Incompressible gas equation of state using the Boussinesq approximation for the density as a function of temperature only: More...

Inheritance diagram for Boussinesq< Specie >:

[legend]

Collaboration diagram for Boussinesq< Specie >:

[legend]

Public Member Functions
	Boussinesq (const Specie &sp, const scalar rho0, const scalar T0, const scalar beta)
	Construct from components. More...

	Boussinesq (const dictionary &dict)
	Construct from dictionary. More...

	Boussinesq (const word &name, const Boussinesq &)
	Construct as named copy. More...

autoPtr< Boussinesq >	clone () const
	Construct and return a clone. More...

scalar	rho (scalar p, scalar T) const
	Return density [kg/m^3]. More...

scalar	H (const scalar p, const scalar T) const
	Return enthalpy departure [J/kg]. More...

scalar	Cp (scalar p, scalar T) const
	Return Cp departure [J/(kg K]. More...

scalar	E (const scalar p, const scalar T) const
	Return internal energy departure [J/kg]. More...

scalar	Cv (scalar p, scalar T) const
	Return Cv departure [J/(kg K]. More...

scalar	S (const scalar p, const scalar T) const
	Return entropy [J/(kg K)]. More...

scalar	psi (scalar p, scalar T) const
	Return compressibility rho/p [s^2/m^2]. More...

scalar	Z (scalar p, scalar T) const
	Return compression factor []. More...

scalar	CpMCv (scalar p, scalar T) const
	Return (Cp - Cv) [J/(kg K]. More...

void	write (Ostream &os) const
	Write to Ostream. More...

void	operator= (const Boussinesq &)

void	operator+= (const Boussinesq &)

void	operator*= (const scalar)

Static Public Member Functions
static autoPtr< Boussinesq >	New (const dictionary &dict)

static word	typeName ()
	Return the instantiated type name. More...

Static Public Attributes
static const bool	incompressible = true
	Is the equation of state is incompressible i.e. rho != f(p) More...

static const bool	isochoric = false
	Is the equation of state is isochoric i.e. rho = const. More...

Friends
Boussinesq	operator+ (const Boussinesq &, const Boussinesq &)

Boussinesq	operator* (const scalar s, const Boussinesq &)

Boussinesq	operator== (const Boussinesq &, const Boussinesq &)

Ostream &	operator (Ostream &, const Boussinesq &)

Detailed Description

template<class Specie>
class Foam::Boussinesq< Specie >

Incompressible gas equation of state using the Boussinesq approximation for the density as a function of temperature only:

    rho = rho0*(1 - beta*(T - T0))

Source files

Definition at line 53 of file Boussinesq.H.

Constructor & Destructor Documentation

◆ Boussinesq() [1/3]

Boussinesq	(	const Specie &	sp,
		const scalar	rho0,
		const scalar	T0,
		const scalar	beta
	)

inline

Construct from components.

Definition at line 28 of file BoussinesqI.H.

◆ Boussinesq() [2/3]

Boussinesq ( const dictionary & dict )

Construct from dictionary.

Definition at line 28 of file Boussinesq.C.

◆ Boussinesq() [3/3]

Boussinesq	(	const word &	name,
		const Boussinesq< Specie > &
	)

inline

Construct as named copy.

Member Function Documentation

◆ clone()

Foam::autoPtr< Foam::Boussinesq< Specie > > clone ( ) const

inline

Construct and return a clone.

Definition at line 55 of file BoussinesqI.H.

References Foam::New().

Here is the call graph for this function:

◆ New()

Foam::autoPtr< Foam::Boussinesq< Specie > > New ( const dictionary & dict )

inlinestatic

Definition at line 64 of file BoussinesqI.H.

References dict, and Foam::New().

Here is the call graph for this function:

◆ typeName()

static word typeName ( )

inlinestatic

Return the instantiated type name.

Definition at line 157 of file Boussinesq.H.

