fvMatrix< symmTensor > &eqn, const label fieldi)

virtual void	addSup (fvMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void	addSup (fvMatrix< tensor > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &rho, fvMatrix< scalar > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &rho, fvMatrix< vector > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &rho, fvMatrix< symmTensor > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &rho, fvMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &rho, fvMatrix< tensor > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< scalar > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< vector > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< symmTensor > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< tensor > &eqn, const label fieldi)

virtual void	constrain (fvMatrix< scalar > &eqn, const label fieldi)

virtual void	constrain (fvMatrix< vector > &eqn, const label fieldi)

virtual void	constrain (fvMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void	constrain (fvMatrix< symmTensor > &eqn, const label fieldi)

virtual void	constrain (fvMatrix< tensor > &eqn, const label fieldi)

virtual void	correct (volScalarField &field)

virtual void	correct (volVectorField &field)

virtual void	correct (volSphericalTensorField &field)

virtual void	correct (volSymmTensorField &field)

virtual void	correct (volTensorField &field)

virtual void	correct (surfaceScalarField &field)

virtual void	correct (surfaceVectorField &field)

virtual void	correct (surfaceTensorField &field)

virtual void	postProcessSens (scalarField &sensField, const word &fieldName=word::null, const word &designVariablesName=word::null)

virtual void	postProcessSens (vectorField &sensField, const word &fieldName=word::null, const word &designVariablesName=word::null)

virtual void	postProcessSens (tensorField &sensField, const word &fieldName=word::null, const word &designVariablesName=word::null)

virtual void	postProcessAuxSens (const volScalarField &primalField, const volScalarField &adjointField, scalarField &sensField, const word &fieldName=word::null)

virtual void	postProcessAuxSens (const volVectorField &primalField, const volVectorField &adjointField, scalarField &sensField, const word &fieldName=word::null)

virtual void	postProcessAuxSens (const volTensorField &primalField, const volTensorField &adjointField, scalarField &sensField, const word &fieldName=word::null)

virtual void	writeHeader (Ostream &) const
	Write the source header information. More...

virtual void	writeFooter (Ostream &) const
	Write the source footer information. More...

virtual void	writeData (Ostream &) const
	Write the source properties. More...

Static Public Attributes
static const Enum< volumeModeType >	volumeModeTypeNames_
	Names for volumeModeType. More...

Static Public Attributes inherited from cellSetOption
static const Enum< selectionModeType >	selectionModeTypeNames_
	List of selection mode type names. More...

Additional Inherited Members
Static Public Member Functions inherited from option
static autoPtr< option >	New (const word &name, const dictionary &dict, const fvMesh &mesh)
	Return a reference to the selected fvOption model. More...

Public Attributes inherited from option
bool	log
	Switch write log to Info. More...

Protected Member Functions inherited from cellSetOption
void	setSelection (const dictionary &dict)
	Set cell selection name or points selection from dictionary input. More...

void	setCellSelection ()
	Set the cell selection based on user input selection mode. More...

void	setVol ()
	Recalculate the volume. More...

Protected Member Functions inherited from option
void	resetApplied ()
	Resize/reset applied flag list for all fieldNames_ entries. More...

Protected Attributes inherited from cellSetOption
selectionModeType	selectionMode_
	Cell selection mode. More...

bool	updateSelection_
	Flag to enable dictionary-based updates of selections. More...

scalar	timeStart_
	Start time of fvOption. More...

scalar	duration_
	Duration of fvOption execution starting from timeStart. More...

wordRes	selectionNames_
	Face selection names (for set or zone selections) More...

List< point >	points_
	List of points for "points" selectionMode. More...

PtrList< Function1< point > >	movingPoints_
	List of points for "movingPoints" selectionMode. More...

dictionary	geometricSelection_
	Dictionary entries for "geometric" (topoSetCellSource) selection. More...

labelList	cells_
	Set of cells to apply source to. More...

scalar	V_
	Sum of cell volumes. More...

Protected Attributes inherited from option
const word	name_
	Source name. More...

const word	modelType_
	Model type. More...

const fvMesh &	mesh_
	Reference to the mesh database. More...

dictionary	dict_
	Top level source dictionary. More...

dictionary	coeffs_
	Dictionary containing source coefficients. More...

wordList	fieldNames_
	Field names to apply source to - populated by derived models. More...

List< bool >	applied_
	Applied flag list - corresponds to each fieldNames_ entry. More...

bool	active_
	Source active flag. More...

Detailed Description

template<class Type>
class Foam::fv::SemiImplicitSource< Type >

Applies semi-implicit source within a specified region for Type, where <Type>=Scalar/Vector/SphericalTensor/SymmTensor/Tensor. The source rate coefficients are specified as pairs of Su-Sp coefficients, i.e.:

$S(x) = S_u + S_p x$

where

	=	net source for field 'x'
	=	explicit source contribution
	=	linearised implicit contribution

Usage

Minimal example by using constant/fvOptions:

<Type>SemiImplicitSource1
{
    // Mandatory entries (unmodifiable)
    type                <Type>SemiImplicitSource;

    // Mandatory entries (runtime modifiable)
    volumeMode          <volumeModeType>;

