Public Member Functions | List of all members
enrichedPatch Class Reference

The enriched patch contains a double set of faces from the two sides of the sliding interface before the cutting. More...

Public Member Functions

 ClassName ("enrichedPatch")

 enrichedPatch (const primitiveFacePatch &masterPatch, const primitiveFacePatch &slavePatch, const labelUList &slavePointPointHits, const labelUList &slavePointEdgeHits, const UList< objectHit > &slavePointFaceHits)
 Construct from components. More...

 ~enrichedPatch ()=default
 Destructor. More...

const Map< point > & pointMap () const
 Return map of points. More...

Map< point > & pointMap ()
 Return non-const access to point map to add points. More...

const Map< label > & pointMergeMap () const
 Return map of point merges. More...

Map< label > & pointMergeMap ()
 Return map of point merges. More...

void calcEnrichedFaces (const labelListList &pointsIntoMasterEdges, const labelListList &pointsIntoSlaveEdges, const pointField &projectedSlavePoints)
 Calculate enriched faces. More...

const faceList & enrichedFaces () const
 Return enriched faces. More...

const labelList & meshPoints () const
 Return mesh points. More...

const faceList & localFaces () const
 Return local faces. More...

const pointField & localPoints () const
 Return local points. More...

const labelListList & pointPoints () const
 Return point-point addressing. More...

const Map< labelList > & masterPointFaces () const
 Master point face addressing. More...

const faceList & cutFaces () const
 Return list of cut faces. More...

const labelList & cutFaceMaster () const
 Return cut face master list. More...

const labelList & cutFaceSlave () const
 Return cut face slave list. More...

bool checkSupport () const
 Check if the patch is fully supported. More...

void writeOBJ (const fileName &fName) const
 Debugging: dump graphical representation to obj format file. More...


Detailed Description

The enriched patch contains a double set of faces from the two sides of the sliding interface before the cutting.

The patch basically consists of two over-lapping sets of faces sitting on a common point support, where every edge may be shared by more than 2 faces. The patch points are collected in a map. Additional information needed for cutting is the point insertion into every edge of master and slave.

Note: If new points are created during master-slave edge cutting, they should be registered with the pointMap.

Source files

Definition at line 64 of file enrichedPatch.H.

Constructor & Destructor Documentation

◆ enrichedPatch()

enrichedPatch ( const primitiveFacePatch &  masterPatch,
const primitiveFacePatch &  slavePatch,
const labelUList &  slavePointPointHits,
const labelUList &  slavePointEdgeHits,
const UList< objectHit > &  slavePointFaceHits
)

Construct from components.

Definition at line 118 of file enrichedPatch.C.

◆ ~enrichedPatch()

~enrichedPatch ( )
default

Destructor.

Member Function Documentation

◆ ClassName()

ClassName ( "enrichedPatch"  )

◆ pointMap() [1/2]

const Foam::Map< Foam::point > & pointMap ( ) const
inline

Return map of points.

Definition at line 23 of file enrichedPatchI.H.

◆ pointMap() [2/2]

Foam::Map< Foam::point > & pointMap ( )
inline

Return non-const access to point map to add points.

Definition at line 34 of file enrichedPatchI.H.

◆ pointMergeMap() [1/2]

const Foam::Map< Foam::label > & pointMergeMap ( ) const
inline

Return map of point merges.

Definition at line 45 of file enrichedPatchI.H.

◆ pointMergeMap() [2/2]

Foam::Map< Foam::label > & pointMergeMap ( )
inline

Return map of point merges.

Definition at line 51 of file enrichedPatchI.H.

◆ calcEnrichedFaces()

void calcEnrichedFaces ( const labelListList &  pointsIntoMasterEdges,
const labelListList &  pointsIntoSlaveEdges,
const pointField &  projectedSlavePoints
)

Calculate enriched faces.

Definition at line 33 of file enrichedPatchFaces.C.

References Foam::abort(), Foam::ensightOutput::debug, Foam::constant::electromagnetic::e, Foam::endl(), Foam::FatalError, FatalErrorInFunction, forAll, Foam::Info, HashTable< T, Key, Hash >::lookup(), Foam::magSqr(), Foam::max(), Foam::min(), Foam::nl, and UList< T >::size().

Here is the call graph for this function:

◆ enrichedFaces()

const Foam::faceList & enrichedFaces ( ) const

Return enriched faces.

Definition at line 380 of file enrichedPatchFaces.C.

References Foam::abort(), Foam::FatalError, and FatalErrorInFunction.

Here is the call graph for this function:

◆ meshPoints()

const Foam::labelList & meshPoints ( ) const

Return mesh points.

Definition at line 152 of file enrichedPatch.C.

◆ localFaces()

const Foam::faceList & localFaces ( ) const

Return local faces.

Definition at line 163 of file enrichedPatch.C.

◆ localPoints()

const Foam::pointField & localPoints ( ) const

Return local points.

Definition at line 174 of file enrichedPatch.C.

◆ pointPoints()

const Foam::labelListList & pointPoints ( ) const

Return point-point addressing.

Definition at line 185 of file enrichedPatch.C.

◆ masterPointFaces()

const Foam::Map< Foam::labelList > & masterPointFaces ( ) const

Master point face addressing.

Definition at line 96 of file enrichedPatchMasterPoints.C.

◆ cutFaces()

const Foam::faceList & cutFaces ( ) const

Return list of cut faces.

Definition at line 648 of file enrichedPatchCutFaces.C.

◆ cutFaceMaster()

const Foam::labelList & cutFaceMaster ( ) const

Return cut face master list.

Definition at line 659 of file enrichedPatchCutFaces.C.

◆ cutFaceSlave()

const Foam::labelList & cutFaceSlave ( ) const

Return cut face slave list.

Definition at line 670 of file enrichedPatchCutFaces.C.

◆ checkSupport()

bool checkSupport ( ) const

Check if the patch is fully supported.

Definition at line 196 of file enrichedPatch.C.

References Foam::endl(), forAll, found, and WarningInFunction.

Here is the call graph for this function:

◆ writeOBJ()

void writeOBJ ( const fileName &  fName) const

Debugging: dump graphical representation to obj format file.

Definition at line 223 of file enrichedPatch.C.

References f(), Foam::nl, and Foam::meshTools::writeOBJ().

Here is the call graph for this function:
The documentation for this class was generated from the following files:
