Thermodynamic parcel class with one/two-way coupling with the continuous phase. Includes Kinematic parcel sub-models, plus: More...

Inheritance diagram for ThermoParcel< ParcelType >:

[legend]

Collaboration diagram for ThermoParcel< ParcelType >:

[legend]

Classes
class	constantProperties
	Class to hold thermo particle constant properties. More...

class	iNew
	Factory class to read-construct particles (for parallel transfer) More...

class	trackingData

Public Member Functions
	TypeName ("ThermoParcel")
	Runtime type information. More...

	AddToPropertyList (ParcelType, " T"+" Cp")
	String representation of properties. More...

	ThermoParcel (const polyMesh &mesh, const barycentric &coordinates, const label celli, const label tetFacei, const label tetPti)
	Construct from mesh, coordinates and topology. More...

	ThermoParcel (const polyMesh &mesh, const vector &position, const label celli)
	Construct from a position and a cell, searching for the rest of the. More...

	ThermoParcel (const polyMesh &mesh, const barycentric &coordinates, const label celli, const label tetFacei, const label tetPti, const label typeId, const scalar nParticle0, const scalar d0, const scalar dTarget0, const vector &U0, const vector &f0, const vector &angularMomentum0, const vector &torque0, const constantProperties &constProps)
	Construct from components. More...

	ThermoParcel (const polyMesh &mesh, Istream &is, bool readFields=true, bool newFormat=true)
	Construct from Istream. More...

	ThermoParcel (const ThermoParcel &p)
	Construct as a copy. More...

	ThermoParcel (const ThermoParcel &p, const polyMesh &mesh)
	Construct as a copy. More...

virtual autoPtr< particle >	clone () const
	Return a (basic particle) clone. More...

virtual autoPtr< particle >	clone (const polyMesh &mesh) const
	Return a (basic particle) clone. More...

scalar	T () const
	Return const access to temperature. More...

scalar	Cp () const
	Return const access to specific heat capacity. More...

scalar	hs () const
	Return the parcel sensible enthalpy. More...

scalar &	T ()
	Return access to temperature. More...

scalar &	Cp ()
	Return access to specific heat capacity. More...

template<class TrackCloudType >
void	setCellValues (TrackCloudType &cloud, trackingData &td)
	Set cell values. More...

template<class TrackCloudType >
void	cellValueSourceCorrection (TrackCloudType &cloud, trackingData &td, const scalar dt)
	Correct cell values using latest transfer information. More...

template<class TrackCloudType >
void	calcSurfaceValues (TrackCloudType &cloud, trackingData &td, const scalar T, scalar &Ts, scalar &rhos, scalar &mus, scalar &Pr, scalar &kappas) const
	Calculate surface thermo properties. More...

template<class TrackCloudType >
void	calc (TrackCloudType &cloud, trackingData &td, const scalar dt)
	Update parcel properties over the time interval. More...

void	writeProperties (Ostream &os, const wordRes &filters, const word &delim, const bool namesOnly=false) const
	Write individual parcel properties to stream. More...

template<class TrackCloudType >
Foam::scalar	calcHeatTransfer (TrackCloudType &cloud, trackingData &td, const scalar dt, const scalar Re, const scalar Pr, const scalar kappa, const scalar NCpW, const scalar Sh, scalar &dhsTrans, scalar &Sph)

Static Public Member Functions
template<class CloudType >
static void	readFields (CloudType &c)
	Read. More...

template<class CloudType >
static void	writeFields (const CloudType &c)
	Write. More...

template<class CloudType >
static void	readObjects (CloudType &c, const objectRegistry &obr)
	Read particle fields as objects from the obr registry. More...

template<class CloudType >
static void	writeObjects (const CloudType &c, objectRegistry &obr)
	Write particle fields as objects into the obr registry. More...

Static Public Attributes
static const std::size_t	sizeofFields
	Size in bytes of the fields. More...

Protected Member Functions
template<class TrackCloudType >
scalar	calcHeatTransfer (TrackCloudType &cloud, trackingData &td, const scalar dt, const scalar Re, const scalar Pr, const scalar kappa, const scalar NCpW, const scalar Sh, scalar &dhsTrans, scalar &Sph)
	Calculate new particle temperature. More...

Protected Attributes
scalar	T_
	Temperature [K]. More...

scalar	Cp_
	Specific heat capacity [J/(kg.K)]. More...

Friends
Ostream &	operator (Ostream &, const ThermoParcel< ParcelType > &)

Detailed Description

template<class ParcelType>
class Foam::ThermoParcel< ParcelType >

Thermodynamic parcel class with one/two-way coupling with the continuous phase. Includes Kinematic parcel sub-models, plus:

heat transfer

Source files

Definition at line 53 of file ThermoParcel.H.

Constructor & Destructor Documentation

◆ ThermoParcel() [1/6]

ThermoParcel	(	const polyMesh &	mesh,
		const barycentric &	coordinates,
		const label	celli,
		const label	tetFacei,
		const label	tetPti
	)

inline

Construct from mesh, coordinates and topology.

Other properties initialised as null

Definition at line 70 of file ThermoParcelI.H.

◆ ThermoParcel() [2/6]

ThermoParcel	(	const polyMesh &	mesh,
		const vector &	position,
		const label	celli
	)

inline

Construct from a position and a cell, searching for the rest of the.

required topology. Other properties are initialised as null.

Definition at line 86 of file ThermoParcelI.H.

◆ ThermoParcel() [3/6]

ThermoParcel	(	const polyMesh &	mesh,
		const barycentric &	coordinates,
		const label	celli,
		const label	tetFacei,
		const label	tetPti,
		const label	typeId,
		const scalar	nParticle0,
		const scalar	d0,
		const scalar	dTarget0,
		const vector &	U0,
		const vector &	f0,
		const vector &	angularMomentum0,
		const vector &	torque0,
		const constantProperties &	constProps
	)

inline

Construct from components.

Definition at line 100 of file ThermoParcelI.H.

◆ ThermoParcel() [4/6]

ThermoParcel	(	const polyMesh &	mesh,
		Istream &	is,
		bool	readFields = `true`,
		bool	newFormat = `true`
	)

Construct from Istream.

Definition at line 44 of file ThermoParcelIO.C.

References Istream::beginRawRead(), IOstream::check(), IOstream::checkLabelSize(), IOstream::checkScalarSize(), Istream::endRawRead(), IOstreamOption::format(), FUNCTION_NAME, Istream::read(), and Foam::readFields().

Here is the call graph for this function:

◆ ThermoParcel() [5/6]

ThermoParcel ( const ThermoParcel< ParcelType > & p )

Construct as a copy.

◆ ThermoParcel() [6/6]

ThermoParcel	(	const ThermoParcel< ParcelType > &	p,
		const polyMesh &	mesh
	)

Construct as a copy.

Member Function Documentation

◆ calcHeatTransfer() [1/2]

scalar calcHeatTransfer	(	TrackCloudType &	cloud,
		trackingData &	td,
		const scalar	dt,
		const scalar	Re,
		const scalar	Pr,
		const scalar	kappa,
		const scalar	NCpW,
		const scalar	Sh,
		scalar &	dhsTrans,
		scalar &	Sph
	)

protected

Calculate new particle temperature.

◆ TypeName()

TypeName ( "ThermoParcel< ParcelType >" )

Runtime type information.

◆ AddToPropertyList()

AddToPropertyList	(	ParcelType	,
		" T"+" Cp"
	)

String representation of properties.

◆ clone() [1/2]

virtual autoPtr<particle> clone ( ) const

inlinevirtual

Return a (basic particle) clone.

Definition at line 456 of file ThermoParcel.H.

References particle< Type >::Clone().

