A special matrix type and solver, designed for finite area solutions of scalar equations. Face addressing is used to make all matrix assembly and solution loops vectorise. More...

Inheritance diagram for faMatrix< Type >:

[legend]

Collaboration diagram for faMatrix< Type >:

[legend]

Classes
class	faSolver
	Solver class returned by the solver function used for systems in which it is useful to cache the solver for reuse. More...

Public Types
typedef GeometricField< Type, faPatchField, areaMesh >	psiFieldType
	The geometric field type for psi. More...

typedef GeometricField< Type, faePatchField, edgeMesh >	faceFluxFieldType
	Field type for face flux (for non-orthogonal correction) More...

typedef GeometricField< Type, faePatchField, edgeMesh > *	faceFluxFieldPtrType
	Declare return type of the faceFluxCorrectionPtr() function. More...

Public Types inherited from lduMatrix
enum	normTypes : char { NO_NORM, DEFAULT_NORM, L1_SCALED_NORM }
	Enumerated matrix normalisation types. More...

Public Member Functions
	ClassName ("faMatrix")

	faMatrix (const GeometricField< Type, faPatchField, areaMesh > &psi, const dimensionSet &ds)
	Construct given a field to solve for. More...

	faMatrix (const faMatrix< Type > &)
	Copy construct. More...

	faMatrix (const tmp< faMatrix< Type >> &)
	Copy/move construct from tmp<faMatrix<Type>> More...

	faMatrix (const GeometricField< Type, faPatchField, areaMesh > &psi, Istream &is)
	Deprecated(2022-05) - construct with dimensionSet instead. More...

tmp< faMatrix< Type > >	clone () const
	Construct and return a clone. More...

virtual	~faMatrix ()
	Destructor. More...

const GeometricField< Type, faPatchField, areaMesh > &	psi () const

const dimensionSet &	dimensions () const noexcept

Field< Type > &	source () noexcept

const Field< Type > &	source () const noexcept

const FieldField< Field, Type > &	internalCoeffs () const noexcept
	faBoundary scalar field containing pseudo-matrix coeffs for internal cells More...

FieldField< Field, Type > &	internalCoeffs () noexcept
	faBoundary scalar field containing pseudo-matrix coeffs for internal cells More...

const FieldField< Field, Type > &	boundaryCoeffs () const noexcept
	faBoundary scalar field containing pseudo-matrix coeffs for boundary cells More...

FieldField< Field, Type > &	boundaryCoeffs () noexcept
	faBoundary scalar field containing pseudo-matrix coeffs for boundary cells More...

faceFluxFieldPtrType &	faceFluxCorrectionPtr ()
	Return pointer to face-flux non-orthogonal correction field. More...

bool	hasFaceFluxCorrection () const noexcept
	True if face-flux non-orthogonal correction field exists. More...

void	setValues (const labelUList &faceLabels, const Type &value)
	Set solution in given faces to the specified value and eliminate the corresponding equations from the matrix. More...

void	setValues (const labelUList &faceLabels, const UList< Type > &values)
	Set solution in given faces to the specified values and eliminate the corresponding equations from the matrix. More...

void	setValues (const labelUList &faceLabels, const UIndirectList< Type > &values)
	Set solution in given faces to the specified values and eliminate the corresponding equations from the matrix. More...

void	setReference (const label facei, const Type &value, const bool forceReference=false)
	Set reference level for solution. More...

void	setReferences (const labelUList &faceLabels, const Type &value, const bool forceReference=false)
	Set reference level for solution. More...

void	setReferences (const labelUList &faceLabels, const UList< Type > &values, const bool forceReference=false)
	Set reference level for solution. More...

void	setComponentReference (const label patchi, const label facei, const direction cmpt, const scalar value)
	Set reference level for a component of the solution on a given patch face. More...

void	relax (const scalar alpha)
	Relax matrix (for steady-state solution). More...

void	relax ()
	Relax matrix (for steady-state solution). More...

SolverPerformance< Type >	solve (const dictionary &)
	Solve returning the solution statistics. More...

SolverPerformance< Type >	solve ()
	Solve returning the solution statistics. More...

tmp< Field< Type > >	residual () const
	Return the matrix residual. More...

tmp< scalarField >	D () const
	Return the matrix diagonal. More...

tmp< areaScalarField >	A () const
	Return the central coefficient. More...

tmp< GeometricField< Type, faPatchField, areaMesh > >	H () const
	Return the H operation source. More...

tmp< GeometricField< Type, faePatchField, edgeMesh > >	flux () const
	Return the face-flux field from the matrix. More...

void	operator= (const faMatrix< Type > &)

void	operator= (const tmp< faMatrix< Type >> &)

void	negate ()
	Inplace negate. More...

void	operator+= (const faMatrix< Type > &)

void	operator+= (const tmp< faMatrix< Type >> &)

void	operator-= (const faMatrix< Type > &)

void	operator-= (const tmp< faMatrix< Type >> &)

void	operator+= (const DimensionedField< Type, areaMesh > &)

void	operator+= (const tmp< DimensionedField< Type, areaMesh >> &)

void	operator+= (const tmp< GeometricField< Type, faPatchField, areaMesh >> &)

void	operator-= (const DimensionedField< Type, areaMesh > &)

void	operator-= (const tmp< DimensionedField< Type, areaMesh >> &)

void	operator-= (const tmp< GeometricField< Type, faPatchField, areaMesh >> &)

void	operator+= (const dimensioned< Type > &)

void	operator-= (const dimensioned< Type > &)

void	operator+= (const Foam::zero)

void	operator-= (const Foam::zero)

void	operator*= (const areaScalarField::Internal &)

void	operator*= (const tmp< areaScalarField::Internal > &)

void	operator*= (const tmp< areaScalarField > &)

void	operator*= (const dimensioned< scalar > &)

template<>
void	setComponentReference (const label patchI, const label edgeI, const direction, const scalar value)

template<>
Foam::solverPerformance	solve (const dictionary &solverControls)

template<>
Foam::tmp< Foam::scalarField >	residual () const

template<>
Foam::tmp< Foam::areaScalarField >	H () const

template<>
void	setComponentReference (const label patchi, const label facei, const direction, const scalar value)

template<>
SolverPerformance< scalar >	solve (const dictionary &)

template<>
tmp< scalarField >	residual () const

template<>
tmp< areaScalarField >	H () const

Public Member Functions inherited from refCount
constexpr	refCount () noexcept
	Default construct, initializing count to 0. More...

int	count () const noexcept
	Return the current reference count. More...

bool	unique () const noexcept
	Return true if the reference count is zero. More...

void	operator++ () noexcept
	Increment the reference count. More...

void	operator++ (int) noexcept
	Increment the reference count. More...

void	operator-- () noexcept
	Decrement the reference count. More...

void	operator-- (int) noexcept
	Decrement the reference count. More...

Public Member Functions inherited from lduMatrix
	ClassName ("lduMatrix")

	lduMatrix (const lduMesh &)
	Construct given an LDU addressed mesh. More...

	lduMatrix (const lduMatrix &)
	Construct as copy. More...

	lduMatrix (lduMatrix &, bool reuse)
	Construct as copy or re-use as specified. More...

	lduMatrix (const lduMesh &, Istream &)
	Construct given an LDU addressed mesh and an Istream from which the coefficients are read. More...

	~lduMatrix ()
	Destructor. More...

const lduMesh &	mesh () const noexcept
	Return the LDU mesh from which the addressing is obtained. More...

void	setLduMesh (const lduMesh &m)
	Set the LDU mesh containing the addressing is obtained. More...

const lduAddressing &	lduAddr () const
	Return the LDU addressing. More...

const lduSchedule &	patchSchedule () const
	Return the patch evaluation schedule. More...

scalarField &	lower ()

scalarField &	diag ()

scalarField &	upper ()

scalarField &	lower (const label size)

scalarField &	diag (const label nCoeffs)

scalarField &	upper (const label nCoeffs)

const scalarField &	lower () const

const scalarField &	diag () const

const scalarField &	upper () const

bool	hasDiag () const noexcept

bool	hasUpper () const noexcept

bool	hasLower () const noexcept

bool	diagonal () const noexcept

bool	symmetric () const noexcept

bool	asymmetric () const noexcept

void	sumDiag ()

void	negSumDiag ()

void	sumMagOffDiag (scalarField &sumOff) const

void	Amul (solveScalarField &, const tmp< solveScalarField > &, const FieldField< Field, scalar > &, const lduInterfaceFieldPtrsList &, const direction cmpt) const
	Matrix multiplication with updated interfaces. More...

void	Tmul (solveScalarField &, const tmp< solveScalarField > &, const FieldField< Field, scalar > &, const lduInterfaceFieldPtrsList &, const direction cmpt) const
	Matrix transpose multiplication with updated interfaces. More...

void	sumA (solveScalarField &, const FieldField< Field, scalar > &, const lduInterfaceFieldPtrsList &) const
	Sum the coefficients on each row of the matrix. More...

void	residual (solveScalarField &rA, const solveScalarField &psi, const scalarField &source, const FieldField< Field, scalar > &interfaceBouCoeffs, const lduInterfaceFieldPtrsList &interfaces, const direction cmpt) const

tmp< solveScalarField >	residual (const solveScalarField &psi, const scalarField &source, const FieldField< Field, scalar > &interfaceBouCoeffs, const lduInterfaceFieldPtrsList &interfaces, const direction cmpt) const

void	initMatrixInterfaces (const bool add, const FieldField< Field, scalar > &interfaceCoeffs, const lduInterfaceFieldPtrsList &interfaces, const solveScalarField &psiif, solveScalarField &result, const direction cmpt) const
	Initialise the update of interfaced interfaces for matrix operations. More...

void	updateMatrixInterfaces (const bool add, const FieldField< Field, scalar > &interfaceCoeffs, const lduInterfaceFieldPtrsList &interfaces, const solveScalarField &psiif, solveScalarField &result, const direction cmpt, const label startRequest) const
	Update interfaced interfaces for matrix operations. More...

void	setResidualField (const scalarField &residual, const word &fieldName, const bool initial) const
	Set the residual field using an IOField on the object registry if it exists. More...

template<class Type >
tmp< Field< Type > >	H (const Field< Type > &) const

template<class Type >
tmp< Field< Type > >	H (const tmp< Field< Type >> &) const

tmp< scalarField >	H1 () const

template<class Type >
tmp< Field< Type > >	faceH (const Field< Type > &) const

template<class Type >
tmp< Field< Type > >	faceH (const tmp< Field< Type >> &) const

InfoProxy< lduMatrix >	info () const
	Return info proxy. More...

void	operator= (const lduMatrix &)

void	negate ()

void	operator+= (const lduMatrix &)

void	operator-= (const lduMatrix &)

void	operator*= (const scalarField &)

void	operator*= (scalar)

template<class Type >
Foam::tmp< Foam::Field< Type > >	H (const Field< Type > &psi) const

template<class Type >
Foam::tmp< Foam::Field< Type > >	H (const tmp< Field< Type >> &tpsi) const

template<class Type >
Foam::tmp< Foam::Field< Type > >	faceH (const Field< Type > &psi) const

template<class Type >
Foam::tmp< Foam::Field< Type > >	faceH (const tmp< Field< Type >> &tpsi) const

Protected Member Functions
template<class Type2 >
void	addToInternalField (const labelUList &addr, const Field< Type2 > &pf, Field< Type2 > &intf) const
	Add patch contribution to internal field. More...

template<class Type2 >
void	addToInternalField (const labelUList &addr, const tmp< Field< Type2 >> &tpf, Field< Type2 > &intf) const

template<class Type2 >
void	subtractFromInternalField (const labelUList &addr, const Field< Type2 > &pf, Field< Type2 > &intf) const
	Subtract patch contribution from internal field. More...

template<class Type2 >
void	subtractFromInternalField (const labelUList &addr, const tmp< Field< Type2 >> &tpf, Field< Type2 > &intf) const

void	addBoundaryDiag (scalarField &diag, const direction cmpt) const

void	addCmptAvBoundaryDiag (scalarField &diag) const

void	addBoundarySource (Field< Type > &source, const bool couples=true) const

template<template< class > class ListType>
void	setValuesFromList (const labelUList &faceLabels, const ListType< Type > &values)
	Set solution in given faces to the specified values. More...

Friends
class	faSolver
	Declare friendship with the faSolver class. More...

tmp< GeometricField< Type, faPatchField, areaMesh > >	operator & (const faMatrix< Type > &, const DimensionedField< Type, areaMesh > &)

tmp< GeometricField< Type, faPatchField, areaMesh > >	operator & (const faMatrix< Type > &, const tmp< GeometricField< Type, faPatchField, areaMesh >> &)

tmp< GeometricField< Type, faPatchField, areaMesh > >	operator & (const tmp< faMatrix< Type >> &, const DimensionedField< Type, areaMesh > &)

tmp< GeometricField< Type, faPatchField, areaMesh > >	operator & (const tmp< faMatrix< Type >> &, const tmp< GeometricField< Type, faPatchField, areaMesh >> &)

Ostream &	operator (Ostream &, const faMatrix< Type > &)

Additional Inherited Members
Static Public Attributes inherited from lduMatrix
static const Enum< normTypes >	normTypesNames_
	Names for the normTypes. More...

static constexpr const label	defaultMaxIter = 1000
	Default maximum number of iterations for solvers (1000) More...

static const scalar	defaultTolerance = 1e-6
	Default (absolute) tolerance (1e-6) More...

Detailed Description

template<class Type>
class Foam::faMatrix< Type >

A special matrix type and solver, designed for finite area solutions of scalar equations. Face addressing is used to make all matrix assembly and solution loops vectorise.

Finite-Area matrix.

Author Zeljko Tukovic, FMENA Hrvoje Jasak, Wikki Ltd.

Source files

Author Zeljko Tukovic, FMENA Hrvoje Jasak, Wikki Ltd.

Definition at line 37 of file faMatricesFwd.H.

Member Typedef Documentation

◆ psiFieldType

typedef GeometricField<Type, faPatchField, areaMesh> psiFieldType

The geometric field type for psi.

Definition at line 123 of file faMatrix.H.

◆ faceFluxFieldType

typedef GeometricField<Type, faePatchField, edgeMesh> faceFluxFieldType

Field type for face flux (for non-orthogonal correction)

Definition at line 130 of file faMatrix.H.

◆ faceFluxFieldPtrType

typedef GeometricField<Type, faePatchField, edgeMesh>* faceFluxFieldPtrType

Declare return type of the faceFluxCorrectionPtr() function.

Definition at line 413 of file faMatrix.H.

Constructor & Destructor Documentation

◆ faMatrix() [1/4]

faMatrix	(	const GeometricField< Type, faPatchField, areaMesh > &	psi,
		const dimensionSet &	ds
	)

Construct given a field to solve for.

Definition at line 178 of file faMatrix.C.

References DebugInFunction, Foam::endl(), regIOobject::eventNo(), forAll, psi, and Foam::Zero.

Here is the call graph for this function:

◆ faMatrix() [2/4]

faMatrix ( const faMatrix< Type > & fam )

Copy construct.

Definition at line 222 of file faMatrix.C.

References DebugInFunction, Foam::endl(), and IOobject::name().

Here is the call graph for this function:

◆ faMatrix() [3/4]

faMatrix ( const tmp< faMatrix< Type >> & tmat )

Copy/move construct from tmp<faMatrix<Type>>

Definition at line 247 of file faMatrix.C.

References DebugInFunction, Foam::endl(), and IOobject::name().

Here is the call graph for this function:

◆ faMatrix() [4/4]

faMatrix	(	const GeometricField< Type, faPatchField, areaMesh > &	psi,
		Istream &	is
	)

inline

Deprecated(2022-05) - construct with dimensionSet instead.

Deprecated:: (2022-05) - construct with dimensionSet instead

Definition at line 326 of file faMatrix.H.

◆ ~faMatrix()

~faMatrix ( )

virtual

Destructor.

Definition at line 284 of file faMatrix.C.

References DebugInFunction, Foam::deleteDemandDrivenData(), and Foam::endl().

Here is the call graph for this function:

Member Function Documentation

◆ addToInternalField() [1/2]

void addToInternalField	(	const labelUList &	addr,
		const Field< Type2 > &	pf,
		Field< Type2 > &	intf
	)		const

protected

Add patch contribution to internal field.

Definition at line 35 of file faMatrix.C.

References Foam::abort(), Foam::endl(), Foam::FatalError, FatalErrorInFunction, forAll, UList< T >::size(), and UList< Type >::size().

Here is the call graph for this function:

◆ addToInternalField() [2/2]

void addToInternalField	(	const labelUList &	addr,
		const tmp< Field< Type2 >> &	tpf,
		Field< Type2 > &	intf
	)		const

protected

Definition at line 59 of file faMatrix.C.

◆ subtractFromInternalField() [1/2]

void subtractFromInternalField	(	const labelUList &	addr,
		const Field< Type2 > &	pf,
		Field< Type2 > &	intf
	)		const

protected

Subtract patch contribution from internal field.

Definition at line 73 of file faMatrix.C.

References Foam::abort(), Foam::endl(), Foam::FatalError, FatalErrorInFunction, forAll, UList< T >::size(), and UList< Type >::size().

Here is the call graph for this function:

◆ subtractFromInternalField() [2/2]

void subtractFromInternalField	(	const labelUList &	addr,
		const tmp< Field< Type2 >> &	tpf,
		Field< Type2 > &	intf
	)		const

protected

Definition at line 97 of file faMatrix.C.

◆ addBoundaryDiag()

void addBoundaryDiag	(	scalarField &	diag,
		const direction	cmpt
	)		const

protected

Definition at line 110 of file faMatrix.C.

References Foam::component(), Foam::diag(), and forAll.

Referenced by faMatrix< Type >::residual().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ addCmptAvBoundaryDiag()

void addCmptAvBoundaryDiag ( scalarField & diag ) const

protected

Definition at line 128 of file faMatrix.C.

References Foam::cmptAv(), Foam::diag(), and forAll.

Here is the call graph for this function:

◆ addBoundarySource()

void addBoundarySource	(	Field< Type > &	source,
		const bool	couples = `true`
	)		const

protected

Definition at line 144 of file faMatrix.C.

References Foam::cmptMultiply(), faPatchField< Type >::coupled(), forAll, and faPatchField< Type >::patchNeighbourField().

Referenced by faMatrix< Type >::residual().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ setValuesFromList()

void setValuesFromList	(	const labelUList &	faceLabels,
		const ListType< Type > &	values
	)

protected

Set solution in given faces to the specified values.

Definition at line 298 of file faMatrix.C.

References fvMesh::boundary(), Foam::diag(), primitiveMesh::faceEdges(), forAll, Foam::stringOps::lower(), mesh, fvMesh::neighbour(), fvMesh::owner(), primitiveFieldRef(), psi, Foam::stringOps::upper(), Foam::HashTableOps::values(), and Foam::Zero.

Here is the call graph for this function:

◆ ClassName()

ClassName ( "faMatrix< Type >" )

◆ clone()

tmp<faMatrix<Type> > clone ( ) const

inline

Construct and return a clone.

Definition at line 337 of file faMatrix.H.

References Foam::New().

Here is the call graph for this function:

◆ psi()

const GeometricField<Type, faPatchField, areaMesh>& psi ( ) const

inline

Definition at line 353 of file faMatrix.H.

Referenced by externalFileSource::addSup(), contactHeatFluxSource::addSup(), jouleHeatingSource::addSup(), externalHeatFluxSource::addSup(), Foam::checkMethod(), optionList::constrain(), and faMatrix< Type >::solve().

Here is the caller graph for this function:

◆ dimensions()

const dimensionSet& dimensions ( ) const

inlinenoexcept

Definition at line 358 of file faMatrix.H.

Referenced by Foam::checkMethod(), and faMatrix< Type >::operator*=().

Here is the caller graph for this function:

◆ source() [1/2]

Field<Type>& source ( )

inlinenoexcept

Definition at line 363 of file faMatrix.H.

◆ source() [2/2]

const Field<Type>& source ( ) const

inlinenoexcept

Definition at line 368 of file faMatrix.H.

◆ internalCoeffs() [1/2]

const FieldField<Field, Type>& internalCoeffs ( ) const

inlinenoexcept

faBoundary scalar field containing pseudo-matrix coeffs for internal cells

Definition at line 377 of file faMatrix.H.

◆ internalCoeffs() [2/2]

FieldField<Field, Type>& internalCoeffs ( )

inlinenoexcept

faBoundary scalar field containing pseudo-matrix coeffs for internal cells

Definition at line 386 of file faMatrix.H.

◆ boundaryCoeffs() [1/2]

const FieldField<Field, Type>& boundaryCoeffs ( ) const

inlinenoexcept

faBoundary scalar field containing pseudo-matrix coeffs for boundary cells

Definition at line 395 of file faMatrix.H.

◆ boundaryCoeffs() [2/2]

FieldField<Field, Type>& boundaryCoeffs ( )

inlinenoexcept

faBoundary scalar field containing pseudo-matrix coeffs for boundary cells

Definition at line 404 of file faMatrix.H.

◆ faceFluxCorrectionPtr()

faceFluxFieldPtrType& faceFluxCorrectionPtr ( )

inline

Return pointer to face-flux non-orthogonal correction field.

Definition at line 418 of file faMatrix.H.

Referenced by gaussLaplacianScheme< Type >::famLaplacian().

Here is the caller graph for this function:

◆ hasFaceFluxCorrection()

bool hasFaceFluxCorrection ( ) const

inlinenoexcept

True if face-flux non-orthogonal correction field exists.

Definition at line 426 of file faMatrix.H.

◆ setValues() [1/3]

void setValues	(	const labelUList &	faceLabels,
		const Type &	value
	)

Set solution in given faces to the specified value and eliminate the corresponding equations from the matrix.

Definition at line 401 of file faMatrix.C.

◆ setValues() [2/3]

void setValues	(	const labelUList &	faceLabels,
		const UList< Type > &	values
	)

Set solution in given faces to the specified values and eliminate the corresponding equations from the matrix.

Definition at line 412 of file faMatrix.C.

References Foam::HashTableOps::values().

Here is the call graph for this function:

◆ setValues() [3/3]

void setValues	(	const labelUList &	faceLabels,
		const UIndirectList< Type > &	values
	)

Set solution in given faces to the specified values and eliminate the corresponding equations from the matrix.

Definition at line 423 of file faMatrix.C.

References Foam::HashTableOps::values().

Here is the call graph for this function:

◆ setReference()

void setReference	(	const label	facei,
		const Type &	value,
		const bool	forceReference = `false`
	)

Set reference level for solution.

Definition at line 434 of file faMatrix.C.

References Foam::diag(), and UPstream::master().

Here is the call graph for this function:

◆ setReferences() [1/2]

void setReferences	(	const labelUList &	faceLabels,
		const Type &	value,
		const bool	forceReference = `false`
	)

Set reference level for solution.

Definition at line 453 of file faMatrix.C.

References Foam::diag(), faceId(), and forAll.

Here is the call graph for this function:

◆ setReferences() [2/2]

void setReferences	(	const labelUList &	faceLabels,
		const UList< Type > &	values,
		const bool	forceReference = `false`
	)

Set reference level for solution.

Definition at line 476 of file faMatrix.C.

References Foam::diag(), faceId(), forAll, and Foam::HashTableOps::values().

Here is the call graph for this function:

◆ setComponentReference() [1/3]

void setComponentReference	(	const label	patchi,
		const label	facei,
		const direction	cmpt,
		const scalar	value
	)

Set reference level for a component of the solution on a given patch face.

