turbulentMixingLengthFrequencyInletFvPatchScalarField Class Reference
Turbulence models » RAS turbulence » Boundary conditionsBoundary conditions » | Inlet

This boundary condition provides a turbulence specific dissipation, $\omega$ (omega) inlet condition based on a specified mixing length. The patch values are calculated using: More...

Inheritance diagram for turbulentMixingLengthFrequencyInletFvPatchScalarField:
Inheritance graph
[legend]
Collaboration diagram for turbulentMixingLengthFrequencyInletFvPatchScalarField:
Collaboration graph
[legend]

Public Member Functions

 TypeName ("turbulentMixingLengthFrequencyInlet")
 Runtime type information. More...

 turbulentMixingLengthFrequencyInletFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &)
 Construct from patch and internal field. More...

 turbulentMixingLengthFrequencyInletFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
 Construct from patch, internal field and dictionary. More...

 turbulentMixingLengthFrequencyInletFvPatchScalarField (const turbulentMixingLengthFrequencyInletFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fvPatchFieldMapper &)
 Construct by mapping given. More...

 turbulentMixingLengthFrequencyInletFvPatchScalarField (const turbulentMixingLengthFrequencyInletFvPatchScalarField &)
 Construct as copy. More...

 turbulentMixingLengthFrequencyInletFvPatchScalarField (const turbulentMixingLengthFrequencyInletFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
 Construct as copy setting internal field reference. More...

virtual tmp< fvPatchField< scalar > > clone () const
 Return a clone. More...

virtual tmp< fvPatchField< scalar > > clone (const DimensionedField< scalar, volMesh > &iF) const
 Clone with an internal field reference. More...

virtual void updateCoeffs ()
 Update the coefficients associated with the patch field. More...

virtual void write (Ostream &) const
 Write. More...


Detailed Description

This boundary condition provides a turbulence specific dissipation, $\omega$ (omega) inlet condition based on a specified mixing length. The patch values are calculated using:

\[ \omega_p = \frac{k^{0.5}}{C_{\mu}^{0.25} L} \]

where

$ \omega_p $ = patch omega values
$ C_{\mu} $ = Model coefficient, set to 0.09
$ k $ = turbulence kinetic energy
$ L $ = length scale
Usage
Property Description Required Default value
mixingLength Length scale [m] yes
phi flux field name no phi
k turbulence kinetic energy field name no k

Example of the boundary condition specification:

    <patchName>
    {
        type            turbulentMixingLengthFrequencyInlet;
        mixingLength    0.005;
        value           uniform 200;   // placeholder
    }
Note
In the event of reverse flow, a zero-gradient condition is applied
See also
Foam::inletOutletFvPatchField
Source files

Definition at line 125 of file turbulentMixingLengthFrequencyInletFvPatchScalarField.H.

Constructor & Destructor Documentation

◆ turbulentMixingLengthFrequencyInletFvPatchScalarField() [1/5]

turbulentMixingLengthFrequencyInletFvPatchScalarField ( const fvPatch &  p,
const DimensionedField< scalar, volMesh > &  iF
)

Construct from patch and internal field.

Definition at line 38 of file turbulentMixingLengthFrequencyInletFvPatchScalarField.C.

References Foam::Zero.

◆ turbulentMixingLengthFrequencyInletFvPatchScalarField() [2/5]

turbulentMixingLengthFrequencyInletFvPatchScalarField ( const fvPatch &  p,
const DimensionedField< scalar, volMesh > &  iF,
const dictionary &  dict
)

Construct from patch, internal field and dictionary.

Definition at line 68 of file turbulentMixingLengthFrequencyInletFvPatchScalarField.C.

References dict, dictionary::getOrDefault(), IOobjectOption::MUST_READ, and Foam::Zero.

Here is the call graph for this function:

◆ turbulentMixingLengthFrequencyInletFvPatchScalarField() [3/5]

turbulentMixingLengthFrequencyInletFvPatchScalarField ( const turbulentMixingLengthFrequencyInletFvPatchScalarField &  ptf,
const fvPatch &  p,
const DimensionedField< scalar, volMesh > &  iF,
const fvPatchFieldMapper &  mapper
)

Construct by mapping given.

turbulentMixingLengthFrequencyInletFvPatchScalarField onto a new patch

Definition at line 54 of file turbulentMixingLengthFrequencyInletFvPatchScalarField.C.

◆ turbulentMixingLengthFrequencyInletFvPatchScalarField() [4/5]

turbulentMixingLengthFrequencyInletFvPatchScalarField ( const turbulentMixingLengthFrequencyInletFvPatchScalarField &  ptf)

Construct as copy.

Definition at line 89 of file turbulentMixingLengthFrequencyInletFvPatchScalarField.C.

◆ turbulentMixingLengthFrequencyInletFvPatchScalarField() [5/5]

turbulentMixingLengthFrequencyInletFvPatchScalarField ( const turbulentMixingLengthFrequencyInletFvPatchScalarField &  ptf,
const DimensionedField< scalar, volMesh > &  iF
)

Construct as copy setting internal field reference.

Definition at line 100 of file turbulentMixingLengthFrequencyInletFvPatchScalarField.C.

Member Function Documentation

◆ TypeName()

TypeName ( "turbulentMixingLengthFrequencyInlet"  )

Runtime type information.

◆ clone() [1/2]

virtual tmp<fvPatchField<scalar> > clone ( ) const
inlinevirtual

Return a clone.

Definition at line 205 of file turbulentMixingLengthFrequencyInletFvPatchScalarField.H.

References fvPatchField< Type >::Clone().

Here is the call graph for this function:

◆ clone() [2/2]

virtual tmp<fvPatchField<scalar> > clone ( const DimensionedField< scalar, volMesh > &  iF) const
inlinevirtual

Clone with an internal field reference.

Definition at line 214 of file turbulentMixingLengthFrequencyInletFvPatchScalarField.H.

References fvPatchField< Type >::Clone().

Here is the call graph for this function:

◆ updateCoeffs()

void updateCoeffs ( )
virtual

Update the coefficients associated with the patch field.

Definition at line 113 of file turbulentMixingLengthFrequencyInletFvPatchScalarField.C.

References turbulenceModel::coeffDict(), dictionary::getOrDefault(), Foam::constant::atomic::group, IOobject::groupName(), Foam::neg(), Foam::foamVersion::patch, Foam::pow(), turbulenceModel::propertiesName, and Foam::sqrt().

Here is the call graph for this function:

◆ write()

void write ( Ostream &  os) const
virtual

Write.

Definition at line 149 of file turbulentMixingLengthFrequencyInletFvPatchScalarField.C.

References os(), fvPatchField< Type >::write(), Ostream::writeEntry(), and fvPatchField< Type >::writeValueEntry().

Here is the call graph for this function:
The documentation for this class was generated from the following files:
