Abstract base class for two-phase alphaContactAngle boundary conditions. More...

Inheritance diagram for alphaContactAngleTwoPhaseFvPatchScalarField:

[legend]

Collaboration diagram for alphaContactAngleTwoPhaseFvPatchScalarField:

Public Types
enum	limitControls { lcNone, lcGradient, lcZeroGradient, lcAlpha }
	Alpha limit options. More...

Public Member Functions
	alphaContactAngleTwoPhaseFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &)
	Construct from patch and internal field. More...

	alphaContactAngleTwoPhaseFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
	Construct from patch, internal field and dictionary. More...

	alphaContactAngleTwoPhaseFvPatchScalarField (const this_bctype &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fvPatchFieldMapper &)
	Construct by mapping onto a new patch. More...

	alphaContactAngleTwoPhaseFvPatchScalarField (const this_bctype &, const DimensionedField< scalar, volMesh > &)
	Construct as copy setting internal field reference. More...

	alphaContactAngleTwoPhaseFvPatchScalarField (const this_bctype &)=delete
	No copy without an internal field. More...

virtual tmp< scalarField >	theta (const fvPatchVectorField &Up, const fvsPatchVectorField &nHat) const =0
	Return the contact angle. More...

virtual void	evaluate (const Pstream::commsTypes commsType=Pstream::commsTypes::buffered)
	Evaluate the patch field. More...

virtual void	write (Ostream &os) const
	Write. More...

Public Attributes
limitControls	limit_

Static Public Attributes
static const Enum< limitControls >	limitControlNames_

Detailed Description

Abstract base class for two-phase alphaContactAngle boundary conditions.

Derived classes must implement the theta() function which returns the wall contact angle field.

The essential entry "limit" controls the gradient of alpha1 on the wall:

none - Calculate the gradient from the contact-angle without limiter
gradient - Limit the wall-gradient such that alpha1 remains bounded on the wall
alpha - Bound the calculated alpha1 on the wall
zeroGradient - Set the gradient of alpha1 to 0 on the wall, i.e. reproduce previous behaviour, the pressure BCs can be left as before.

Note that if any of the first three options are used the boundary condition on p_rgh must set to guarantee that the flux is corrected to be zero at the wall e.g.:

<patchName>
{
    type            alphaContactAngle;
    limit           none;
}

Source files

Definition at line 74 of file alphaContactAngleTwoPhaseFvPatchScalarField.H.

Member Enumeration Documentation

◆ limitControls

enum limitControls

Alpha limit options.

Enumerator
lcNone
lcGradient
lcZeroGradient
lcAlpha

Definition at line 88 of file alphaContactAngleTwoPhaseFvPatchScalarField.H.

Constructor & Destructor Documentation

◆ alphaContactAngleTwoPhaseFvPatchScalarField() [1/5]

alphaContactAngleTwoPhaseFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF
	)

Construct from patch and internal field.

Definition at line 45 of file alphaContactAngleTwoPhaseFvPatchScalarField.C.

◆ alphaContactAngleTwoPhaseFvPatchScalarField() [2/5]

alphaContactAngleTwoPhaseFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const dictionary &	dict
	)

Construct from patch, internal field and dictionary.

Definition at line 57 of file alphaContactAngleTwoPhaseFvPatchScalarField.C.

References dict, Foam::stringOps::evaluate(), and Foam::Zero.

Here is the call graph for this function:

◆ alphaContactAngleTwoPhaseFvPatchScalarField() [3/5]

alphaContactAngleTwoPhaseFvPatchScalarField	(	const this_bctype &	acpsf,
		const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)
