For use with FaceCellWave. Determines topological distance to starting faces. More...

Collaboration diagram for wallPoints:

Classes
class	trackData
	Class used to pass additional data in. More...

Public Member Functions
	wallPoints ()
	Default construct. More...

	wallPoints (const UList< point > &origin, const UList< scalar > &distSqr, const UList< FixedList< label, 3 >> &surface)
	Construct from count. More...

const List< point > &	origin () const

const List< scalar > &	distSqr () const

const List< FixedList< label, 3 > > &	surface () const

template<class TrackingData >
bool	valid (TrackingData &td) const
	Changed or contains original (invalid) value. More...

template<class TrackingData >
bool	sameGeometry (const polyMesh &, const wallPoints &, const scalar, TrackingData &td) const
	Check for identical geometrical data (eg, cyclics checking) More...

template<class TrackingData >
void	leaveDomain (const polyMesh &, const polyPatch &, const label patchFacei, const point &faceCentre, TrackingData &td)
	Convert any absolute coordinates into relative to (patch)face. More...

template<class TrackingData >
void	enterDomain (const polyMesh &, const polyPatch &, const label patchFacei, const point &faceCentre, TrackingData &td)
	Reverse of leaveDomain. More...

template<class TrackingData >
void	transform (const polyMesh &, const tensor &, TrackingData &td)
	Apply rotation matrix to any coordinates. More...

template<class TrackingData >
bool	updateCell (const polyMesh &, const label thisCelli, const label neighbourFacei, const wallPoints &neighbourInfo, const scalar tol, TrackingData &td)
	Influence of neighbouring face. More...

template<class TrackingData >
bool	updateFace (const polyMesh &, const label thisFacei, const label neighbourCelli, const wallPoints &neighbourInfo, const scalar tol, TrackingData &td)
	Influence of neighbouring cell. More...

template<class TrackingData >
bool	updateFace (const polyMesh &, const label thisFacei, const wallPoints &neighbourInfo, const scalar tol, TrackingData &td)
	Influence of different value on same face. More...

template<class TrackingData >
bool	equal (const wallPoints &, TrackingData &) const
	Test for equality, with TrackingData. More...

template<class TrackingData >
bool	interpolate (const polyMesh &, const point &pt, const label i0, const wallPoints &f0, const label i1, const wallPoints &f1, const scalar weight, const scalar tol, TrackingData &td)
	Interpolate between two values (lerp). Returns true if causes changes. Not sure if needs to be specialised between face and cell and what index is needed... More...

bool	operator== (const wallPoints &) const
	Test for equality. More...

bool	operator!= (const wallPoints &) const
	Test for inequality. More...

Protected Member Functions
template<class TrackingData >
bool	update (const point &pt, const label index1, const wallPoints &w2, const label index2, const scalar tol, TrackingData &td)
	Originating normal. More...

Protected Attributes
DynamicList< point >	origin_
	Starting points. More...

DynamicList< scalar >	distSqr_
	Distance (squared) from cellcenter to origin. More...

DynamicList< FixedList< label, 3 > >	surface_
	Originating surface,region and topological region. More...

Friends
Ostream &	operator<< (Ostream &, const wallPoints &)

Istream &	operator>> (Istream &, wallPoints &)

Detailed Description

For use with FaceCellWave. Determines topological distance to starting faces.

Source files

Definition at line 59 of file wallPoints.H.

Constructor & Destructor Documentation

◆ wallPoints() [1/2]

wallPoints ( )

inline

Default construct.

Definition at line 83 of file wallPointsI.H.

◆ wallPoints() [2/2]

wallPoints	(	const UList< point > &	origin,
		const UList< scalar > &	distSqr,
		const UList< FixedList< label, 3 >> &	surface
	)

inline

Construct from count.

Definition at line 93 of file wallPointsI.H.

Member Function Documentation

◆ update()

bool update	(	const point &	pt,
		const label	index1,
		const wallPoints &	w2,
		const label	index2,
		const scalar	tol,
		TrackingData &	td
	)

inlineprotected

Originating normal.

DynamicList<vector> normal_;

Evaluate distance to point.

Update distSqr, origin from whomever is nearer pt.

Returns: true if w2 is closer to point, false otherwise.

Definition at line 28 of file wallPointsI.H.

References Foam::diff(), Foam::magSqr(), td(), and w2.

Here is the call graph for this function:

◆ origin()

const List<point>& origin ( ) const

inline

Definition at line 164 of file wallPoints.H.

References wallPoints::origin_.

◆ distSqr()

const List<scalar>& distSqr ( ) const

inline

Definition at line 168 of file wallPoints.H.

References wallPoints::distSqr_.

◆ surface()

const List<FixedList<label, 3> >& surface ( ) const

inline

Definition at line 173 of file wallPoints.H.

References wallPoints::surface_.

◆ valid()

bool valid ( TrackingData & td ) const

inline

Changed or contains original (invalid) value.

Definition at line 110 of file wallPointsI.H.

Referenced by wallPoints::interpolate().

Here is the caller graph for this function:

◆ sameGeometry()

bool sameGeometry	(	const polyMesh &	,
		const wallPoints &	,
		const scalar	,
		TrackingData &	td
	)		const

inline

Check for identical geometrical data (eg, cyclics checking)

Definition at line 119 of file wallPointsI.H.

◆ leaveDomain()

void leaveDomain	(	const polyMesh &	,
		const polyPatch &	patch,
		const label	patchFacei,
		const point &	faceCentre,
		TrackingData &	td
	)

inline

Convert any absolute coordinates into relative to (patch)face.

centre

Definition at line 133 of file wallPointsI.H.

◆ enterDomain()

void enterDomain	(	const polyMesh &	,
		const polyPatch &	patch,
		const label	patchFacei,
		const point &	faceCentre,
		TrackingData &	td
	)

inline

Reverse of leaveDomain.

Definition at line 167 of file wallPointsI.H.

◆ transform()

void transform	(	const polyMesh &	,
		const tensor &	rotTensor,
		TrackingData &	td
	)

inline

Apply rotation matrix to any coordinates.

Definition at line 151 of file wallPointsI.H.

References Foam::transform().

Here is the call graph for this function:

◆ updateCell()

bool updateCell	(	const polyMesh &	mesh,
		const label	thisCelli,
		const label	neighbourFacei,
		const wallPoints &	neighbourInfo,
		const scalar	tol,
		TrackingData &	td
	)

inline

Influence of neighbouring face.

Definition at line 186 of file wallPointsI.H.

References primitiveMesh::cellCentres(), UList< T >::find(), forAll, Foam::labelMax, Foam::magSqr(), mesh, wallPoints::origin_, wallPoints::trackData::regionToBlockSize_, Foam::sqr(), wallPoints::surface_, td(), and update().

Here is the call graph for this function:

◆ updateFace() [1/2]

bool updateFace	(	const polyMesh &	mesh,
		const label	thisFacei,
		const label	neighbourCelli,
		const wallPoints &	neighbourInfo,
		const scalar	tol,
		TrackingData &	td
	)

inline

Influence of neighbouring cell.

Definition at line 268 of file wallPointsI.H.

References primitiveMesh::faceCentres(), UList< T >::find(), forAll, wallPoints::trackData::isBlockedFace_, Foam::labelMax, Foam::magSqr(), mesh, wallPoints::origin_, wallPoints::trackData::regionToBlockSize_, Foam::sqr(), wallPoints::surface_, td(), and update().

Here is the call graph for this function:

◆ updateFace() [2/2]

bool updateFace	(	const polyMesh &	mesh,
		const label	thisFacei,
		const wallPoints &	neighbourInfo,
		const scalar	tol,
		TrackingData &	td
	)

inline

Influence of different value on same face.

Definition at line 350 of file wallPointsI.H.

References primitiveMesh::faceCentres(), UList< T >::find(), forAll, wallPoints::trackData::isBlockedFace_, Foam::labelMax, Foam::magSqr(), mesh, wallPoints::origin_, wallPoints::trackData::regionToBlockSize_, Foam::sqr(), wallPoints::surface_, td(), and update().

Here is the call graph for this function:

◆ equal()

bool equal	(	const wallPoints &	rhs,
		TrackingData &	td
	)		const

inline

Test for equality, with TrackingData.

Definition at line 430 of file wallPointsI.H.

References Foam::operator==(), and Foam::rhs().

Here is the call graph for this function:

◆ interpolate()

bool interpolate	(	const polyMesh &	,
		const point &	pt,
		const label	i0,
		const wallPoints &	f0,
		const label	i1,
		const wallPoints &	f1,
		const scalar	weight,
		const scalar	tol,
		TrackingData &	td
	)

inline

Interpolate between two values (lerp). Returns true if causes changes. Not sure if needs to be specialised between face and cell and what index is needed...

Definition at line 441 of file wallPointsI.H.

References td(), and wallPoints::valid().

Here is the call graph for this function:

◆ operator==()

bool operator== ( const wallPoints & rhs ) const

inline

Test for equality.

Definition at line 477 of file wallPointsI.H.

References Foam::rhs().

Here is the call graph for this function:

◆ operator!=()

bool operator!= ( const wallPoints & rhs ) const

inline

Test for inequality.

Definition at line 490 of file wallPointsI.H.

References Foam::rhs().

Here is the call graph for this function:

Friends And Related Function Documentation

◆ operator<<

Ostream& operator<<	(	Ostream &	,
		const wallPoints &
	)

friend

◆ operator>>

Istream& operator>>	(	Istream &	,
		wallPoints &
	)

friend

Member Data Documentation

◆ origin_

DynamicList<point> origin_

protected

Starting points.

Definition at line 99 of file wallPoints.H.

Referenced by wallPoints::origin(), wallPoints::updateCell(), and wallPoints::updateFace().

◆ distSqr_

DynamicList<scalar> distSqr_

protected

Distance (squared) from cellcenter to origin.

Definition at line 104 of file wallPoints.H.

Referenced by wallPoints::distSqr().

◆ surface_

DynamicList<FixedList<label, 3> > surface_

protected

Originating surface,region and topological region.

Definition at line 109 of file wallPoints.H.

Referenced by wallPoints::surface(), wallPoints::updateCell(), and wallPoints::updateFace().

The documentation for this class was generated from the following files:

src/mesh/snappyHexMesh/meshRefinement/wallPoints.H
src/mesh/snappyHexMesh/meshRefinement/wallPointsI.H
