Processor agglomeration of GAMGAgglomerations. More...

Inheritance diagram for masterCoarsestGAMGProcAgglomeration:

Collaboration diagram for masterCoarsestGAMGProcAgglomeration:

Public Member Functions
	TypeName ("masterCoarsest")
	Runtime type information. More...

	masterCoarsestGAMGProcAgglomeration (GAMGAgglomeration &agglom, const dictionary &controlDict)
	Construct given agglomerator and controls. More...

virtual	~masterCoarsestGAMGProcAgglomeration ()
	Destructor. More...

virtual bool	agglomerate ()
	Modify agglomeration. Return true if modified. More...

Public Member Functions inherited from GAMGProcAgglomeration
	TypeName ("GAMGProcAgglomeration")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, GAMGProcAgglomeration, GAMGAgglomeration,(GAMGAgglomeration &agglom, const dictionary &controlDict),(agglom, controlDict))
	Runtime selection table for pure geometric agglomerators. More...

	GAMGProcAgglomeration (const GAMGProcAgglomeration &)=delete
	No copy construct. More...

void	operator= (const GAMGProcAgglomeration &)=delete
	No copy assignment. More...

	GAMGProcAgglomeration (GAMGAgglomeration &agglom, const dictionary &controlDict)
	Construct given agglomerator and controls. More...

virtual	~GAMGProcAgglomeration ()
	Destructor. Clears allocated communicators. More...

Additional Inherited Members
Static Public Member Functions inherited from GAMGProcAgglomeration
static autoPtr< GAMGProcAgglomeration >	New (const word &type, GAMGAgglomeration &agglom, const dictionary &controlDict)
	Return the selected agglomerator. More...

Protected Member Functions inherited from GAMGProcAgglomeration
void	printStats (Ostream &os, GAMGAgglomeration &agglom) const
	Debug: write agglomeration info. More...

bool	agglomerate (const label fineLevelIndex, const labelList &procAgglomMap, const labelList &masterProcs, const List< label > &agglomProcIDs, const label procAgglomComm)
	Agglomerate a level. Return true if anything has changed. More...

void	clearCommunicators ()
	Clear/free allocated communicators. More...

Static Protected Member Functions inherited from GAMGProcAgglomeration
static labelListList	globalCellCells (const lduMesh &)
	Debug: calculate global cell-cells. More...

Protected Attributes inherited from GAMGProcAgglomeration
GAMGAgglomeration &	agglom_
	Reference to agglomeration. More...

DynamicList< label >	comms_
	Allocated communicators. More...

Detailed Description

Processor agglomeration of GAMGAgglomerations.

by default agglomerates onto the master processor
optionally have multiple masters through the nProcessorsPerMaster parameter. e.g.

p { solver GAMG; tolerance 1e-06; relTol 0.1; smoother GaussSeidel;

nCellsInCoarsestLevel 10;

processorAgglomerator masterCoarsest; Groups of 32 cores get combined so each 'master' gets (roughly) 32*nCellsInCoarsestLevel cells. nProcessorsPerMaster 32;

Alternative : specify number of (equi-distributed) masters nMasters 2;

Restart local agglomeration after processor agglomeration. Used as nCellsInCoarsestLevel. Only applicable for pair-wise local agglomeration methods. nCellsInMasterLevel 1; }

Source files

Definition at line 77 of file masterCoarsestGAMGProcAgglomeration.H.

Constructor & Destructor Documentation

◆ masterCoarsestGAMGProcAgglomeration()

masterCoarsestGAMGProcAgglomeration	(	GAMGAgglomeration &	agglom,
		const dictionary &	controlDict
	)

Construct given agglomerator and controls.

Definition at line 44 of file masterCoarsestGAMGProcAgglomeration.C.

References lduMesh::comm(), controlDict(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, MeshObject< Mesh, MeshObjectType, Type >::mesh(), and Foam::readLabel().

Here is the call graph for this function:

◆ ~masterCoarsestGAMGProcAgglomeration()

~masterCoarsestGAMGProcAgglomeration ( )

virtual

Destructor.

Definition at line 100 of file masterCoarsestGAMGProcAgglomeration.C.

Member Function Documentation

◆ TypeName()

TypeName ( "masterCoarsest" )

Runtime type information.

◆ agglomerate()

bool agglomerate ( )

virtual

Modify agglomeration. Return true if modified.

Implements GAMGProcAgglomeration.

Definition at line 106 of file masterCoarsestGAMGProcAgglomeration.C.

References GAMGProcAgglomeration::agglomerate(), UList< T >::back(), GAMGAgglomeration::calculateRegionMaster(), lduMesh::comm(), Foam::ensightOutput::debug, Foam::endl(), Foam::flatOutput(), forAll, Foam::Info, Foam::invertOneToMany(), lduMesh::lduAddr(), UPstream::myProcNo(), UPstream::newCommunicator(), Foam::nl, UPstream::nProcs(), p, Foam::Pout, UList< T >::size(), and Foam::Zero.
