This boundary condition provides a wall constraint on the kinematic turbulent thermal conductivity (i.e. alphat) for atmospheric boundary layer modelling. It assumes a logarithmic distribution of the potential temperature within the first cell. More...

Inheritance diagram for atmAlphatkWallFunctionFvPatchScalarField:

[legend]

Collaboration diagram for atmAlphatkWallFunctionFvPatchScalarField:

[legend]

Public Member Functions
	TypeName ("atmAlphatkWallFunction")
	Runtime type information. More...

	atmAlphatkWallFunctionFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &)
	Construct from patch and internal field. More...

	atmAlphatkWallFunctionFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
	Construct from patch, internal field and dictionary. More...

	atmAlphatkWallFunctionFvPatchScalarField (const atmAlphatkWallFunctionFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fvPatchFieldMapper &)
	Construct by mapping given atmAlphatkWallFunctionFvPatchScalarField onto a new patch. More...

	atmAlphatkWallFunctionFvPatchScalarField (const atmAlphatkWallFunctionFvPatchScalarField &)
	Construct as copy. More...

	atmAlphatkWallFunctionFvPatchScalarField (const atmAlphatkWallFunctionFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
	Construct as copy setting internal field reference. More...

virtual tmp< fvPatchField< scalar > >	clone () const
	Return a clone. More...

virtual tmp< fvPatchField< scalar > >	clone (const DimensionedField< scalar, volMesh > &iF) const
	Clone with an internal field reference. More...

virtual void	updateCoeffs ()
	Update the coefficients associated with the patch field. More...

virtual void	autoMap (const fvPatchFieldMapper &)
	Map (and resize as needed) from self given a mapping object. More...

virtual void	rmap (const fvPatchScalarField &, const labelList &)
	Reverse map the given fvPatchField onto this fvPatchField. More...

virtual void	write (Ostream &) const
	Write. More...

Protected Member Functions
virtual void	checkType ()
	Check the type of the patch. More...

void	writeLocalEntries (Ostream &) const
	Write local wall function variables. More...

Protected Attributes
const scalar	Cmu_
	Empirical model constant. More...

const scalar	kappa_
	von Kármán constant More...

autoPtr< Function1< scalar > >	Pr_
	Molecular Prandtl number. More...

autoPtr< PatchFunction1< scalar > >	Prt_
	Turbulent Prandtl number field. More...

autoPtr< PatchFunction1< scalar > >	z0_
	Surface roughness length [m]. More...

Static Protected Attributes
static scalar	tolerance_ = 0.01
	Solution parameters. More...

static label	maxIters_ = 10

Detailed Description

This boundary condition provides a wall constraint on the kinematic turbulent thermal conductivity (i.e. alphat) for atmospheric boundary layer modelling. It assumes a logarithmic distribution of the potential temperature within the first cell.

Required fields:

  alphat    | Kinematic turbulent thermal conductivity    [m2/s]

Usage

Example of the boundary condition specification:

<patchName>
{
    // Mandatory entries
    type            atmAlphatkWallFunction;
    Pr              <Function1<scalar>>;
    Prt             <PatchFunction1<scalar>>;
    z0              <PatchFunction1<scalar>>;

    // Optional entries
    Cmu             <scalar>;
    kappa           <scalar>;

    // Inherited entries
    ...
}

where the entries mean:

Property	Description	Type	Reqd	Deflt
`type`	Type name: atmAlphatkWallFunction	word	yes	-
`Pr`	Molecular Prandtl number	Function1<scalar>	yes	-
`Prt`	Turbulent Prandtl number	PatchFunction1<scalar>	yes	-
`z0`	Surface roughness length [m]	PatchFunction1<scalar>	yes	-
`Cmu`	Empirical model constant	scalar	no	0.09
`kappa`	von Kármán constant	scalar	no	0.41

The inherited entries are elaborated in:

Source files

Definition at line 140 of file atmAlphatkWallFunctionFvPatchScalarField.H.

Constructor & Destructor Documentation

◆ atmAlphatkWallFunctionFvPatchScalarField() [1/5]

atmAlphatkWallFunctionFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF
	)

Construct from patch and internal field.

Definition at line 82 of file atmAlphatkWallFunctionFvPatchScalarField.C.

◆ atmAlphatkWallFunctionFvPatchScalarField() [2/5]

atmAlphatkWallFunctionFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const dictionary &	dict
	)

Construct from patch, internal field and dictionary.

Definition at line 120 of file atmAlphatkWallFunctionFvPatchScalarField.C.

◆ atmAlphatkWallFunctionFvPatchScalarField() [3/5]

atmAlphatkWallFunctionFvPatchScalarField	(	const atmAlphatkWallFunctionFvPatchScalarField &	ptf,
		const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)

Construct by mapping given atmAlphatkWallFunctionFvPatchScalarField onto a new patch.

Definition at line 100 of file atmAlphatkWallFunctionFvPatchScalarField.C.

◆ atmAlphatkWallFunctionFvPatchScalarField() [4/5]

atmAlphatkWallFunctionFvPatchScalarField ( const atmAlphatkWallFunctionFvPatchScalarField & wfpsf )

Construct as copy.

Definition at line 155 of file atmAlphatkWallFunctionFvPatchScalarField.C.

◆ atmAlphatkWallFunctionFvPatchScalarField() [5/5]

atmAlphatkWallFunctionFvPatchScalarField	(	const atmAlphatkWallFunctionFvPatchScalarField &	wfpsf,
		const DimensionedField< scalar, volMesh > &	iF
	)

Construct as copy setting internal field reference.