    // Specification of sources (OpenFOAM-2206 and newer)
    sources
    {
        // Specified as explicit(Su)/implicit(Sp) tuple:
        k           (30.7 0);
        epsilon     (1.5  0);

        // Specified as Function1 or exprField
        k
        {
            // Time-ramp from 0 to 30.7 at time 5
            explicit table ((0 0) (5 30.7));
            implicit none;
        }
        epsilon
        {
            explicit
            {
                type        exprField:
                expression  "(mag(pos()) < 0.1) ? 1.5 : 0";
            }
        }
    }

    // Traditional specification of sources (OpenFOAM-2112 and older)
    injectionRateSuSp
    {
        // Specified as explicit(Su)/implicit(Sp) tuple:
        k           (30.7 0);
        epsilon     (1.5  0);

        // Specified as Function1
        k
        {
            // Time-ramp from 0 to 30.7 at time 5
            Su  table ((0 0) (5 30.7));
            Sp  0;
        }
        epsilon
        {
            Su  1.5;
            Sp  0;
        }
    }

    // Mandatory/Optional (inherited) entries
    ...
}

where the entries mean:

Property	Description	Type	Reqd	Dflt
`type`	Type name: <Type>SemiImplicitSource	word	yes	-
`volumeMode`	Volume mode type	word	yes	-
`sources`	Explicit/implicit sources	dict	cndtnl	-
`injectionRateSuSp`	Explicit/implicit sources	dict	cndtnl	-

The inherited entries are elaborated in:

Options for the volumeMode entry:

      absolute  | Values are given as \<quantity\>
      specific  | Values are given as \<quantity\>/m3

Note: Missing explicit/implicit, Su/Sp entries are equivalent to constant values of zero. However, at one entry must be supplied for the source terms.; To use the exprField (expression fields) handling, the sources dictionary form must be used.

See also

Foam::fvOption

Source files

Definition at line 207 of file SemiImplicitSource.H.

Member Enumeration Documentation

◆ volumeModeType

enum volumeModeType

Options for the volume mode type.

Enumerator
vmAbsolute
vmSpecific

Definition at line 218 of file SemiImplicitSource.H.

Constructor & Destructor Documentation

◆ SemiImplicitSource()

SemiImplicitSource	(	const word &	name,
		const word &	modelType,
		const dictionary &	dict,
		const fvMesh &	mesh
	)

Construct from components.

Definition at line 209 of file SemiImplicitSource.C.

References dict, and Foam::blockMeshTools::read().

Here is the call graph for this function:

Member Function Documentation

◆ TypeName()

TypeName ( "SemiImplicitSource< Type >" )

Runtime type information.

◆ volumeMode() [1/2]

volumeModeType volumeMode ( ) const

inlinenoexcept

The volume mode.

Definition at line 318 of file SemiImplicitSource.H.

◆ volumeMode() [2/2]

volumeModeType& volumeMode ( )

inlinenoexcept

Modifiable access to the volume mode.

Definition at line 329 of file SemiImplicitSource.H.

◆ addSup() [1/2]

void addSup	(	fvMatrix< Type > &	eqn,
		const label	fieldi
	)

virtual

Add explicit contribution to incompressible equation.

Definition at line 228 of file SemiImplicitSource.C.

◆ addSup() [2/2]

void addSup	(	const volScalarField &	rho,
		fvMatrix< Type > &	eqn,
		const label	fieldi
	)

virtual

Add explicit contribution to compressible equation.

Definition at line 239 of file SemiImplicitSource.C.

References Foam::ensightOutput::debug, fvMatrix< Type >::dimensions(), Foam::dimVolume, Foam::endl(), Foam::ListOps::equal(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::Info, Foam::mag(), Foam::New(), Foam::nl, Foam::notNull(), psi, fvMatrix< Type >::psi(), tmp< T >::ref(), rho, Foam::fam::SuSp(), tmp< T >::valid(), and Foam::Zero.

Here is the call graph for this function:

◆ read()

bool read ( const dictionary & dict )

virtual

Read source dictionary.

Reimplemented from cellSetOption.

Definition at line 521 of file SemiImplicitSource.C.

References dict, dictionary::findDict(), and Foam::blockMeshTools::read().

Here is the call graph for this function:

Member Data Documentation

◆ volumeModeTypeNames_

const Foam::Enum< typename Foam::fv::SemiImplicitSource< Type >::volumeModeType > volumeModeTypeNames_

static

Names for volumeModeType.

Definition at line 227 of file SemiImplicitSource.H.

The documentation for this class was generated from the following files:

src/fvOptions/sources/general/semiImplicitSource/SemiImplicitSource.H
src/fvOptions/sources/general/semiImplicitSource/SemiImplicitSource.C

Public Types

Public Member Functions

Static Public Attributes

Additional Inherited Members

Detailed Description

template<class Type> class Foam::fv::SemiImplicitSource< Type >

Member Enumeration Documentation

◆ volumeModeType

Constructor & Destructor Documentation

◆ SemiImplicitSource()

Member Function Documentation

◆ TypeName()

◆ volumeMode() [1/2]

◆ volumeMode() [2/2]

◆ addSup() [1/2]

◆ addSup() [2/2]

◆ read()

Member Data Documentation

◆ volumeModeTypeNames_

template<class Type>
class Foam::fv::SemiImplicitSource< Type >