◆ rho()

Foam::scalar rho	(	scalar	p,
		scalar	T
	)		const

inline

Return density [kg/m^3].

Definition at line 76 of file BoussinesqI.H.

References Foam::T().

Here is the call graph for this function:

◆ H()

Foam::scalar H	(	const scalar	p,
		const scalar	T
	)		const

inline

Return enthalpy departure [J/kg].

Definition at line 86 of file BoussinesqI.H.

◆ Cp()

Foam::scalar Cp	(	scalar	p,
		scalar	T
	)		const

inline

Return Cp departure [J/(kg K].

Definition at line 93 of file BoussinesqI.H.

◆ E()

Foam::scalar E	(	const scalar	p,
		const scalar	T
	)		const

inline

Return internal energy departure [J/kg].

Definition at line 99 of file BoussinesqI.H.

◆ Cv()

Foam::scalar Cv	(	scalar	p,
		scalar	T
	)		const

inline

Return Cv departure [J/(kg K].

Definition at line 106 of file BoussinesqI.H.

◆ S()

Foam::scalar S	(	const scalar	p,
		const scalar	T
	)		const

inline

Return entropy [J/(kg K)].

Definition at line 114 of file BoussinesqI.H.

◆ psi()

Foam::scalar psi	(	scalar	p,
		scalar	T
	)		const

inline

Return compressibility rho/p [s^2/m^2].

Definition at line 125 of file BoussinesqI.H.

◆ Z()

Foam::scalar Z	(	scalar	p,
		scalar	T
	)		const

inline

Return compression factor [].

Definition at line 136 of file BoussinesqI.H.

◆ CpMCv()

Foam::scalar CpMCv	(	scalar	p,
		scalar	T
	)		const

inline

Return (Cp - Cv) [J/(kg K].

Definition at line 147 of file BoussinesqI.H.

◆ write()

void write ( Ostream & os ) const

Write to Ostream.

Definition at line 42 of file Boussinesq.C.

References Ostream::beginBlock(), Ostream::endBlock(), Foam::vtk::write(), and Ostream::writeEntry().

Here is the call graph for this function:

◆ operator=()

void operator= ( const Boussinesq< Specie > & )

inline

Definition at line 160 of file BoussinesqI.H.

References Foam::constant::physicoChemical::b.

◆ operator+=()

void operator+= ( const Boussinesq< Specie > & )

inline

Definition at line 174 of file BoussinesqI.H.

References Foam::constant::physicoChemical::b, Foam::mag(), and Y.

Here is the call graph for this function:

◆ operator*=()

void operator*= ( const scalar s )

inline

Definition at line 194 of file BoussinesqI.H.

References s.

Friends And Related Function Documentation

◆ operator+

Boussinesq operator+	(	const Boussinesq< Specie > &	,
		const Boussinesq< Specie > &
	)

friend

◆ operator*

Boussinesq operator*	(	const scalar	s,
		const Boussinesq< Specie > &
	)

friend

◆ operator==

Boussinesq operator==	(	const Boussinesq< Specie > &	,
		const Boussinesq< Specie > &
	)

friend

◆ operator

Ostream& operator	(	Ostream &	,
		const Boussinesq< Specie > &
	)

friend

Member Data Documentation

◆ incompressible

const bool incompressible = true

static

Is the equation of state is incompressible i.e. rho != f(p)

Definition at line 170 of file Boussinesq.H.

◆ isochoric

const bool isochoric = false

static

Is the equation of state is isochoric i.e. rho = const.

Definition at line 175 of file Boussinesq.H.

The documentation for this class was generated from the following files:

src/thermophysicalModels/specie/equationOfState/Boussinesq/Boussinesq.H
src/thermophysicalModels/specie/equationOfState/Boussinesq/Boussinesq.C
src/thermophysicalModels/specie/equationOfState/Boussinesq/BoussinesqI.H
