A surface geometry mesh with zone information, not to be confused with the similarly named surfaceMesh, which actually refers to the cell faces of a volume mesh. More...

Inheritance diagram for MeshedSurface< Face >:

[legend]

Collaboration diagram for MeshedSurface< Face >:

[legend]

Public Types
typedef Face	face_type
	The face type (same as the underlying PrimitivePatch) More...

typedef point	point_type
	The point type (same as the underlying PrimitivePatch) More...

Public Types inherited from PrimitivePatch<::Foam::List< Face >, pointField >
enum	surfaceTopo
	Enumeration defining the surface type. Used in check routines. More...

typedef std::remove_reference< ::Foam::List< Face > >::type::value_type	face_type
	The face type. More...

typedef std::remove_reference< pointField >::type::value_type	point_type
	The point type. More...

typedef ::Foam::List< Face >	FaceListType
	The face list type. More...

typedef pointField	PointFieldType
	The point field type. More...

typedef face_type	FaceType
	Deprecated(2020-03) prefer face_type typedef. More...

Public Types inherited from List< Face >
typedef SubList< Face >	subList
	Declare type of subList. More...

Public Types inherited from UList< Face >
typedef Face	value_type
	The value type the list contains. More...

typedef Face *	pointer
	The pointer type for non-const access to value_type items. More...

typedef const Face *	const_pointer
	The pointer type for const access to value_type items. More...

typedef Face &	reference
	The type used for storing into value_type objects. More...

typedef const Face &	const_reference
	The type used for reading from constant value_type objects. More...

typedef Face *	iterator
	Random access iterator for traversing a UList. More...

typedef const Face *	const_iterator
	Random access iterator for traversing a UList. More...

typedef label	size_type
	The type to represent the size of a UList. More...

typedef label	difference_type
	The difference between iterator objects. More...

typedef std::reverse_iterator< iterator >	reverse_iterator
	Reverse iterator (non-const access) More...

typedef std::reverse_iterator< const_iterator >	const_reverse_iterator
	Reverse iterator (const access) More...

Public Member Functions
	ClassName ("MeshedSurface")
	Declare type-name (with debug switch) More...

	MeshedSurface ()
	Default construct, an empty surface. More...

	MeshedSurface (const MeshedSurface &surf)
	Copy construct. More...

	MeshedSurface (const UnsortedMeshedSurface< Face > &surf)
	Copy construct from an UnsortedMeshedSurface. More...

	MeshedSurface (MeshedSurface &&surf)
	Move construct. More...

	MeshedSurface (UnsortedMeshedSurface< Face > &&surf)
	Move construct from an UnsortedMeshedSurface. More...

	MeshedSurface (const pointField &pointLst, const UList< Face > &faceLst, const UList< surfZone > &zoneLst)
	Copy construct from components (points, faces, zones). More...

	MeshedSurface (pointField &&pointLst, List< Face > &&faceLst, const UList< surfZone > &zoneLst)
	Move construct from components (points, faces). More...

	MeshedSurface (const pointField &pointLst, const UList< Face > &faceLst, const labelUList &zoneSizes=labelUList(), const UList< word > &zoneNames=UList< word >())
	Copy construct from components (points, faces). More...

	MeshedSurface (pointField &&pointLst, List< Face > &&faceLst, const labelUList &zoneSizes=labelUList(), const UList< word > &zoneNames=UList< word >())
	Move construct from components (points, faces). More...

	MeshedSurface (const polyBoundaryMesh &bMesh, const bool globalPoints=false)
	Construct from a boundary mesh with local points/faces. More...

	MeshedSurface (const surfMesh &mesh)
	Construct from a surfMesh. More...

	MeshedSurface (const fileName &name)
	Construct from file name (uses extension to determine type) More...

	MeshedSurface (const fileName &name, const word &fileType)
	Construct from file name and given file type. More...

	MeshedSurface (Istream &is)
	Construct from Istream. More...

	MeshedSurface (const Time &runTime)
	Construct from database (as surfMesh) with default name. More...

	MeshedSurface (const Time &runTime, const word &surfName)
	Construct from database (as surfMesh) with given surface name. More...

	MeshedSurface (const IOobject &io, const dictionary &dict, const bool isGlobal=true)
	Read construct using IO to find the file location. More...

	declareRunTimeSelectionTable (autoPtr, MeshedSurface, fileExtension,(const fileName &name),(name))

virtual	~MeshedSurface ()
	Destructor. More...

	declareMemberFunctionSelectionTable (void, UnsortedMeshedSurface, write, fileExtension,(const fileName &name, const MeshedSurface< Face > &surf, IOstreamOption streamOpt, const dictionary &options),(name, surf, streamOpt, options))

label	size () const
	The surface size is the number of faces. More...

const List< Face > &	surfFaces () const
	Return const access to the faces. More...

const labelList &	faceIds () const
	Return const access to faces ids. More...

const surfZoneList &	surfZones () const
	Const access to the surface zones. More...

const vectorField &	Sf () const
	Face area vectors (normals) More...

const scalarField &	magSf () const
	Face area magnitudes. More...

const vectorField &	Cf () const
	Face centres. More...

virtual void	clear ()
	Clear all storage. More...

virtual void	addZones (const UList< surfZone > &, const bool cullEmpty=false)
	Add surface zones. More...

virtual void	addZones (const labelUList &sizes, const UList< word > &names, const bool cullEmpty=false)
	Add surface zones. More...

virtual void	addZones (const labelUList &sizes, const bool cullEmpty=false)
	Add surface zones. More...

bool	addZonesToFaces ()
	Propagate zone information on face regions. More...

virtual void	removeZones ()
	Remove surface zones. More...

virtual void	movePoints (const pointField &newPoints)
	Move points. More...

virtual void	scalePoints (const scalar scaleFactor)
	Scale points. A non-positive factor is ignored. More...

virtual void	cleanup (const bool verbose)
	Remove invalid faces. More...

virtual void	compactPoints (labelList &pointMap=const_cast< labelList &>(labelList::null()))
	Remove unused points and renumber faces in local visit order. More...

virtual bool	stitchFaces (const scalar tol=SMALL, const bool verbose=false)

virtual bool	checkFaces (const bool verbose=false)

virtual label	nTriangles () const
	Count number of triangles. More...

virtual label	nTriangles (labelList &faceMap) const
	Count number of triangles, returning a face map of original ids. More...

virtual label	triangulate ()
	Triangulate in-place, returning the number of triangles added. More...

virtual label	triangulate (labelList &faceMap)
	Triangulate in-place, returning the number of triangles added. More...

template<class BoolListType >
void	subsetMeshMap (const BoolListType &include, labelList &pointMap, labelList &faceMap) const
	Create mappings for a sub-surface. More...

MeshedSurface	subsetMesh (const UList< bool > &include, labelList &pointMap, labelList &faceMap) const
	Return a new surface subsetted on the selected faces. More...

MeshedSurface	subsetMesh (const bitSet &include, labelList &pointMap, labelList &faceMap) const
	Return a new surface subsetted on the selected faces. More...

MeshedSurface	subsetMesh (const UList< bool > &include) const
	Return a new surface subsetted on the selected faces. More...

MeshedSurface	subsetMesh (const bitSet &include) const
	Return a new surface subsetted on the selected faces. More...

MeshedSurface	subsetMesh (const wordRes &includeNames, const wordRes &excludeNames=wordRes()) const
	Return a new surface subsetted on the selected zone names. More...

void	swap (MeshedSurface< Face > &surf)
	Swap contents. More...

void	transfer (pointField &pointLst, List< Face > &faceLst)
	Transfer the components. More...

void	transfer (MeshedSurface< Face > &surf)
	Transfer the contents of the argument and annul the argument. More...

void	transfer (UnsortedMeshedSurface< Face > &surf)
	Transfer the contents of the argument and annul the argument. More...

autoPtr< MeshedSurface< Face > >	releaseGeom ()
	Release (clear) geometry and return for reuse. More...

void	swapFaces (List< Face > &faces)
	Swap the stored faces. Use with caution. More...

void	swapPoints (pointField &points)
	Swap the stored points. More...

bool	read (const fileName &name, const word &fileType)
	Read from file. Chooses reader based on explicit extension. More...

virtual bool	read (const fileName &name)
	Read from file. Chooses reader based on detected extension. More...

void	writeStats (Ostream &os) const

virtual void	write (const fileName &name, IOstreamOption streamOpt=IOstreamOption(), const dictionary &options=dictionary::null) const
	Generic write routine. Chooses writer based on extension. More...

virtual void	write (const fileName &name, const word &fileType, IOstreamOption streamOpt=IOstreamOption(), const dictionary &options=dictionary::null) const
	Generic write routine for given format type. More...

void	write (const Time &runTime, const word &surfName=word::null) const
	Write to database. More...

void	operator= (const MeshedSurface< Face > &surf)
	Copy assignment. More...

void	operator= (MeshedSurface< Face > &&surf)
	Move assignment. More...

	operator MeshedSurfaceProxy< Face > () const
	Conversion operator to MeshedSurfaceProxy. More...

template<class Face>
	MeshedSurface (const MeshedSurface< Face > &surf)

template<class Face>
	MeshedSurface (MeshedSurface< Face > &&surf)

template<>
bool	addZonesToFaces ()
	Specialization for labelledTri. More...

template<>
bool	addZonesToFaces ()

Public Member Functions inherited from PrimitivePatch<::Foam::List< Face >, pointField >
	PrimitivePatch (const ::Foam::List< Face > &faces, const pointField &points)
	Construct from components. More...

	PrimitivePatch (::Foam::List< Face > &&faces, const pointField &points)
	Construct from components, transferring faces. More...

	PrimitivePatch (::Foam::List< Face > &faces, pointField &points, const bool reuse)
	Construct from components, reuse storage. More...

	PrimitivePatch (const PrimitivePatch< ::Foam::List< Face >, pointField > &pp)
	Copy construct. More...

virtual	~PrimitivePatch ()
	Destructor. More...

void	clearOut ()

void	clearGeom ()

void	clearTopology ()

void	clearPatchMeshAddr ()

void	swap (PrimitivePatch &)=delete
	Suppress direct swapping, since storage containers may be const. More...

const Field< point_type > &	points () const noexcept
	Return reference to global points. More...

label	nFaces () const noexcept
	Number of faces in the patch. More...

label	nPoints () const
	Number of points supporting patch faces. More...

label	nEdges () const
	Number of edges in patch. More...

const edgeList &	edges () const
	Return list of edges, address into LOCAL point list. More...

const edgeList::subList	internalEdges () const
	Return sub-list of internal edges, address into LOCAL point list. More...

const edgeList::subList	boundaryEdges () const
	Return sub-list of boundary edges, address into LOCAL point list. More...

label	nInternalEdges () const
	Number of internal edges. More...

label	nBoundaryEdges () const
	Number of boundary edges == (nEdges() - nInternalEdges()) More...

bool	isInternalEdge (const label edgei) const
	Is internal edge? More...

const labelList &	boundaryPoints () const
	Return list of boundary points, address into LOCAL point list. More...

const labelListList &	faceFaces () const
	Return face-face addressing. More...

const labelListList &	edgeFaces () const
	Return edge-face addressing. More...

const labelListList &	faceEdges () const
	Return face-edge addressing. More...

const labelListList &	pointEdges () const
	Return point-edge addressing. More...

const labelListList &	pointFaces () const
	Return point-face addressing. More...

const List< face_type > &	localFaces () const
	Return patch faces addressing into local point list. More...

labelList	boundaryFaces () const
	Extract list of local faces corresponding to the boundary edges. More...

labelList	uniqBoundaryFaces () const
	Extract sorted list of unique local faces associated with the boundary edges. More...

const labelList &	meshPoints () const
	Return labelList of mesh points in patch. More...

const Map< label > &	meshPointMap () const
	Mesh point map. More...

const Field< point_type > &	localPoints () const
	Return pointField of points in patch. More...

const labelList &	localPointOrder () const
	Return orders the local points for most efficient search. More...

label	whichPoint (const label gp) const
	Given a global point index, return the local point index. More...

edge	meshEdge (const label edgei) const
	From patch edge to global edge using meshPoints. More...

edge	meshEdge (const edge &e) const
	From patch edge to global edge using meshPoints. More...

label	meshEdge (const label edgei, const edgeList &allEdges, const labelListList &pointEdges) const
	Return label of the local patch edge into the global edge list using basic edge addressing. More...

label	findEdge (const edge &e) const
	Search for edge (local point labels) and return its index in the edge list or -1 if not found. More...

labelList	meshEdges (const edgeList &allEdges, const labelListList &cellEdges, const labelList &faceCells) const
	Return labels of patch edges in the global edge list using cell addressing. More...

labelList	meshEdges (const edgeList &allEdges, const labelListList &pointEdges) const
	Return labels of patch edges into the global edge list using basic edge addressing. More...

labelList	meshEdges (const labelUList &edgeLabels, const edgeList &allEdges, const labelListList &pointEdges) const
	Return labels of specified patch edges into the global edge list using basic edge addressing. More...

const Field< point_type > &	faceCentres () const
	Return face centres for patch. More...

const Field< point_type > &	faceAreas () const
	Return face area vectors for patch. More...

const Field< scalar > &	magFaceAreas () const
	Return face area magnitudes for patch. More...

const Field< point_type > &	faceNormals () const
	Return face unit normals for patch. More...

const Field< point_type > &	pointNormals () const
	Return point normals for patch. More...

Pair< point_type >	box () const
	The enclosing (bounding) box for the patch points. More...

scalar	sphere (const label facei) const
	The enclosing (bounding) sphere radius^2 for specified face. More...

bool	hasFaceAreas () const

bool	hasFaceCentres () const

bool	hasFaceNormals () const

bool	hasPointNormals () const

bool	hasBoundaryPoints () const

bool	hasEdges () const

bool	hasFaceFaces () const

bool	hasEdgeFaces () const

bool	hasFaceEdges () const

bool	hasPointEdges () const

bool	hasPointFaces () const

bool	hasMeshPoints () const

bool	hasMeshPointMap () const

List< objectHit >	projectPoints (const ToPatch &targetPatch, const Field< point_type > &projectionDirection, const intersection::algorithm=intersection::FULL_RAY, const intersection::direction=intersection::VECTOR) const
	Project vertices of patch onto another patch. More...

Foam::List< Foam::objectHit >	projectPoints (const ToPatch &targetPatch, const Field< typename Foam::PrimitivePatch< ::Foam::List< Face >, pointField >::point_type > &projectionDirection, const intersection::algorithm alg, const intersection::direction dir) const

List< objectHit >	projectFaceCentres (const ToPatch &targetPatch, const Field< point_type > &projectionDirection, const intersection::algorithm=intersection::FULL_RAY, const intersection::direction=intersection::VECTOR) const
	Project vertices of patch onto another patch. More...

Foam::List< Foam::objectHit >	projectFaceCentres (const ToPatch &targetPatch, const Field< typename Foam::PrimitivePatch< ::Foam::List< Face >, pointField >::point_type > &projectionDirection, const intersection::algorithm alg, const intersection::direction dir) const

const labelListList &	edgeLoops () const
	Return list of closed loops of boundary vertices. More...

surfaceTopo	surfaceType (labelHashSet *badEdgesPtr=nullptr) const
	Calculate surface type formed by patch, optionally recording the indices of illegal edges. More...

bool	checkTopology (const bool report=false, labelHashSet *pointSetPtr=nullptr) const
	Check surface formed by patch for manifoldness (see above). More...

bool	checkPointManifold (const bool report=false, labelHashSet *pointSetPtr=nullptr) const
	Checks primitivePatch for faces sharing point but not edge. More...

virtual void	movePoints (const Field< point_type > &)
	Correct patch after moving points. More...

void	operator= (const PrimitivePatch< ::Foam::List< Face >, pointField > &rhs)
	Copy assign faces. Leave points alone (could be a reference). More...

void	operator= (PrimitivePatch< ::Foam::List< Face >, pointField > &&rhs)
	Move assign faces. Leave points alone (could be a reference). More...

label	whichEdge (const edge &e) const
	Identical to findEdge. More...

Public Member Functions inherited from PrimitivePatchBase
	ClassName ("PrimitivePatch")
	Runtime type information. More...

	PrimitivePatchBase ()=default
	Default construct. More...

Public Member Functions inherited from List< Face >
constexpr	List () noexcept
	Default construct. More...

	List (const label len)
	Construct with given size. More...

	List (const label len, const Face &val)
	Construct with given size and value for all elements. More...

	List (const label len, const Foam::zero)
	Construct with given size initializing all elements to zero. More...

	List (const Foam::one, const Face &val)
	Construct with length=1, copying the value as the only content. More...

	List (const Foam::one, Face &&val)
	Construct with length=1, moving the value as the only content. More...

	List (const Foam::one, const Foam::zero)
	Construct with length=1, initializing content to zero. More...

	List (const List< Face > &list)
	Copy construct from list. More...

	List (const UList< Face > &list)
	Copy construct contents from list. More...

	List (List< Face > &list, bool reuse)
	Construct as copy or re-use as specified. More...

	List (const UList< Face > &list, const labelUList &indices)
	Copy construct subset of list. More...

	List (const UList< Face > &list, const FixedList< label, N > &indices)
	Copy construct subset of list. More...

	List (const FixedList< Face, N > &list)
	Construct as copy of FixedList<T, N> More...

	List (const PtrList< Face > &list)
	Construct as copy of PtrList<T> More...

	List (const IndirectListBase< Face, Addr > &list)
	Construct as copy of IndirectList contents. More...

	List (std::initializer_list< Face > list)
	Construct from an initializer list. More...

	List (List< Face > &&list) noexcept
	Move construct from List. More...

	List (DynamicList< Face, SizeMin > &&list)
	Move construct from DynamicList. More...

	List (Istream &is)
	Construct from Istream. More...

	List (const SLList< Face > &list)
	Copy construct from SLList. More...

autoPtr< List< Face > >	clone () const
	Clone. More...

	~List ()
	Destructor. More...

void	clear ()
	Clear the list, i.e. set size to zero. More...

void	resize (const label len)
	Adjust allocated size of list. More...

void	resize (const label len, const Face &val)
	Adjust allocated size of list and set val for new elements. More...

void	resize (const label newLen)

void	resize_fill (const label len, const Face &val)
	Adjust allocated size of list and set val for all elements. More...

void	resize_nocopy (const label len)
	Adjust allocated size of list without necessarily. More...

void	resize_unsafe (const label len) noexcept
	Change the addressed list size directly without affecting any memory management (advanced usage). More...

void	setSize (const label n)
	Alias for resize() More...

void	setSize (const label n, const Face &val)
	Alias for resize() More...

void	transfer (List< Face > &list)
	Transfer the contents of the argument List into this list and annul the argument list. More...

void	transfer (DynamicList< Face, SizeMin > &list)
	Transfer the contents of the argument List into this list and annul the argument list. More...

Face &	newElmt (const label i)
	Return subscript-checked element of UList and resizing the list if required. More...

Face &	emplace_back (Args &&... args)
	Construct an element at the end of the list, return reference to the new list element. More...

void	push_back (const Face &val)
	Append an element at the end of the list. More...

void	push_back (Face &&val)
	Move append an element at the end of the list. More...

void	push_back (const UList< Face > &list)
	Append a List to the end of this list. More...

void	push_back (const IndirectListBase< Face, Addr > &list)
	Append IndirectList contents at the end of this list. More...

label	push_uniq (const Face &val)
	Append an element if not already in the list. More...

void	pop_back (label n=1)
	Reduce size by 1 or more elements. Can be called on an empty list. More...

void	operator= (const UList< Face > &list)
	Assignment to UList operator. Takes linear time. More...

void	operator= (const List< Face > &list)
	Assignment operator. Takes linear time. More...

void	operator= (const IndirectListBase< Face, Addr > &list)
	Assignment from IndirectList. Takes linear time. More...

void	operator= (const FixedList< Face, N > &list)
	Copy assignment from FixedList. More...

void	operator= (std::initializer_list< Face > list)
	Assignment to an initializer list. More...

void	operator= (const Face &val)
	Assignment of all entries to the given value. More...

void	operator= (const Foam::zero)
	Assignment of all entries to zero. More...

void	operator= (List< Face > &&list)
	Move assignment. Takes constant time. More...

void	operator= (DynamicList< Face, SizeMin > &&list)
	Move assignment. Takes constant time. More...

void	operator= (const SLList< Face > &list)
	Copy assign from SLList in linear time. More...

Istream &	readList (Istream &is)
	Read List from Istream, discarding contents of existing List. More...

void	shallowCopy (const UList< Face > &)=delete
	No shallowCopy permitted. More...

std::enable_if< std::is_same< bool, TypeT >::value, bool >::type	set (const label i, bool val=true)
	A bitSet::set() method for a list of bool. More...

void	append (const Face &val)
	Append an element at the end of the list. More...

void	append (Face &&val)
	Move append an element at the end of the list. More...

void	append (const UList< Face > &list)
	Append a List to the end of this list. More...

void	append (const IndirectListBase< Face, Addr > &list)
	Append IndirectList contents at the end of this list. More...

label	appendUniq (const Face &val)
	Same as push_uniq() More...

Public Member Functions inherited from UList< Face >
label	size () const noexcept
	The number of elements in the container. More...

void	writeEntry (const word &keyword, Ostream &os) const
	Write the List as a dictionary entry with keyword. More...

void	operator= (const Face &val)
	Assignment of all entries to the given value. More...

void	operator= (const Foam::zero)
	Assignment of all entries to zero. More...

	UList (const UList< Face > &)=default
	Copy construct. More...

constexpr	UList () noexcept
	Default construct, zero-sized and nullptr. More...

	UList (Face *__restrict__ v, const label len) noexcept
	Construct from components. More...

label	fcIndex (const label i) const noexcept
	The forward circular index. The next index in the list which returns to the first at the end of the list. More...

label	rcIndex (const label i) const noexcept
	The reverse circular index. The previous index in the list which returns to the last at the beginning of the list. More...

const Face &	fcValue (const label i) const
	Return forward circular value (ie, next value in the list) More...

Face &	fcValue (const label i)
	Return forward circular value (ie, next value in the list) More...

const Face &	rcValue (const label i) const
	Return reverse circular value (ie, previous value in the list) More...

Face &	rcValue (const label i)
	Return reverse circular value (ie, previous value in the list) More...

const Face *	cdata () const noexcept
	Return pointer to the underlying array serving as data storage. More...

Face *	data () noexcept
	Return pointer to the underlying array serving as data storage. More...

const char *	cdata_bytes () const noexcept
	Return pointer to the underlying array serving as data storage,. More...

char *	data_bytes () noexcept
	Return pointer to the underlying array serving as data storage,. More...

Face &	front ()
	Access first element of the list, position [0]. More...

const Face &	front () const
	Access first element of the list. More...

Face &	back ()
	Access last element of the list, position [size()-1]. More...

const Face &	back () const
	Access last element of the list, position [size()-1]. More...

std::streamsize	size_bytes () const noexcept
	Number of contiguous bytes for the List data. More...

std::streamsize	byteSize () const
	Number of contiguous bytes for the List data, runtime FatalError if type is not contiguous. More...

void	checkStart (const label start) const
	Check start is within valid range [0,size) More...

void	checkSize (const label size) const
	Check size is within valid range [0,size]. More...

void	checkRange (const label start, const label len) const
	Check that start and length define a valid range. More...

void	checkIndex (const label i) const
	Check index is within valid range [0,size) More...

bool	uniform () const
	True if all entries have identical values, and list is non-empty. More...

bool	contains (const Face &val) const
	True if the value is contained in the list. More...

bool	contains (const Face &val, label pos, label len=-1) const
	Is the value contained in the list? More...

label	find (const Face &val) const
	Find index of the first occurrence of the value. More...

label	find (const Face &val, label pos, label len=-1) const
	Find index of the first occurrence of the value. More...

label	rfind (const Face &val, label pos=-1) const
	Find index of the last occurrence of the value. More...

void	moveFirst (const label i)
	Move element to the first position. More...

void	moveLast (const label i)
	Move element to the last position. More...

void	swapFirst (const label i)
	Swap element with the first element. Fatal on an empty list. More...

void	swapLast (const label i)
	Swap element with the last element. Fatal on an empty list. More...

void	shallowCopy (Face *__restrict__ ptr, const label len) noexcept
	Copy the pointer and size. More...

void	shallowCopy (std::nullptr_t) noexcept
	Copy nullptr and zero size. More...

void	shallowCopy (const UList< Face > &list) noexcept
	Copy the pointer and size held by the given UList. More...

void	deepCopy (const UList< Face > &list)
	Copy elements of the given UList. Sizes must match! More...

void	deepCopy (const IndirectListBase< Face, Addr > &list)
	Copy elements of the given indirect list. Sizes must match! More...

SubList< Face >	slice (const label pos, label len=-1)
	Return SubList slice (non-const access) - no range checking. More...

const SubList< Face >	slice (const label pos, label len=-1) const
	Return SubList slice (const access) - no range checking. More...

SubList< Face >	slice (const labelRange &range)
	Return SubList slice (non-const access) - with range checking. More...

const SubList< Face >	slice (const labelRange &range) const
	Return SubList slice (const access) - with range checking. More...

Face &	operator[] (const label i)
	Return element of UList. More...

const Face &	operator[] (const label i) const
	Return element of constant UList. More...

const bool &	operator[] (const label i) const

UPstream::commsStruct &	operator[] (const label procID)

const UPstream::commsStruct &	operator[] (const label procID) const

Foam::UPstream::commsStruct &	operator[] (const label procID)

const Foam::UPstream::commsStruct &	operator[] (const label procID) const

	operator const Foam::List< Face > & () const
	Allow cast to a const List<T>&. More...

iterator	begin () noexcept
	Return an iterator to begin traversing the UList. More...

iterator	begin (const label i) noexcept
	Return iterator at offset i from begin, clamped to [0,size] range. More...

const_iterator	begin () const noexcept
	Return const_iterator to begin traversing the constant UList. More...

const_iterator	begin (const label i) const noexcept
	Return const_iterator at offset i from begin, clamped to [0,size] range. More...

iterator	end () noexcept
	Return an iterator to end traversing the UList. More...

const_iterator	end () const noexcept
	Return const_iterator to end traversing the constant UList. More...

const_iterator	cbegin () const noexcept
	Return const_iterator to begin traversing the constant UList. More...

const_iterator	cbegin (const label i) const noexcept
	Return const_iterator at offset i from begin, clamped to [0,size] range. More...

const_iterator	cend () const noexcept
	Return const_iterator to end traversing the constant UList. More...

reverse_iterator	rbegin ()
	Return reverse_iterator to begin reverse traversing the UList. More...

const_reverse_iterator	rbegin () const
	Return const_reverse_iterator to begin reverse traversing the UList. More...

reverse_iterator	rend ()
	Return reverse_iterator to end reverse traversing the UList. More...

const_reverse_iterator	rend () const
	Return const_reverse_iterator to end reverse traversing the UList. More...

const_reverse_iterator	crbegin () const
	Return const_reverse_iterator to begin reverse traversing the UList. More...

const_reverse_iterator	crend () const
	Return const_reverse_iterator to end reverse traversing the UList. More...

bool	empty () const noexcept
	True if List is empty (ie, size() is zero) More...

label	capacity () const noexcept
	Size of the underlying storage. More...

void	swap (UList< Face > &list) noexcept
	Swap content with another UList of the same type in constant time. More...

bool	operator== (const UList< Face > &list) const
	Equality operation on ULists of the same type. More...

bool	operator!= (const UList< Face > &list) const
	The opposite of the equality operation. Takes linear time. More...

bool	operator< (const UList< Face > &list) const
	Compare two ULists lexicographically. Takes linear time. More...

bool	operator> (const UList< Face > &list) const
	Compare two ULists lexicographically. Takes linear time. More...

bool	operator<= (const UList< Face > &list) const
	Return true if !(a > b). Takes linear time. More...

bool	operator>= (const UList< Face > &list) const
	Return true if !(a < b). Takes linear time. More...

Istream &	readList (Istream &is)
	Read List contents from Istream. More...

Ostream &	writeList (Ostream &os, const label shortLen=0) const
	Write List, with line-breaks in ASCII when length exceeds shortLen. More...

std::enable_if< std::is_same< bool, TypeT >::value, bool >::type	test (const label i) const
	Test `bool` value at specified position, always false for out-of-range access. More...

std::enable_if< std::is_same< bool, TypeT >::value, bool >::type	get (const label i) const
	Return `bool` value at specified position, always false for out-of-range access. More...

std::enable_if< std::is_same< bool, TypeT >::value, bool >::type	unset (const label i)
	Unset the `bool` entry at specified position, always false for out-of-range access. More...

Face &	first ()
	Access first element of the list, position [0]. More...

const Face &	first () const
	Access first element of the list. More...

Face &	last ()
	Access last element of the list, position [size()-1]. More...

const Face &	last () const
	Access last element of the list, position [size()-1]. More...

bool	found (const Face &val, label pos=0) const
	Same as contains() More...

Public Member Functions inherited from surfaceFormatsCore
	surfaceFormatsCore ()=default
	Default construct. More...

virtual	~surfaceFormatsCore ()=default
	Destructor. More...

Static Public Member Functions
static wordHashSet	readTypes ()
	Known readable file-types, without friends or proxies. More...

static wordHashSet	writeTypes ()
	Known writable file-types, without friends or proxies. More...

static bool	canReadType (const word &fileType, bool verbose=false)
	Can we read this file format? Also checks friend types. More...

static bool	canWriteType (const word &fileType, bool verbose=false)
	Can we write this file format? Also checks proxy types. More...

static bool	canRead (const fileName &name, bool verbose=false)
	Can we read this file format? More...

static autoPtr< MeshedSurface >	New (const fileName &name, const word &fileType, bool mandatory=true)
	Read construct from filename with given file type. More...

static autoPtr< MeshedSurface >	New (const fileName &name)
	Read construct from filename (file type implicit from extension) More...

static void	write (const fileName &name, const MeshedSurface< Face > &surf, IOstreamOption streamOpt=IOstreamOption(), const dictionary &options=dictionary::null)
	Write to file, selecting writer based on its extension. More...

static void	write (const fileName &name, const word &fileType, const MeshedSurface< Face > &surf, IOstreamOption streamOpt=IOstreamOption(), const dictionary &options=dictionary::null)
	Write to file, selecting writer based on the given extension. More...

Static Public Member Functions inherited from List< Face >
static const List< Face > &	null () noexcept
	Return a null List (reference to a nullObject). Behaves like an empty List. More...

Static Public Member Functions inherited from UList< Face >
static const UList< Face > &	null () noexcept
	Return a null UList (reference to a nullObject). Behaves like an empty UList. More...

static constexpr label	max_size () noexcept
	The size of the largest possible UList. More...

Static Public Member Functions inherited from surfaceFormatsCore
static bool	checkSupport (const wordHashSet &available, const word &fileType, const bool verbose=false, const char *functionName=nullptr)
	Verbose checking of fileType in the list of available types. More...

static fileName	findFile (const IOobject &io, const bool isGlobal=true)
	Use IOobject information to resolve file to load from, or empty if the file does not exist. More...

static fileName	findFile (const IOobject &io, const dictionary &dict, const bool isGlobal=true)
	Use IOobject information to resolve file to load from, or empty if the file does not exist. More...

Protected Member Functions
void	transcribe (MeshedSurface< face > &surf)
	Transfer points/zones from 'face' to other other shapes. More...

void	checkZones (const bool verbose=true)
	Sanity check/resizing on zones. More...

pointField &	storedPoints ()
	Non-const access to global points. More...

List< Face > &	storedFaces ()
	Non-const access to the faces. More...

labelList &	storedFaceIds ()
	Non-const access to face ids. More...

surfZoneList &	storedZones ()
	Non-const access to the zones. More...

void	sortFacesAndStore (DynamicList< Face > &unsortedFaces, DynamicList< label > &zoneIds, DynamicList< label > &elemIds, bool sorted)
	Sort faces by zones and store sorted faces. More...

virtual void	remapFaces (const labelUList &faceMapNewToOld)
	Set new zones from faceMap. More...

template<>
void	transcribe (MeshedSurface< face > &surf)

template<>
void	transcribe (MeshedSurface< face > &surf)

template<>
void	transcribe (MeshedSurface< face > &surf)

Protected Member Functions inherited from UList< Face >
void	setAddressableSize (const label n) noexcept
	Set addressed size to be inconsistent with allocated storage. More...

void	size (const label n)
	Older name for setAddressableSize. More...

void	writeEntry (Ostream &os) const
	Write the UList with its compound type. More...

void	writeEntry (Ostream &os) const
	Character list writeEntry. More...

void	writeEntry (Ostream &os) const

labelRange	validateRange (const labelRange &requestedRange) const
	Return a validated (start,size) subset range, which means that it always addresses a valid section of the list. More...

void	fill_uniform (const Face &val)
	Assign all entries to the given value. More...

void	fill_uniform (const Foam::zero)
	Assign all entries to zero. More...

UList< Face > &	operator= (const UList< Face > &)=delete
	No copy assignment (default: shallow copy) More...

void	operator= (const Foam::zero)
	Character list assign zero - avoids Foam::zero casting ambiguities. More...

void	operator= (const Foam::zero)

Friends
template<class Face2 >
class	MeshedSurface

template<class Face2 >
class	UnsortedMeshedSurface

class	surfMesh

Istream &	operator>> (Istream &is, MeshedSurface< Face > &surf)
	Read MeshedSurface from Istream. More...

Ostream &	operator (Ostream &os, const MeshedSurface< Face > &surf)
	Write MeshedSurface to Ostream. More...

Additional Inherited Members
Static Public Attributes inherited from surfaceFormatsCore
static word	nativeExt
	The file extension corresponding to 'native' surface format. More...

Static Protected Member Functions inherited from surfaceFormatsCore
static string	getLineNoComment (ISstream &is, const char comment='#')
	Read non-empty and non-comment line. More...

template<class Container >
static List< surfZone >	oneZone (const Container &container, const word &name="zone0")
	Return a surfZone list with a single entry, the size of which corresponds to that of the container. More...

static labelList	getSelectedPatches (const surfZoneList &patches, const wordRes &allow, const wordRes &deny=wordRes())
	Return ids for zone/patch that match by name. More...

static fileName	relativeFilePath (const IOobject &io, const fileName &f, const bool isGlobal=true)
	Return fileName. More...

static fileName	checkFile (const IOobject &io, const bool isGlobal=true)
	Return fileName to load IOobject from. More...

static fileName	checkFile (const IOobject &io, const dictionary &dict, const bool isGlobal=true)
	Return fileName to load IOobject from. More...

Detailed Description

template<class Face>
class Foam::MeshedSurface< Face >

A surface geometry mesh with zone information, not to be confused with the similarly named surfaceMesh, which actually refers to the cell faces of a volume mesh.

A MeshedSurface can have zero or more surface zones (roughly equivalent to faceZones for a polyMesh). If surface zones are defined, they must be contiguous and cover all of the faces.

The MeshedSurface is intended for surfaces from a variety of sources.

A set of points and faces without any surface zone information.
A set of points and faces with randomly ordered zone information. This could arise, for example, from reading external file formats such as STL, etc.

Source files

Definition at line 76 of file triSurfaceTools.H.

Member Typedef Documentation

◆ face_type

typedef Face face_type

The face type (same as the underlying PrimitivePatch)

Definition at line 236 of file MeshedSurface.H.

◆ point_type

typedef point point_type

The point type (same as the underlying PrimitivePatch)

Definition at line 241 of file MeshedSurface.H.

Constructor & Destructor Documentation

◆ MeshedSurface() [1/19]

MeshedSurface ( )

Default construct, an empty surface.

Definition at line 178 of file MeshedSurface.C.

◆ MeshedSurface() [2/19]

MeshedSurface ( const MeshedSurface< Face > & surf )

Copy construct.

◆ MeshedSurface() [3/19]

MeshedSurface ( const UnsortedMeshedSurface< Face > & surf )

Copy construct from an UnsortedMeshedSurface.

Definition at line 200 of file MeshedSurface.C.

◆ MeshedSurface() [4/19]

MeshedSurface ( MeshedSurface< Face > && surf )

Move construct.

◆ MeshedSurface() [5/19]

MeshedSurface ( UnsortedMeshedSurface< Face > && surf )

Move construct from an UnsortedMeshedSurface.

Definition at line 255 of file MeshedSurface.C.

◆ MeshedSurface() [6/19]

MeshedSurface	(	const pointField &	pointLst,
		const UList< Face > &	faceLst,
		const UList< surfZone > &	zoneLst
	)

Copy construct from components (points, faces, zones).

Definition at line 267 of file MeshedSurface.C.

◆ MeshedSurface() [7/19]

MeshedSurface	(	pointField &&	pointLst,
		List< Face > &&	faceLst,
		const UList< surfZone > &	zoneLst
	)

Move construct from components (points, faces).

Zone information is fairly lightweight and is copied.

Definition at line 283 of file MeshedSurface.C.

◆ MeshedSurface() [8/19]

MeshedSurface	(	const pointField &	pointLst,
		const UList< Face > &	faceLst,
		const labelUList &	zoneSizes = `labelUList()`,
		const UList< word > &	zoneNames = `UList<word>()`
	)

Copy construct from components (points, faces).

Use zone information if available

Definition at line 299 of file MeshedSurface.C.

◆ MeshedSurface() [9/19]

MeshedSurface	(	pointField &&	pointLst,
		List< Face > &&	faceLst,
		const labelUList &	zoneSizes = `labelUList()`,
		const UList< word > &	zoneNames = `UList<word>()`
	)

Move construct from components (points, faces).

Use zone information if available

Definition at line 326 of file MeshedSurface.C.

◆ MeshedSurface() [10/19]

MeshedSurface	(	const polyBoundaryMesh &	bMesh,
		const bool	globalPoints = `false`
	)

Construct from a boundary mesh with local points/faces.

Definition at line 370 of file MeshedSurface.C.

◆ MeshedSurface() [11/19]

MeshedSurface ( const surfMesh & mesh )

explicit

Construct from a surfMesh.

Definition at line 352 of file MeshedSurface.C.

◆ MeshedSurface() [12/19]

MeshedSurface ( const fileName & name )

explicit

Construct from file name (uses extension to determine type)

Definition at line 450 of file MeshedSurface.C.

◆ MeshedSurface() [13/19]

MeshedSurface	(	const fileName &	name,
		const word &	fileType
	)

explicit

Construct from file name and given file type.

If the format type is "", uses the file extension.

Definition at line 438 of file MeshedSurface.C.

◆ MeshedSurface() [14/19]

MeshedSurface ( Istream & is )

explicit

Construct from Istream.

Definition at line 459 of file MeshedSurface.C.

◆ MeshedSurface() [15/19]

MeshedSurface ( const Time & runTime )

explicit

Construct from database (as surfMesh) with default name.

Definition at line 469 of file MeshedSurface.C.

◆ MeshedSurface() [16/19]

MeshedSurface	(	const Time &	runTime,
		const word &	surfName
	)

Construct from database (as surfMesh) with given surface name.

Definition at line 479 of file MeshedSurface.C.

◆ MeshedSurface() [17/19]

MeshedSurface	(	const IOobject &	io,
		const dictionary &	dict,
		const bool	isGlobal = `true`
	)

Read construct using IO to find the file location.

Dictionary may contain the following entries:

file = alternative file name (default is dictionary name)
fileType = file format (default is from file extension)
scale (eg, 0.001: mm to m)

Parameters

isGlobal resolve as a global file

Definition at line 512 of file MeshedSurface.C.

◆ ~MeshedSurface()

~MeshedSurface ( )

virtual

Destructor.

Definition at line 534 of file MeshedSurface.C.

◆ MeshedSurface() [18/19]

MeshedSurface ( const MeshedSurface< Face > & surf )

Definition at line 188 of file MeshedSurface.C.

◆ MeshedSurface() [19/19]

MeshedSurface ( MeshedSurface< Face > && surf )

Definition at line 243 of file MeshedSurface.C.

Member Function Documentation

◆ transcribe() [1/4]

void transcribe ( MeshedSurface< face > & surf )

protected

Transfer points/zones from 'face' to other other shapes.

Eg, transcribe face to triFace, or face -> labelledTri, including any addZonesToFaces adjustment. No general form, only specializations.

◆ checkZones()

void checkZones ( const bool verbose = true )

protected

Sanity check/resizing on zones.

Adjust zones so that they cover the number of faces The last zone will be extended as needed

Definition at line 28 of file MeshedSurfaceZones.C.

◆ storedPoints()

pointField& storedPoints ( )

inlineprotected

Non-const access to global points.

Definition at line 183 of file MeshedSurface.H.

Referenced by UnsortedMeshedSurface< Face >::swap(), MeshedSurface< Foam::face >::swap(), MeshedSurface< Foam::face >::transcribe(), surfMesh::transfer(), polySurface::transfer(), UnsortedMeshedSurface< Face >::transfer(), and MeshedSurface< Foam::face >::transfer().

Here is the caller graph for this function:

◆ storedFaces()

List<Face>& storedFaces ( )

inlineprotected

Non-const access to the faces.

Definition at line 191 of file MeshedSurface.H.

Referenced by UnsortedMeshedSurface< Face >::swap(), MeshedSurface< Foam::face >::swap(), surfMesh::transfer(), polySurface::transfer(), UnsortedMeshedSurface< Face >::transfer(), and MeshedSurface< Foam::face >::transfer().

Here is the caller graph for this function:

◆ storedFaceIds()

labelList& storedFaceIds ( )

inlineprotected

Non-const access to face ids.

Definition at line 199 of file MeshedSurface.H.

Referenced by MeshedSurface< Foam::face >::swap(), and MeshedSurface< Foam::face >::transfer().

Here is the caller graph for this function:

◆ storedZones()

surfZoneList& storedZones ( )

inlineprotected

Non-const access to the zones.

Definition at line 207 of file MeshedSurface.H.

Referenced by UnsortedMeshedSurface< Face >::swap(), MeshedSurface< Foam::face >::swap(), MeshedSurface< Foam::face >::transcribe(), surfMesh::transfer(), and MeshedSurface< Foam::face >::transfer().

Here is the caller graph for this function:

◆ sortFacesAndStore()

void sortFacesAndStore	(	DynamicList< Face > &	unsortedFaces,
		DynamicList< label > &	zoneIds,
		DynamicList< label > &	elemIds,
		bool	sorted
	)

protected

Sort faces by zones and store sorted faces.

Definition at line 84 of file MeshedSurfaceZones.C.

◆ remapFaces()

void remapFaces ( const labelUList & faceMapNewToOld )

protectedvirtual

Set new zones from faceMap.

Reimplemented in UnsortedMeshedSurface< Face >, and cuttingSurfaceBase.

Definition at line 544 of file MeshedSurface.C.

◆ ClassName()

ClassName ( "MeshedSurface< Face >" )

Declare type-name (with debug switch)

◆ readTypes()

Foam::wordHashSet readTypes ( )

static

Known readable file-types, without friends or proxies.

Definition at line 38 of file MeshedSurface.C.

◆ writeTypes()

Foam::wordHashSet writeTypes ( )

static

Known writable file-types, without friends or proxies.

Definition at line 45 of file MeshedSurface.C.

◆ canReadType()

bool canReadType	(	const word &	fileType,
		bool	verbose = `false`
	)

static

Can we read this file format? Also checks friend types.

Definition at line 53 of file MeshedSurface.C.

◆ canWriteType()

bool canWriteType	(	const word &	fileType,
		bool	verbose = `false`
	)

static

Can we write this file format? Also checks proxy types.

Definition at line 70 of file MeshedSurface.C.

◆ canRead()

bool canRead	(	const fileName &	name,
		bool	verbose = `false`
	)

static

Can we read this file format?

Definition at line 87 of file MeshedSurface.C.

◆ declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	autoPtr	,
		MeshedSurface< Face >	,
		fileExtension	,
		(const fileName &name)	,
		(name)
	)

◆ New() [1/2]

Foam::autoPtr< Foam::MeshedSurface< Face > > New	(	const fileName &	name,
		const word &	fileType,
		bool	mandatory = `true`
	)

static

Read construct from filename with given file type.

Note: Use mandatory=false if support for the file type is optional (the file still needs to exist!).

Definition at line 31 of file MeshedSurfaceNew.C.

◆ New() [2/2]

Foam::autoPtr< Foam::MeshedSurface< Face > > New ( const fileName & name )

static

Read construct from filename (file type implicit from extension)

Definition at line 110 of file MeshedSurfaceNew.C.

◆ declareMemberFunctionSelectionTable()

declareMemberFunctionSelectionTable	(	void	,
		UnsortedMeshedSurface< Face >	,
		write	,
		fileExtension	,
		(const fileName &name, const MeshedSurface< Face > &surf, IOstreamOption streamOpt, const dictionary &options)	,
		(name, surf, streamOpt, options)
	)

◆ write() [1/5]

void write	(	const fileName &	name,
		const MeshedSurface< Face > &	surf,
		IOstreamOption	streamOpt = `IOstreamOption()`,
		const dictionary &	options = `dictionary::null`
	)

static

Write to file, selecting writer based on its extension.

Definition at line 105 of file MeshedSurface.C.

◆ write() [2/5]

void write	(	const fileName &	name,
		const word &	fileType,
		const MeshedSurface< Face > &	surf,
		IOstreamOption	streamOpt = `IOstreamOption()`,
		const dictionary &	options = `dictionary::null`
	)

static

Write to file, selecting writer based on the given extension.

Definition at line 118 of file MeshedSurface.C.

◆ size()

label size ( ) const

inline

The surface size is the number of faces.

Definition at line 501 of file MeshedSurface.H.

Referenced by surfaceNoise::calculate(), distanceSurface::filterFaceProximity(), isoSurfaceTopo::isoSurfaceTopo(), UnsortedMeshedSurface< Face >::size(), and GTSsurfaceFormat< Face >::write().

Here is the caller graph for this function:

◆ surfFaces()

const List<Face>& surfFaces ( ) const

inline

Return const access to the faces.

Definition at line 509 of file MeshedSurface.H.

Referenced by polySurface::copySurface(), surfMesh::copySurface(), sampledInterface::faces(), sampledCuttingSurface::faces(), sampledPlane::faces(), sampledDistanceSurface::faces(), sampledCuttingPlane::faces(), sampledIsoSurface::faces(), UnsortedMeshedSurface< Face >::operator=(), MeshedSurface< Foam::face >::operator=(), MeshedSurface< Foam::face >::transcribe(), GTSsurfaceFormat< Face >::write(), AC3DsurfaceFormat< Face >::write(), TRIsurfaceFormat< Face >::write(), VTPsurfaceFormat< Face >::write(), VTKsurfaceFormat< Face >::write(), STLsurfaceFormat< Face >::writeAscii(), STLsurfaceFormat< Face >::writeBinary(), and surfaceNoise::writeSurfaceData().

Here is the caller graph for this function:

◆ faceIds()

const labelList& faceIds ( ) const

inline

Return const access to faces ids.

If these exist, they are typically arise from reading a mesh format from another CAE software (eg, NASTRAN, STARCD, ...)

Definition at line 520 of file MeshedSurface.H.

Referenced by MeshedSurface< Foam::face >::MeshedSurface(), and MeshedSurface< Foam::face >::operator=().

Here is the caller graph for this function:

◆ surfZones()

const surfZoneList& surfZones ( ) const

inline

Const access to the surface zones.

If zones are defined, they must be contiguous and cover the entire surface

Definition at line 531 of file MeshedSurface.H.

Referenced by polySurface::copySurface(), surfMesh::copySurface(), MeshedSurface< Foam::face >::operator=(), polySurface::transfer(), UnsortedMeshedSurface< Face >::transfer(), triSurface::transfer(), UnsortedMeshedSurface< Face >::UnsortedMeshedSurface(), and GTSsurfaceFormat< Face >::write().

Here is the caller graph for this function:

◆ Sf()

const vectorField& Sf ( ) const

inline

Face area vectors (normals)

Definition at line 539 of file MeshedSurface.H.

Referenced by sampledInterface::Sf(), sampledCuttingSurface::Sf(), sampledPlane::Sf(), sampledDistanceSurface::Sf(), sampledCuttingPlane::Sf(), and sampledIsoSurface::Sf().

Here is the caller graph for this function:

◆ magSf()

const scalarField& magSf ( ) const

inline

Face area magnitudes.

Definition at line 547 of file MeshedSurface.H.

Referenced by surfaceNoise::calculate(), sampledInterface::magSf(), sampledCuttingSurface::magSf(), sampledPlane::magSf(), sampledDistanceSurface::magSf(), sampledCuttingPlane::magSf(), sampledIsoSurface::magSf(), FilterField::reset(), surfaceNoise::surfaceAverage(), and surfaceNoise::writeSurfaceData().

Here is the caller graph for this function:

◆ Cf()

const vectorField& Cf ( ) const

inline

Face centres.

Definition at line 555 of file MeshedSurface.H.

Referenced by sampledInterface::Cf(), sampledCuttingSurface::Cf(), sampledPlane::Cf(), sampledDistanceSurface::Cf(), sampledCuttingPlane::Cf(), sampledIsoSurface::Cf(), and Curle::read().

Here is the caller graph for this function:

◆ clear()

void clear ( )

virtual

Clear all storage.

Reimplemented in UnsortedMeshedSurface< Face >.

Definition at line 593 of file MeshedSurface.C.

Referenced by distanceSurface::createGeometry(), MeshedSurface< Foam::face >::transcribe(), triSurface::transfer(), and MeshedSurface< Foam::face >::transfer().

Here is the caller graph for this function:

◆ addZones() [1/3]

void addZones	(	const UList< surfZone > &	srfZones,
		const bool	cullEmpty = `false`
	)

virtual

Add surface zones.

Definition at line 145 of file MeshedSurfaceZones.C.

◆ addZones() [2/3]

void addZones	(	const labelUList &	sizes,
		const UList< word > &	names,
		const bool	cullEmpty = `false`
	)

virtual

Add surface zones.

Definition at line 170 of file MeshedSurfaceZones.C.

◆ addZones() [3/3]

void addZones	(	const labelUList &	sizes,
		const bool	cullEmpty = `false`
	)

virtual

Add surface zones.

Definition at line 204 of file MeshedSurfaceZones.C.

◆ addZonesToFaces() [1/3]

bool addZonesToFaces ( )

Propagate zone information on face regions.

Normally a no-op, only used by the labelledTri specialization. Specializations return true, others return false.

Definition at line 236 of file MeshedSurfaceZones.C.

◆ removeZones()

void removeZones ( )

virtual

Remove surface zones.

Definition at line 244 of file MeshedSurfaceZones.C.

◆ movePoints()

void movePoints ( const pointField & newPoints )

virtual

Move points.

Definition at line 605 of file MeshedSurface.C.

◆ scalePoints()

void scalePoints ( const scalar scaleFactor )

virtual

Scale points. A non-positive factor is ignored.

Definition at line 618 of file MeshedSurface.C.

◆ cleanup()

void cleanup ( const bool verbose )

virtual

Remove invalid faces.

Definition at line 636 of file MeshedSurface.C.

◆ compactPoints()

void compactPoints ( labelList & pointMap = const_cast<labelList&>(labelList::null()) )

virtual

Remove unused points and renumber faces in local visit order.

Parameters

[out] pointMap from new to old points (optional)

Definition at line 647 of file MeshedSurface.C.

◆ stitchFaces()

bool stitchFaces	(	const scalar	tol = `SMALL`,
		const bool	verbose = `false`
	)

virtual

Definition at line 688 of file MeshedSurface.C.

◆ checkFaces()

bool checkFaces ( const bool verbose = false )

virtual

Definition at line 778 of file MeshedSurface.C.

◆ nTriangles() [1/2]

Foam::label nTriangles ( ) const

virtual

Count number of triangles.

Definition at line 945 of file MeshedSurface.C.

Referenced by STLsurfaceFormat< Face >::writeBinary().

Here is the caller graph for this function:

◆ nTriangles() [2/2]

Foam::label nTriangles ( labelList & faceMap ) const

virtual

Count number of triangles, returning a face map of original ids.

The faceMap is zero-sized when no triangulation would be needed.

Definition at line 961 of file MeshedSurface.C.

◆ triangulate() [1/2]

Foam::label triangulate ( )

virtual

Triangulate in-place, returning the number of triangles added.

Definition at line 1005 of file MeshedSurface.C.

Referenced by MeshedSurface< Foam::face >::transcribe().

Here is the caller graph for this function:

◆ triangulate() [2/2]

Foam::label triangulate ( labelList & faceMap )

virtual

Triangulate in-place, returning the number of triangles added.

and setting a map of original face Ids. The faceMap is zero-sized when no triangulation was done.

Definition at line 1024 of file MeshedSurface.C.

◆ subsetMeshMap()

void subsetMeshMap	(	const BoolListType &	include,
		labelList &	pointMap,
		labelList &	faceMap
	)		const

inline

Create mappings for a sub-surface.

Parameters

[in]	include	the faces to select
[out]	pointMap	from new to old localPoints
[out]	faceMap	from new to old localFaces

Definition at line 684 of file MeshedSurface.H.

◆ subsetMesh() [1/5]

Foam::MeshedSurface< Face > subsetMesh	(	const UList< bool > &	include,
		labelList &	pointMap,
		labelList &	faceMap
	)		const

Return a new surface subsetted on the selected faces.

Parameters

[in]	include	the faces to select
[out]	pointMap	from new to old localPoints
[out]	faceMap	from new to old localFaces

Definition at line 1215 of file MeshedSurface.C.

Referenced by distanceSurface::filterFaceProximity().

Here is the caller graph for this function:

◆ subsetMesh() [2/5]

Foam::MeshedSurface< Face > subsetMesh	(	const bitSet &	include,
		labelList &	pointMap,
		labelList &	faceMap
	)		const

Return a new surface subsetted on the selected faces.

Parameters

[in]	include	the faces to select
[out]	pointMap	from new to old localPoints
[out]	faceMap	from new to old localFaces

Definition at line 1229 of file MeshedSurface.C.

◆ subsetMesh() [3/5]

Foam::MeshedSurface< Face > subsetMesh ( const UList< bool > & include ) const

Return a new surface subsetted on the selected faces.

Parameters

[in] include the faces to select

Definition at line 1243 of file MeshedSurface.C.

◆ subsetMesh() [4/5]

Foam::MeshedSurface< Face > subsetMesh ( const bitSet & include ) const

Return a new surface subsetted on the selected faces.

Parameters

[in] include the faces to select

Definition at line 1255 of file MeshedSurface.C.

◆ subsetMesh() [5/5]

Foam::MeshedSurface< Face > subsetMesh	(	const wordRes &	includeNames,
		const wordRes &	excludeNames = `wordRes()`
	)		const

Return a new surface subsetted on the selected zone names.

Parameters

[in]	includeNames	surface zone names to include
[in]	excludeNames	surface zone names to exclude

See also: Foam::stringListOps::findMatching for details about matching

Definition at line 1266 of file MeshedSurface.C.

◆ swap()

void swap ( MeshedSurface< Face > & surf )

Swap contents.

Definition at line 1293 of file MeshedSurface.C.

◆ transfer() [1/3]

void transfer	(	pointField &	pointLst,
		List< Face > &	faceLst
	)

Transfer the components.

Definition at line 1314 of file MeshedSurface.C.

Referenced by distanceSurface::createGeometry(), distanceSurface::filterFaceProximity(), and distanceSurface::filterRegionProximity().

Here is the caller graph for this function:

◆ transfer() [2/3]

void transfer ( MeshedSurface< Face > & surf )

Transfer the contents of the argument and annul the argument.

Definition at line 1330 of file MeshedSurface.C.

◆ transfer() [3/3]

void transfer ( UnsortedMeshedSurface< Face > & surf )

Transfer the contents of the argument and annul the argument.

Definition at line 1352 of file MeshedSurface.C.

◆ releaseGeom()

Foam::autoPtr< Foam::MeshedSurface< Face > > releaseGeom ( )

Release (clear) geometry and return for reuse.

Definition at line 1392 of file MeshedSurface.C.

◆ swapFaces()

void swapFaces ( List< Face > & faces )

Swap the stored faces. Use with caution.

Definition at line 1399 of file MeshedSurface.C.

Referenced by triSurface::transfer().

Here is the caller graph for this function:

◆ swapPoints()

void swapPoints ( pointField & points )

Swap the stored points.

Definition at line 1412 of file MeshedSurface.C.

Referenced by triSurface::transfer().

Here is the caller graph for this function:

◆ read() [1/2]

bool read	(	const fileName &	name,
		const word &	fileType
	)

Read from file. Chooses reader based on explicit extension.

Definition at line 1432 of file MeshedSurface.C.

◆ read() [2/2]

bool read ( const fileName & name )

virtual

Read from file. Chooses reader based on detected extension.

Reimplemented in UnsortedMeshedSurface< Face >, STLsurfaceFormat< Face >, VTKsurfaceFormat< Face >, NASsurfaceFormat< Face >, TRIsurfaceFormat< Face >, GTSsurfaceFormat< Face >, ABAQUSsurfaceFormat< Face >, AC3DsurfaceFormat< Face >, STARCDsurfaceFormat< Face >, OFFsurfaceFormat< Face >, and OBJsurfaceFormat< Face >.

Definition at line 1422 of file MeshedSurface.C.

◆ writeStats()

void writeStats ( Ostream & os ) const

Definition at line 55 of file MeshedSurfaceIO.C.

◆ write() [3/5]

virtual void write	(	const fileName &	name,
		IOstreamOption	streamOpt = `IOstreamOption()`,
		const dictionary &	options = `dictionary::null`
	)		const

inlinevirtual

Generic write routine. Chooses writer based on extension.

Reimplemented in UnsortedMeshedSurface< Face >, STLsurfaceFormat< Face >, FLMAZsurfaceFormat< Face >, VTKsurfaceFormat< Face >, VTPsurfaceFormat< Face >, FLMAsurfaceFormat< Face >, NASsurfaceFormat< Face >, TRIsurfaceFormat< Face >, GTSsurfaceFormat< Face >, ABAQUSsurfaceFormat< Face >, AC3DsurfaceFormat< Face >, STARCDsurfaceFormat< Face >, OFFsurfaceFormat< Face >, OBJsurfaceFormat< Face >, SMESHsurfaceFormat< Face >, and X3DsurfaceFormat< Face >.

Definition at line 811 of file MeshedSurface.H.

◆ write() [4/5]

virtual void write	(	const fileName &	name,
		const word &	fileType,
		IOstreamOption	streamOpt = `IOstreamOption()`,
		const dictionary &	options = `dictionary::null`
	)		const

inlinevirtual

Generic write routine for given format type.

If the format type is "", uses the file extension.

Reimplemented in UnsortedMeshedSurface< Face >, STLsurfaceFormat< Face >, FLMAZsurfaceFormat< Face >, VTKsurfaceFormat< Face >, VTPsurfaceFormat< Face >, FLMAsurfaceFormat< Face >, NASsurfaceFormat< Face >, TRIsurfaceFormat< Face >, GTSsurfaceFormat< Face >, ABAQUSsurfaceFormat< Face >, AC3DsurfaceFormat< Face >, STARCDsurfaceFormat< Face >, OFFsurfaceFormat< Face >, OBJsurfaceFormat< Face >, SMESHsurfaceFormat< Face >, and X3DsurfaceFormat< Face >.

Definition at line 826 of file MeshedSurface.H.

◆ write() [5/5]

void write	(	const Time &	runTime,
		const word &	surfName = `word::null`
	)		const

Write to database.

Definition at line 1445 of file MeshedSurface.C.

◆ operator=() [1/2]

void operator= ( const MeshedSurface< Face > & surf )

Copy assignment.

Definition at line 1457 of file MeshedSurface.C.

◆ operator=() [2/2]

void operator= ( MeshedSurface< Face > && surf )

Move assignment.

Definition at line 1475 of file MeshedSurface.C.

◆ operator MeshedSurfaceProxy< Face >()

operator MeshedSurfaceProxy< Face > ( ) const

Conversion operator to MeshedSurfaceProxy.

◆ addZonesToFaces() [2/3]

bool addZonesToFaces ( )

Specialization for labelledTri.

◆ transcribe() [2/4]

void transcribe ( MeshedSurface< face > & surf )

protected

Definition at line 32 of file MeshedSurfaceCore.C.

◆ transcribe() [3/4]

void transcribe ( MeshedSurface< face > & surf )

protected

Definition at line 44 of file MeshedSurfaceCore.C.

◆ transcribe() [4/4]

void transcribe ( MeshedSurface< face > & surf )

protected

Definition at line 77 of file MeshedSurfaceCore.C.

◆ addZonesToFaces() [3/3]

bool addZonesToFaces ( )

Definition at line 108 of file MeshedSurfaceCore.C.

Friends And Related Function Documentation

◆ MeshedSurface

friend class MeshedSurface

friend

Definition at line 94 of file MeshedSurface.H.

◆ UnsortedMeshedSurface

friend class UnsortedMeshedSurface

friend

Definition at line 95 of file MeshedSurface.H.

◆ surfMesh

friend class surfMesh

friend

Definition at line 98 of file MeshedSurface.H.

◆ operator>>

Istream& operator>>	(	Istream &	is,
		MeshedSurface< Face > &	surf
	)

friend

Read MeshedSurface from Istream.

Avoid using to read/write file content (fragile).

◆ operator

Ostream& operator	(	Ostream &	os,
		const MeshedSurface< Face > &	surf
	)

friend

Write MeshedSurface to Ostream.

Avoid using to read/write file content (fragile).

The documentation for this class was generated from the following files:

src/meshTools/triSurface/triSurfaceTools/triSurfaceTools.H
src/surfMesh/MeshedSurface/MeshedSurface.H
src/surfMesh/MeshedSurface/MeshedSurface.C
src/surfMesh/MeshedSurface/MeshedSurfaceIO.C
src/surfMesh/MeshedSurface/MeshedSurfaceNew.C
src/surfMesh/MeshedSurface/MeshedSurfaceZones.C

Public Types

Public Member Functions

Static Public Member Functions

Protected Member Functions

Friends

Additional Inherited Members

Detailed Description

template<class Face> class Foam::MeshedSurface< Face >

Member Typedef Documentation

◆ face_type

◆ point_type

Constructor & Destructor Documentation

◆ MeshedSurface() [1/19]

◆ MeshedSurface() [2/19]

◆ MeshedSurface() [3/19]

◆ MeshedSurface() [4/19]

◆ MeshedSurface() [5/19]

◆ MeshedSurface() [6/19]

◆ MeshedSurface() [7/19]

◆ MeshedSurface() [8/19]

◆ MeshedSurface() [9/19]

◆ MeshedSurface() [10/19]

◆ MeshedSurface() [11/19]

◆ MeshedSurface() [12/19]

◆ MeshedSurface() [13/19]

◆ MeshedSurface() [14/19]

◆ MeshedSurface() [15/19]

◆ MeshedSurface() [16/19]

◆ MeshedSurface() [17/19]

◆ ~MeshedSurface()

◆ MeshedSurface() [18/19]

◆ MeshedSurface() [19/19]

Member Function Documentation

◆ transcribe() [1/4]

◆ checkZones()

◆ storedPoints()

◆ storedFaces()

◆ storedFaceIds()

◆ storedZones()

◆ sortFacesAndStore()

◆ remapFaces()

◆ ClassName()

◆ readTypes()

◆ writeTypes()

◆ canReadType()

◆ canWriteType()

◆ canRead()

◆ declareRunTimeSelectionTable()

◆ New() [1/2]

◆ New() [2/2]

◆ declareMemberFunctionSelectionTable()

◆ write() [1/5]

◆ write() [2/5]

◆ size()

◆ surfFaces()

◆ faceIds()

◆ surfZones()

◆ Sf()

◆ magSf()

◆ Cf()

◆ clear()

◆ addZones() [1/3]

◆ addZones() [2/3]

◆ addZones() [3/3]

◆ addZonesToFaces() [1/3]

◆ removeZones()

◆ movePoints()

◆ scalePoints()

◆ cleanup()

◆ compactPoints()

◆ stitchFaces()

◆ checkFaces()

◆ nTriangles() [1/2]

◆ nTriangles() [2/2]

◆ triangulate() [1/2]

◆ triangulate() [2/2]

◆ subsetMeshMap()

◆ subsetMesh() [1/5]

◆ subsetMesh() [2/5]

◆ subsetMesh() [3/5]

template<class Face>
class Foam::MeshedSurface< Face >
