Inheritance diagram for kEpsilon:

Collaboration diagram for kEpsilon:

Public Member Functions
	TypeName ("kEpsilon")
	Runtime type information. More...

	kEpsilon (const fvMesh &mesh, const solverControl &SolverControl)
	Construct from components. More...

virtual	~kEpsilon ()=default
	Destructor. More...

virtual tmp< volScalarField::Internal >	G ()
	Return the turbulence production term. More...

virtual void	computeMeanFields ()
	Compute mean fields on the fly. More...

Public Member Functions inherited from RASModelVariables
	TypeName ("RASModelVariables")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, RASModelVariables, dictionary,(const fvMesh &mesh, const solverControl &SolverControl),(mesh, SolverControl))

	RASModelVariables (const fvMesh &mesh, const solverControl &SolverControl)
	Construct from components. More...

	RASModelVariables (const RASModelVariables &rmv)
	Copy constructor. More...

autoPtr< RASModelVariables >	clone () const
	Clone. More...

virtual	~RASModelVariables ()=default

const word &	TMVar1BaseName () const
	Turbulence field names. More...

const word &	TMVar2BaseName () const

const word &	nutBaseName () const

virtual bool	hasTMVar1 () const
	Bools to identify which turbulent fields are present. More...

virtual bool	hasTMVar2 () const

virtual bool	hasNut () const

bool	hasDist () const

const volScalarField &	TMVar1 () const
	Return references to turbulence fields. More...

volScalarField &	TMVar1 ()

const volScalarField &	TMVar2 () const

volScalarField &	TMVar2 ()

const volScalarField &	nutRef () const

volScalarField &	nutRef ()

tmp< volScalarField >	nut () const

const volScalarField &	d () const

volScalarField &	d ()

tmp< scalarField >	TMVar1 (const label patchi) const

tmp< scalarField >	TMVar2 (const label patchi) const

tmp< scalarField >	nut (const label patchi) const

tmp< fvPatchScalarField >	nutPatchField (const label patchi) const

const volScalarField &	TMVar1Inst () const
	Return references to instantaneous turbulence fields. More...

volScalarField &	TMVar1Inst ()

const volScalarField &	TMVar2Inst () const

volScalarField &	TMVar2Inst ()

const volScalarField &	nutRefInst () const

volScalarField &	nutRefInst ()

virtual tmp< volScalarField >	nutJacobianVar1 (const singlePhaseTransportModel &laminarTransport) const
	Return nut Jacobian wrt the TM vars. More...

virtual tmp< volScalarField >	nutJacobianVar2 (const singlePhaseTransportModel &laminarTransport) const

void	restoreInitValues ()
	Restore turbulent fields to their initial values. More...

void	resetMeanFields ()
	Reset mean fields to zero. More...

tmp< volSymmTensorField >	devReff (const singlePhaseTransportModel &laminarTransport, const volVectorField &U) const
	Return stress tensor based on the mean flow variables. More...

virtual void	correctBoundaryConditions (const incompressible::turbulenceModel &turbulence)
	correct bounday conditions of turbulent fields More...

virtual void	transfer (RASModelVariables &rmv)
	Transfer turbulence fields from an another object. More...

Protected Member Functions
virtual void	allocateMeanFields ()

tmp< volScalarField::Internal >	computeG ()

Protected Member Functions inherited from RASModelVariables
virtual void	allocateInitValues ()

refPtr< volScalarField >	cloneRefPtr (const refPtr< volScalarField > &obj) const

void	copyAndRename (volScalarField &f1, volScalarField &f2)

void	operator= (const RASModelVariables &)=delete
	No copy assignment. More...

Protected Attributes
autoPtr< volScalarField::Internal >	GMean_
	Average of the production term. More...

Protected Attributes inherited from RASModelVariables
const fvMesh &	mesh_

const solverControl &	solverControl_

word	TMVar1BaseName_

word	TMVar2BaseName_

word	nutBaseName_

refPtr< volScalarField >	TMVar1Ptr_

refPtr< volScalarField >	TMVar2Ptr_

refPtr< volScalarField >	nutPtr_

refPtr< volScalarField >	distPtr_

refPtr< volScalarField >	TMVar1InitPtr_

refPtr< volScalarField >	TMVar2InitPtr_

refPtr< volScalarField >	nutInitPtr_

refPtr< volScalarField >	TMVar1MeanPtr_

refPtr< volScalarField >	TMVar2MeanPtr_

refPtr< volScalarField >	nutMeanPtr_

Additional Inherited Members
Static Public Member Functions inherited from RASModelVariables
static autoPtr< RASModelVariables >	New (const fvMesh &mesh, const solverControl &SolverControl)
	Return a reference to the selected turbulence model. More...

Detailed Description

Source files

Definition at line 52 of file kEpsilon.H.

Constructor & Destructor Documentation

◆ kEpsilon()

kEpsilon	(	const fvMesh &	mesh,
		const solverControl &	SolverControl
	)

Construct from components.

Definition at line 72 of file kEpsilon.C.

◆ ~kEpsilon()

virtual ~kEpsilon ( )

virtualdefault

Destructor.

Member Function Documentation

◆ allocateMeanFields()

void allocateMeanFields ( )

protectedvirtual

Reimplemented from RASModelVariables.

Definition at line 43 of file kEpsilon.C.

References RASModelVariables::allocateMeanFields(), IOobjectOption::AUTO_WRITE, solverControl::average(), Foam::dimArea, Foam::dimTime, kEpsilon::GMean_, RASModelVariables::mesh_, Foam::pow3(), IOobjectOption::READ_IF_PRESENT, RASModelVariables::solverControl_, fvMesh::time(), Time::timeName(), and Foam::Zero.

Here is the call graph for this function:

◆ computeG()

tmp< volScalarField::Internal > computeG ( )

protected

Definition at line 93 of file kEpsilon.C.

References GeometricField< Type, PatchField, GeoMesh >::correctBoundaryConditions(), Foam::devTwoSymm(), turbulenceModel::GName(), Foam::fvc::grad(), Foam::constant::atomic::group, IOobject::groupName(), objectRegistry::lookupObject(), RASModelVariables::mesh_, tmp< T >::New(), RASModelVariables::nutRefInst(), turbulenceModel::propertiesName, IOobject::scopedName(), RASModelVariables::TMVar2(), RASModelVariables::TMVar2Inst(), Foam::type(), U, and turbulenceModel::U().

Referenced by kEpsilon::computeMeanFields(), and kEpsilon::G().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ TypeName()

TypeName ( "kEpsilon" )

Runtime type information.

◆ G()

tmp< volScalarField::Internal > G ( )

virtual

Return the turbulence production term.

Reimplemented from RASModelVariables.

Definition at line 130 of file kEpsilon.C.

References kEpsilon::computeG(), DebugInfo, Foam::endl(), kEpsilon::GMean_, RASModelVariables::solverControl_, and solverControl::useAveragedFields().

Here is the call graph for this function:

◆ computeMeanFields()

void computeMeanFields ( )

virtual

Compute mean fields on the fly.

Reimplemented from RASModelVariables.

Definition at line 144 of file kEpsilon.C.

References solverControl::averageIter(), kEpsilon::computeG(), RASModelVariables::computeMeanFields(), solverControl::doAverageIter(), kEpsilon::GMean_, and RASModelVariables::solverControl_.

Here is the call graph for this function:

Member Data Documentation

◆ GMean_

autoPtr<volScalarField::Internal> GMean_

protected

Average of the production term.

Avaraged separetely due the bi-zonal treatment next to the wall

Definition at line 66 of file kEpsilon.H.

Referenced by kEpsilon::allocateMeanFields(), kEpsilon::computeMeanFields(), and kEpsilon::G().

The documentation for this class was generated from the following files:

src/optimisation/adjointOptimisation/adjoint/turbulenceModels/turbulenceModelVariables/RAS/kEpsilon/kEpsilon.H
src/optimisation/adjointOptimisation/adjoint/turbulenceModels/turbulenceModelVariables/RAS/kEpsilon/kEpsilon.C