Definition at line 32 of file faMatrixSolve.C.

References Foam::diag().

Here is the call graph for this function:

◆ relax() [1/2]

void relax ( const scalar alpha )

Relax matrix (for steady-state solution).

alpha = 1 : diagonally equal alpha < 1 : ,, dominant alpha = 0 : do nothing Note: Requires positive diagonal.

Definition at line 498 of file faMatrix.C.

References Foam::constant::atomic::alpha, Foam::cmptMag(), Foam::cmptMin(), Foam::cmptMultiply(), Foam::component(), faPatchField< Type >::coupled(), D, Foam::diag(), forAll, Foam::mag(), Foam::max(), UList< Type >::size(), and Foam::Zero.

Referenced by kinematicThinFilm::evolveRegion().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ relax() [2/2]

void relax ( )

Relax matrix (for steady-state solution).

alpha is read from controlDict

Definition at line 588 of file faMatrix.C.

References DebugInFunction, Foam::endl(), and relax().

Here is the call graph for this function:

◆ solve() [1/4]

Foam::SolverPerformance< Type > solve ( const dictionary & solverControls )

Solve returning the solution statistics.

Use the given solver controls

Definition at line 49 of file faMatrixSolve.C.

References Field< Type >::component(), DebugInFunction, Foam::diag(), Foam::endl(), dictionary::getOrDefault(), Foam::Info, Foam::New(), SolverPerformance< Type >::print(), psi, refPtr< Container< Type > >::ref(), solve(), and SolverPerformance< Type >::solverName().

Here is the call graph for this function:

◆ solve() [2/4]

Foam::SolverPerformance< Type > solve ( )

Solve returning the solution statistics.

Solver controls read from faSolution

Definition at line 173 of file faMatrixSolve.C.

References lduMatrix::mesh(), Foam::name(), and faMatrix< Type >::psi().

Here is the call graph for this function:

◆ residual() [1/3]

Foam::tmp< Foam::Field< Type > > residual ( ) const

Return the matrix residual.

Definition at line 180 of file faMatrixSolve.C.

References faMatrix< Type >::addBoundaryDiag(), faMatrix< Type >::addBoundarySource(), GeometricField< Type, PatchField, GeoMesh >::boundaryField(), DimensionedField< Type, GeoMesh >::component(), Field< Type >::component(), GeometricField< Type, PatchField, GeoMesh >::internalField(), tmp< T >::ref(), Field< Type >::replace(), lduMatrix::residual(), GeometricBoundaryField< Type, PatchField, GeoMesh >::scalarInterfaces(), UList< T >::size(), and Foam::Zero.

Here is the call graph for this function:

◆ D()

Foam::tmp< Foam::scalarField > D ( ) const

Return the matrix diagonal.

Definition at line 604 of file faMatrix.C.

References Foam::diag(), and tmp< T >::ref().

Here is the call graph for this function:

◆ A()

Foam::tmp< Foam::areaScalarField > A ( ) const

Return the central coefficient.

Definition at line 613 of file faMatrix.C.

References GeometricField< Type, PatchField, GeoMesh >::correctBoundaryConditions(), D, Foam::dimArea, GeometricField< Type, PatchField, GeoMesh >::primitiveFieldRef(), and tmp< T >::ref().

Here is the call graph for this function:

◆ H() [1/3]

Foam::tmp< Foam::GeometricField< Type, Foam::faPatchField, Foam::areaMesh > > H ( ) const

Return the H operation source.

Definition at line 640 of file faMatrix.C.

References GeometricField< Type, PatchField, GeoMesh >::correctBoundaryConditions(), Foam::dimArea, lduMatrix::H(), GeometricField< Type, PatchField, GeoMesh >::primitiveFieldRef(), tmp< T >::ref(), and Foam::Zero.

Here is the call graph for this function:

◆ flux()

Foam::tmp< Foam::GeometricField< Type, Foam::faePatchField, Foam::edgeMesh > > flux ( ) const

Return the face-flux field from the matrix.

Definition at line 684 of file faMatrix.C.

References Foam::abort(), GeometricField< Type, PatchField, GeoMesh >::boundaryField(), GeometricField< Type, PatchField, GeoMesh >::boundaryFieldRef(), Foam::cmptMultiply(), lduMatrix::faceH(), Foam::FatalError, FatalErrorInFunction, forAll, GeometricField< Type, PatchField, GeoMesh >::primitiveFieldRef(), and tmp< T >::ref().

Here is the call graph for this function:

◆ operator=() [1/2]

void operator= ( const faMatrix< Type > & famv )

Definition at line 766 of file faMatrix.C.

References Foam::abort(), Foam::FatalError, FatalErrorInFunction, and lduMatrix::operator=().

Here is the call graph for this function:

◆ operator=() [2/2]

void operator= ( const tmp< faMatrix< Type >> & tfamv )

Definition at line 799 of file faMatrix.C.

◆ negate()

void negate ( )

Inplace negate.

Definition at line 807 of file faMatrix.C.

References lduMatrix::negate().

Here is the call graph for this function:

◆ operator+=() [1/7]

void operator+= ( const faMatrix< Type > & famv )

Definition at line 822 of file faMatrix.C.

References Foam::checkMethod(), and lduMatrix::operator+=().

Here is the call graph for this function:

◆ operator+=() [2/7]

void operator+= ( const tmp< faMatrix< Type >> & tfamv )

Definition at line 848 of file faMatrix.C.

◆ operator-=() [1/7]

void operator-= ( const faMatrix< Type > & famv )

Definition at line 856 of file faMatrix.C.

References Foam::checkMethod(), and lduMatrix::operator-=().

Here is the call graph for this function:

◆ operator-=() [2/7]

void operator-= ( const tmp< faMatrix< Type >> & tfamv )

Definition at line 880 of file faMatrix.C.

◆ operator+=() [3/7]

void operator+= ( const DimensionedField< Type, areaMesh > & su )

Definition at line 889 of file faMatrix.C.

References Foam::checkMethod().

Here is the call graph for this function:

◆ operator+=() [4/7]

void operator+= ( const tmp< DimensionedField< Type, areaMesh >> & tsu )

Definition at line 900 of file faMatrix.C.

◆ operator+=() [5/7]

void operator+= ( const tmp< GeometricField< Type, faPatchField, areaMesh >> & tsu )

Definition at line 911 of file faMatrix.C.

◆ operator-=() [3/7]

void operator-= ( const DimensionedField< Type, areaMesh > & su )

Definition at line 922 of file faMatrix.C.

References Foam::checkMethod().

Here is the call graph for this function:

◆ operator-=() [4/7]

void operator-= ( const tmp< DimensionedField< Type, areaMesh >> & tsu )

Definition at line 933 of file faMatrix.C.

◆ operator-=() [5/7]

void operator-= ( const tmp< GeometricField< Type, faPatchField, areaMesh >> & tsu )

Definition at line 944 of file faMatrix.C.

◆ operator+=() [6/7]

void operator+= ( const dimensioned< Type > & su )

Definition at line 955 of file faMatrix.C.

References DimensionedField< Type, GeoMesh >::mesh(), and psi.

Here is the call graph for this function:

◆ operator-=() [6/7]

void operator-= ( const dimensioned< Type > & su )

Definition at line 965 of file faMatrix.C.

References DimensionedField< Type, GeoMesh >::mesh(), and psi.

Here is the call graph for this function:

◆ operator+=() [7/7]

void operator+= ( const Foam::zero )

Definition at line 974 of file faMatrix.C.

◆ operator-=() [7/7]

void operator-= ( const Foam::zero )

Definition at line 979 of file faMatrix.C.

◆ operator*=() [1/4]

void operator*= ( const areaScalarField::Internal & dsf )

Definition at line 985 of file faMatrix.C.

References Foam::abort(), faMatrix< Type >::dimensions(), Foam::FatalError, FatalErrorInFunction, forAll, and lduMatrix::operator*=().

Here is the call graph for this function:

◆ operator*=() [2/4]

void operator*= ( const tmp< areaScalarField::Internal > & tfld )

Definition at line 1014 of file faMatrix.C.

◆ operator*=() [3/4]

void operator*= ( const tmp< areaScalarField > & tfld )

Definition at line 1025 of file faMatrix.C.

◆ operator*=() [4/4]

void operator*= ( const dimensioned< scalar > & ds )

Definition at line 1036 of file faMatrix.C.

References lduMatrix::operator*=().

Here is the call graph for this function:

◆ setComponentReference() [2/3]

void setComponentReference	(	const label	patchI,
		const label	edgeI,
		const direction	,
		const scalar	value
	)

Definition at line 34 of file faScalarMatrix.C.

References Foam::diag().

Here is the call graph for this function:

◆ solve() [3/4]

Foam::solverPerformance solve ( const dictionary & solverControls )

Definition at line 51 of file faScalarMatrix.C.

References Foam::ensightOutput::debug, DebugInFunction, Foam::diag(), Foam::endl(), dictionary::getOrDefault(), Foam::Info, Foam::New(), SolverPerformance< Type >::print(), psi, and solve().

Here is the call graph for this function:

◆ residual() [2/3]

Foam::tmp< Foam::scalarField > residual ( ) const

Definition at line 102 of file faScalarMatrix.C.

References psi, refPtr< Container< Type > >::ref(), and Foam::Zero.

Here is the call graph for this function:

◆ H() [2/3]

Foam::tmp< Foam::areaScalarField > H ( ) const

Definition at line 131 of file faScalarMatrix.C.

References GeometricField< Type, PatchField, GeoMesh >::correctBoundaryConditions(), Foam::dimArea, H(), DimensionedField< Type, GeoMesh >::mesh(), GeometricField< Type, PatchField, GeoMesh >::primitiveFieldRef(), tmp< T >::ref(), and GeometricField< Type, PatchField, GeoMesh >::ref().

Here is the call graph for this function:

◆ setComponentReference() [3/3]

void setComponentReference	(	const label	patchi,
		const label	facei,
		const direction	,
		const scalar	value
	)

◆ solve() [4/4]

SolverPerformance< scalar > solve ( const dictionary & )

◆ residual() [3/3]

tmp< scalarField > residual ( ) const

◆ H() [3/3]

tmp< areaScalarField > H ( ) const

Friends And Related Function Documentation

◆ faSolver

friend class faSolver

friend

Declare friendship with the faSolver class.

Definition at line 179 of file faMatrix.H.

◆ operator & [1/4]

tmp<GeometricField<Type, faPatchField, areaMesh> > operator&	(	const faMatrix< Type > &	,
		const DimensionedField< Type, areaMesh > &
	)

friend

◆ operator & [2/4]

tmp<GeometricField<Type, faPatchField, areaMesh> > operator&	(	const faMatrix< Type > &	,
		const tmp< GeometricField< Type, faPatchField, areaMesh >> &
	)

friend

◆ operator & [3/4]

tmp<GeometricField<Type, faPatchField, areaMesh> > operator&	(	const tmp< faMatrix< Type >> &	,
		const DimensionedField< Type, areaMesh > &
	)

friend

◆ operator & [4/4]

tmp<GeometricField<Type, faPatchField, areaMesh> > operator&	(	const tmp< faMatrix< Type >> &	,
		const tmp< GeometricField< Type, faPatchField, areaMesh >> &
	)

friend

◆ operator

Ostream& operator	(	Ostream &	,
		const faMatrix< Type > &
	)

friend

The documentation for this class was generated from the following files:

src/finiteArea/faMatrices/faMatricesFwd.H
src/finiteArea/faMatrices/faMatrix/faMatrix.H
src/finiteArea/faMatrices/faMatrix/faMatrix.C
src/finiteArea/faMatrices/faMatrix/faMatrixSolve.C

Classes

Public Types

Public Member Functions

Protected Member Functions

Friends

Additional Inherited Members

Detailed Description

template<class Type> class Foam::faMatrix< Type >

Member Typedef Documentation

◆ psiFieldType

◆ faceFluxFieldType

◆ faceFluxFieldPtrType

Constructor & Destructor Documentation

◆ faMatrix() [1/4]

◆ faMatrix() [2/4]

◆ faMatrix() [3/4]

◆ faMatrix() [4/4]

◆ ~faMatrix()

Member Function Documentation

◆ addToInternalField() [1/2]

◆ addToInternalField() [2/2]

◆ subtractFromInternalField() [1/2]

◆ subtractFromInternalField() [2/2]

◆ addBoundaryDiag()

◆ addCmptAvBoundaryDiag()

◆ addBoundarySource()

◆ setValuesFromList()

◆ ClassName()

◆ clone()

◆ psi()

◆ dimensions()

◆ source() [1/2]

◆ source() [2/2]

◆ internalCoeffs() [1/2]

◆ internalCoeffs() [2/2]

◆ boundaryCoeffs() [1/2]

◆ boundaryCoeffs() [2/2]

◆ faceFluxCorrectionPtr()

◆ hasFaceFluxCorrection()

◆ setValues() [1/3]

◆ setValues() [2/3]

◆ setValues() [3/3]

◆ setReference()

◆ setReferences() [1/2]

◆ setReferences() [2/2]

◆ setComponentReference() [1/3]

◆ relax() [1/2]

◆ relax() [2/2]

◆ solve() [1/4]

◆ solve() [2/4]

◆ residual() [1/3]

◆ D()

◆ A()

◆ H() [1/3]

◆ flux()

◆ operator=() [1/2]

◆ operator=() [2/2]

◆ negate()

◆ operator+=() [1/7]

◆ operator+=() [2/7]

◆ operator-=() [1/7]

◆ operator-=() [2/7]

◆ operator+=() [3/7]

◆ operator+=() [4/7]

◆ operator+=() [5/7]

◆ operator-=() [3/7]

◆ operator-=() [4/7]

◆ operator-=() [5/7]

◆ operator+=() [6/7]

◆ operator-=() [6/7]

◆ operator+=() [7/7]

◆ operator-=() [7/7]

◆ operator*=() [1/4]

◆ operator*=() [2/4]

◆ operator*=() [3/4]

◆ operator*=() [4/4]

◆ setComponentReference() [2/3]

◆ solve() [3/4]

◆ residual() [2/3]

◆ H() [2/3]

template<class Type>
class Foam::faMatrix< Type >
