leastSquaresEdgeInterpolation< Type > Class Template Reference

Least-squares edge interpolation scheme class, from face centers to points then from points to edges. More...

Inheritance diagram for leastSquaresEdgeInterpolation< Type >:

Collaboration diagram for leastSquaresEdgeInterpolation< Type >:

Public Member Functions
	TypeName ("leastSquares")
	Runtime type information. More...
	leastSquaresEdgeInterpolation (const faMesh &mesh)
	Construct from mesh. More...
	leastSquaresEdgeInterpolation (const faMesh &mesh, Istream &)
	Construct from Istream. More...
	leastSquaresEdgeInterpolation (const faMesh &mesh, const edgeScalarField &, Istream &)
	Construct from faceFlux and Istream. More...
tmp< GeometricField< Type, faePatchField, edgeMesh > >	interpolate (const GeometricField< Type, faPatchField, areaMesh > &) const
	Return the edge-interpolate of the given face field. More...
tmp< edgeScalarField >	weights (const GeometricField< Type, faPatchField, areaMesh > &) const
	Return the interpolation weighting factors. More...
Public Member Functions inherited from edgeInterpolationScheme< Type >
	declareRunTimeSelectionTable (tmp, edgeInterpolationScheme, Mesh,(const faMesh &mesh, Istream &schemeData),(mesh, schemeData))
	declareRunTimeSelectionTable (tmp, edgeInterpolationScheme, MeshFlux,(const faMesh &mesh, const edgeScalarField &faceFlux, Istream &schemeData),(mesh, faceFlux, schemeData))
	edgeInterpolationScheme (const faMesh &mesh)
	Construct from mesh. More...
virtual	~edgeInterpolationScheme ()
const faMesh &	mesh () const
	Return mesh reference. More...
virtual bool	corrected () const
	Return true if this scheme uses an explicit correction. More...
virtual tmp< GeometricField< Type, faePatchField, edgeMesh > >	correction (const GeometricField< Type, faPatchField, areaMesh > &) const
	Return the explicit correction to the face-interpolate. More...
virtual tmp< GeometricField< Type, faePatchField, edgeMesh > >	euclidianInterpolate (const GeometricField< Type, faPatchField, areaMesh > &) const
	Return the euclidian edge-interpolate of the given area field. More...
tmp< GeometricField< Type, faePatchField, edgeMesh > >	interpolate (const tmp< GeometricField< Type, faPatchField, areaMesh >> &) const
	Return the face-interpolate of the given tmp cell field. More...
Public Member Functions inherited from refCount
constexpr	refCount () noexcept
	Default construct, initializing count to 0. More...
int	count () const noexcept
	Return the current reference count. More...
bool	unique () const noexcept
	Return true if the reference count is zero. More...
void	operator++ () noexcept
	Increment the reference count. More...
void	operator++ (int) noexcept
	Increment the reference count. More...
void	operator-- () noexcept
	Decrement the reference count. More...
void	operator-- (int) noexcept
	Decrement the reference count. More...

Additional Inherited Members
Static Public Member Functions inherited from edgeInterpolationScheme< Type >
static tmp< edgeInterpolationScheme< Type > >	New (const faMesh &mesh, Istream &schemeData)
	Return new tmp interpolation scheme. More...
static tmp< edgeInterpolationScheme< Type > >	New (const faMesh &mesh, const edgeScalarField &faceFlux, Istream &schemeData)
	Return new tmp interpolation scheme. More...
static tmp< GeometricField< Type, faePatchField, edgeMesh > >	interpolate (const GeometricField< Type, faPatchField, areaMesh > &, const tmp< edgeScalarField > &, const tmp< edgeScalarField > &)
	Return the face-interpolate of the given cell field. More...
static tmp< GeometricField< Type, faePatchField, edgeMesh > >	interpolate (const GeometricField< Type, faPatchField, areaMesh > &, const tmp< edgeScalarField > &)
	Return the face-interpolate of the given cell field. More...
static tmp< GeometricField< Type, faePatchField, edgeMesh > >	euclidianInterpolate (const GeometricField< Type, faPatchField, areaMesh > &, const tmp< edgeScalarField > &)
	Return the euclidian edge-interpolate of the given area field. More...

Detailed Description

template<class Type>
class Foam::leastSquaresEdgeInterpolation< Type >

Least-squares edge interpolation scheme class, from face centers to points then from points to edges.

References:

    Governing equations (tag:P):
        Pesci, C. (2019).
        Computational analysis of fluid interfaces
        influenced by soluble surfactant.
        Darmstadt, Technische Universität. PhD thesis.
        URI:https://tuprints.ulb.tu-darmstadt.de/id/eprint/9303

Source files

• leastSquaresEdgeInterpolation.H
• leastSquaresEdgeInterpolationMake.C

Definition at line 61 of file leastSquaresEdgeInterpolation.H.

Constructor & Destructor Documentation

leastSquaresEdgeInterpolation() [1/3]

leastSquaresEdgeInterpolation ( const faMesh &  mesh )

inline

Construct from mesh.

Definition at line 86 of file leastSquaresEdgeInterpolation.H.

leastSquaresEdgeInterpolation() [2/3]

leastSquaresEdgeInterpolation ( const faMesh &  mesh, Istream &    )

inline

Construct from Istream.

Definition at line 94 of file leastSquaresEdgeInterpolation.H.

leastSquaresEdgeInterpolation() [3/3]

leastSquaresEdgeInterpolation ( const faMesh &  mesh, const edgeScalarField &  , Istream &    )

inline

Construct from faceFlux and Istream.

Definition at line 103 of file leastSquaresEdgeInterpolation.H.

Member Function Documentation

TypeName()

TypeName

(

"leastSquares"

)

Runtime type information.

interpolate()

tmp< GeometricField< Type, faePatchField, edgeMesh > > interpolate ( const GeometricField< Type, faPatchField, areaMesh > &  af ) const

virtual

Return the edge-interpolate of the given face field.

Reimplemented from edgeInterpolationScheme< Type >.

Definition at line 140 of file leastSquaresEdgeInterpolation.H.

References GeometricField< Type, PatchField, GeoMesh >::boundaryField(), tmp< T >::clear(), tmp< T >::cref(), IOobject::db(), DimensionedField< Type, GeoMesh >::dimensions(), primitiveMesh::edges(), UList< T >::end(), forAll, Foam::fac::grad(), IOobject::instance(), Foam::mag(), Foam::max(), mesh, DimensionedField< Type, GeoMesh >::mesh(), IOobject::name(), tmp< T >::New(), primitiveMesh::nInternalEdges(), primitiveMesh::pointFaces(), polyMesh::points(), UList< T >::size(), Foam::sum(), and Foam::Zero.

Here is the call graph for this function:

weights()

tmp<edgeScalarField> weights ( const GeometricField< Type, faPatchField, areaMesh > &  ) const

inlinevirtual

Return the interpolation weighting factors.

Implements edgeInterpolationScheme< Type >.

Definition at line 128 of file leastSquaresEdgeInterpolation.H.

References edgeInterpolationScheme< Type >::mesh().

Here is the call graph for this function:

---

The documentation for this class was generated from the following file:

• src/finiteArea/interpolation/edgeInterpolation/schemes/leastSquares/leastSquaresEdgeInterpolation.H
