Public Member Functions | List of all members
ODESystem Class Referenceabstract

Abstract base class for the systems of ordinary differential equations. More...

Inheritance diagram for ODESystem:
Inheritance graph
[legend]

Public Member Functions

 ODESystem ()
 Construct null. More...

virtual ~ODESystem ()=default
 Destructor. More...

virtual label nEqns () const =0
 Return the number of equations in the system. More...

virtual void derivatives (const scalar x, const scalarField &y, scalarField &dydx) const =0
 Calculate the derivatives in dydx. More...

virtual void jacobian (const scalar x, const scalarField &y, scalarField &dfdx, scalarSquareMatrix &dfdy) const =0
 Calculate the Jacobian of the system. More...


Detailed Description

Abstract base class for the systems of ordinary differential equations.

Definition at line 43 of file ODESystem.H.

Constructor & Destructor Documentation

◆ ODESystem()

ODESystem ( )
inline

Construct null.

Definition at line 53 of file ODESystem.H.

◆ ~ODESystem()

virtual ~ODESystem ( )
virtualdefault

Destructor.

Member Function Documentation

◆ nEqns()

virtual label nEqns ( ) const
pure virtual

Return the number of equations in the system.

Implemented in StandardChemistryModel< ReactionThermo, ThermoType >, StandardChemistryModel< CompType, ThermoType >, thermoCoupleProbes, solidChemistryModel< CompType, SolidThermo >, and pyrolysisChemistryModel< CompType, SolidThermo, GasThermo >.

◆ derivatives()

virtual void derivatives ( const scalar  x,
const scalarField &  y,
scalarField &  dydx
) const
pure virtual

Calculate the derivatives in dydx.

Implemented in StandardChemistryModel< ReactionThermo, ThermoType >, StandardChemistryModel< CompType, ThermoType >, thermoCoupleProbes, solidChemistryModel< CompType, SolidThermo >, pyrolysisChemistryModel< CompType, SolidThermo, GasThermo >, TDACChemistryModel< ReactionThermo, ThermoType >, and TDACChemistryModel< CompType, ThermoType >.

Referenced by adaptiveSolver::solve().

Here is the caller graph for this function:

◆ jacobian()

virtual void jacobian ( const scalar  x,
const scalarField &  y,
scalarField &  dfdx,
scalarSquareMatrix &  dfdy
) const
pure virtual

Calculate the Jacobian of the system.

Need by the stiff-system solvers

Implemented in StandardChemistryModel< ReactionThermo, ThermoType >, StandardChemistryModel< CompType, ThermoType >, thermoCoupleProbes, solidChemistryModel< CompType, SolidThermo >, TDACChemistryModel< ReactionThermo, ThermoType >, TDACChemistryModel< CompType, ThermoType >, and pyrolysisChemistryModel< CompType, SolidThermo, GasThermo >.

The documentation for this class was generated from the following file:
