The class nutWallFunction is an abstract base class that hosts $y^+$ calculation methods and common functions for nut wall-function boundary conditions. More...

Inheritance diagram for nutWallFunctionFvPatchScalarField:

[legend]

Collaboration diagram for nutWallFunctionFvPatchScalarField:

[legend]

Public Member Functions
	TypeName ("nutWallFunction")
	Runtime type information. More...

	nutWallFunctionFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &)
	Construct from patch and internal field. More...

	nutWallFunctionFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
	Construct from patch, internal field and dictionary. More...

	nutWallFunctionFvPatchScalarField (const nutWallFunctionFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fvPatchFieldMapper &)
	Construct by mapping given nutWallFunctionFvPatchScalarField onto a new patch. More...

	nutWallFunctionFvPatchScalarField (const nutWallFunctionFvPatchScalarField &)
	Construct as copy. More...

	nutWallFunctionFvPatchScalarField (const nutWallFunctionFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
	Construct as copy setting internal field reference. More...

virtual tmp< scalarField >	yPlus () const =0
	Calculate and return the yPlus at the boundary. More...

const wallFunctionCoefficients &	wallCoeffs () const noexcept
	Return wallFunctionCoefficients. More...

virtual void	updateCoeffs ()
	Update the coefficients associated with the patch field. More...

virtual void	write (Ostream &) const
	Write. More...

Static Public Member Functions
static const nutWallFunctionFvPatchScalarField &	nutw (const turbulenceModel &turbModel, const label patchi)
	Return the nut patchField for the given wall patch. More...

Protected Member Functions
virtual const volVectorField &	U (const turbulenceModel &turb) const
	Helper to return the velocity field either from the turbulence model (default) or the mesh database. More...

virtual void	checkType ()
	Check the type of the patch. More...

virtual tmp< scalarField >	calcNut () const =0
	Calculate the turbulent viscosity. More...

void	writeLocalEntries (Ostream &) const
	Write local wall function variables. More...

Protected Attributes
word	UName_
	Name of velocity field. More...

wallFunctionCoefficients	wallCoeffs_
	Wall-function coefficients. More...

Detailed Description

The class nutWallFunction is an abstract base class that hosts $y^+$ calculation methods and common functions for nut wall-function boundary conditions.

Usage

Example of the boundary condition specification:

<patchName>
{
    // Top-level entries
    ...

    // Optional entries
    U             U;

    // Inherited entries
    ...
}

where the entries mean:

Property	Description	Type	Reqd	Deflt
`U`	Name of operand velocity field	word	no	U

The inherited entries are elaborated in:

Source files

Definition at line 93 of file nutWallFunctionFvPatchScalarField.H.

Constructor & Destructor Documentation

◆ nutWallFunctionFvPatchScalarField() [1/5]

nutWallFunctionFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF
	)

Construct from patch and internal field.

Definition at line 79 of file nutWallFunctionFvPatchScalarField.C.

◆ nutWallFunctionFvPatchScalarField() [2/5]

nutWallFunctionFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const dictionary &	dict
	)

Construct from patch, internal field and dictionary.

Definition at line 109 of file nutWallFunctionFvPatchScalarField.C.

◆ nutWallFunctionFvPatchScalarField() [3/5]

nutWallFunctionFvPatchScalarField	(	const nutWallFunctionFvPatchScalarField &	ptf,
		const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)

Construct by mapping given nutWallFunctionFvPatchScalarField onto a new patch.

Definition at line 93 of file nutWallFunctionFvPatchScalarField.C.

◆ nutWallFunctionFvPatchScalarField() [4/5]

nutWallFunctionFvPatchScalarField ( const nutWallFunctionFvPatchScalarField & wfpsf )

Construct as copy.

Definition at line 124 of file nutWallFunctionFvPatchScalarField.C.

◆ nutWallFunctionFvPatchScalarField() [5/5]

nutWallFunctionFvPatchScalarField	(	const nutWallFunctionFvPatchScalarField &	wfpsf,
		const DimensionedField< scalar, volMesh > &	iF
	)

Construct as copy setting internal field reference.

Definition at line 137 of file nutWallFunctionFvPatchScalarField.C.

Member Function Documentation

◆ U()

const Foam::volVectorField & U ( const turbulenceModel & turb ) const

protectedvirtual

Helper to return the velocity field either from the turbulence model (default) or the mesh database.

Definition at line 53 of file nutWallFunctionFvPatchScalarField.C.

References word::null, and turb.

Referenced by nutUWallFunctionFvPatchScalarField::calcNut(), nutUTabulatedWallFunctionFvPatchScalarField::calcNut(), nutUBlendedWallFunctionFvPatchScalarField::calcNut(), atmNutUWallFunctionFvPatchScalarField::calcNut(), and nutUSpaldingWallFunctionFvPatchScalarField::calcNut().

Here is the caller graph for this function:

◆ checkType()

void checkType ( )

protectedvirtual

Check the type of the patch.

Definition at line 38 of file nutWallFunctionFvPatchScalarField.C.

References Foam::abort(), Foam::endl(), Foam::FatalError, FatalErrorInFunction, Foam::nl, and Foam::foamVersion::patch.

Here is the call graph for this function:

◆ calcNut()

virtual tmp<scalarField> calcNut ( ) const

protectedpure virtual

Calculate the turbulent viscosity.

Implemented in atmNutWallFunctionFvPatchScalarField, atmNutkWallFunctionFvPatchScalarField, nutUSpaldingWallFunctionFvPatchScalarField, atmNutUWallFunctionFvPatchScalarField, nutUBlendedWallFunctionFvPatchScalarField, nutkFilmWallFunctionFvPatchScalarField, nutkRoughWallFunctionFvPatchScalarField, nutUTabulatedWallFunctionFvPatchScalarField, nutUWallFunctionFvPatchScalarField, nutkWallFunctionFvPatchScalarField, and nutLowReWallFunctionFvPatchScalarField.

◆ writeLocalEntries()

void writeLocalEntries ( Ostream & os ) const

protected

Write local wall function variables.

Definition at line 67 of file nutWallFunctionFvPatchScalarField.C.

References word::null, os(), and Ostream::writeEntryIfDifferent().

Here is the call graph for this function:

◆ TypeName()

TypeName ( "nutWallFunction" )

Runtime type information.

◆ nutw()

const Foam::nutWallFunctionFvPatchScalarField & nutw	(	const turbulenceModel &	turbModel,
		const label	patchi
	)

static

Return the nut patchField for the given wall patch.

Definition at line 154 of file nutWallFunctionFvPatchScalarField.C.

References turbulenceModel::nut().

Referenced by nutkWallFunctionFvPatchScalarField::calcNut(), nutUWallFunctionFvPatchScalarField::calcNut(), nutkRoughWallFunctionFvPatchScalarField::calcNut(), atmNutUWallFunctionFvPatchScalarField::calcNut(), nutUSpaldingWallFunctionFvPatchScalarField::calcNut(), atmNutkWallFunctionFvPatchScalarField::calcNut(), and atmNutWallFunctionFvPatchScalarField::calcNut().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ yPlus()

virtual tmp<scalarField> yPlus ( ) const

pure virtual

Calculate and return the yPlus at the boundary.

yPlus is the first-cell-centre height from boundary in wall units

Implemented in nutURoughWallFunctionFvPatchScalarField, nutUSpaldingWallFunctionFvPatchScalarField, nutUBlendedWallFunctionFvPatchScalarField, nutkFilmWallFunctionFvPatchScalarField, nutUTabulatedWallFunctionFvPatchScalarField, nutUWallFunctionFvPatchScalarField, nutkWallFunctionFvPatchScalarField, and nutLowReWallFunctionFvPatchScalarField.

Referenced by yPlus::execute(), and alphatJayatillekeWallFunctionFvPatchScalarField::yPlus().

Here is the caller graph for this function:

◆ wallCoeffs()

const wallFunctionCoefficients& wallCoeffs ( ) const

inlinenoexcept

Return wallFunctionCoefficients.

Definition at line 222 of file nutWallFunctionFvPatchScalarField.H.

References nutWallFunctionFvPatchScalarField::wallCoeffs_.

Referenced by adjointkOmegaSST::addWallFunctionTerms(), adjointkOmegaSST::adjointMeanFlowSource(), and kaqRWallFunctionFvPatchScalarField::manipulateMatrix().

Here is the caller graph for this function:

◆ updateCoeffs()

void updateCoeffs ( )

virtual

Update the coefficients associated with the patch field.

Definition at line 168 of file nutWallFunctionFvPatchScalarField.C.

References Foam::operator==().

Here is the call graph for this function:

◆ write()

void write ( Ostream & os ) const

virtual

Write.

Definition at line 182 of file nutWallFunctionFvPatchScalarField.C.

References os(), and fvPatchField< Type >::write().

Here is the call graph for this function:

Here is the caller graph for this function:

Member Data Documentation

◆ UName_

word UName_

protected

Name of velocity field.

Default is null (not specified) in which case the velocity is retrieved from the turbulence model

Definition at line 107 of file nutWallFunctionFvPatchScalarField.H.

◆ wallCoeffs_

wallFunctionCoefficients wallCoeffs_

protected

Wall-function coefficients.

Definition at line 112 of file nutWallFunctionFvPatchScalarField.H.

Referenced by nutkWallFunctionFvPatchScalarField::calcNut(), nutUWallFunctionFvPatchScalarField::calcNut(), nutkRoughWallFunctionFvPatchScalarField::calcNut(), atmNutUWallFunctionFvPatchScalarField::calcNut(), atmNutkWallFunctionFvPatchScalarField::calcNut(), atmNutWallFunctionFvPatchScalarField::calcNut(), and nutWallFunctionFvPatchScalarField::wallCoeffs().

The documentation for this class was generated from the following files:

src/TurbulenceModels/turbulenceModels/derivedFvPatchFields/wallFunctions/nutWallFunctions/nutWallFunction/nutWallFunctionFvPatchScalarField.H
src/TurbulenceModels/turbulenceModels/derivedFvPatchFields/wallFunctions/nutWallFunctions/nutWallFunction/nutWallFunctionFvPatchScalarField.C