Here is the call graph for this function:

◆ clone() [2/2]

virtual autoPtr<particle> clone ( const polyMesh & mesh ) const

inlinevirtual

Return a (basic particle) clone.

Definition at line 464 of file ThermoParcel.H.

References particle< Type >::Clone(), and mesh.

Here is the call graph for this function:

◆ T() [1/2]

Foam::scalar T ( ) const

inline

Return const access to temperature.

Definition at line 200 of file ThermoParcelI.H.

References ThermoParcel< ParcelType >::T_.

◆ Cp() [1/2]

Foam::scalar Cp ( ) const

inline

Return const access to specific heat capacity.

Definition at line 207 of file ThermoParcelI.H.

References ThermoParcel< ParcelType >::Cp_.

◆ hs()

Foam::scalar hs ( ) const

inline

Return the parcel sensible enthalpy.

Definition at line 214 of file ThermoParcelI.H.

References ThermoParcel< ParcelType >::Cp_, and ThermoParcel< ParcelType >::T_.

◆ T() [2/2]

Foam::scalar & T ( )

inline

Return access to temperature.

Definition at line 221 of file ThermoParcelI.H.

References ThermoParcel< ParcelType >::T_.

◆ Cp() [2/2]

Foam::scalar & Cp ( )

inline

Return access to specific heat capacity.

Definition at line 228 of file ThermoParcelI.H.

References ThermoParcel< ParcelType >::Cp_.

◆ setCellValues()

void setCellValues	(	TrackCloudType &	cloud,
		trackingData &	td
	)

Set cell values.

Definition at line 31 of file ThermoParcel.C.

References coordinates(), Foam::ensightOutput::debug, Foam::endl(), Foam::nl, td(), and WarningInFunction.

Here is the call graph for this function:

◆ cellValueSourceCorrection()

void cellValueSourceCorrection	(	TrackCloudType &	cloud,
		trackingData &	td,
		const scalar	dt
	)

Correct cell values using latest transfer information.

Definition at line 61 of file ThermoParcel.C.

References Foam::ensightOutput::debug, Foam::endl(), Foam::nl, td(), and WarningInFunction.

Here is the call graph for this function:

◆ calcSurfaceValues()

void calcSurfaceValues	(	TrackCloudType &	cloud,
		trackingData &	td,
		const scalar	T,
		scalar &	Ts,
		scalar &	rhos,
		scalar &	mus,
		scalar &	Pr,
		scalar &	kappas
	)		const

Calculate surface thermo properties.

Definition at line 95 of file ThermoParcel.C.

References coordinates(), Foam::ensightOutput::debug, Foam::endl(), Foam::max(), Foam::nl, Pr(), Foam::T(), td(), and WarningInFunction.

Here is the call graph for this function:

◆ calc()

void calc	(	TrackCloudType &	cloud,
		trackingData &	td,
		const scalar	dt
	)

Update parcel properties over the time interval.

Definition at line 138 of file ThermoParcel.C.

References Foam::pow4(), Pr(), Foam::Re(), Su, T0, td(), and Foam::Zero.

Here is the call graph for this function:

◆ readFields()

void readFields ( CloudType & c )

static

Read.

Definition at line 84 of file ThermoParcelIO.C.

References Foam::constant::universal::c, Cp, p, Foam::readFields(), and T.

Here is the call graph for this function:

◆ writeFields()

void writeFields ( const CloudType & c )

static

Write.

Definition at line 110 of file ThermoParcelIO.C.

References Foam::constant::universal::c, Cp, p, T, and Foam::writeFields().

Here is the call graph for this function:

◆ writeProperties()

void writeProperties	(	Ostream &	os,
		const wordRes &	filters,
		const word &	delim,
		const bool	namesOnly = `false`
	)		const

Write individual parcel properties to stream.

Definition at line 136 of file ThermoParcelIO.C.

References os(), and writeProp.

Here is the call graph for this function:

◆ readObjects()

void readObjects	(	CloudType &	c,
		const objectRegistry &	obr
	)

static

Read particle fields as objects from the obr registry.

Definition at line 159 of file ThermoParcelIO.C.

References Foam::constant::universal::c, Cp, p, Foam::readFields(), and T.

Here is the call graph for this function:

◆ writeObjects()

void writeObjects	(	const CloudType &	c,
		objectRegistry &	obr
	)

static

Write particle fields as objects into the obr registry.

Definition at line 185 of file ThermoParcelIO.C.

References Foam::constant::universal::c, Cp, p, and T.

◆ calcHeatTransfer() [2/2]

Foam::scalar calcHeatTransfer	(	TrackCloudType &	cloud,
		trackingData &	td,
		const scalar	dt,
		const scalar	Re,
		const scalar	Pr,
		const scalar	kappa,
		const scalar	NCpW,
		const scalar	Sh,
		scalar &	dhsTrans,
		scalar &	Sph
	)

Definition at line 247 of file ThermoParcel.C.

References Foam::clamp(), coordinates(), epsilon, Foam::constant::electromagnetic::kappa, Foam::pow4(), Pr(), Foam::Re(), rho, sigma(), Foam::constant::physicoChemical::sigma, td(), dimensioned< Type >::value(), and Foam::fieldTypes::volume.

Here is the call graph for this function:

Friends And Related Function Documentation

◆ operator

Ostream& operator	(	Ostream &	,
		const ThermoParcel< ParcelType > &
	)

friend

Member Data Documentation

◆ sizeofFields

const std::size_t sizeofFields

static

Size in bytes of the fields.

Definition at line 76 of file ThermoParcel.H.

◆ T_

scalar T_

protected

Temperature [K].

Definition at line 334 of file ThermoParcel.H.

Referenced by ThermoParcel< ParcelType >::hs(), and ThermoParcel< ParcelType >::T().

◆ Cp_

scalar Cp_

protected

Specific heat capacity [J/(kg.K)].

Definition at line 339 of file ThermoParcel.H.

Referenced by ThermoParcel< ParcelType >::Cp(), and ThermoParcel< ParcelType >::hs().

The documentation for this class was generated from the following files:

src/lagrangian/intermediate/parcels/Templates/ThermoParcel/ThermoParcel.H
src/lagrangian/intermediate/parcels/Templates/ThermoParcel/ThermoParcel.C
src/lagrangian/intermediate/parcels/Templates/ThermoParcel/ThermoParcelI.H
src/lagrangian/intermediate/parcels/Templates/ThermoParcel/ThermoParcelIO.C

Classes

Public Member Functions

Static Public Member Functions

Static Public Attributes

Protected Member Functions

Protected Attributes

Friends

Detailed Description

template<class ParcelType> class Foam::ThermoParcel< ParcelType >

Constructor & Destructor Documentation

◆ ThermoParcel() [1/6]

◆ ThermoParcel() [2/6]

◆ ThermoParcel() [3/6]

◆ ThermoParcel() [4/6]

◆ ThermoParcel() [5/6]

◆ ThermoParcel() [6/6]

Member Function Documentation

◆ calcHeatTransfer() [1/2]

◆ TypeName()

◆ AddToPropertyList()

◆ clone() [1/2]

◆ clone() [2/2]

◆ T() [1/2]

◆ Cp() [1/2]

◆ hs()

◆ T() [2/2]

◆ Cp() [2/2]

◆ setCellValues()

◆ cellValueSourceCorrection()

◆ calcSurfaceValues()

◆ calc()

◆ readFields()

◆ writeFields()

◆ writeProperties()

◆ readObjects()

◆ writeObjects()

◆ calcHeatTransfer() [2/2]

Friends And Related Function Documentation

◆ operator

Member Data Documentation

◆ sizeofFields

◆ T_

◆ Cp_

template<class ParcelType>
class Foam::ThermoParcel< ParcelType >