Definition at line 172 of file atmAlphatkWallFunctionFvPatchScalarField.C.

Member Function Documentation

◆ checkType()

void checkType ( )

protectedvirtual

Check the type of the patch.

Definition at line 41 of file atmAlphatkWallFunctionFvPatchScalarField.C.

References Foam::abort(), Foam::endl(), Foam::FatalError, FatalErrorInFunction, Foam::nl, and Foam::foamVersion::patch.

Here is the call graph for this function:

◆ writeLocalEntries()

void writeLocalEntries ( Ostream & os ) const

protected

Write local wall function variables.

Definition at line 56 of file atmAlphatkWallFunctionFvPatchScalarField.C.

References os(), and Ostream::writeEntryIfDifferent().

Referenced by atmAlphatkWallFunctionFvPatchScalarField::write().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ TypeName()

TypeName ( "atmAlphatkWallFunction" )

Runtime type information.

◆ clone() [1/2]

virtual tmp<fvPatchField<scalar> > clone ( ) const

inlinevirtual

Return a clone.

Definition at line 257 of file atmAlphatkWallFunctionFvPatchScalarField.H.

References fvPatchField< Type >::Clone().

Here is the call graph for this function:

◆ clone() [2/2]

virtual tmp<fvPatchField<scalar> > clone ( const DimensionedField< scalar, volMesh > & iF ) const

inlinevirtual

Clone with an internal field reference.

Definition at line 266 of file atmAlphatkWallFunctionFvPatchScalarField.H.

References fvPatchField< Type >::Clone().

Here is the call graph for this function:

◆ updateCoeffs()

void updateCoeffs ( )

virtual

Update the coefficients associated with the patch field.

Definition at line 190 of file atmAlphatkWallFunctionFvPatchScalarField.C.

References atmAlphatkWallFunctionFvPatchScalarField::Cmu_, Foam::constant::electromagnetic::e, Foam::exit(), Foam::FatalError, FatalErrorInFunction, forAll, Foam::constant::atomic::group, IOobject::groupName(), k, atmAlphatkWallFunctionFvPatchScalarField::kappa_, Foam::log(), Foam::max(), Foam::foamVersion::patch, Foam::pow025(), Pr(), atmAlphatkWallFunctionFvPatchScalarField::Pr_, turbulenceModel::propertiesName, Prt(), atmAlphatkWallFunctionFvPatchScalarField::Prt_, Foam::sqrt(), fvPatchField< Type >::updateCoeffs(), y, and atmAlphatkWallFunctionFvPatchScalarField::z0_.

Here is the call graph for this function:

◆ autoMap()

void autoMap ( const fvPatchFieldMapper & m )

virtual

Map (and resize as needed) from self given a mapping object.

Definition at line 274 of file atmAlphatkWallFunctionFvPatchScalarField.C.

◆ rmap()

void rmap	(	const fvPatchScalarField &	ptf,
		const labelList &	addr
	)

virtual

Reverse map the given fvPatchField onto this fvPatchField.

Definition at line 292 of file atmAlphatkWallFunctionFvPatchScalarField.C.

◆ write()

void write ( Ostream & os ) const

virtual

Write.

Definition at line 313 of file atmAlphatkWallFunctionFvPatchScalarField.C.

References os(), fvPatchField< Type >::write(), atmAlphatkWallFunctionFvPatchScalarField::writeLocalEntries(), and fvPatchField< Type >::writeValueEntry().

Here is the call graph for this function:

Member Data Documentation

◆ Cmu_

const scalar Cmu_

protected

Empirical model constant.

Definition at line 151 of file atmAlphatkWallFunctionFvPatchScalarField.H.

Referenced by atmAlphatkWallFunctionFvPatchScalarField::updateCoeffs().

◆ kappa_

const scalar kappa_

protected

von Kármán constant

Definition at line 156 of file atmAlphatkWallFunctionFvPatchScalarField.H.

Referenced by atmAlphatkWallFunctionFvPatchScalarField::updateCoeffs().

◆ Pr_

autoPtr<Function1<scalar> > Pr_

protected

Molecular Prandtl number.

Definition at line 161 of file atmAlphatkWallFunctionFvPatchScalarField.H.

Referenced by atmAlphatkWallFunctionFvPatchScalarField::updateCoeffs().

◆ Prt_

autoPtr<PatchFunction1<scalar> > Prt_

protected

Turbulent Prandtl number field.

Definition at line 166 of file atmAlphatkWallFunctionFvPatchScalarField.H.

Referenced by atmAlphatkWallFunctionFvPatchScalarField::updateCoeffs().

◆ z0_

autoPtr<PatchFunction1<scalar> > z0_

protected

Surface roughness length [m].

Definition at line 171 of file atmAlphatkWallFunctionFvPatchScalarField.H.

Referenced by atmAlphatkWallFunctionFvPatchScalarField::updateCoeffs().

◆ tolerance_

scalar tolerance_ = 0.01

staticprotected

Solution parameters.

Definition at line 178 of file atmAlphatkWallFunctionFvPatchScalarField.H.

◆ maxIters_

label maxIters_ = 10

staticprotected

Definition at line 179 of file atmAlphatkWallFunctionFvPatchScalarField.H.

The documentation for this class was generated from the following files:

src/atmosphericModels/derivedFvPatchFields/wallFunctions/atmAlphatkWallFunction/atmAlphatkWallFunctionFvPatchScalarField.H
src/atmosphericModels/derivedFvPatchFields/wallFunctions/atmAlphatkWallFunction/atmAlphatkWallFunctionFvPatchScalarField.C
